Nibe VVM 310 Guide de l'utilisateur

Installer manual

Indoor module

NIBE VVM 310 EMK

IHB EN 2235-1

731202

Quick guide

Navigation Ok button (confirm/select)

Back button (back/undo/exit)

Control knob (move/increase/reduce)

A detailed explanation of the button functions can be found on page 35.

How to scroll through menus and make different settings is described on page 37.

Set the indoor climate

MY INSTALLATION

INDOOR CLIMATE HOT WATER

INFO

The mode for setting the indoor temperature is accessed by pressing the OK button twice, when in the start mode in

the main menu.

Increase hot water volume

1X INDOOR CLIMATE HOT WATER

MY INSTALLATION INFO

To temporarily increase the amount of hot water, first turn the control knob to mark menu 2 (water droplet) and then

press the OK button twice.

41 Important information

4Safety information

4Symbols

4Marking

4Serial number

5Recovery

5Inspection of the installation

6Outdoor modules

72 Delivery and handling

7Transport

7Assembly

7Supplied components

8Removing panels

93 Design VVM 310

10List of components

114 Pipe connections

11General pipe connections

14Dimensions and pipe connections

15Connecting air/water heat pump

15Connection during use without heat pump

15Climate system

15Cold and hot water

15Installation alternative

175 Electrical connections

17General

20Connections

23Settings

24Optional connections

28Connecting accessories

296 Commissioning and adjusting

29Preparations

29Filling and venting

30Start-up and inspection

32Setting the heating curve

33Cooling in 2-pipe system

33Setting hot water circulation

33Pool

33SG Ready

357 Control - Introduction

35Display unit

35Menu system

398 Control – Menus

39Menu 1 - INDOOR CLIMATE

40Menu 2 - HOT WATER

40Menu 3 - INFO

41Menu 4 - MY SYSTEM

42Menu 5 - SERVICE

519 Service

51Service actions

5410 Disturbances in comfort

54Info-menu

54Manage alarm

54Troubleshooting

56Electrical addition only

5711 Accessories

5812 Technical data

58Dimensions

59Technical specifications

60Electrical circuit diagram

65Item register

67Contact information

3Table of ContentsNIBE VVM 310

Table of Contents

Safety information

This manual describes installation and service procedures

for implementation by specialists.

The manual must be left with the customer.

This appliance can be used by children

aged from 8 years and above and per-

sons with reduced physical, sensory or

mental capabilities or lack of experience

and knowledge if they have been given

supervision or instruction concerning use

of the appliance in a safe way and under-

stand the hazards involved. Children shall

not play with the appliance. Cleaning and

user maintenance shall not be made by

children without supervision.

This is an original manual. It may not be

translated without the approval of NIBE.

Rights to make any design or technical

modifications are reserved.

©NIBE 2022.

MinMaxSystem pres-

sure

0.05 MPa

(0.5 bar)

0.3 MPa

(3 bar)

Heating medium

0.01 MPa

(0.1 bar)

1.0 MPa

(10 bar)

Domestic water

Water may drip from the safety valve’s

overflow pipe. The overflow pipe must be

routed to a suitable drain, so hot water

splashes cannot cause harm. The entire

length of the overflow pipe must be inclined

to prevent water pockets, and must also be

frost-proof. The overflow pipe must be at

least the same size as the safety valve. The

overflow pipe must be visible and its mouth

must be open and not placed close to elec-

trical components.

VVM 310 must be installed via an isolator

switch. The cable area has to be dimen-

sioned based on the fuse rating used.

Symbols

Explanation of symbols that may be present in this manual.

NOTE

This symbol indicates danger to person or machine.

Caution

This symbol indicates important information about

what you should consider when installing or servi-

cing the installation.

TIP

This symbol indicates tips on how to facilitate us-

ing the product.

Marking

Explanation of symbols that may be present on the product’s

label(s).

Danger to person or machine.

Read the User Manual.

Serial number

The serial number can be found at the bottom right of the

front cover, in the info menu (menu 3.1) and on the type

plate (PZ1).

Serial number

Caution

You need the product’s (14 digit) serial number for

servicing and support.

NIBE VVM 310Chapter 1 | Important information4

Important information

Recovery

Leave the disposal of the packaging to the installer

who installed the product or to special waste sta-

tions.

Do not dispose of used products with normal

household waste. It must be disposed of at a special waste

station or dealer who provides this type of service.

Improper disposal of the product by the user results in ad-

ministrative penalties in accordance with current legislation.

Inspection of the installation

Current regulations require the heating installation to be inspected before it is commissioned. The inspection must be

carried out by a suitably qualified person.

In addition, fill in the page for the installation data in the User Manual.

DateSignatureNotesDescription

✔

Heating medium, see section "System diagram"

System flushed

System vented

Expansion vessel

Particle filter

Safety valve

Shut off valves

System pressure

Connected according to outline diagram

Hot water, see section "Cold and hot water"

Shut off valves

Mixing valve

Safety valve

Electricity, see section "Electrical connections"

Connected communication

Fuses, indoor module

Fuses property

Outside sensor

Room sensor

Current sensor

Safety breaker

Earth circuit-breaker

Setting of emergency mode thermostat

Miscellaneous

Docked to

5Chapter 1 | Important informationNIBE VVM 310

Outdoor modules

COMPATIBLE AIR/WATER HEAT PUMPS

F2040

F2040-16

Part no. 064 108

F2040-12

Part no. 064 092

F2050

F2050-10

Part no. 064 318

F2050-6

Part no. 064 328

F2120

F2120-16 3x400V

Part no. 064 139

S2125

S2125-8 3x400V

Part no. 064 219

S2125-8 1x230V

Part no. 064 220

S2125-12 3x400V

Part no. 064 217

S2125-12 1x230V

Part no. 064 218

NIBE SPLIT HBS 05

HBS 05-12

Part no. 067 480

AMS 10-12

Part no. 064 110

HBS 05-16

Part no. 067 536

AMS 10-16

Part no. 064 035

NIBE SPLIT

HBS 20-6

Part no. 067 668

AMS 20-6

Part no. 064 235

HBS 20-10

Part no. 067 819

AMS 20-10

Part no. 064 319

Check the software version of compatible older NIBE

air/water heat pumps, see page 16.

NIBE VVM 310Chapter 1 | Important information6

Transport

VVM 310 should be transported and stored vertically in a dry

place.

However, the VVM 310 can be carefully laid on its back when

being moved into a building.

Assembly

•Place VVM 310 on a solid foundation indoors that can take

its weight.

Use the product’s adjustable feet to attain a horizontal

and stable set-up.

30 - 50 mm

15 - 40 mm

20-55 mm

•The space where VVM 310 is located must be frost-free.

•Because water can exit the safety valve1for hot water,

when connected to VVM 310, the space where VVM 310

is placed must be provided with a floor drain.

1Not enclosed.

INSTALLATION AREA

Leave a free space of 800 mm in front of the product. All

service on VVM 310 can be carried out from the front.

800

10-25

NOTE

Leave 10 – 25 mm free space between VVM 310

and the wall behind for routing cables and pipes.

Supplied components

Room sensorOutside sensor

LEK

Current sensor

LOCATION

The kit of supplied items is placed on top of the product.

7Chapter 2 | Delivery and handlingNIBE VVM 310

Delivery and handling

Removing panels

FRONT PANEL

LEK

1. Remove the screws from the lower edge of the front

panel.

2. Lift the panel out at the bottom edge and up.

SIDE PANELS

LEK

The side panels can be removed to make installation easier.

Caution

50 mm space required to remove the side panels.

1. Remove the screws from the upper and lower edges.

2. Twist the panel slightly outwards.

3. Move the panel backwards and slightly to the side.

4. Pull the panel to one side.

5. Pull the panel forwards.

6. Assembly takes place in the reverse order.

NIBE VVM 310Chapter 2 | Delivery and handling8

Wilo

VVM 310

AA3

QM1

EB1

FQ10

FC1

PZ3

PZ1

GP1

QM20

AA2

UB1

AA4-XF4

AA4-XF3

GP12

BT63

UB2

BF1*

BT6

BT54

XL30

AA7

XL18

XL3XL4

XL8

XL19

QN11

AA1-X3

BT30

AA1-X1

AA1-X7

AA1-S2

AA1

AA3-X4

BP5 QN35

PZ3

XL1

XL2

BT3

BT2

AA4

W130

SF1

QN10

BT7

XL9

PZ1

PZ4

FQ10-S2

*Applies to VVM 310 EMK. Available as accessory EMK 310 for other markets.

9Chapter 3 | Design VVM 310NIBE VVM 310

Design VVM 310

List of components

PIPE CONNECTIONS

Connection, heating medium flow lineXL1

Connection, heating medium return lineXL2

Connection, cold waterXL3

Connection, hot waterXL4

Connection, docking from heat pumpXL8

Connection, docking to heat pumpXL9

Connection, docking in high tempXL18

Connection, docking out high tempXL19

Connection, expansion vesselXL30

HVAC COMPONENTS

Circulation pumpGP1

Charge pumpGP12

Drain valve, climate systemQM1

Venting valve, climate systemQM20

Reversing valve, climate system/water heating, flow

line

QN10

Mixing valve, additionQN11

Reversing valve, climate system/water heating, return

line

QN35

SENSORS ETC.

Manometer, heating systemBP5

Temperature sensor, heating medium supply1

BT2

Temperature sensor, heating medium return1

BT3

Temperature sensor, hot water, controlBT6

Temperature sensor, hot water, displayBT7

Thermostat, standby modeBT30

Sensor, external heat source, tankBT54

Temperature sensor, heating medium supply after immer-

sion heater

BT63

1Not visible in the image

ELECTRICAL COMPONENTS

Immersion heater cardAA1

AA1-S2 Switch (DIP switch) on circuit board

AA1-X1 Terminal block incoming

AA1-X3 Terminal block, immersion heater

AA1-X7 Terminal block, immersion heater

Base cardAA2

Input circuit boardAA3

AA3-X4 Terminal block, current sensors

Display unitAA4

AA4-XF3 USB socket

AA4-XF4 Service socket

Extra relay circuit boardAA7

Flow meter1

BF1

Immersion heaterEB1

Miniature circuit-breakerFC1

Temperature limiterFQ10

Resetting temperature limiterFQ10-S2

Auxiliary relay, emergency mode.K1

SwitchSF1

Network cable for NIBE UplinkW130

1Applies to VVM 310 EMK. Available as accessory EMK 310 for other markets.

MISCELLANEOUS

Rating platePZ1

Serial number platePZ3

Sign, pipe connectionsPZ4

Cable glandUB1

Cable glandUB2

Designations according to standard EN 81346-2.

NIBE VVM 310Chapter 3 | Design VVM 31010

Autres manuels pour VVM 310

Table des matières

Autres manuels Nibe Pompe à chaleur

Nibe

Nibe SPLIT ACVM 27 Manuel utilisateur

Nibe

Nibe F750 Manuel utilisateur

Nibe

Nibe F470 Guide de l'utilisateur

Nibe

Nibe F1245 Mode d'emploi

Nibe

Nibe F2040 Series Manuel utilisateur

Nibe

Nibe FIGHTER 1120 Instructions d'utilisation et d'entretien

Nibe

Nibe F130 Manuel utilisateur

Nibe

Nibe F1126 Manuel utilisateur

Nibe

Nibe ClimateMaster Trilogy VE Series Mode d’emploi

Nibe

Nibe SPLIT ACVM270 Manuel utilisateur

Nibe

Nibe F1155 Series Guide de l'utilisateur

Nibe

Nibe F1255 Series Manuel utilisateur

Nibe

Nibe F2300 Guide de l'utilisateur

Nibe

Nibe DEMO 40 Guide de l'utilisateur

Nibe

Nibe F1345 Series Guide de l'utilisateur

Nibe

Nibe F1255PC BE Guide de l'utilisateur

Nibe

Nibe ClimateMaster Tranquility TCW Series Mode d’emploi

Nibe

Nibe FIGHTER 1120 Manuel utilisateur

Nibe

Nibe VVM 500 Manuel utilisateur

Nibe

Nibe VST 20 Manuel utilisateur

Nibe

Nibe S2125 Manuel utilisateur

Nibe

Nibe Fighter 2005 Manuel d'utilisation original

Nibe

Nibe F1145 5 Guide de l'utilisateur

Nibe

Nibe HMF 10-55 Guide de l'utilisateur

Manuels Pompe à chaleur populaires d'autres marques

MICROWELL

MICROWELL HP 1000 GREEN Manuel utilisateur

Sanyo

Sanyo SAP120FCH Manuel utilisateur

Daikin

Daikin EHYHBH05AA Manuel utilisateur

Panasonic

Panasonic WH-SDF03E3E5 Mode d’emploi

Bryant

Bryant 544B Manuel utilisateur

Airxcel

Airxcel 45000 Series Manuel

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manuel utilisateur

Dimplex

Dimplex LI 16I-TUR Guide de l'utilisateur

Carrier

Carrier WSHP Open v3 Guide de configuration rapide

TGM

TGM CTV14CN018A Manuel utilisateur

Carrier

Carrier 38MGQ Series Manuel utilisateur

Kokido

Kokido K2O K880BX/EU Guide de dépannage

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guide rapide

Carrier

Carrier 48EZN Manuel utilisateur

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Mode d'emploi

Ariston

Ariston NIMBUS Manuel utilisateur

Weishaupt

Weishaupt WWP L 7 Guide de l'utilisateur

GE Zoneline AZ85H09EAC Manuel utilisateur
