NexWatch PW-5000 Manuel utilisateur

PW-5000

Intelligent Controller

Installation Manual

Part Number: PW5K1IC

TD1115 rev1101

PW-5000 Intelligent Controller 3

Installation Guide

TD1115 rev1101

Contents

Warnings and Cautions ........................................................................................ 4

Disclaimer........................................................................................................... 6

Unpacking Procedure ........................................................................................... 6

Shipping Instructions ............................................................................................ 7

Limited Warranty ................................................................................................. 7

Confidentiality ..................................................................................................... 8

Description .......................................................................................................... 9

Set Up ................................................................................................................ 9

LED Operation .................................................................................................. 10

Power................................................................................................................ 10

Communications ............................................................................................... 11

Alarm Inputs...................................................................................................... 12

Memory Backup Battery ...................................................................................... 12

Mounting Options ............................................................................................. 12

Suggested Installation Sequence ......................................................................... 12

Specification Summary ....................................................................................... 13

Wiring Diagram ................................................................................................ 14

4PW-5000 Intelligent ControllerInstallation Guide

TD1115 rev1101

Warnings and Cautions

WARNING

Before installation, TURN OFF the external circuit breaker which supplies power to the

system.

Before connecting the device to the power supply, verify that the output voltage is within

specifications of the power supply.

Do not apply power to the system until after the installation has been completed.

Personal injury or death could occur, and the equipment could be damaged beyond

repair, if this precaution is not observed!

WARNING

Fire Safety and Liability Notice

Never connect card readers to any critical entry, exit door, barrier, elevator or gate without

providing an alternative exit in accordance with all fire and life safety codes pertinent to

the installation.These fire and safety codes vary from city to city and you must get

approval from local fire officials whenever using an electronic product to control a door or

other barrier. Use of egress buttons, for example, may be illegal in some cities.In most

applications, single action exit without prior knowledge of what to do is a life safety

requirement.Always make certain that any required approvals are obtained in writing.DO

NOT ACCEPTVERBAL APPROVALS, ASTHEY ARE NOTVALID.

NexWatchnever recommends using the PW-3000 orPW-5000 or related productsforuse

as a primary warning or monitoring system. Primary warningormonitoring systems should

always meet local fire and safety code requirements.The installer must also test the

system on a regular basis by instructing the end user in appropriate daily testing proce-

dures.Failure to test a system regularly could make

installer liable for damages to the end user if a problem occurs.

WARNING

EARTH groundall enclosures, for proper installation.

WARNING

Use suppressors on all door strikes.Use S-4 suppressors for installation.NexWatch, Inc.

recommends only DC strikes.

The information in this document is subject to change without notice.

PW-5000 Intelligent Controller 5

Installation Guide

TD1115 rev1101

CAUTION

IF ANY DAMAGETOTHE SHIPMENT IS NOTICED, A CLAIM MUST BE FILEDWITH

THE COMMERCIAL CARRIER RESPONSIBLE.

CAUTION

Electro-static discharge can damage CMOS integrated circuits and modules.

To prevent damage always follow these procedures:

Use static shield packaging and containers to transport all electronic components,

including completed reader assemblies.

Handle all ESD sensitive components at an approved static controlled workstation.These

workstations consist of a desk mat, floor mat and an ESD wrist strap.Workstations are

available from various vendors.

NOTICE

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules.These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment.This equipment generates, uses, and can radiate radio fre-

quency energy and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications.Operation of this equipment in

a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

NOTICE

This document and the data in it shall not be duplicated, used or disclosed to others for

procurement or manufacture, except as authorized by and with the written permission of,

NexWatch, Inc.The information contained in this document or in the product itself is

considered the exclusive property and trade secrets of NexWatch, Inc.Copyright laws of

the United States protect all information in this document or in the software product itself.

NOTICE

Any use of this product is subject to the terms and acceptance of the NexWatch, Inc.

Software Agreement.Please request a copy from NexWatch, Inc., and review the agree-

mentcarefully.

6PW-5000 Intelligent ControllerInstallation Guide

TD1115 rev1101

Disclaimer

Product Liability; Mutual Indemnification

In the event that a Customer receives a claim that a Product or any component thereof

has caused personal injury or damage to property of others, Customer shall immediately

notify NexWatch in writing of all such claims.NexWatch shall defend or settle such claims

and shall indemnify and hold Customer harmless for any costs or damages including

reasonable attorneys’ fees which Customer may be required to pay as a result of the

defective Product or the negligence of NexWatch, its agents, or its employees.

Customer shall hold harmless and indemnify NexWatch from and against all claims,

demands, losses and liability arising out of damage to property or injury to persons

occasioned by or in connection with the acts or omissions of Customer and its agents and

employees, and from and against all claims, demands, losses and liability for costs of

fees,including reasonable attorneys’ fees, inconnectiontherewith.

Unpacking Procedure

CAUTION

If any damage to the shipment is noticed before unpacking, a claim must be filed with the

commercial carrier.

All containers should be opened and unpacked carefully in order to prevent damage to

the contents.

The following steps are used to unpack equipment in preparation for installation:

1.Open the container and remove the unit(s) and all packing material.Retain the

container and all packing materials. They may be used again for reshipment

of the equipment, if needed.

2.Inspect the contents for shortage.If items are missing items, contact the order entry

departmentat800-227-1667 Option-2.

3.Visually check contents.If damage is discovered, perform the following:

If shipping caused damage to the unit, a claim must be filed with the

commercialcarrier.

If any other defect is apparent, call for a return authorization.

PW-5000 Intelligent Controller 7

Installation Guide

TD1115 rev1101

Shipping Instructions

To ship equipment back to NexWatch,Inc.:

1.Contactthecustomerservice department at800-227-1667 Option-2 beforereturning

equipment. When you call please have available:

• A description of the problem or reason you are returning the equipment.

• Your original purchase order number, invoice number and if the unit is still under

warranty.

• A new purchase order number if the unit is not under warranty

2.From the customer service department, obtain the Return Authorization Number (RMA).

3.Show the RMA number on all packages shipped.Packages, which are not marked with

an RMA number will be refused at the factory and returned to you COD.

4.Carefully pack the equipment for shipment.Use the original packing material whenever

possible

Limited Warranty

All Products sold or licensed by NexWatch include a warranty registration card which

must be completed and returned to NexWatch by or on behalf of the end user in order for

NexWatch to provide warranty service, repair, credit or exchange. All warranty work shall

be handled through Customer which shall notify NexWatch and apply for a Return Mer-

chandise Authorization (RMA) number prior to returning any Product for service, repair,

credit or exchange. NexWatch warrants that its Products shall be free from defects in

materials and workmanship for a period of two years from date of shipment of the Prod-

uct to Customer.The warranty on Terminals, Printers, Communications Products and

Upgrade kits is 90 days from date of shipment.Satisfaction of this warranty shall be

limited to repair or replacement of Products which are defective or defective under

normal use.NexWatch’s warranty shall not extend to any Product which, upon examina-

tion, is determined to be defective as a result of misuse, improper storage, incorrect

installation, operation or maintenance, alteration, modification, accident or unusual

deterioration of the Product due to physical environments in excess of the limits set forth

in Product manuals.THERE ARE NO WARRANTIESWHICH EXTEND BEYONDTHIS

PROVISION.THIS WARRANTY IS IN LIEU OF ALL OTHERWARRANTIES WHETHER

EXPRESS, IMPLIED OR STATUTORY, INCLUDING IMPLIEDWARRANTIES OF MER-

CHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE. NO REPRESENTA-

TION OR WARRANTY OF THE DISTRIBUTOR SHALL EXTEND THE LIABILITY OR

RESPONSIBILITY OF THE MANUFACTURER BEYOND THE TERMS OF THIS PROVI-

SION.IN NO EVENT SHALL NEXWATCH BE LIABLE FOR ANY RE-PROCUREMENT

COSTS, LOSS OF PROFITS, LOSS OF USE, INCIDENTAL, CONSEQUENTIAL OR

SPECIAL DAMAGESTO ANY PERSON RESULTING FROMTHE USE OF NEXWATCH’S

PRODUCTS.

8PW-5000 Intelligent ControllerInstallation Guide

TD1115 rev1101

Confidentiality

All software, drawings, diagrams, specifications, catalogs, literature, manuals and other

materials furnished by NexWatch relating to the design, use and service of the Products

shall remain confidential and shall constitute proprietary rights of NexWatch and Customer

agrees to treat such information as confidential.Customer shall acquire no rights in the

design of the Products or the related materials except to use such information solely for

the purpose of and only during the time it sells the Products.Customer shall not copy the

design of any of the Products or use or cause to be used any Product design or related

materials for its own benefit or for the benefit of any other party.The covenants contained

in this section shall remain effective throughout the term of this Agreement and thereafter

unless specifically waived by NexWatch in writing.

PW-5000 Intelligent Controller 9Installation Guide

TD1115 rev1101

Description

The Intelligent Controller is the heart of the PW-5000 and provides the real time process-

ing for the connected I/O interfaces. It holds the database for the subsystem configura-

tion and card holders, and the event log buffer in battery-backed memory.

Port 1 provides the standard connection to the host computer.

Port 2 provides a redundant connection to the host computer via modem or direct

connection.Up to a total of 32 I/O boards can be connected to ports 3, 4, 5, and 6. This

board has an optional memory expansion board (PW5KxM4) that allows the card data-

base to hold as many as 100,000 cards in addition to a buffer capable of storing 50,000

transactions while this board is off-line. The PW5KxIC is designed to be rack-mounted

for maximum density or tile-mounted to save cost when it is remotely mounted near the

devices to be controlled.

1. Port 1 may be set up as an RS-232 interface or an RS-485 interface. An optional

interface board (PW5KxEN) converts the RS-232 output of port 1 into an Ethernet port

capable of supportingTCP/IP. If this interface board is present, this port must be set up

as an RS-232 interface. See Jumper Settings in the setup section on how to perform this

setup

2. Port 2 may be set up as an RS-232 interface or an RS-485 interface.

3. Ports 3, 4, 5, and 6 are RS-485 interfaces.

An on-board real time clock maintains the date and time, taking into account leap year

and accounting for global time zones and daylight savings time changes. The program is

stored in FLASH memory and may be downloaded through a serial port, allowing the

program to be changed without physically changing board components.

Set Up

The controller hardware is configured with jumpers and a set of 8 switches.These jump-

ers/switches setup the memory chip size, port interface, end of line termination, controller

address, and baud rate. Please refer to the tables.

JumperSettings:

repmuJ gnitteS tluafeD detceleS

6J,5J,4J 2-1

584-SR1troP

3-2 )NExK5WProfderiuqeR(232-SR1troP

9J FFOevitcatonsirotanimretLOE584-SR1troP

evitcasirotanimretLOE584-SR1troP

51J,41J,31J 2-1584-SR2troP

3-2

232-SR2troP

81J FFOevitcatonsirotanimretLOE584-SR2troP

evitcasirotanimretLOE584-SR2troP

12J FFO

evitcatonsirotanimretLOE584-SR3troP

NO evitcasirotanimretLOE584-SR3troP

22J FFO

evitcatonsirotanimretLOE584-SR4troP

NO evitcasirotanimretLOE584-SR4troP

32J FFO

evitcatonsirotanimretLOE584-SR5troP

NO evitcasirotanimretLOE584-SR5troP

42J FFO

evitcatonsirotanimretLOE584-SR6troP

NO evitcasirotanimretLOE584-SR6troP

52J 2-1derongirepmujyltnerruc-devreseR

3-2

derongirepmujyltnerruc-devreseR

10 PW-5000 Intelligent ControllerInstallation Guide

TD1115 rev1101

DIP Switch Settings:

8S 7S 6S 5S 4S 3S 2S 1S NOITCELES

FFOFFOFFOFFO

23SSERDDA

FFOFFOFFONO

*1SSERDDA

FFOFFONOFFO

2SSERDDA

FFOFFONONO

3SSERDDA

FFONOFFOFFO

4SSERDDA

FFONOFFONO

5SSERDDA

FFONONOFFO

6SSERDDA

FFONONONO

7SSERDDA

FFO

*ekahsdnaHerawdraHoN

**STCyBdelbanEXT

FFOFFO

devreseR

FFONO

SPB006,9

NOFFO

SPB002,91

NONO

*SPB004,83

FFO

*drowssaPoN

deriuqeRdrowssaP

tluafeD* NExK5-WProfderiuqeR**

LED Operation

Thecontroller uses 3 on-boardLEDs toprovidestatusinformation during its power-up

sequence and normal operation.

EDOM

DELADELBDELCNOITPIRCSED

pu-rewoP ecneuqeS

NOFFOFFOputeserawdrah,pu-rewoPtratS

FFONONOesabataDgniraelCdnaMARgnitseT )BM/.ces5.xorppa(

FFONOFFO esabataDgniraelCTONdnaMARgnitseT .K.Osiesabatad)BM/.ces5.xorppa(

NONONOdnoces1rofdleh,etelpmocpu-rewoP

lamroN noitarepO

HSALF ecnohsalfdluohsdnarekcilftniafasahDELsihT .evitcasimetsysnehwdnocesyreve

HSALF rehtienoytivitcasierehtnehwhsalF 2ro1troPtsoH

HSALF .troPO/InoytivitcasierehtnehwhsalF )6,5,4,3stroP(

Power

The controller accepts 12VDC with an operating range of 10 to 16VDC and consumes

400mAofcurrent.

Locate power source as close to this board as possible. Connect power with minimum of

18AWG wires.

The addition of the PW5KxEN adds an additional consumption of 150 mA.

The addition of the PW5KxM4 adds an additional consumption of less than 1 mA.

Autres manuels pour PW-5000

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NexWatch Contrôleurs

NexWatch

NexWatch PW-3000 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
