Newland NLS-HR200 Manuel utilisateur

NLS-HR200

Hand-held 2D Barcode Scanner

手持式二维码扫描器

Quick Start

快速使用指南

V2.0.0

Version/版本 Description/更新描述 Date/日期

V1.0 Initial release,only 6 pages .

最初版本，仅6页。 20090708

V 2.0.0 Support as from HR200 ﬁrmware V 3.06.007 and higher.

支持V 3.06.007 和更高的固件版本。 20100315

Revisions/版本信息

Getting to Start

Unpacking.......................................... E-01

Main Unit........................................... E-01

Accessories........................................ E-01

Outline and Function ......................... E-03

Speciﬁcation ...................................... E-04

Distance of Field................................ E-05

Connect HR200 to the Host............... E-06

Removal of Communication Cable ... E-07

ON, OFF, IDLE, RESTART .............. E-08

Reading

Hand-held Mode................................ E-09

Hands-Free Mode .............................. E-10

Programming Code

Query ................................................ E-11

Factory Default.................................. E-12

Reading Mode ................................... E-13

RS232 Programming ......................... E-14

USB Programming ............................ E-17

USB HID-KBW Programming.......... E-18

Beeper................................................ E-21

Line Feed and Carriage Return.......... E-22

1D Symbols ....................................... E-23

2D Symbols ....................................... E-28

Appendix

A. Testing Codes................................ E-30

B. Digit Code and Save ..................... E-31

C. Troubleshooting ............................ E-32

开始使用

打开包装 ........................................... C-01

主机 ................................................... C-01

配件 ................................................... C-01

产品外观 ........................................... C-03

性能参数 ........................................... C-04

识读景深 ........................................... C-05

如何连接HR200和信息接收主机.... C-06

如何拆卸通讯线 ............................... C-07

开机、关机、待机和重启 ............... C-08

识读条码

手动识读模式 ................................... C-09

自动识读模式 ................................... C-10

常用设置码

查询命令 ........................................... C-11

恢复出厂设置 ................................... C-12

识读模式设置 ................................... C-13

RS232 通讯设置 ............................... C-14

USB 通讯设置 .................................. C-17

USB HID-KBW 相关设置................ C-18

提示音设置 ....................................... C-21

回车换行设置 ................................... C-22

1D 条码设置 ..................................... C-23

2D 条码设置 ..................................... C-28

附表

A. 测试样码 ...................................... C-30

B. 数据码和保存 .............................. C-31

C. 常见故障及判处方法 .................. C-32

Content 目录

E-01

请更换节标题

Getting to Start

HR200»

PS/2 Cable»

Unpacking

Unpack and check the main unit and accessories.In case there is any problem, please

contact with your dealer.

Main Unit

Accessories

E-02

Getting to Start

Accessories

Stand»

USB Cable»

RS232 Cable + Power Adapter»

E-03

Getting to Start

Outline and Function

Power Indicator

Led

Beeper

Scan Windows

Tag（S/N，Cetiﬁcations，etc）

Trigger

Cable Slot

E-04

Getting to Start

Speciﬁcation

Performance

Image Sensor CMOS

Resoluing 752 * 480

Interface RS232 / HID-KBW / UDP / USB COM Port Emulation / HID-POS

Symbologies

2D PDF417, QR Code(Model 1/2), DataMatrix (ECC200, ECC000, 050,

080,100,140), Aztec, Maxicode, etc.

Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar,

China post 25,Interleaved 2 of 5, ISBN, Code 93, GS1 Databar,

Code 11,etc

Precision ≥5mil

Light Source LED(630 nm ±10 nm)

Light Intensity 300 LUX (130 mm )

Depth of Scan Field 30 mm ~ 445 mm

Print Contrast Signal ≥30%

Roll 360°

Pitch 45°

Yaw 45°

Illumination 0 ~ 100,000 LUX

Mechanical/ Electrical

Power Consumption 1.65 W

Voltage DC 5 V

Current

Max 330 mA

Oper. 290 mA

Idle 200 mA

Weight 250g

Environment

Operate Temperature -5°C - +45°C

Storage Temperature -40°C - +60°C

Humidity 5% - 95% ( non-condensing )

Certiﬁcates

FCC Part15 Class B, CE EMC Class B

E-05

Getting to Start

Distance of Field

36°

63mm Code 39 (5 mil) 120mm

25mm Code 39 (10 mil) 210mm

57mm PDF417 (5 mil) 115mm

37mm PDF417 (10 mil) 215mm

35mm QR Code (10 mil) 145mm

25mm QR Code (15 mil) 210mm

35mm Data Matrix (10 mil) 155mm

30mm Data Matrix (15 mil) 220mm

0 50 100 150 200 250

E-06

Getting to Start

Connect HR200 to the Host

Connecting with USB Cable

Connecting with PS/2 Cable

Insert PS/2 cable (RJ 45 male DIN) into HR2001、

cable slot;

Insert PS/2 cable (PS/2 male DIN) into Host PS/22、

female slot;

If necessary, connect PS/2 cable and the power3、

adapter;

If necessary, keyboard can connect to female slot4、

on the PS/2 cable.

Insert USB Cable (RJ45 male head) into HR2001、

cable slot;

Insert USB Cable (USB male head) into Host’s2、

(female) USB connector.

Connecting with RS232 Cable

Insert RS232 cable (RJ45 male head) into HR2001、

cable slot;

Insert RS232 cable (RS232 male head) into2、

Host’s (female) RS232 connector;

Connect RS232 cable and the power adapter.3、

E-07

Getting to Start

Removal of Communication Cable

A Pin that ﬁt the HR200 “dismount hole”is needed. A paper clip could be ideal. Stretch one

end of the paper clip to ﬁt the “Dismount Hole”. Follow the steps:

For RS232 and PS/2 connections, unplug the power adaptor.1、

Insert the Pin into “Dismount Hole”and keep some pressure.2、

Pull out the cable gently.3、

Pull out the Pin after the cable is removed.4、

Unplug the connector from the Host.5、
