ZigBeeTM-Range Extender

User Manual

Range Extender

With backup battery

Model: Z809D

For Home Automation

20120831

Range Extender

Figure: Z809D (different plug head is provided for different region)



Binding key

Introduction

NETVOX Z809D is a dedicated network range extender. It is designed to have electrical

outlet which inherent the look of its Z809A neighbor. The difference between them is that

Z809D doesn’t have power consumption monitoring nor does it support wireless on/off

control. User may use it as a simple range extender.

Z809D is equipped with a battery backup power in time of power cut.

Z809D is IEEE802.15.4 ZigBee HA compliant and is applicable in any ZigBee Pro HA

Protocol network.

What is ZigBee?

ZigBee is a short range wireless transmission technology which defined for a minimum

complexity, low power consumption, low data rate, cost effective wireless solution. ZigBee

lies in between wireless markup technology and Bluetooth. ZigBee is based on

IEEE802.15.4 standard, the mutual co-ordination between thousands of sensors to

exchange data. Sensor to sensor or node-to-node communication is achieved through

relays of control data between devices with only a fraction of energy use which denoted

for highly transmission efficiency.

Note: Wireless communication, in some real use cases, can be limited by the signal

blockage. Please consult your service provider or place of purchase.

Product Specification

Fully IEEE 802.15.4 compliant (ZigBee Pro)

Utilizes 2.4GHz ISM band, up to 16 channels

Signal power: 7dBm (max); Rx sensitivity: -101dBm

AC Input: 100-240VAC, 50/60HZ power

Operating Temperature: -10oC to 50oC;

Storage temperature: -40oC to 85oC;

Up to 150 meters (line-of-sight)

Simple operation and device configuration

Operating

Ambient

Temp: -10oC ~50oC

R.Hum: 5% ~ 85%

Storage

Ambient Temp: -40oC ~85oC

Backup

Battery

Lasts 10 hr. approx.

Setting up the Z809D and network

To allow Z809D to function, it must first join to a ZigBee network. When it is given powered

it will automatically start searching for an existed network. So before you give power to

Z809D make sure it is within the wireless coverage distance (~150 meters or less) and

make sure first you have the permit-join feature enabled either on a coordinator or a

router device in the network so that Z809D will join to the network through it then give

power to Z809D and it will join into the network by itself.

*On how to enable permit-join please refer to the router or coordinator device user manual

Operation:

Ensure you have detached any home appliance from Z809D.

Step 1: Make sure you have open up permit-join function (valid for 60 seconds) of a

coordinator or a router.

Step 2: Now plug in Z809D into AC power socket to power it. Z809D device will start to

search for the network within reach.

Step 3: A non-flashing solid light indicates successful otherwise the indicator stays dark.

Setting Up Summary

(1) Startup and network association

(2) It is ready to be used.

Step 1. Startup and Network Association

If you wish to remove Z809D from previous joined network, please read Restore to

factory section of this manual first. Then come back to this section.

How to use Z809D

On/Off control

Z809D doesn’t support wireless on/off control.

Permit other device to join

Z809D is featured to be a router in the network. It permits other devices to join the network.

In normal operation, by default the router device Z809D does not permit any device to join

to the network to protect the network from unexpected or unauthorized join attempt. You

will need to open up the permit-join on Z809D or on other router device to allow new

devices (a router or an end device) to join.

Z809D is capable of holding 6 routers and 14 end devices.

Operation:

1. Short press the binding key only once. (press the 2nd time will force it to cease)

2. The permit join is now enabled for 60 seconds during which the indicator light will flash

60 times.

3. Z809D waits the new device to join in automatically. Please note that the maximum

waiting time to join is 60 seconds. Repeat the process if you missed the 60 seconds

period.

To force to stop, by pressing the binding key once again before permit-join expires.

Restore to factory setting

Z809D is capable of storing and saving includes network routing information. If you wish to

remove Z809D from an exited network, you would need to clear the saved routing

information to join to a new network by simply reset the device to restore to the factory

setting.

Step 1. Hold on to the binding key 15 seconds. Until you see indicator flash once then

release the key. Within 2 seconds, short press binding key once again.

Step 2. If successful, the indicator light flashes 10 times.

Now if you wish Z809D to join to a new network please power cycle the device again to

put the device into network search mode.

The power backup

Z809D has the ability to continue to function at the event of power outage.

There are times when user would want to disable the supplied power from backup battery

to function in the time of power outage event.

To disable:

Hold press binding key for 3 seconds, until the indicator flashes once then release the key.

If successful, the indicator would flash 10 times quickly.

To enable:

Hold press binding key for 3 seconds, until the indicator flashes once then release the key.

If successful, the indicator would flash 10 times slowly.

Backup battery power condition indication

Z809 device checks its backup battery level every 10 minutes. When the battery is bellow

2.6V, Z809 will start the battery charging cycle with its indicator flashes 10 times slowly;

and stop charging when it is above 3.0V.

When Z809D is power cycled, by default, the supplied power from backup battery is

enabled.

Clusters of Home Automation for Z809D

Home Automation device feature is defined by the endpoint which contains functional

clusters. Table 1 lists clusters for the endpoint of Z809D

Table 1: Clusters supported by the endpoint

Cluster for Z809D

Device ID: Range Extender (0x0008)

EndPoint: 0x01

Server side Client side

Basic (0x0000) None

Identify (0x0003)

Commission (0x0015)

Attributes of the Basic Information

Identifier Name Type Range Access Default Mandatory

/ Optional

0x0000 ZCLVersion 8-bit

Unsigned

integer

0x00 –0xff Read

only

0x03 M

0x0001 ApplicationVersion 8-bit

Unsigned

integer

0x00 –0xff Read

only

0x0A O

0x0002 StackVersion 8-bit

Unsigned

integer

0x00 –0xff Read

only

0x46 O

0x0003 HWVersion 8-bit

Unsigned

integer

0x00 –0xff Read

only

0x01 O

0x0004 ManufacturerName Character

string

0 – 32

Bytes

Read

only

netvox O

0x0005 ModelIdentifier Character

string

0 – 32bytes Read

only

Z809DE3R O

0x0006 DateCode Character

string

0 – 16

bytes

Read

only

20120522 O

0x0007 PowerSource 8-bit

Enumeration

0x00 –0xff Read

only

0x81 M

Attributes of the device configuration attribute set

Identifier Name Type Range Access Default Mandatory

/ Optional

0x0010 LocationDescription Character

string

0 – 16bytes Read/write Empty

string

0x0011 PhysicalEnvironment 8-bit

Enumeration

0x00 –0xff Read/write 0x00 O

0x0012 DeviceEnabled Boolean 0x00–0x01 Read/write 0x01 M

Important Maintenance Instructions

As the device is not water proof it is recommended to keep the device in a dry place.

Liquid and heavy moisture contains minerals that may oxidize the electronic circuitry. In

case of liquid spill, please leave the device to completely dry before storing or using.

Do not use or store the device in a dusty area. Dust may cause electronic parts to

destroy.

Do not use or store the device in an over heated place. Store in a hotter temperature

than the suggested maximum temperature may shorten the life span of the device; and

may damage the battery and causing the housing to deform.

Do not use or store the device in a very cold place than the suggested minimum

temperature. The water can be condensed inside the device when moving to an area that

is higher in temperature. This can severely damage the PCB board and circuitry. This may

shorten the life span of the device; damage the battery and cause the housing to deform.

Do not throw or strongly vibrate the device. This may damage connectivity of the

electronic parts and other sensitive components on the PCB board.

Do not use any strong chemical or washing to cleanse the device.

Do not use any coloring materials on any removable parts which my cause poor

connections and may keep the device from function properly.

All the above applies to the purchased products, battery and other packaged items. If any

unusable or damaged items are found please return the product to your nearest

authorized repairing center.

Important Notice

Under any circumstances without Netvox written approval, copy or redistribute any parts

of this document is strongly prohibited.

Netvox adhere to product development policy and therefore reserve the right to change

and/or add contents to this document without any further notice.

Under any circumstances or matters, Netvox is not responsible for data or revenue loss or

any indirect additional loss that may arise from special cases or any sudden obligations.

This documentation is provided according to the product at the time of purchase.

Netvox do not inherent any responsibility and promise or guarantee of the reliability of the

document contents –this applies but not limited to market piloting or real use case

purposes or otherwise it is legally stated. Netvox reserve the right to change and/or add

contents to this document without any further notice.
