Night Owl XHD Series Manuel utilisateur

www.NightOwlSP.com

USER MANUAL

XHD 5MP SERIES

4/8 CHANNEL

2XHD Series User’s Manual

Thank you for choosing Night Owl Security Products!

By purchasing a Night Owl product, you receive a one (1) year warranty covering

manufacturing defects in material and workmanship. Make the most of your

warranty by completing the registration form online. In addition to warranty

and technical support beneﬁts, you will have access to our multitude of free

instructional “How to Videos”. You can also view our instructional videos by

clicking the “How to Videos” tab within your product’s page on our website.

Night Owl’s XHD Series Camera Compatibility:

Night Owl’s XHD Series DVRs are compatible with most analog cameras (400-

900TVL), Night Owl’s Analog HD (AHD) and HD Analog (HDA) cameras. If the

camera’s video quality either day or night is degraded, you may need to change

the cable run from the camera to the DVR. This system is designed to work with

24 AWG UL Approved cabling or better.

Please see the warranty section of this manual for exclusions and additional details.

Not all features and capabilities are shared across all models so you may see

features which are not applicable. In addition you may see screen images that

do not exactly match those on your display. This manual was accurate at the time

it was completed. Due to our ongoing effort to constantly improve our products,

functions may have been added or changed.

Scan the QR code below to access our Quick Setup Guide that can

assist you in conﬁguring your Night Owl Security system.

Night Owl highly recommends installing the most

current ﬁrmware version available for your system.

Verify your ﬁrmware version on the Info screen of

the System menu tab.

Quick Setup Guide

3Table of Contents

TABLE

OF CONTENTS

4XHD Series User’s Manual

Table of Contents

CHAPTER 1: FCC WARNINGS.................................7

CHAPTER 2: SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . 9

CHAPTER 3: SPECIFICATIONS ...............................11

3.1 System Requirements ............................12

3.2 Package Contents...............................12

3.2.1 DVR Diagram ...........................12

3.2.2 Camera Diagram .........................14

3.2.3 Mouse Diagram ..........................14

CHAPTER 4: CAMERA INSTALLATION .........................15

4.1 Video/Audio ...................................16

4.2 Power .....................................16

4.2.1 Standard Camera Power ......................16

4.3 Mounting the Cameras ...........................17

CHAPTER 5: DVR INSTALLATION .............................19

5.1 Connecting to a TV (via HDMI)......................20

5.2 Power .....................................21

CHAPTER 6: GETTING STARTED .............................22

6.1 Startup Wizard .................................23

6.1.1 Camera Test ............................24

6.1.2 Network Check ..........................24

6.1.3 Firmware Check .........................26

6.1.4 Password Creation ........................27

6.1.5 Date and Time Setup ......................28

6.1.6 Night Owl X ............................29

6.1.7 Password Veriﬁcation ......................30

6.1.8 Camera/Channel Settings...................30

5Table of Contents

6.1.9 Camera Positioning .......................31

6.1.10 Channel Conﬁguration .....................31

6.1.11 Default View ............................32

6.1.12 Helpful Links ...........................33

6.1.13 Wizard Complete .........................34

6.2 Night Owl X Mobile App ..........................34

6.3 Displays and Icons ..............................35

6.3.1 Login Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6.3.2 Live View (All Channels)....................36

6.3.3 Menu Screen ...........................37

CHAPTER 7: MENUS AND SETTINGS ..........................38

7.1 General Menu .................................40

7.1.1 Display................................40

7.1.2 Network ...............................41

7.2 Cameras Menu .................................42

7.2.1 Settings ...............................42

7.2.2 Encode................................43

7.2.3 Motion ................................44

7.2.4 Alarm Status............................45

7.2.5 Setting Detection Area .....................46

7.3 Record Menu ..................................47

7.3.1 Schedule ..............................47

7.3.2 Playback ..............................48

7.3.3 Exporting Recordings......................50

7.4 Device Menu ..................................52

7.4.1 HDD .................................52

7.4.2 PTZ ..................................52

6XHD Series User’s Manual

7.5 System Menu..................................54

7.5.1 General ...............................54

7.5.2 Users .................................55

7.5.3 Info ..................................56

7.5.4 Log ..................................56

7.6 Advanced Menu ................................57

7.6.1 Maintain...............................57

7.6.2 Events ................................58

7.6.3 Auto Upgrade ...........................59

CHAPTER 8 GLOSSARY ...................................60

CHAPTER 9: WARRANTY ...................................62

CHAPTER 10: TROUBLESHOOTING ............................65

CHAPTER 11: USER INFORMATION ............................68

CUSTOMER SUPPORT .....................Back Cover

Night Owl’s DVRs are manufactured for quality and ease of use.

As such, our DVRs contain menus designed for advanced user’s

that should not be adjusted without having enhanced knowledge

regarding the menu. In most cases the default settings allow for

optimal functionality. The menus that should maintain the default

settings are indicated with this icon.

ADVANCED

DISCLAIMER: The exact components of your system, images and quantities may

vary depending on your model number. While these may vary, this Manual will

address the setup and initial conﬁguration of your DVR and cameras.

7Chapter 1: FCC Warnings

CHAPTER 1

FCC WARNINGS

8XHD Series User’s Manual

Chapter 1: FCC Warnings

FCC

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

FCC Compliance Statement

These limits are designed to provide reasonable protection against frequency

interference in residential installation. This equipment generates, uses and can

radiate radio frequency energy and if not installed or used in accordance with the

instructions, may cause harmful interference to radio communication. However,

there is no guarantee that interference will not occur in television reception, which

can be determined by turning the equipment off and on. The user is encouraged

to try and correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION

The Federal Communications Commission warns the user that changes or

modiﬁcations to the unit not expressly approved by the part responsible for

compliance could void the user’s authority to operate the equipment.

9Chapter 2: Safety Instructions

CHAPTER 2

SAFETY

INSTRUCTIONS

10 XHD Series User’s Manual

Use the provided power adapter.

Do not use this product with a power

source that applies more than the

speciﬁed voltage.

Never insert metal into the DVR case

or its openings. Inserting metal into the

DVR case may cause electric shock.

Do not operate in wet or dusty areas.

Avoid placing the DVR in areas such

as a damp basement or dusty attic.

Do not expose the DVR to rain or use

near water. If the DVR accidentally

gets wet, unplug it and contact

technical support immediately.

Keep product surfaces clean and dry.

To clean the outside case of the DVR,

use a lightly dampened cloth. Do not

use cleaning solutions or solvents.

Do not install near any heat sources.

Do not install the DVR near any heat

sources such as stoves, heat registers,

radiators or electronics (including

ampliﬁers) that produce heat.

Unplug the DVR when moving it.

Make sure that the DVR is unplugged

before you move it. When moving this

device, be sure to handle it with care.

Make sure there is good air circulation

around the DVR.

This DVR uses an internal hard drive,

which generates heat during operation

for video storage. Do not block vents

on the DVR, as these vents reduce

the generated heat while the system

is running. Place this product in well-

ventilated area.

Do not attempt to remove the top

cover. If you observe any abnormal

operation, unplug the DVR immediately

and contact technical support. Do not

attempt to open the DVR to diagnose

the cause of the problem.

Handle the DVR carefully.

If you drop the DVR on any hard

surface, it may damage the device.

If the DVR doesn’t work properly

due to physical damage, contact an

authorized dealer for repair.

It is recommended to use your DVR

with an uninterruptible power supply

(UPS). Connecting your DVR and

cameras to a UPS allows continuous

operation even during power outages.

The run-time duration will depend on

the rating of the UPS used.

Chapter 2: Safety Instructions

You may be subjected to severe electrical shock

if you remove the cover of the DVR.
