Ness SecurityGuard III Manuel utilisateur

WIRELESS SECURITY SYSTEM

WITH GSM MONITORING

& TWO WAY VOICE

Owner's Manual

SecurityGuard iii

With tWo Way Voice MonitorinG

SECURITYGUARD III Main Unit

Onboard siren / Speaker

Siren and spoken voice prompts.

Scrolling LED Display

Indicator LED

One flash every 5 sec indicates normal operation.

Control Buttons

LEFT BUTTON RIGHT BUTTON

Adjust Main Volume - Press x 1 Main Volume 1 – 4

Adjust Bell Type - Press x 2 Bell Type 1 – 3

Adjust Bell Volume - Press x 3 Bell Volume 1 – 4 – OFF

Rechargeable Main Battery

(Internal).

Onboard Motion Sensor (PIR)

Emergency over-ride keyswitch

GSM Dialler built-in.

Congratulations on selecting SECURITYGUARD III

to protect your family and home.

Your SECURITYGUARD III with its "speak easy"

technology is a revolutionary radio based state-

of-the-art alarm system which has been built to

the highest standards of industrial design and

manufacturing.

The many sophisticated and innovative

design features of the SECURITYGUARD III

make the system highly secure as well as

being easy to use.

This Owner's Manual will help you identify the

various parts of your SECURITYGUARD III

system and give you an overview of operation

and functions.

Operation

ARM

HOME MODE (If enabled)

HOME2 (If enabled)

DISARM (or to reset alarms)

System is fully armed

System is partially armed

System is disarmed

button

Press once.

In these example house plans Armed areas are shown shaded ,Disarmed areas shown unshaded.

Vali

ow Battery

press +[User Code]+

button

Press once.

By Radio Key By Radio Keypad

Vali

ow Battery

press [User Code]+

button

Press twice.

Vali

ow Battery

press +[User Code]+

By Radio Key By Radio Keypad

button

Press 3 times.

By Radio Key

PANIC ALARM

Operation

GSM Dialler

to Monitoring

Station

Alarm

CLEARING DISPLAYS

To clear any display,

press the Disarm button

on a Radio Key. To recall

the display press Disarm

again, (unless the display

has been reset by arming

and disarming.)

EMERGENCY OVER-RIDE KEY

Only to be used if your remote radio

Keys are lost. Insert key and turn anti-

clockwise to disable the SECURIT-

YGUARD III. (Store these keys in safe,

hidden place).

SECURITYGUARD III

POWER OFF

Turn the key anti-

clockwise.

SECURITYGUARD III

POWER ON

Turn the key clockwise.

button

Press once.

button

Press & hold for

4 seconds.

Vali

ow Battery

By Radio Key By Radio Keypad

Press both

star keys together

Radio Key (RK4)

OPERATION

RK4 Radio Keys have four buttons for operating your

SECURITYGUARD III.

Press the button to Disarm the system or to si-

lence alarms.

Press the button to Arm the system or press

twice for HOME mode (if enabled on your system.)

Press the button to sound the Panic alarm.

Press the button for auxiliary functions as pro-

grammed by your installer.

BATTERY REPLACEMENT

Your RK4 Radio Keys are sealed units with an ex-

pected battery life of 10 years. Low battery warning

might indicate a battery fault or the battery has been

depleted by continuous presses. Contact Ness or

your SGIII dealer for advice.

* Example device

number

Radio Keypad (RKP)

OPERATION

RKP Radio Keypads have a full PIN pad for operat-

ing your SECURITYGUARD III using 3 to 6 digit user

codes. Your installer will set up and program the

RKP to suit.

Buttons

Used with your user code to arm the system.

Used with your user code to arm Home mode.

Enter button, used when arming and disarming.

(Press together) Sounds the Panic alarm.

Not used.

Used by your installer only.

Lights

Valid: Flashes once when a valid radio signal is

sent to the Securityguard.

Low Battery: If flashing indicates that the RKP's

internal battery is low. Replace the battery.

BATTERY REPLACEMENT

Carefully open the RKP Radio Keypad by pushing

both tabs at the top of the unit using a flat-bladed

screwdriver or blunt knife.

Insert a new high energy Lithium 9V battery and

then test the sensor.

* Example device

number

Insert the new high

energy Lithium 9V

battery.

Motion Sensors (PIR)

PIR BATTERY REPLACEMENT

The PIR motion sensors use a high energy Lithium

9V battery.

* Example device

number

OPERATION

R15 PIR motion sensors can be added to the system

to provide protection in additional rooms.

Maximum detection range is 15m.

BATTERY SAVING TIMER

The PIR motion sensors have a unique battery saving

feature which greatly extends battery life.

The Battery Saving Timer conserves the PIR battery

by preventing activation when it detects continuous

motion, such as in a busy room during the day.

The timer 'wakes' the PIR only when there has been no

motion for 5 minutes. The PIR will ignore any motion if

the timer has not expired. This is normal operation!

To test a PIR, leave the room for at least 5 minutes and

then re-enter. The red light in the PIR will flash to indi-

cate that it has sensed your motion into the room. If you

don't see the red light you may not have waited long

enough - try again.

Leave the

room.

Wait 5

minutes.

Red light

indicates motion

sensed.

Insert the new high

energy Lithium 9V

battery.

Unclip cover

at the bottom.

Carefully lift off the sensor's cover by unclipping at

the bottom using a flat-bladed screwdriver or blunt

knife.

Insert a new high energy Lithium 9V battery and

then test the sensor.

Remove the

cover.

Main Unit Battery

Connect the charger

for 24 hours.

LOW MAIN BATTERY

(Battery Powered Systems)

Your SECURITYGUARD III main battery will provide

3-4 month's operation before it must be recharged.

When the "Low Main Battry" message is displayed

you must charge the main battery.

Plug the charger into a mains power outlet and plug

the charging connector into the SECURITYGUARD III

for 24 hours.

The red Indicator LED

will be on while charging.

Radio Panic Button (RPB) Optional

OPERATION

Press the red Panic button to sound the Panic alarm.

(As programmed by your installer.)

BATTERY REPLACEMENT

Carefully lift off the Panic Button's cover by unclip-

ping at the bottom using a flat-bladed screwdriver or

blunt knife.

Insert a new CR2477 3V Lithium battery and then

test the sensor.

The new battery must be inserted in the battery clip

with the positive (+) side up.

Open here. Insert the new

battery. CR2477

3V Lithium

battery.

Remove

cover.

Posit ive (+)

side up.

Radio Door Bell (RDB)

OPERATION

Press the Door Bell button to sound the door chime at

the SECURITYGUARD III main unit.

BATTERY REPLACEMENT

Carefully lift off the RDB Door Bell unit's cover by

unclipping at the bottom using a flat-bladed screw-

driver or blunt knife.

Insert a new CR2032 3V Lithium battery and then

test the sensor.

The new battery must be inserted in the battery clip

with the positive (+) side up.

Open here. Insert the new

battery. CR2032

3V Lithium

battery.

Remove

cover.

Posit ive (+)

side up.

* Example device

number

* Example device

number

Radio Micro Reed Switch (RR3)

OPERATION

RR3 Radio Micro Reed Switches can be installed on

windows and doors to detect opening.

BATTERY REPLACEMENT

Carefully lift off the reed switch cover by unclipping

at the bottom using a flat-bladed screwdriver or

blunt knife.

Insert a new CR2032 3V Lithium battery and then

test the reed switch.

The new battery must be inserted in the battery clip

with the positive (+) side up.

* Example device

number

Universal Transmitter (RR2) Optional

OPERATION

Universal Transmitters can be used as window and

door switches (same as Radio Reed Switches) or as a

universal transmitter for other devices as connected

by your installer.

The RR2 also has an onboard vibration analyser with

sensitivity adjustment. This allows optional Nessen-

sor™ vibration sensors to provide wireless protection

of door and window frames, works of art, jewellery

cases, safes and other valuables.

BATTERY REPLACEMENT

Carefully lift off the Universal Transmitter cover by

unclipping at the bottom using a flat-bladed screw-

driver or blunt knife.

A warning sound will be heard when opening the

case - this is normal.

Insert a new high capacity Lithium 9V battery and

then test the transmitter.

Open here. Remove the

cover.

* Example device

number

Insert the new

high energy

Lithium 9V

battery.

Lift battery

out.

Insert the new

battery. CR2032

3V Lithium battery.

Positive (+) side up.

RR3

Open here.

Radio Smoke Detector

BATTERY REPLACEMENT

Remove the detector from its base by twisting anti-

clockwise. Replace the battery with a high energy

Lithium 9V battery.

Make sure the red safety bar in the battery compart-

ment folds down under the new battery. The safety bar

ensures that the smoke detector cannot be connected

to the base without the battery fitted.

To replace the detector on the base, line up the slot

on the detector with the alignment arrow on the base

and twist the detector clockwise to lock it in. Test the

smoke detector.

Insert the new high

energy Lithium 9V

battery.

* Example device

number

OPERATION

The SECURITYGUARD III Radio Smoke Detector

(RSM) is a photoelectric smoke detector and on-board

radio transmitter are powered by a single 9V Lithium

battery (supplied).

Alarm signals are delayed by 10 seconds before be-

ing sent to allow the on-board sounder to be tested

without triggering the alarm system.

TESTING

To test the sounder press and hold the Test button for

at least 2 seconds.

If you hold the Test button for longer than 10 seconds it

will also send an alarm signal to the SECURITYGUARD

III.

Twist off.

NOTICE

The RSM radio smoke detector is intended for use as an optional and supplementary smoke detection system in

addition to existing smoke alarms as required by relevant building codes.

If there is any doubt as to the suitability of this device for a particular application it is recommended that you seek

advice from the appropriate authorities or professional fire protection services.

Radio Siren

OPERATION

The Radio Siren may be installed inside the premises

to provide an extra loud noise deterrent in the event of

an alarm.

The Radio Siren is powered by a plug pack which must

always remain on at the power point.

Table des matières

Autres manuels Ness Système de sécurité

Ness

Ness Guardpost Manuel utilisateur

Ness

Ness Radio Siren Guide de démarrage rapide

Ness

Ness Guardpost Manuel utilisateur

Ness

Ness PRO-LD Manuel utilisateur

Ness

Ness LUX Guide de démarrage rapide

Ness

Ness SmartLiving 505 Instructions de montage

Ness

Ness 5000 Series Manuel utilisateur

Ness

Ness MEDI-ALARM Manuel du propriétaire

Ness

Ness Lux Guide de démarrage rapide

Ness

Ness 5000 Series Manuel utilisateur

Ness

Ness Guardpost Instructions de montage

Ness

Ness Guardpost Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
