Quick Start

AC750 WiFi Range Extenders

Model EX3920

Getting Started

The NETGEAR WiFi Range Extenders increase the distance of a WiFi

network by boosting the existing WiFi signal and enhancing the overall

signal quality over long distances. An extender repeats the signals from an

existing WiFi router or access point.

Note: Each extender must connect to your router’s WiFi network. Do not

connect the extenders to another extender’s WiFi network.

WiFi Range Extenders

Boost the range of your

existing WiFi and create

a stronger signal in

hard‑to‑reach areas

Existing WiFi

Sometimes your router

does not provide the

WiFi coverage that you

need

Meet Your Extenders

Before you install your extenders, familiarize yourself with their

LEDs, buttons, and ports.

Front Panel

Router

Link LED

Device

Link LED

Power LED

WPS LED

Side Panels

Factory

Reset

button

WPS button

Power On/O

button

Ethernet port

Power connector

(varies by region)

Power connector

(varies by region)

LED Descriptions

Router Link LED This LED indicates the connection between the extender and

the router or access point.

Solid green. Best connection.

Solid amber. Good connection.

Solid red. Poor connection.

O. No connection.

Device Link LED

This LED indicates the connection between the extender and

a computer or WiFi device.

Solid green. Best connection.

Solid amber. Good connection.

Solid red. Poor connection.

O. No connection.

Power LED Solid amber. The extender is booting.

Solid green. The extender is powered on.

O. The extender is powered o.

WPS LED Solid green. WiFi security is enabled (WPA or WPA2).

Blinking green. A WPS connection is being established.

O. WiFi security is not enabled.

Note: If the Router Link LED or Device Link LED lights amber or red, see

Find the Best Location on page 11.

Use the Extenders in Extender Mode

Place the extenders, apply power, and connect them to your router’s WiFi

network.

Place the Extenders and Apply Power

1. Place an extender in the same room as your WiFi router.

Proximity to the WiFi router is required only during the initial setup

process.

2. Plug the extender into an electrical outlet.

Wait for the Power LED to light green. If the Power LED does not light,

press the Power On/Off button on the extender.

3. Repeat Steps 1–2 for the second extender.

Connect to an Existing WiFi Network

To extend the range of your WiFi network, you must connect the

extenders to your existing router’s WiFi network. You can do this in one of

two ways:

• Connect with WPS. For more information, see Connect with WPS on

page 7.

• Connect with web browser setup. For more information, see

Connect with Web Browser Setup on page 9.

Note: Each extender must connect to your router’s WiFi network. Do not

connect the extenders to another extender’s WiFi network.

Connect with WPS

Wi‑Fi Protected Setup (WPS) lets you join a secure WiFi network without

typing the network name and password.

Note: WPS does not support WEP network security. If you are using WEP

security, follow the instructions in Connect with Web Browser Setup on

page 9.

1. Press the WPS button on the side panel of the extender.

The WPS LED blinks.

2. Within two minutes, press the WPS button on your router.

The WPS LED on the extender lights solid green, the Router Link LED

lights, and the extender connects to your existing WiFi network.

If the Router Link LED does not light, try again. If it still does not light,

see Connect with Web Browser Setup on page 9.

3. If your WiFi router supports the 5 GHz band, repeat Steps 1 and 2 to

connect the extender to the 5 GHz band.

4. Find the new extended WiFi network name on your computer or WiFi

device.

The extender creates two new extended WiFi networks. The

extender’s new WiFi network names are based on your existing WiFi

network name, with _2GEXT and _5GEXT at the end of the name.

For example:

• Existing WiFi network name. MyNetworkName

• New extended WiFi network names. MyNetworkName_2GEXT

and MyNetworkName_5GEXT

5. Connect your computer or WiFi device to the new extended WiFi

network.

Use the same WiFi password that you use for your WiFi router.

6. Unplug the extender and move it to a new location closer to the area

with a poor WiFi signal.

The location that you choose must be within the range of your

existing router’s WiFi network.

7. Plug the extender into an electrical outlet.

Wait for the Power LED to light green. If the Power LED does not light,

press the Power On/Off button on the extender.

8. Use the Router Link LED on the front panel to help you choose a spot

where the extender‑to‑router connection is optimal.

9. Repeat Steps 1–8 to connect the second extender.

Connect with Web Browser Setup

1. Use a WiFi network manager on a computer or WiFi device to find and

connect to the NETGEAR_EXT (SSID) WiFi network.

After the connection with the computer or WiFi device is established,

the Device Link LED lights.

2. Launch a web browser.

3. Enter www.mywifiext.net in the address field of the browser.

The New Extender Setup screen displays.

4. Click the NEW EXTENDER SETUP button.

The Extender Setup screen displays.

5. Complete the fields on the Extender Setup screen and click the NEXT

button.

6. Click the WIFI RANGE EXTENDER button.

The extender searches for WiFi networks in your area and displays a

list.

7. Select a WiFi network to extend and click the NEXT button.

If you do not want to extend both WiFi bands, clear the 2.4GHz WiFi

Networks or the 5GHz WiFi Networks check box.

Note: If you already installed an extender, do not select the

extender’s WiFi network.

8. In the Password (network key) field, type the existing WiFi network

password (also called passphrase or security key) and click the NEXT

button.

9. Set the network name (SSID) and password for your extender and

click the NEXT button.

10. Use a WiFi network manager on the computer or WiFi device to

connect to the new extended WiFi network.

Repeat this step for all of your computers and WiFi devices.

11. Click the Continue button.

A message displays confirming that the extender is connected to the

new extended WiFi network.

12. Click the Next button.

The Status screen displays.
