Netvision NV4004HC Manuel utilisateur
WELCOME
Thank you for purchasing our product!
Before installation, please read this user’s guide carefully and keep this for
future references.
INDEX
II
Chapter1 Product Description...6
1.1 General Description.......................................
.
1.1.1 Feature ................................................................
1.2 Technical Specification..................................
.
1.2.1 NV40XXHC Series.............................................
1.2.2 DG40xxHC Series..............................................
1.2.3 DG41xxHC(HF) Series.....................................
1.2.4 DG42xxHF Series..............................................
1.2.5 DG4204HD.........................................................
Chapter2 Environment
DVR Board User Manual
III
Requirement...............................12
2.1 Operating System...........................................
.
2.2 CPU and Motherboard...................................
.
2.3 System Memory.............................................
.
2.4 VideoAdapter.................................................
.
2.5 HDD................................................................
.
Chapter3 Driver Installation......14
3.1 Install NV & DG Card Together...................
.
3.1.1 In Windows XP ...................................................
3.1.2 In Windows 7.......................................................
INDEX
IV
Chapter4 Audio Preview...........27
Chapter5 Cable Connection.....29
5.1 NV Series Card ..............................................
.
5.2 DG series card................................................
.
5.2.1 DG 40xx series cable.........................................
5.2.2 DG 42xxHF series cable ...................................
Chapter6 Applications...............32
6.1 Matrix Output.................................................
.
6.1.1 NV4002MD/4004MD........................................
6.1.2 DG4208HF/4216HF/4004HD .........................
DVR Board User Manual
V
6.2 Motion Detection & Mask Setup..................
.
6.2.1 Motion Detection Setup .....................................
6.2.2 Add Mask.............................................................
6.3 Virtual IP Matrix.............................................
.
6.4 Mobile Client..................................................
.
6.5 POS-DVR System.........................................
.
Chapter7 Appendix FAQ...........42
Environment Requirement
6
Chapter1 Product Description
1.1 General Description
NV & DG Series DVR Boards are professional digital security products using H.264 video
and PCM/ADPCM (G.711) audio compression technology. They are designed for real time
video & audio capturing with encoding in surveillance system. Different models of NV & DG
series cards can be mixed installed and operate smoothly in one PC DVR.
1.1.1 Feature
Comply with PCI 2.2 / PCI-E 1.0 standard
Support Windows 2000/2003 / Windows XP / Vista / 7, 32 / 64-bit OS
Support up to 64 channel input in a PC
Support 4CIF preview on any cameras, support 1920x1080 layout.
Support dual stream encoding
User-adjustable image quality and bit rate
User-adjustable video brightness / hue / contrast
Build-in motion detect
Support OSD, LOGO, and mask settings
Support video output (some specific model)
DVR Board User Manual
1.2 Technical Specification
1.2.1 NV40XXHC Series
NV4004HC NV4008HC NV4016HC
Model
Video Compression H.264
Input 4/8/16 CH BNC(1.0Vp-p, 75Ω)
Preview Resolution 704*576(PAL), 704*480(NTSC)
Encoding
Full-channels D1 with 12/15fps, no sub stream;
Full-channels DCIF/CIF or half-channels D1 with 25/30fps,
support sub stream in CIF/QCIF with 25/30fps
Recording
Bit Rate
48K~900K bps(CIF) per channel
80K~1.5M bps(DCIF) per channel
108K~2.4M bps(4CIF) per channel
Audio Input 4 / 8 / 16 Ch BNC (2.0Vp-p, 1Kohm)
Audio Compression G.711, 16bit/8KHz, 64Kbps
Working Environment -10 ~ +55℃ / 10 ~ 90%RH / 86 ~ 106kpa
Power Consumption 3.5W 7.5W 21W
Dimension (unit: mm) 152*87 201*101 250*98
7
Environment Requirement
1.2.2 DG40xxHC Series
DG4004HC DG4008HC(-E) DG4016HC(-E)
Model
Video Compression H.264
Standard PAL / NTSC
Input 4/8/16 CH BNC(1.0Vp-p, 75Ω)
Preview Resolution 4CIF/CIF, Realtime
Encoding
Full-channels D1 with 12/15fps, no sub stream;
Full-channels DCIF/CIF or half-channels D1 with 25/30fps,
support sub stream in CIF/QCIF with 25/30fps
Recording
Bit Rate
48K-900K bps(CIF) per channel
80K-1.5M bps(2CIF) per channel
108K-2.4M bps(4CIF) per channel
Audio Input 4/8/16 Ch BNC (2.0Vp-p, 1Kohm)
Audio Compression G.711, 16bit/8KHz, 64Kbps
Working Environment -10~+55℃/ 10~90%RH / 86~106kpa
Power Consumption 3W 7W 11W
Dimension (unit: mm) 152.5*93.2 182.5*106.6 257*106.6
1.2.3 DG41xxHC(HF) Series
8
DVR Board User Manual
DG4108HC DG4116HC DG4108HF
Model
Video Compression H.264
Standard PAL/NTSC
Input 8/16 CH BNC(1.0Vp-p, 75Ω)
Preview Resolution 4CIF/CIF, Realtime
Full-channels D1 with 6 / 7fps,
half-channels 2CIF with 12 / 15fps
Sub Stream: N/A
Full-channels D1
/ 2CIF / CIF with
25 / 30fps
Encoding
Full channels CIF with 25/30fps
Sub Stream: QCIF with 25/30fps
Sub Stream:
CIF/QCIF with
25/30fps
Recording
Bit Rate
48K~900K bps(CIF) per channel
80K~1.5M bps(2CIF) per channel
108K~2.4M bps(4CIF) per channel
Audio Input 8/16 Ch BNC (2.0Vp-p, 1Kohm)
Audio Compression G.711, 16bit/8KHz, 64Kbps
Working Environment -10 ~ +55℃/ 10~90%RH / 86 ~ 106kpa
Power Consumption 3W 7W 11W
Dimension (unit: mm) 152.5*93.2 182.5*106.6 257*106.6
1.2.4 DG42xxHF Series
9
Environment Requirement
DG4208HF DG4216HF
Model
Video Compression H.264
Standard PAL/NTSC
Input 8/16 BNC(1.0Vp-p, 75Ω)
Preview Resolution 4CIF/CIF, Realtime
Encoding Full-channels D1 / 2CIF / CIF with 25/30fps
Sub Stream CIF/QCIF : 1~25/30fps
Recording
Bit Rate
48K~900K bps(CIF) per channel
80K~1.5M bps(DCIF) per channel
108K~2.4M bps(4CIF) per channel
1 CH BNC 1CH BNC
Video Output
1 / 4 / 8 / 9 / 16 Views, support tour display
Audio Input 8 / 16 Ch BNC (2.0Vp-p, 1Kohm)
Audio Compression G.711, 16bit/8KHz, 64Kbps
Working Environment -10 ~ +55℃/ 10~90%RH / 86~106kpa
Power Consumption 8W 12W
Dimension (unit: mm) 145*93 175* 106.6
Note: The DG4216HF has two video-audio cables. So the DG4216HF has two TV
outputs. But only the first TV output (the TV output of the cable that connects to upper
interface) is available.
10
