network HD-EO Manuel utilisateur
network-electronics.com
High Definition Electrical to
Optical Converter
Rev. 2
Flashlink User Manual
HD-EO
HD-EO Rev. 2
2
Network Electronics ASA
Thorøya
P.O. Box 1020
Sandefjord, Norway
Phone: +47 33 48 99 99
Fax: +47 33 48 99 98
1Hwww.network-electronics.com
Service Phone: +47 90 60 99 99
Revision history
Current revision of this document is the uppermost in the table below.
Revision Replaces Date Change description
2 1 2007-10-26 New front page.
1 0 2007-10-05 Added Materials Declaration and EFUP
0 B 04/05/06 Added specs and configuration of HW version 2
B A 13/08/02 Corrected printing errors
A - 09/08/02 Preliminary release
HD-EO Rev. 2
3
Contents
Revision history............................................................................... 2
1 Product overview......................................................................... 4
2 Specifications .............................................................................. 6
2.1 Optical output.............................................................................................6
2.2 Electrical input.............................................................................................6
2.3 Electrical output ..........................................................................................6
2.4 Electrical ......................................................................................................7
2.5 Standards ....................................................................................................7
2.6 Product versions ..........................................................................................7
2.7 Connector module ......................................................................................8
2.8 Terminal format support..............................................................................9
3 Configuration ............................................................................ 10
3.1 Version 2 Configuration.............................................................................10
3.2 Version 1 Configuration.............................................................................11
4 Module status............................................................................ 12
4.1 GPI ALARM – Module Status Outputs ........................................................12
4.2 GPI connections ........................................................................................12
4.2.1 Version 2 GPI pinout...............................................................................12
4.2.2 Version 1 GPI pinout...............................................................................13
4.3 Front Panel - Status Monitoring .................................................................13
5 Laser safety precautions ............................................................. 15
General environmental requirements for flashlink®equipment ...... 16
Certificate of Conformity .............................................................. 17
Product Warranty ......................................................................... 18
Materials declaration and recycling information............................ 19
Materials declaration .................................................................... 19
Environmentally-friendly use period.............................................. 19
Recycling information................................................................... 20
HD-EO Rev. 2
4
1Product overview
The flashlink®HD-EO is a multi bit-rate electrical to optical converter module
providing high performance media conversion for various signal formats from
19.4Mbps up to 1485Mbps. This state of the art unit offers Fabry-Perot (F-P)
or “Distributed Feedback” (DFB) laser technology with long wavelength on
single mode fiber. Unmatched signal accuracy, even in critical applications
with pathological signal patterns makes the HD-EO the first choice for all
optical transport demands.
The HD-EO can transport all HD and SD signal formats in addition to DVB-ASI
and SMPTE 310. It can also perform signal reclocking, which is selectable on
application. The optical output comes with a sophisticated 1310nm F-P laser
covering the demands of short and medium haul applications, optionally a
DFB laser for medium and long haul applications, with 16 CWDM
wavelengths available. The open system platform of Network Electronics
flashlink®system allows easy interoperability with third party fiber optical
systems.
The electrical input(s) are equipped with a multi rate cable equaliser(s)
providing an equalisation of typically 100m of high quality coax cable at
1485Mbps. A distribution amplifier with 2 outputs reduces the need for
additional DA’s (on HW version 1, only one can be used for DVB-ASI).
Optionally, a built-in change-over can switch to the standby input if the main
input experiences a loss of signal (version 2 hardware only).
Figure 1 – HD-EO (Version 2) HD-SDI Electrical to Optical Converter
HD-EO Rev. 2
5
Figure 2 – HD-EO (Version 1) HD-SDI Electrical to Optical Converter
HD-EO Rev. 2
6
2Specifications
2.1 Optical output
Transmission circuit fibre: Single Mode.
Light source: F-P or DFB laser.
Optical power: -7.5dBm (F-P laser) or 0dBm (DFB laser).
Optical centre wavelength
(F-P laser):
1310nm ±20nm.
Optical centre wavelength
(DFB laser):
1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410,
1470, 1490, 1510, 1530, 1550, 1570, 1590 or 1610nm
±6nm.
Temperature range: 0 to +50 degC.
Jitter (UI = Unit Interval): 0.135 UI max. @ 270Mbps,
0.2 UI max. @ 1485Mbps.
Connector Return Loss: >40dB with SM fibre.
Maximum reflected power: 4%
Connector: SC/UPC
2.2 Electrical input
Number of inputs: 2 (Hardware version 2),
1 (Hardware version 1).
Data rate NRZ: 19.4 to 1485 Mbps.
Equalisation: Automatic,
Cable equaliser and reclocker can be bypassed to support
bitrates down to 2Mbps.
Impedance: 75 ohm.
Return loss: >15dB @ 1485MHz.
Signal level: Nominal 800 mV.
Connector: BNC.
2.3 Electrical output
Number of outputs: 2.
Impedance: 75 ohm.
Return loss: >15dB @ 1485MHz.
Jitter: Maximum 0.2 UI
Peak to peak signal level: 0.8V ±0.1V
Signal polarity: Non-inverting (both, on Hardware version 2),
1 non-inverting + 1 inverting output (on HW version 1).
Connector: BNC.
HD-EO Rev. 2
7
2.4 Electrical
Power: +5 VDC, 3W Maximum.
Control: Control system for access to setup and module status
with BITE (Built-In Test Equipment).
2.5 Standards
Supported standards for electrical and optical ports:
SMPTE: SMPTE 292, SMPTE259M, SMPTE297, SMPTE305M,
SMPTE310.
DVB-ASI: EN50083-9.
2.6 Product versions
The following versions of HD-EO are available:
Part number Wavelength Laser type Output power
HD-EO-13T -7.5dBm 1310nm ±20nm F-P -7.5dBm
HD-EO-13T 0dBm 1310 ±6nm DFB 0dBm
HD-EO-15T 0dBm 1550 ±6nm DFB 0dBm
HD-EO-C1270 0dBm 1270 ±6nm DFB 0dBm
HD-EO-C1290 0dBm 1390 ±6nm DFB 0dBm
HD-EO-C1310 0dBm 1310 ±6nm DFB 0dBm
HD-EO-C1330 0dBm 1330 ±6nm DFB 0dBm
HD-EO-C1350 0dBm 1350 ±6nm DFB 0dBm
HD-EO-C1370 0dBm 1370 ±6nm DFB 0dBm
HD-EO-C1390 0dBm 1390 ±6nm DFB 0dBm
HD-EO-C1410 0dBm 1410 ±6nm DFB 0dBm
HD-EO-C1470 0dBm 1470 ±6nm DFB 0dBm
HD-EO-C1490 0dBm 1490 ±6nm DFB 0dBm
HD-EO-C1510 0dBm 1510 ±6nm DFB 0dBm
HD-EO-C1530 0dBm 1530 ±6nm DFB 0dBm
HD-EO-C1550 0dBm 1550 ±6nm DFB 0dBm
HD-EO-C1570 0dBm 1570 ±6nm DFB 0dBm
HD-EO-C1590 0dBm 1590 ±6nm DFB 0dBm
HD-EO-C1610 0dBm 1610 ±6nm DFB 0dBm
HD-EO Rev. 2
8
2.7 Connector module
HD-EO version 1 uses the connector module: SDI-C1 (Rev.1 or later, figure 3).
Figure 3: HD-EO (version 1) backplane.
HD-EO version 2 uses the connector module HD-EO-2-C1 (figure 4).
Figure 4: HD-EO (version 2) backplane.
The connector module is mounted at the rear of the sub-rack.
In typical use an HD-EO / HD-OE module at each end will be used. The
electrical input signal is connected to the IN1 or IN2 (DIGITAL INPUT for
version 1) BNC on the transmitting HD-EO, and the electrical output is
connected to an output BNC on the receiving HD-OE (see HD-OE manual for
possible configurations). The fibre cable is connected to the OPTICAL ports on
HD-EO and HD-OE.
Please note that some output BNCs on HD-OE might carry an inverted signal,
so formats like DVB-ASI can not be used on these outputs.
HD-EO Rev. 2
9
The details of how the connector module is mounted can be found in the user
manual for the frame. This manual is also available from our web site:
45Hhttp://www.network-electronics.com/.
2.8 Terminal format support
The different input and output ports on HD-EO can support a number of
formats. The table below shows which signal formats are supported on the
selected terminals.
Terminal format support, version 2:
Terminal Function Supported Format Mode
IN1 Electrical Input 1 HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Input
IN2 Electrical Input 2 HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Input
OUT1 Electrical Output – Reclocked
DA output
HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Output
OUT1 Electrical Output – Reclocked
DA output
HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Output
OPTICAL Optical Output (Transmitter) HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Output
GPI ALARM Open Collector Alarms Wired alarms OC Output
Terminal format support, version 1:
Terminal Function Supported Format Mode
DIGITAL
INPUT
Electrical Input HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Input
DIGITAL
OUTPUT 1
Electrical Output – None
inverted
Reclocked DA output
HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Output
DIGITAL
OUTPUT 2
Electrical Output – Inverted
Reclocked DA output
HD-SDI, SD-SDI,
Transparent1
Output
OPTICAL Optical Output (Transmitter) HD-SDI, SD-SDI, DVB-ASI,
SMPTE310, Transparent1
Output
GPI ALARM Open Collector Alarms Wired alarms OC Output
1HD-EO has a “Transparent mode”. In this mode all reclockers are switched off and no jitter attenuation
will be performed. This mode may be used for non-standard or unsupported bit rates over shorter
distances and up to 1 Gbps.
HD-EO Rev. 2
10
3Configuration
3.1 Version 2 Configuration
The HD-EO can support a number of different broadcast formats. The correct
configuration can either be set with a DIP switch or with the GYDA Control
System. The layout of HD-EO is shown in the drawing below with the DIP
switch to the upper left position. Look at the labels beside the 8 dip switches
near the release handle in order to find out what hardware version of HD-EO
you have. If the labels match the table below, you have version 2. If they
match the table in chapter 3.2, you have version 1.
Figure 5 - HD-EO version 2 board layout.
DIP switch configuration must be set according to the table below:
Switch # Label Function DIP=ON Function DIP=OFF Comment
1 RCL1 Reclocker ON Reclocker Bypass Reclocker mode
2 EQ1 Cable equaliser 1 ON Cable equaliser 1
Bypass
Equaliser 1 mode
3 ASI1 DVB-ASI Reclocker
support
SDI 177Mbps Reclocker
support
Select ASI or 177Mbps
support
4 RCL2 Not in use Not in use Not in use
5 EQ2 Cable equaliser 2 ON Cable equaliser 2
Bypass
Equaliser 2 mode
6 ASI2 Go to standby on LOS Stay in main at all
times
Change-over mode
7 SWP Input 1 is main Input 2 is main Input select
8 OVR Override GYDA control
Config. with DIP switch
GYDA control
Config. with GYDA
Select configuration
from GYDA
All DIP switches are off when pointing towards the release handle.
All clock rates for HD-SDI, SD-SDI and DVB-ASI are automatically configured
by the module itself.
