NIBBLE NURIA Manuel utilisateur

User Manual

Version 0.10

Analogue Addressable Fire Alarm Panel

1 / 26

User Manual

Version 0.10

Contents

1 Overview .................................................. 4

1.1 Appearance.............................................. 4

1.2 Features................................................ 4

2 Installation ................................................. 4

2.1 Enclosure............................................... 5

2.2 Electronics .............................................. 5

2.3 Mounting ............................................... 5

2.4 Connections ............................................. 5

2.4.1 Mainpowersupply...................................... 5

2.4.2 Backup power supply (batteries) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.4.3 Externalbatterypack .................................... 6

2.4.4 Loopsanddevices...................................... 7

2.4.5 28Voutputs.......................................... 8

2.4.6 Relayoutputs......................................... 8

2.4.7 Network(CANandEthernet) ................................ 9

3 Maintenance ................................................ 10

3.1 Testingthepanel........................................... 10

3.2 Testingtheoutputs.......................................... 10

3.3 Testing the battery and loop communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.4 Testingthedevices.......................................... 10

4 Interface .................................................. 10

4.1 Lightindicators ............................................ 10

4.2 Physicalbuttons ........................................... 10

4.3 Touchscreen ............................................. 11

4.3.1 Header ............................................ 11

4.3.2 Panelinformation....................................... 11

5 Conﬁguration ............................................... 14

5.1 Accesslevels............................................. 14

5.1.1 Accesslevel2 ........................................ 14

5.1.2 Accesslevel3 ........................................ 14

5.1.3 Changing access level codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5.2 Deviceconﬁguration ......................................... 15

5.3 Zoneconﬁguration .......................................... 15

5.3.1 Sounderdelay ........................................ 15

5.3.2 Enabletype.......................................... 15

5.3.3 Mode ............................................. 16

5.4 Eventconﬁguration.......................................... 16

5.4.1 Eventinput .......................................... 16

5.4.2 Eventoutputs......................................... 16

5.4.3 Event ............................................. 17

5.5 Loopconﬁguration .......................................... 18

5.6 Fieldconﬁguration .......................................... 18

2 / 26

User Manual

Version 0.10

5.7 Globaldeviceconﬁgurations..................................... 19

5.8 Setdateandtime........................................... 19

5.9 Panelnetwork............................................. 19

5.9.1 IPaddress .......................................... 19

5.10Day/Night ............................................... 19

5.11Enable/Disableitems......................................... 20

5.12Testingzones............................................. 20

5.13Firmwareupdate ........................................... 20

5.13.1Motherboard ......................................... 20

5.13.2Loops ............................................. 20

5.14Factorydefaults............................................ 21

5.15Earthleakagedetection ....................................... 21

6 Operation .................................................. 21

6.1 Firealarmcondition ......................................... 21

6.1.1 Sounderdelay ........................................ 21

6.2 Systemfault.............................................. 21

6.2.1 Memoryfault ......................................... 21

6.2.2 Loopcardprogramfault................................... 22

6.2.3 Mainprogramfault...................................... 22

7 EN54 - References and functions .................................... 24

8 Speciﬁcations ............................................... 25

9 Declarations ................................................ 26

9.1 Productdevelopment......................................... 26

9.2 Performanceandconformity..................................... 26

3 / 26

User Manual

Version 0.10

1 Overview

NURIA is an addressable ﬁre alarm panel with ongoing EN54-2/4 certiﬁcation and EN54-13 pending.

Its main features are listed in this section.

1.1 Appearance

• Friendly user interface;

• 7” resistive touchscreen (800x480);

• Modern and functional design;

• Customizable main screen logo;

• Surface or ﬂush installation;

• Easy installation with extractable electronics;

• Extractable front door for easy manipulation of internal components;

• Metallic enclosure with dimensions of 436x443x110 mm.

1.2 Features

• Up to 4 loops;

• Up to 32 panels and repeaters on the same network;

• Compatible with Apollo XP95 / Discovery (up to 126 devices per loop);

• Compatible with Apollo CoreProtocol (Soteria) (up to 254 devices per loop);

• 120 customizable zones;

• Redundancy network communication: Ethernet and CAN;

• 4 supervised voltage outputs:

–2 for ﬁre;

–2 for sounders;

• 1 fault output;

• 3 relay outputs;

• 2 auxiliary voltage outputs;

• 12W of power per loop;

• 150W power supply;

• 2 lead acid 12V 12Ah batteries;

• Optional external enclosure with capacity to hold 6 lead acid 12V 12Ah batteries;

• Logical programming of events;

• Firmware update over USB ﬂash drive;

• MicroSD card support for event logging.

2 Installation

NURIA was designed for indoor use to operate under the following conditions:

•Temperature: -5º to 45ºC;

•Relative humidity: < 95%;

To make the installation easier, NURIA has several mechanical features to make the installation process

quicker.

4 / 26

User Manual

Version 0.10

2.1 Enclosure

Dimensions 436x443x110 mm

Weight 6.95 kg

Color Dark grey

Table 1: Enclosure speciﬁcations.

NURIA has a metallic enclosure with dimensions 436x443x110 mm that can be ﬂush mounted or at

surface. The cables for the setup can pass through the holes located on the top, where plastic glands

should be used, or through the opening on the back of the cover.

The inside can be accessed by opening the front door using a speciﬁc key supplied with the equipment.

The door can be removed and reinstalled quickly, without the need of unscrewing anything, using the

existent pivot hinges, making the setup process easier.

The enclosure was designed to hold two 12V 12Ah lead-acid batteries on its bottom part with maximum

dimensions of 151x98x99 mm.

2.2 Electronics

The electronics of NURIA can be completely separated from the enclosure to simplify the installation or

for maintenance proposes by removing the four screws in the lower part, without the need of splitting all

parts of the panel.

For the panel to work correctly, at least the following hardware should be installed inside the enclosure:

• 150W power supply;

• Two 12V batteries connected in series;

• Touch screen and main boards;

• One loop board.

There are also additional modules that can be acquired separately to provide NURIA with extra capa-

bilities such as:

• Wi-Fi;

• GSM;

• DALI.

2.3 Mounting

Mounting the NURIA directly on the wall should be made using the four screws available on the back of

the enclosure according to ﬁgure 1.

2.4 Connections

This section explains how the connections to the panel should be made in order to put it to work. To

make NURIA compatible to the standards EN54-2/4, the following instructions should be followed carefully.

2.4.1 Main power supply

There is a three terminal connector with an incorporated fuse of 4A that should be used to connect the

panel to the mains (230VAC) using a cable with 3 wires with cross section of at least 0.5mm2.

5 / 26

User Manual

Version 0.10

Figure 1: Mechanical details of the mounting holes. Dimensions in mm.

2.4.2 Backup power supply (batteries)

As a backup power supply NURIA uses 2 lead-acid 12V batteries connected in series. Connections

should be made using the available faston terminals. The capacity of the batteries depends on the desired

lifetime for the installation. A previous calculation should be made to specify the batteries capacity.

The absolute minimum battery voltage is 19.2V for each battery series.

The supplied Velcro strip should be used to ﬁx the batteries by wrapping it around them as showed in

ﬁgure 2. The two tips of the tape should then be placed over each other and over the tape that ﬁx the

batteries.

Figure 2: Top view. Demonstration of how to ﬁx the batteries using the Velcro strip.

2.4.3 External battery pack

NURIA is designed to support two 12V 12Ah batteries on its enclosure. For greater lifetime, additional

batteries can be connected using an external enclosure placed next to the main one, which should be ﬁxed

6 / 26

User Manual

Version 0.10

to the wall by using all of its 5 mounting holes. The batteries should be connected in parallels of 24V just

like in ﬁgure 3.

When using an external enclosure with a battery pack, the connection with the panel should be per-

formed using cables with a maximum length of 1m according to table 2. Cable glands with clamping should

be used on both enclosures.

Function Terminal Conductor core section

Battery +1.5 mm2

Bat sensor

0.25 mm2

Earth Earth 0.5 mm2

Table 2: Cable speciﬁcations to connect external batteries.

Figure 3: Additional batteries connection.

The ﬁxation of external batteries should use the same method as the internal ones (Figure 2).

To provide additional protection, two 250V 10A fuses are supplied. One of them is already assembled in

the battery enclosure while the other shall be placed in series with the plus (+) terminal inside of the panel

enclosure.

2.4.4 Loops and devices

Before connecting devices to the panel, at least a loop board is required. A loop board should be ﬁtted

in the connectors identiﬁed with the words Loop n card where nis the number that identiﬁes each board.

The maximum number of devices per loop, depends on the protocol supported by the devices:

• Apollo XP95/Discovery - 126 devices;

• Apollo CoreProtocol - 254 devices.

It is possible to place devices communicating with different protocols on the same loop. The panel

will automatically detect the device type and communicate using the appropriate protocol. To use mixed

protocols on the same loop the following restrictions apply:

• XP95/Discovery devices must have their addresses between 1 and 126 inclusive;

7 / 26

User Manual

Version 0.10

• Devices with CoreProtocol must not have the addresses 127, 128 and 255;

• Each XP95/Discovery device will block an address at 128 over its own address, this will create a

duplicated address error. Ex: a XP95/Discovery device with address 10 will block the use of address

138 (128+10) for a CoreProtocol (Soteria) device.

Connections to devices should be made using shielded cables with at least 1.5mm2cross section

per wire and the shield should be connected to the PE terminal. They should always be connected

from the terminals with the LOOP nA indications, go through all devices and return to the panel on the

LOOP nB terminals, where nis the loop number. Each loop can supply up to 500mA.

Figure 4 shows an example of how to connect two detectors on loop 1.

Figure 4: Example connection of two detectors.

2.4.5 28V outputs

NURIA has 4 supervised,1 fault and 2 unsupervised auxiliary voltage outputs. Table 3 shows all

the voltage outputs as well as its speciﬁcations. Supervised outputs must be terminated with a 10 kΩ

resistor. Figure 5 shows an example of how to correctly connect a sounder to the SND1 output. Any other

supervised output should follow the same logic.

The supervised outputs are enable by default, which means that if they are not properly terminated a

fault will be generated by the panel. It is possible to disable a supervised output in the conﬁguration menu,

in that case there is no need to place a terminating resistor.

Connection of unsupervised outputs works the same way as the supervised ones but without the need

of a terminating resistor.

2.4.6 Relay outputs

NURIA also has 3 relay outputs with capability of handling 250VAC and 5A. The trigger of these

outputs can be deﬁned in the event conﬁguration (see 5.4).

8 / 26

User Manual

Version 0.10

Name Supervised Max. current On Off

FIRE1

Yes

100mA

28V10V2

FIRE2

SND1 500mA

SND2

FAULT

100mA 0V228V1

AUX1 1A (shared) 28V10V

AUX2

Table 3: 28V outputs and its speciﬁcations.

1When mains is not present, the voltage may vary

from 28V to 21.6V, according to the battery voltage.

2A residual voltage of 3.3V might be present to super-

vise the output.

Figure 5: Example connection of a supervised output using a sounder (SND1).

2.4.7 Network (CAN and Ethernet)

It is possible to connect several panels and create a network. If the Ethernet interface is used, the panels

should be connected to a switch or router compliant with the EMC3standards to enable full compatibility

with the EN54-2 standard.

When connecting panels over CAN, a termination resistor of 120Ωshould be placed on the last one.

Always use a bus topology when connecting devices over CAN.

3Electromagnetic compatibility

9 / 26

User Manual

Version 0.10

3 Maintenance

The system should be periodically maintained in order to keep the installation safe. The instructions in

this section should be followed carefully to make sure the installation site is protected.

3.1 Testing the panel

Menu →Test →Panel

To test the panel interface, navigate to the Test Panel screen. Press each button to test the correspond-

ing function. Visual indicators, internal buzzers and physical buttons can be tested here.

3.2 Testing the outputs

Menu →Test →Outputs

Testing the outputs will make sure that they operate correctly when needed. Navigate to the Test

Outputs screen and test all, one by one. This will enable the output, check if it safe to enable in order

to avoid unwanted behaviours in the installation site.

3.3 Testing the battery and loop communication

Menu →Test →Diagnostic

In the diagnostic menu, check if the Power DC and Battery voltages are correct, indicated by a green

background in the box that contains the value.

The communication errors must also be noticed, to verify that the loop is operating correctly, a rate of

errors over frames should keep a value less than 1%.

3.4 Testing the devices

Devices should be tested following the recommended instructions of the manufacturer. To test if the

devices operate correctly, place a zone under test mode (see 5.12) and activate the devices that you want

to test.

4 Interface

NURIA has an interface composed by nine light indicators, two physical buttons and a 7” 800x480

touchscreen.

4.1 Light indicators

Table 4 contains the meaning of those visible indicators. Fault and ﬁre indicators will remain blinking

when there are any unacknowledged alarms or faults.

4.2 Physical buttons

There are two physical buttons on the panel to enable quick access level 1 operations, described in

table 5.

10 / 26

Table des matières

Manuels Alarme incendie populaires d'autres marques

Zeta Alarm Systems

Zeta Alarm Systems INFINITY ID2 Manuel utilisateur

System Sensor

System Sensor 22051TLE-RF-26 Manuel utilisateur

Pittway

Pittway Notifier AM2020 Manuel utilisateur

Ampac

Ampac ZoneSense Manuel utilisateur

Kidde

Kidde VM-1 Manuel du produit

LST

LST SIM016-3 Manuel utilisateur

Fireboy- Xintex

Fireboy- Xintex FBD-MZ Instructions originales

bolid

bolid S2000-IP-03 Manuel utilisateur

GST

GST DI-9204 Manuel utilisateur

E2S

E2S BExTBG05D Manuel utilisateur

Notifier

Notifier UZC-256 Manuel utilisateur

Fire-Lite Alarms

Fire-Lite Alarms MS-2 Manuel utilisateur

Siemens

Siemens FDOOT221 Manuel utilisateur

hyfire

hyfire HY5000 Series Manuel utilisateur

FlameStop

FlameStop PFSIFP8 Manuel utilisateur

Radionics

Radionics Radionics 9124 Manuel utilisateur

UniPOS

UniPOS FD 7120 Manuel utilisateur

FIREWOLF

FIREWOLF FW-C01224 Manuel utilisateur
