200Mbps Powerline Adapters with AC Pass-through - NP205
NetCommWireless
200Mbps Powerline Adapters
with AC Pass-through
QUICK START GUIDE
NetComm
Wireless
NP205
NetComm
Wireless
This quick start guide is designed to get you up and running quickly
with your new device. More advanced set up instructions can be found
in the user manual which can be downloaded from
www.netcommwireless.com
SETTING UP YOUR POWERLINE
ADAPTERS
1 2
3
Router
1. Using one of the supplied Ethernet cables connect one end into the
LAN Ethernet port of your modem/router.
2. Connect the other end of the same cable into one of the
Powerline adapters.
3. Connect the Powerline adapter to a power point near your
modem/router.
NOTE: For best performance plug your Powerline adapters directly into the wall. Do
not connect to a powerboard.
200Mbps Powerline Adapters with AC Pass-through - NP205
4. Connect one end of the other supplied Ethernet cable into the
Ethernet port of any device you want to connect to the Internet (PC,
set-top box, gaming console, PVR, blu-ray player etc).
5. Connect the other end of the cable into the second Powerline adapter.
6. Connect the Powerline adapter to a power point near your device.
NOTE: For best performance plug your Powerline adapters directly into the wall. Do
not connect to a powerboard.
TV
Powerboard
At this point, you can plug another electrical appliance into the Powerline
adapter’s AC pass-through socket if you wish to do so.
Both adapters will take a short time to nd each other. Once they have, all
three lights on both adapters should be on.
NOTE: For best performance connect other electrical devices to the AC
Pass-through socket rather than connecting the Powerline adapter to a
powerboard. If possible, also avoid plugging other electrical devices into
the socket next to the Powerline adapter to ensure your network performs
to its full potential.
NetComm
Wireless
LEDS
What can the LEDs tell me?
The Powerline LED changes colour depending on the speed of your
data transfer.
- Fastest
- Faster
- Fast
LED Off- The adapter is not paired or wall socket not
turned on.
NOTE: The devices work on the same electrical circuit with the same circuit
breaker. When they are on different circuit breakers they wont work and
the LED will be off.
- Lights up when a device is connected to the adapter via an
Ethernet cable
- Lights up when the adapter is connected to a power point
200Mbps Powerline Adapters with AC Pass-through - NP205
TROUBLE SHOOTING
My Powerline adapters will not connect to each other
1. Connect all adapters to a powerboard or powerpoints near each
other in the same room
2. Press and hold down the Simple Connect button on one of the
adapters for 15 seconds, or until the LED’s ash. This will reset the
password on that device.
3. Press and hold the Simple Connect button on the other device for
2 seconds. This will put the adapter in pairing mode. When the
adapter is in pairing mode, the LED will ash.
4. Finally hold the Simple Connect button on the rst device for
2 seconds to complete the pairing process. When pairing is
complete, the LED on both adapters will be lit. Both adapters
now share the same password and will be able to communicate with
each other.
NetComm
Wireless
To connect additional adapters
1. Connect adapter 1 and adapter 2 to a powerboard or powerpoints
near each other in the same room
Powerboard
1 2
Additional
adapter
(unpaired)
Already Paired
adapter
200Mbps Powerline Adapters with AC Pass-through - NP205
2. Press and hold the Simple Connect button on adapter 1 for 15
seconds, or until the LEDs ash to reset the password
1
Additional
adapter
(unpaired)
(press for 15 seconds)
3. Press and hold the Simple Connect button on adapter 2 for
2 seconds to put the adapter into pairing mode. The LED
will ash
2
Already
paired
adapter
(press for 2 seconds)
NetComm
Wireless
4. Hold the Simple Connect button on adapter 1 for 2 seconds to
complete the pairing process. When pairing is complete, the LED
on both Adapters will be lit and all adapters will share the same
password. Repeat for any further additions
1
Additional
adapter
(unpaired)
(press for 2 seconds)
Congratulations now you have paired an extra Powerline adapter
YML-NP205-V6
