Newall DP8 Manuel utilisateur
DP8 Digital Readout Display
NEWALL MEASUREMENT SYSTEMS LTD
N
Contents
Newall Measurement Systems
1
ONTENTS
1.0 Introduction
1.1 EMC and Low Voltage Compliance
1.2 Technical Specifications
2.0 Installation
2.1 Mounting
2.2 Power Supply
2.3 Connections
2.4 Switching On
3.0 User Instructions
3.1 Options
3.2 Using the Keypad
4.0 Set-Up
4.1 Set-Up Introduction
4.2 Set-Up Defaults
4.3 Set-Up Menu
5.0 Standard Functions
5.1 Absolute/Incremental
5.1.1 Using Incremental
5.1.2 Using Absolute
5.1.3 Establishing a datum
5.2 Centre Find
5.3 Digifind (Ref)
5.3.1 Using a machine marker or
workpiece marker
5.3.2 Find Absolute Zero
5.4 Sub Datums (SDM)
5.4.1 Method 1 (Teach mode)
5.4.2 Method 2 (Manual Mode)
5.4.3 Job Number
5.4.4 Editing Sub Datums and Job Number
5.5 Inch/mm
5.6 Datahold (Display Off)
5.7 Zero Approach
6.0 Mill Functions
6.1 Arc
6.2 PCD (Bolt Hole Circle)
6.3 Line Hole
6.4 Polar Co-ordinates
7.0 Lathe Functions
7.1 Tool Offsets
7.2 Taper
7.3 Summing
7.4 Vectoring
8.0 Auxiliary Output Option
8.1 Position Pulse Output
8.2 Remote Zero and Enter Inputs
9.0 Troubleshooting
10.0 Cleaning
CONTENTS
Introduction
Newall Measurement Systems 2
1.0 INTRODUCTION
The DP8 Digital Readout conforms to the relevant European standards for electromagnetic compatibility and
low voltage directive as detailed below.
BS EN 50081-2: Electromagnetic compatibility.
Generic Emission Standard - Industrial Environment
BS EN 50082-2: Electromagnetic compatibility.
Generic Immunity Standard - Industrial Environment.
BS EN 61010-1: Safety requirements for electrical equipment for
measurement, control and laboratory use.
Construction: Two part system - display/keyboard separate from DSU/Inputs
Dimension Display/Keyboard DSU
Height: 170mm (6.7in) 130mm (5.1in)
Width: 295mm (11.6in) 185mm (7.3in)
Depth: 30mm (1.2in) 60mm (2.4in)
Weight: 2.1kg (4.6lbs) 1.7kg (3.7lbs)
Operating Voltage: 115 or 230V (switch selection)
Supply Voltage Fluctuation: Not to exceed +/-15% of the operating voltage
Supply Frequency: 50 to 60 Hz
Maximum Power Consumption: 26VA
Operating Temperature: 0 to 45°C (32°F to 113°F)
Storage Temperature: -20 to 60°C (-4°F to 140°F)
Inputs: Dependant on model, two or three Spherosyn/Microsyn transducers
Resolution:
Spherosyn/Microsyn 10 5µm (0.0002in) / 10µm (0.0005in) / 20µm (0.001in) / 50µm (0.002in)
Microsyn 5 1µm (0.00005in) / 2µm(0.0001in) / 5µm (0.0002in) / 10µm (0.0005in)
Environmental Conditions: Indoor Use, IP20 (IEC 529)
Relative humidity - maximum 80% for temperatures up to 31°C (87.8°F),
decreasing linearly to 33% at 45°C (113°F).
Transient overvoltage according to INSTALLATION CATEGORY II of IEC664
POLLUTION DEGREE 2 in accordance with IEC664
NEWALL MEASUREMENT SYSTEMS LIMITED RESERVES THE RIGHT TO CHANGE SPECIFICATION
WITHOUT NOTICE
Certificate No FM36096
1.1 EMC and Low Voltage Compliance
1.2 Technical Specifications
Installation
Newall Measurement Systems
3
2.0 INSTALLATION
Select the location of the DP8 with due regard of safety and ease of operation. Keep it clear of moving parts
and coolant spray. Ensure that the natural ventilation around the digital sending unit (DSU) is not restricted.
To ensure correct operation of the DP8, it is recommended that the digital sending unit (DSU) is grounded to
the machine from the equipotential terminal. A ground strap is provided in the fitting kit. The strap should be
cut to a suitable length once the DSU had been fixed to the machine. A terminal is provided for crimping to
the ground strap. This operation should be conducted by a suitably qualified engineer. The machine must
also be grounded to a good earth point.
The DP8 can be mounted in two basic ways as shown in Figure 2.1
ack view)
Figure 2.1 - Mounting Procedures
2.1.1 Display and digital sending unit (DSU) mounted separately (Figure 2.1a)
The keypad/display unit incorporates an M10 tapped hole in the rear of the unit. The M10 hole can be used
to mount the display in any of the standard methods as shown in Figure 2.2. The M10 stud mount is
provided as standard. The swivel mount assembly (Part No. 294-37740), the DP8 mounting arm (Part No
294-40050) and the DSU mounting assembly (Part No 600-65590) are all optional items as detailed on the
price list.
(a) Mounting DSU separately (b) Mounting DSU with display
2.1 Mounting
Installation
Newall Measurement Systems 4
INSTALLATION
The DSU is normally mounted on a vertical face on the rear of the machine. The DSU facilitates the fixing in
2, 3 or 4 point location. For metric applications drill and tap an M6 hole and locate the DSU by inserting one
of the M6 bolts provided. Ensure the DSU is level, mark the next location and drill and tap the second hole.
Repeat this process for the required number of fixing locations. For those customers requiring imperial
(Inch) fittings, repeat the above process substituting 1/4 inch UNC tapped hole and bolts.
Note: The fitting kit includes both the metric and imperial fittings. The metric fittings are zinc
coated whereas the imperial fittings are black
The DSU is connected to the keypad/display via a 3.5 metre 9 pin “D” type cable. The cable can only be
connected in one direction. Once connected, secure the cable at both ends using the slotted locking
screws.
Please note, as shown in Figure 2.1, the transducer and mains leads should be positioned underneath the
DSU to avoid any ingress of coolant.
2.1.2 Display and data sending unit (DSU) mounted together (Figure 2.1b)
An optional bracket (Part No 600-65590) is available to facilitate the mounting of the DSU directly to the
keypad/display. This assembly can be mounted using the standard M10 stud, the swivel mount assembly
(Part No 294-37740), the DP8 mounting arm (Part No 294-40050) . The last three items are optional and are
detailed on the price list.
The DSU is mounted to the optional bracket by four M6 bolts. These bolts are provided with the bracket
assembly.
The bracket kit includes a 300mm 9 pin “D” type cable. This cable is to be used to connect the DSU to the
keypad/display. The 3.5 metre cable is not needed in this configuration. The cable can only be connected in
one direction. Once the sockets are located in the DSU and the keypad/display secure the slotted locking
screws.
Figure 2.2 - M10, Swivel Mount and Arm .
Installation
Newall Measurement Systems
5
INSTALLATION
BEFORE CONNECTING THE ELECTRICAL SUPPLY TO THE DIGITAL SENDING UNIT (DSU), CHECK
THAT THE VOLTAGE SELECTOR SWITCH IS CORRECTLY SET. Figure 2.3 shows the position of this
switch.
The mains supply is connected through a detachable supply cord. The counter is supplied with a cord with a
right-angle connector. If another supply cord is used, it must have fitted a IEC320, 10A, EARTHED mains
connector with a cord rated for at least 10A.
The PROTECTIVE EARTH CIRCUIT of the mains supply MUST BE CONNECTED to the protective earth
terminal of the DSU through the supply cord.
The supply cord should be secured with cable ties to ensure that it cannot drop into a hazardous position,
ie. the floor or coolant tray, when disconnected from the DSU.
The supply cord must be routed away from moving parts, swarf, coolant or sources of heat.
If a mains plug is not already fitted to the supply cord or is of the wrong type, then a suitable EARTHED plug
should be used which complies with the relevant specifications for plugs and socket-outlets.
The mains supply fuse is a 20x5mm, type T0.5A, 250V. It is not to be replaced by the operator. If the fuse
blows it is a possible indication of some significant problem with the power source. Check the supply and
wiring carefully. If the fuse is replaced, the DSU must first be disconnected from the supply by the removal
of the IEC socket from the inlet. This connector is the primary disconnect device for the equipment and must
be accessible at all times. Do not position the equipment so that it is difficult to operate the disconnect
device.
NOTE: If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
Figure 2.3 - Connection diagram for the Digital Sending Unit (DSU)
2.2 Power Supply
Equipotential terminal for grounding the DSU to the machine. Refer to section 2.1.
Caution. Refer to section 2.2 before connection to the mains supply.
Installation
Newall Measurement Systems 6
The mains supply switch for the DP8 is mounted on the side of the DSU as shown in Figure 2.3.
When you switch on the DP8, the unit will automatically go through a brief self diagnostic routine.
During this routine, the name DP8 will be shown, then the software version number will be displayed and all
segments of the displays will be lit.
After this routine, the unit will display measurements and is ready for use.
The DP8 can be switched off via the mains switch on the DSU. Alternatively, the keypad/display can be
switched off by pressing the key. Please note that the DSU remains under power when the
key is pressed.
Figure 2.3 shows the connection sockets on the DSU. The DP8 is designed for use with Newall’s Spherosyn
and Microsyn transducers only. The transducers are connected to the DSU with Bleecon type connectors.
These connectors have a sliding sleeve that locks the connectors to their sockets.
Switch off the DSU before connecting or disconnecting the transducers. To fit the connectors into the
appropriate socket on the DSU, first align the connector and then push firmly in place. You should hear a
click confirming that the locking sleeve has engaged. To remove the connector, pull back on the connector
sleeve to disengage the locking mechanism.
The transducers and the display/keyboard are connected to the DSU at a separated extra low voltage
(SELV) level. Any additional interconnections must also be at SELV level.
CONVENTIONS USED IN THIS MANUAL
The direction of travel of an axis refers to the travel of the tool relative to the workpiece.
Keys on the keypad are signified in bold print, such as [ ENT ] for the enter key.
2.3 Transducer Connection
2.4 Switching On
User Instructions
Newall Measurement Systems
7
Standard Keys Purpose
3.0 USER INSTRUCTIONS
The DP8 is available in three models, the DP8 Mill, DP8 Lathe and the DP8 EDM. Each DP8 model is avail-
able with an optional auxiliary port. The auxiliary port is used for (i) a remote zero pendant (part number 600-
17690) and (ii) for positional output data
The keys are used as follows
Models 2 Axes 3 Axes Additional Features
DP8 Mill 33
Bolt Hole Circle (PCD) and Bolt Hole Arc mode,
Line Hole (max 999 holes), Arc contouring, Polar co-ordinates, Sub-
Datums
DP8 Lathe 33Tool Offsets,99 , Taper calculations, Internal summing,Vectoring, Sub-
Datums
On/Off (Display only, not DSU)
Select axis to enter dimension (preset)
Set the current position for the axis to zero (reset)
Clear entry values in preset mode
Enter key to confirm data entry
Switches between absolute and incremental readings
(LED indicates choice of mode)
Centre find function
Select the Digifind function
Switches between inch and millimetre display
(LED indicates choice of mode)
Numeric keypad for data entry
Selecting the required Sub-Datum number
Setting the selected Sub-Datum to zero
Insert / Delete
Scroll Previous / Scroll Next
X Y Z Z
XoYoZoZo
abs
inc
ce
12
ent
ref
in
mm
1 2 3 45
6 7 89 0
.
+
_
sdm
sdm
zero
del.
ins.
<>
3.2 Using the keypad
3.1 Options
User Instructions
Newall Measurement Systems 8
Mill Option Keys Purpose
For using the Pitch Circle Diameter (PCD) function
For using the Line Hole function
For using the ARC function
For selecting between Cartesian (x,y,z) and Polar (Length+Angle)
co-ordinates
Lathe Option Keys Purpose
For Taper calculations
For using Tool Off-Sets
Setting Tool Off-Sets
Summing function, vectoring function
R
set
1+1
DP8 Mill 2 Axes DP8 Mill 3 Axes
DP8 Lathe 2 Axes DP8 Lathe 3 Axes
Set-Up
Newall Measurement Systems
9
abs
inc
4.0 SET-UP
The DP8 digital readout display is equipped with a Set-Up Routine. The routine enables the operator to
change factory settings in order to increase efficiency and productivity. If the factory defaults are suitable,
select the NORMAL option at the end of the Routine to restore the factory defaults.
Generally, the entire Set-Up Routine is performed only one time. Changing some parameters in Set-Up may
alter datums, SDMs, tool compensations and Digifind.
DO NOT RUN SET-UP IF YOU ARE NOT PREPARED TO LOSE THIS DATA.
Set-Up is enabled while the unit is running its initial self-test, just after powering on. Press the [ ON/OFF ] on
the face of the display as the self-test is running.
The Set-Up procedure makes use of a menu system. The main menu consists of a list of options that can be
customised for your use (See Table 1). You simply press the [ <<]and [ >>]keys to scroll through this list
until you reach the option you wish to change. To change the option when selected, press [ ENT].
To exit the Set-Up routine scroll through to the quit option and press [ENT ].
If the keypad/display has been switched off by pressing the [ ON/OFF ] key rather than switching off at the
mains, it is possible to enter the Set-Up routine by pressing the [ ABS/INC ] key followed by the [ ON/OFF ]
key.
ON/OFF key
ABS/INC key
ON/OFF key This is required to complete the proper sequence as described in text
above
4.1 Set-Up Introduction
Table des matières
Autres manuels Newall Moniteur
