This manual will help you to learn about the features of the NetPing Infra Red Universal Remote Control 3802
device, get an idea of its functionality and technical characteristics and prepare the device for operation.
A User Guide is designed for network administrators and users, who set up or operate a device. To work with a
device properly, a user must have an idea about the principles of building and functioning of local networks as well
as possess the next knowledge and skills:
Basic knowledge in the area of local and global networks;
Basicknowledgeintheareaofarchitectureandprinciples of work of TCP/IP networks;
Basic knowledge in the area of architecture and principles of work of Ethernet networks.
[ENG] NetPing Infra Red Universal Remote Control 3802, User guide -[ENG] [IR3801] Limitation of Liability and Copyright
[ENG] [IR3801] Limitation of Liability and Copyright
–
[ENG] [IR3801] Limitation of Liability and Copyright
The information, contained in this document, can be changed by a manufacturer without a prior notice.Although
every effort was made to make the information in this document accurate and without errors, a manufacturer is not
liable for their possible presence and for the consequences that may result from the errors herein. A manufacturer is
not liable if supplied equipment, software and this user guide does not correspond to expectations of a user and
his/her opinion about where and how to use all the above.All copyrights on supplied devices, described in this User
Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Сopying,
replication and translation of this user guide to other languagesare not allowed without a prior written permission
of a rightholder. Copying, replication, changing, disassembling of provided software are not allowed without a
prior written permission of a rightholder. For the part of software that is provided in source codes, there is a
separate license agreement, which defines an order of its use and modification. Other trademarks used in this
description belong to corresponding rightholders.
Developer and manufacturer:
NetPing east Co Ltd.
[ENG] NetPing Infra Red Universal Remote Control 3802, User guide -[ENG] [IR3801] Connectors and Indicators
[ENG] [IR3801] Connectors and Indicators
–
•
•
•
•
[ENG] [IR3801] Connectors and Indicators
Front panel
Element Function
1W port 1-Wire connection port for temperature or humidity sensors.
Digital input terminals
IN1, IN2 (Input)
Terminals for connecting discrete sensors.
Inputs specification:
logic "0" less than 3,5 V ;
logic "1" more than 8,2 V.
GND-terminals Ground (GROUND) for connecting discrete sensors
Link Indicator of Ethernet-port:
lights up if there is a connection
flashes while receiving packets.
CPU Device operation indicator. Lit when the device is powered on. Flashes when sending
packets to the network. Blinks quickly when reset to default.
[ENG] NetPing Infra Red Universal Remote Control 3802, User guide -[ENG] [IR3801] Connectors and Indicators
[ENG] [IR3801] Connectors and Indicators
–
Element Function
Ethernetports 2x10/100 BASE-TX, a built-in unmanaged L2 switch. PoE in 30-50V on both ports.
If PoE is applied to one, then it passes through, regardless of whether the device
is powered from PoE or not!
DC in DJK-02A under the pin of 2,1 mm "+" power in the centre. The range is 10-12V.
Back panel
Element Function
PWR Device operation indicator. It lights up when power is on.
ACT When transmitting an IR command, it does not light up, flashes 1 time.
If the command record contains garbage, it is lit for 1 s.
When a write command is sent, IR - blinks quickly.
When a command is received and successfully recorded, it stops
blinking and goes out.
Too long waiting for an IR command, timeout (> 20s) - stops blinking
and goes out.
IR recording buffer overflow - stops blinking, lights up for 1s, goes out.
RESET A button to reset the device to factory settings (it resets when the
button is held down when the device is turned on).
[ENG] NetPing Infra Red Universal Remote Control 3802, User guide -[ENG] [IR3801] Connectors and Indicators
[ENG] [IR3801] Connectors and Indicators
–
Element Function
IR-transmitters Direct them to the equipment that needs to be controlled, +/- 8-10
degrees.
IR-receiver It is used to read commands from the remote control.
[ENG] NetPing Infra Red Universal Remote Control 3802, User guide -[ENG] [IR3801] Installation and Connection
[ENG] [IR3801] Installation and Connection
–
•
•
[ENG] [IR3801] Installation and Connection
Step 1. Initial turning-on
1.Connect the device to the local network and power the device using a 12V DC power supply (PoE is disabled by
default).
2. To configure the device, open the device web interface at http://192.168.0.100 using a browser (it is advisable to
use the latest version of Google Chrome browser). For authorization use:
Login: visor
Password: ping
3. If you need, you can change the IP address to a free one from the pool of your network and configure the device
as needed, following the documentation:3.2. [DKSF 38.1 IU] Where Can I Change the Settings of the Network
Interface?
Step 2. IR commands recording
1.Direct the IR remote control, the commands from which you want to record to the IR receiver of the device
(incoming arrows).
[ENG] NetPing Infra Red Universal Remote Control 3802, User guide -[ENG] [IR3801] Installation and Connection
[ENG] [IR3801] Installation and Connection
–
2. Start recording the command to the required channel in the device web interface according to the
documentation ([ENG] 4.1. [DKSF 38.1 IU] How to write IR-commands Correctly?). In this case, the CPU LED on the
second Ethernet connector will light up continuously.
3. Press the button on the remote control for a short period of time, the command from which you want to record.
After a successful reading, the CPU LED on the second Ethernet port will turn off.
4. If possible, in order to check, direct the device with IR transmitters (outgoing arrows) to the target device and test
the command which has just been recorded.
Step 3. Mounting and sensors connection
1. Mount the device using the standard mount on a surface in the line of sight of the IR receiver of the device you
want to control.
2. Using the mount rotary joint, direct the device with the IR transmitters to the controlled device.
3. According to the documentation (Connecting Sensors), connect all necessary sensors to the device..
