Nextar X3E Instructions de montage
X3E
© gate5 AG, 2006. All rights reserved.
1
Contents
Typographic conventions........................................................................................
Icons……………………………………………………………………………………..…..
Introduction………………………………………………………………………………...
Key features…………………………………………………………………………...…
First steps……………………………………………………………………………..…….
Choosing a language…………………………………………………………..……….
Safety precautions……………………………………………………………..……….
Set time……………………………………………………………………….………….
GPS connection……………………………………………………………..…………..
Detailed description…………………………………………………………….…………
Using the map…………………………………………………………………..……….
Tracking mode and selection mode………………………………….…………
Choosing and finding locations……………………………………………….……….
Choosing a location on the map………………………………………..……….
Search for an address…………………………………………………..………..
Searching for and choosing POIs………………………………………..……..
Search for a location by recent…………………………………………………..
Favourites………………………………………………………………………….
Navigation………………………………………………………………………………..
Navigation screen…………………………………………………………………
Options during navigation………………………………………………………..
Planning a route………………………………………………………………………….
Settings…………………………………………………………………………………...
Route options………………………………………………………………….….
Language…………………………………………………………………………..
3
4
5
5
6
6
6
6
7
8
8
8
10
10
11
14
16
17
20
20
21
23
25
25
27
© gate5 AG, 2006. All rights reserved.
2
Map settings……………………………………………………………………..
Volume………………………………………………………………………..…
Optional features…………………………………………………………………..…….
Guides……………………………………………………………………………..……
Traffic Message Channel (TMC)…………………………………………………………
Route Recording…………………………………………………………………………..
Speed Camera Alert………………………………………………………………………
smart2go™ Setup Assistant……………………………………………………………
Frequently asked questions……………………………………………………………
Index……………………………………………………………………………..………...
Copyright and license notes…………………………………………………………..
27
28
29
29
29
30
30
31
34
35
37
TYPOGRAPHIC CONVENTIONS
© gate5 AG, 2006. All rights reserved.
3
TYPOGRAPHIC CONVENTIONS
Bold
Items you must select, such as menu options, command buttons, or items in a list.
• Bullet
Step-by-step procedures. You can follow these instructions to complete a specific
task.
Comment
Especially important or remarkable information.
Monospace
Information that you must type, or information like folders and filenames.
CAPITALS
Names of keys on the keyboard. For example, SHIFT, CTRL, or ALT.
ICONS
© gate5 AG, 2006. All rights reserved.
4
ICONS
The following icons and symbols are used throughout the application:
Icon Name Function
Menu icon Opens a menu with various options.
Back icon Go back to the previous screen.
Navigation icon Start navigation.
Search icon Opens a search screen
Confirmation icon Apply settings. Select/deselect all.
Exit icon Exit the application. Only visible in the
tracking mode (see page 8).
GPS icon Press this icon to move map back to your
GPS position. Only visible in the selection
mode (see page 8).
INTRODUCTION
© gate5 AG, 2006. All rights reserved.
5
INTRODUCTION
You have chosen a cutting-edge navigation system. Congratulations! Please enjoy
using it. This navigation system leads you straight to your destination, whether you
are travelling by car or on foot. You may navigate and plan your route with an easy to
use and intuitive interface, just by using your finger. You may also use this application
to plan your trip to suit your personal preferences and interests and to save
interesting destinations before you set off on your trip. This manual leads you through
the main features of the system.
Key features
• Cross-border navigation in Europe through map of Europe (optional
feature)
• Dynamic Traffic Information, TMC (optional feature)
• Real pedestrian mode
• Look-ahead search function
• State-of-the art polygon view of individual houses for selected European
cities (optional feature)
• Earth browsing
• Unique night mode
• Improved guidance engine
• Premium content through branded guides (optional feature)
FIRST STEPS
© gate5 AG, 2006. All rights reserved.
6
FIRST STEPS
Please make sure that the battery of your device is fully charged.
• Switch on the unit and tap on NAVI or NAVIGATION in the first screen.
Choosing a language
If more than one language is available on your device, you are prompted to choose
your language.
• Click on the flag representing your country/language.
• On the following screen, choose the voice skins used for the voice
commands during navigation (e.g. female or male voice).
Safety precautions
Next, a screen with safety precautions will be shown.
• Read those safety precautions.
• Mark the Hide at startup checkbox to hide these notes for future
start-ups.
• Press the forward arrow.
Set time
Your PND is able to automatically determine the time through the GPS signal. For this
purpose, you need to set your time zone.
• Choose your time zone from the list. You can later change this (see page
27).
• During Summer Time, please mark the corresponding check box in order to
adjust the time shown forward by one hour.
Press the confirmation icon.
FIRST STEPS
© gate5 AG, 2006. All rights reserved.
7
GPS connection
Your PND uses GPS technology for navigation. Your device receives signals from a
number of GPS satellites in order to determine your current position.
• Place your PND in a position with an unobstructed view to the sky to set up
your first satellite connection. In the car this will usually be on the
dashboard.
It may take up to 10 minutes to establish the first connection. Subsequent
connections will be faster (30 seconds to 1 minute), but if you have not used
the unit for several days or are very far away from the last location you used
it, it may take up to 5 minutes again to find a strong signal.
DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
8
DETAILED DESCRIPTION
This chapter describes the functions of your Personal Navigation Device in detail. On
the following pages you will learn how to
- Use the map (see page 8)
- Find and choose locations (see page 10)
- Navigate to your destination (see page 20)
- Use the route planner (see page 23)
- Configure the application (see page 25)
Using the map
The map is the core component of your Personal Navigation Device. It will be centred
on your current location by default, provided you have a GPS connection. You can
browse the map, display information about the different locations shown on it and e.g.
choose them for routing and navigating.
Tracking mode and selection mode
The map knows two basic states, the tracking and the selection mode.
In the tracking mode, the map follows your actual position (GPS position), displaying
information about your geographic position, your speed, etc:
DETAILED DESCRIPTION
© gate5 AG, 2006. All rights reserved.
9
Speed
Geographic
coordinates
Time
Elevation
above mean
sea level
GPS status
Menu icon Info box Exit application
As soon as you browse the map, you enter the selection mode:
Current (GPS)
position
Menu icon Info box Tracking icon
• Use a pen or your finger to browse the map. The actual position will be
identified by a cursor.
Clicking on an icon on the map opens an overlay window with information
about the selected item.
• To zoom in or out, press the +or -icons. As soon as you press one of the
icons, the zoom slider will be shown, which can be used for smooth
zooming.
Zoom out
Zoom in
GPS position
Compass rose
Compass rose
Zoom out
Cursor
Zoom in
