Niles MSU140 Guide de dépannage

MSU140

INFRARED MAIN SYSTEM UNIT

MSU140

BLENDING HIGH FIDELITY AND ARCHITECTURE®

INSTALLATION & OPERATION GUIDE

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 20

TABLE OF CONTENTS

Introduction 1

Features and

Benefits 2

MSU140 Parts

Guide 4

Installation

Considerations 5

Installation 8

Testing the

IR Extender

System 11

Power Status 13

Trouble-

Shooting 15

Specifications 17

Contents 17

Addendum 18

NFRARED

AIN

YSTEM

NIT

MSU140

Infrared Main

System Unit

Introduction

An infrared (IR) extender system enables you to control

your IR remote controlled A/V equipment from a remote

location. This enables you to place your A/V components

out of sight (behind cabinet doors, in the rear of a room, or

in a different room) and still conveniently operate your

equipment.

Installed at the equipment location, the MSU140 receives

the IR commands transmitted from your existing hand-

held remotes in that room. The commands are carried via a

small category 5 cable to your A/V equipment in another

room, and instantly “repeated”.

The MSU140 is compatible with all current Niles infrared

systems. It may be used along with the Niles TS100, MS100,

MS200, WS100, MVC100IR and CS100 IR sensors or the

IntelliPad®.

The model MSU140 is an IR Main System Unit. It is one of

three elements that make up an infrared extender system:

• IR Main System Unit—Models MSU140, MSU250,

MSU480 and MSU440Z.

• IR Sensors/Keypads—Models WS100, TS100, MS100,

MS200, CS100, IntelliPad, MVC100IR.

• IR Flashers—Models MF1, MF2, MF1VF, MF2VF.

An IR sensor expansion hub, Model IRH610, is available to

provide additional sensor inputs to your system.

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 1

NFRARED

AIN

YSTEM

NIT

Features and Benefits

The MSU140 offers a number of improvements over other

IR Extender Main System Units:

• Universal system—compatible with virtually all brands

of A/V equipment and remote controls.

• Accommodates one IR sensor or keypad.

• Provides four flasher outputs via convenient 3.5mm

jacks.

• System feedback LED confirms operation.

• 3-30V AC/DC status input. Provides system status to con-

nected sensors and keypads.

• Expandable—an IRH610 IR expansion hub can be used

to provide additional inputs.

• Printed circuit board design assures high reliability.

• Low profile and small footprint with integrated mount-

ing wings that allow for both horizontal and vertical

installation.

• UL listed regulated in-line power supply with universal

voltage capability.

• Two year parts and labor warranty.

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 2

NFRARED

AIN

YSTEM

NIT

1234

POWER

+12V DC

3-30V

AC/DC

STATUS

FLASHER OUTPUTS

MSU140

IR MAIN SYSTEM UNIT

INPUT 1

Niles IR

Flasher

MSU140

WS100 IR Sensor

Power, IR data, status signal and ground

via category 5 wire

Stereo Receiver

12V DC power supply

(supplied with the

MSU140 Main

System Unit) plugged

into an unswitched

AC outlet powers

the system

3-30V AC/ DC power supply

(Not Supplied) plugged

into the switched outlet

Niles Stock # FG01035

Figure 1

Connecting the WS100 to a Niles MSU140

Main System Unit broadcasting a status

feedback signal.

In a typical system, the MSU140 provides

for the connection for one remote room

sensor (or keypad) and will control multiple

audio/video components via its flasher

connections.

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 3

1234

POWER

+12V DC

3-30V

AC/DC

STATUS

FLASHER OUTPUTS

MSU140

IR MAIN SYSTEM UNIT

INPUT 1

NFRARED

AIN

YSTEM

NIT

MSU140 Parts Guide

1. 12V DC Jack – Provides 12 volt DC power to

MSU via a regulated power supply.

2. IR Flasher Outputs – 3.5mm jacks provide out-

put for either single or dual (MF1, MF2,

MF1VF, MF2VF) low-level flashers.

3. 3-30V AC/DC Status – 3.5mm jack provides

system status to sensors/ keypads via a 12 volt

power supply attached to a switched outlet on

the system receiver or a 12V trigger output.

4. Status/ IR Confirmation LED – This LED

performs two functions: (1) it provides a

visible indication of system status via a green

LED and (2) confirms the reception of IR data

via a blinking blue LED.

5. Sensor Input – Removable quick connect

sensor plug for connection of IR sensors

(WS100, TS100, MS100, MS200, CS100

MVC100IR and the IntelliPad) to the system.

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 4

Installation Considerations

Placement of the MSU140

Place the MSU140 conveniently close to the equipment it

will be controlling. Generally, the unit is placed in a con-

cealed location because its controls and indicators are only

used during installation. Placement possibilities include:

1) Table-top (on the shelf behind the equipment)

See Figure 2.

2) Wall-mount (affixed to the back of the equipment

cabinet or a nearby wall). See Figure 3.

NFRARED

AIN

YSTEM

NIT

IMPORTANT

Do not place the

MSU140 on top

of or directly

behind a television

set. Some

television sets

produce intense

electromagnetic

interference which

may disable

your IR extender

system.

Figure 2: Table-top placement

Affix the enclosed self-adhesive

rubber feet to the base of the MSU140.

Self-Adhesive

Rubber Feet

POWER

+12V DC

Figure 3: Wall-mount placement

Use sheetrock screws

1234

POWER

+12V DC

3-30V

AC/DC

STATUS

FLASHER OUTPUTS

MSU140

IR MAIN SYSTEM UNIT

INPUT 1

MSU140 Base

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 5

Wiring

From every IR Sensor location you must “home-run” a

category 5 cable back to the MSU140. Home run means

that an individual cable is connected between each IR

Sensor and the MSU140. See Figure 4.

NFRARED

AIN

YSTEM

NIT

“TECH TIP”

Wire size is

expressed by it’s

AWG (American

Wire Gauge)

number. The lower

the AWG number,

the larger the wire,

i.e., 20 AWG wire is

physically larger

than 22 AWG.

IMPORTANT – AVOIDING INTERFERENCE

Avoid locating any of the cables, sensors, keypads or the

Main System Unit near any potential sources of Electro-

Magnetic Interference (EMI), such as light dimmers, speed

controls for ceiling fans, electrical ballasts, television sets,

large motors, heaters or air conditioners.

Figure 4: Home run the

sensor cable from the

sensor to the MSU140.

Remotely Located

IR Sensor

SENSORS IN

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 6

Intellipad Wiring

When you are placing both a Intellipad and a sensor (or

two keypads) in one room you may “daisy-chain” using a

single cable. A cable is run between the keypad and the

sensor and a single cable is run from the sensor back to the

MSU140. To prevent data feedback an IN4003 Blocking

Diode is inserted on the data (IR) line between the

Intellipad and the sensor. The cathode, or blocking side of

the diode, faces the Intellipad. See Figure 5. Note that the

status wire is connected to Intellipad’s status (+) connector.

NFRARED

AIN

YSTEM

NIT

1234

POWER

+12V DC

3-30V

AC/DC

STATUS

FLASHER OUTPUTS

MSU140

IR MAIN SYSTEM UNIT

INPUT 1

Figure 5: An IR sensor

cable is “daisy-chained”

from an Intellipad, to a

sensor and back to the

MSU140.

IN4003

Blocking

Diode

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 7

1234

POWER

+12V DC

3-30V

AC/DC

STATUS

FLASHER OUTPUTS

MSU140

IR MAIN SYSTEM UNIT

INPUT 1

Sensor/Keypad Cable

The MSU140 connects to IR sensors and the Intellipad with

category 5 cable, with a maximum cable run of 500'.

Flasher Cable

Niles infrared flashers come supplied with a 10 foot 2-con-

ductor 22 gauge cable. Should you need to extend it, use a

16 gauge 2-conductor cable (“zip-cord”). Shielding is not

necessary for a flasher. Flasher wires can be extended up to

200 feet.

NFRARED

AIN

YSTEM

NIT

TOOLS

REQUIRED

• 1/8" Standard

Slotted

Screwdriver

• Wire Stripper

WS100 Sensor

To unswitched

AC Outlet

Figure 6:

MSU140

Installation

MSU140 Sensor

Connection

MSU140

To Niles

IR Flasher

To 3-30V AC/ DC power supply

plugged into a switched

AC outlet.Typically found

on back of a receiver.

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 8

NFRARED

AIN

YSTEM

NIT

STEP DESCRIPTION

1. Connect and test the

power supply. If it tests

OK, unplug the connector

from the power socket

and proceed.

A) Plug the supplied 12vDC power supply into an unswitched

120V AC outlet, 50-60 HZ .

B) Plug the connector into the socket marked “Power” on the

MSU140.

C) If the Power LED does not light, test the unswitched 120

VAC outlet, 50-60 HZ with another appliance. If the outlet

tests OK, you have a defective power supply which must be

replaced for you to continue.

2. Connect the Sensor/

Keypad cable the Sensor

input.

A) Strip 1/4" of insulation from the end of each wire. Tightly

twist the end of each wire until no frayed ends remain.

B) Use a small flathead screwdriver or your thumbnail to raise the

locking tabs, exposing the holes on the removable connectors.

C) Insert each wire into the appropriate hole on the removable

connector plug (Figure 6), and snap the locking tab down.

To help you, the connector plug is keyed. Insert the smooth

side of the connector plug into the smooth side of the sock-

et. Don’t force the scalloped side of the connector plug into

the smooth side of the socket.

DS00329BCN-MSU140-1.qxp 8/17/05 11:26 AM Page 9

Autres manuels pour MSU140

Table des matières

Autres manuels Niles Accessoires

Niles

Niles CE-DS6 Manuel utilisateur

Niles

Niles CM8 Series Bracket Manuel utilisateur

Niles

Niles WS100R Guide d'installation

Niles

Niles CAT-5 Manuel utilisateur

Niles

Niles CM75 Series Bracket Manuel utilisateur

Niles

Niles Convenience Outlets Manuel utilisateur

Niles

Niles CS120 Instructions d'utilisation d'origine

Niles

Niles C5-DA Manuel utilisateur

Niles

Niles Component Commander Manuel utilisateur

Niles

Niles Voltage Activated AC Outlet AC-3 Manuel utilisateur

Niles

Niles CE 70 Manuel utilisateur

Niles

Niles IE5 Manuel utilisateur

Niles

Niles MS-360 Guide de dépannage

Niles

Niles IE6 Manuel utilisateur

Niles

Niles CE 5 Manuel utilisateur

Niles

Niles MS-1 Guide de dépannage

Niles

Niles C1 Guide d'installation

Niles

Niles MS-2 Guide de dépannage

Niles

Niles SRK-4W Manuel utilisateur

Niles

Niles DS6 Series Bracket Manuel utilisateur

Niles

Niles WS120 Manuel utilisateur

Niles

Niles CM6 Series Bracket Manuel utilisateur

Niles

Niles TS100 Guide de dépannage

Niles

Niles C5-VA2 Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
