Installaon guide WiFi speakers
CONO canto WiFi:
Clip the CONO canto WiFi speaker into the 3 phase lighng track. If you hear a
“plop” from the speaker and the Led is flashing, you are on the correct phase
and the speaker is connected to power. If not, turn the phase switch ll you
hear the “plop” sound => see first page
CONO pendo WiFi:
Install and connect the CONO pendo WiFi to the power supply
SUB quadro WiFi:
Install the SUB quadro WiFi, connect to the power supply and turn the switch
on the backside to “ON”
SUB canto WiFi:
Clip the SUB canto WiFi speaker into the 3 phase lighng track. If you hear a
“plop” from the subwoofer and the Led is flashing, you are on the correct phase
and the subwoofer is connected to power. If not, turn the phase switch ll you
hear the “plop” sound
Repeat the procedure with all WiFi speakers and control if the LEDs on all
speakers are flashing.
Connect the transmier to an electrical outlet using the supplied AC adapter.
Check that the green and orange LEDs on the transmier are flashing (if not,
check that the power adapter is properly connected and the outlet is supplying
power).
Connect a player to the Cinch jacks using the supplied audio cable and start
playback. When the orange LED is connuously lit, the music is sent wirelessly
to the speakers.
The sll flashing green LED confirms the correct funconing of the internal
sound processor.
CONNECT: Use the supplied remote control to aim at the orange LED of the
transmier and press the arrow key upwards. As soon as the blue LED is on,
the transmier is in pairing mode.
Pairing mode: The transmier acvates the pairing mode to connect all
speakers. Every 15 seconds the transmier plays the connected music signal
for 5 seconds to check a successful connecon. This will be repeated unl you
disable the pairing mode on the transmier. (see point 6)
Now go with the remote control from speaker to speaker and aim at the orange
LED of the speaker and press the arrow key upwards. The speaker confirms a
successful pairing aer a short me with a long beep tone.
Deacvate the pairing mode on the transmier by using the remote control to
aim at the blue LED of the transmier and press the arrow key downwards.
Aer a few seconds, the transmier will switch to normal operaon and all
connected speakers will output the connected music signal. You can start now
playing music.
