NextBase Uno Cinema Pro Manuel utilisateur
Instruction Manual
Duo Cinema Pro
Professional Automotive Rear Seat Entertainment System
Uno Cinema Pro
EN-2
Cinema Pro Instruction Manual
Regulatory Statements
FCC Statement
This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CE Compliance Statement
This device meets the EU requirements (1999/5/EC) on the limitation of
exposureofthegeneralpublictoelectromagneticeldsbywayofhealth
protection.
WEEE Compliance Statement
This symbol on the product or on the packaging indicates that this
can not be disposed of as household waste. You must dispose
of your waste equipment and/or battery by handing it over to
the applicable take-back scheme for the recycling of electronic
equipment and/or battery. For more information please contact your
localhouseholdwastedisposalofce.
EN-2 EN-3
Cinema Pro Instruction Manual
Safety Instructions
Read through this manual carefully and observe the following safety
instructions before operating this device.
• Use only the car power cable and accessories supplied by dealer. Use of
unauthorized accessories may void the warranty.
• Do not install near any heat sources such as radiators, heat registers,
stoves,orotherequipment(includingampliers)thatproduceheat.
• Keep this device away from water, drinks, or all types of liquids.
• Do not drop or apply excessive force to this device.
• Disconnect this device from the power supply when not in use.
• It is forbidden by law to duplicate, broadcast, play in public, or rent
copyrighted material without permission.
• Do not use alcohol based products to clean your device. Clean only with
dry cloth. Always disconnect this device from the power source before
cleaning.
• Refer all servicing to authorized repair centres only. Do not attempt to
repair this device yourself. Doing so may result in electric shock and will
void the warranty.
• Keep this manual in a convenient place for future reference.
SPECIAL NOTE REGARDING USE OF THIS DEVICE IN A VEHICLE
• We strongly advise against the driver of a vehicle using this device, whilst
moving.
• Most countries and states have laws which prohibit or severely restrict the
use of this device in vehicles while driving, where the driver can see the
screen. Please adhere to these laws.
• Do not leave this device in places where the temperature is extremely low
(about -10ºC or lower) or extremely high (about 50ºC or higher), such as
inside the passenger cabin or trunk in midsummer.
• Always switch the engine on before connecting power via the car power
cable.
• Always disconnect the power from this device before switching off the
engine.
EN-4
Cinema Pro Instruction Manual
Contents
Introduction ...................................................................................................5
Package Contents ........................................................................................... 5
Uno Cinema Pro ........................................................................................ 5
Duo Cinema Pro ........................................................................................ 6
Specications .................................................................................................. 7
Media Support List .......................................................................................... 8
Product Overview ............................................................................................ 9
Player ......................................................................................................... 9
Stanchion Mount ...................................................................................... 10
Remote Control ..............................................................................................11
Functions Overview ..................................................................................11
Replacing the Battery ...............................................................................11
Getting Started ............................................................................................12
Installing Cinema Pro in Vehicle .................................................................... 12
Basic Connection .......................................................................................... 15
Turning the Power On/Off ............................................................................. 16
Turn the Power On................................................................................... 16
Turn the Power Off ................................................................................... 16
Making Connection ....................................................................................... 17
Insert the DVD Disc ................................................................................. 17
Connect to HDMI Input Source ................................................................ 18
Insert USB Flash Drive ............................................................................ 18
Connect Headphones .............................................................................. 19
Monitor Sharing (Duo Cinema Pro only) ..................................................20
Screen Mirroring With Your Smartphone .................................................21
Conguring the Settings ............................................................................23
General Operations ....................................................................................... 23
Switch the Input Source ........................................................................... 23
Media Playback ....................................................................................... 24
ConguringtheSettings ................................................................................ 27
DVD Menu (DVD/USB input source only) ................................................ 27
Auto Power Menu ........................................................................................
Reset Menu .................................................................................................
EN-4 EN-5
Cinema Pro Instruction Manual
Introducon
“Cinema Pro” is a new dual-screen rear seat car entertainment system that
will revolutionize the way we view in car entertainment. Cinema Pro has been
designed to keep passengers entertained on the move with the greatest of
ease. Users can easily send videos, pictures, and music from their portable
deviceorUSBashdrivetoCinemaProtowatchwhattheywant.
Package Contents
The following items come with your package. If any of them is missing, please
contact your local dealer.
Uno Cinema Pro
Player Stanchion Mount
123
Quick Start Guide
Remote Control Carrying Bag Quick Start Guide T-cable
12V/5A
5V/2.4A
Cigarette Charger Cable Lock Hex Key L-wrench
EN-6
Cinema Pro Instruction Manual
Duo Cinema Pro
Players
123
Quick Start Guide
Stanchion Mounts Remote Control Carrying Bag Quick Start
Guide
12V/5A
5V/2.4A
T-cable 1 T-cable 2 T-cable 3 Cigarette
Charger
Cable Lock Hex Key
L-wrench
Note:
♦The actual products might appear slightly different from illustration shown above.
EN-6 EN-7
Cinema Pro Instruction Manual
Specicaons
Item Description
Panel
Display 10.1” Active Matrix Color TFT LCD
Aspect Ratio 16:9
Resolution 1024 x RGB x 600
Luminance 300nits (typical)
DVD
Supported Disc
DVD, DVD-R, DVD+R, DVD-RW, DVD+RW,
DVD-R DL, DVD-RW DL, VCD2.0, SVCD,
CD, CD-R, CD+R, CD-RW, CD+RW
Supported
Format
DVD-Video Navigation Ver1.0, VCD
Ver1.0/2.0, SVCD, D-DA, Data (MP3, JPEG,
MPEG 1/2/4)
USB
Version USB 2.0 (Media Play)
File System FAT, FAT16, FAT32
Charging 5V/1.5A
HDMI Input HDMI Type A: HDMI 1.3 / 1.4
HDMI TypeC: HDMI 1.3 / 1.4
Speaker
Maximum
Output
• 2W (maximum)
• 1.5W (typical)
Total Harmonic 0.2% (maximum)
Signal/Noise ≥60dB
Channel
Separation ≥40dB
Dynamic Range ≥70dB
Output Level 2Vpp (typical)
(Input 0dB 1KHz)
Acoustic Noise 50 dB
Remote Control Key
Support
(NEXTBASE 16-key RC)
NEC Format
EN-8
Cinema Pro Instruction Manual
Item Description
Operating Voltage 9V to 16V/2.2A
Operating / Performance
Temperature -10°C to 50°C
Function Temperature
-10°C to 50°C functional but may not meet
specications(anydeviationsmustbe
recoverable)
Storage Temperature -20°C to 60°C
Housing Dimension 267 x 195 x 32 mm
Unit Weight 1.750 kg
Media Support List
Video Video Type Audio Type
DVD Video/(ISO)
• MPEG-1
• MPEG-2
• LPCM
• AC3
• MPEG-1 Layer 2
• MPEG-1 Layer 3
• DTS
AVI (.avi, .divx)
• MPEG-1
• DIVX 3/4/5/6
• Motion JPEG
• MPEG-4 SP/ASP(XviD)
• MPEG-4 AVC(H.264)
• VC-1
• LPCM, uLaw, aLaw
• MPEG-AUDIO
• HE-AAC,LC-AAC
• AC3,DolbyDigital Plus
• DTS
• MS-ADPCM
• WMA. WMA pro
Audio
MPEG-1 Layer 3
JPEG
EN-9
Cinema Pro Instruction Manual
Product Overview
Player
Speakers
Open button
HDMI1 port
HDMI2 port
USB port
Headphone jack
DC IN jack
Volume
(Up) key
Volume
(Down) key
Stop key
Mount slot
Power key
Source key
Play/Pause
key
IR Headphone LEDs
EN-10
Cinema Pro Instruction Manual
Stanchion Mount
Bracket
Backplate
DC IN jack
AV IN port
Locking latches
Latch pads
