NEP BDM-600 Manuel utilisateur

Installation and Operation Manual

BDM-600x Microinverter

(BDM-300x2 CEC Listing)

Modified 05/18/2023 by JMB

Contents:

COMPANY PROFILE------------------------------------------------------------------------------------------------------------------------------------- 4

1. INTRODUCTION-------------------------------------------------------------------------------------------------------------------------------------- 5

1.1 Prefix------------------------------------------------------------------------------------------------------------------------------------------- 5

1.2 Standards Compliance--------------------------------------------------------------------------------------------------------------------- 5

1.3 How to Use This Manual-------------------------------------------------------------------------------------------------------------------5

1.4 Label--------------------------------------------------------------------------------------------------------------------------------------------5

2. SAFETY INSTRUCTION------------------------------------------------------------------------------------------------------------------------------ 6

3. FCC COMPLIANCE----------------------------------------------------------------------------------------------------------------------------------- 7

4. INSTALLATION---------------------------------------------------------------------------------------------------------------------------------------- 8

4.1 NEP Parts Needed---------------------------------------------------------------------------------------------------------------------------8

4.2 Additional Parts and Tools Required----------------------------------------------------------------------------------------------------8

4.3 Lightning Surge Suppression--------------------------------------------------------------------------------------------------------------8

4.4 Installation Procedure----------------------------------------------------------------------------------------------------------------------9

4. 5 Install the AC Branch Circuit Junction Box------------------------------------------------------------------------------------------ 10

4.6 Attach BDM-600x to the Racking------------------------------------------------------------------------------------------------------ 11

4.7 Connect the BDM-600x Wiring Harnesses------------------------------------------------------------------------------------------ 11

4.8 Ground the System------------------------------------------------------------------------------------------------------------------------12

4.8A Through Trunk Cable------------------------------------------------------------------------------------------------------------- 12

4.8.B Through Racking------------------------------------------------------------------------------------------------------------------ 12

5. Commissioning------------------------------------------------------------------------------------------------------------------------------------- 13

5.1 Commissioning Steps--------------------------------------------------------------------------------------------------------------------- 13

5.2 Inverter/RSD Serial Input---------------------------------------------------------------------------------------------------------------- 13

5.2.A Manually on Device--------------------------------------------------------------------------------------------------------------13

5.2.B Using USB Barcode Scanner----------------------------------------------------------------------------------------------------14

5.2.C Using Web Browser-------------------------------------------------------------------------------------------------------------- 14

5.3 Installer Registration---------------------------------------------------------------------------------------------------------------------- 15

5.4 Homeowner Registration---------------------------------------------------------------------------------------------------------------- 15

5.5 Pre-Commissioning Setup--------------------------------------------------------------------------------------------------------------- 15

5.6 Create a Site on NEP Website-----------------------------------------------------------------------------------------------------------16

5.7 Verify and Map Site----------------------------------------------------------------------------------------------------------------------- 17

5.8 Commission the Gateway and Confirm Site Setup-------------------------------------------------------------------------------- 17

5.9 Grant Homeowner Access to Module View (Optional)---------------------------------------------------------------------------18

6. Operating Instructions----------------------------------------------------------------------------------------------------------------------------18

6.1 Status: Standby-----------------------------------------------------------------------------------------------------------------------------18

6.2 Producing Power---------------------------------------------------------------------------------------------------------------------------18

6.3 Grounding Fault---------------------------------------------------------------------------------------------------------------------------- 18

Modified 05/18/2023 by JMB

7. TROUBLESHOOTING AND MAINTENANCE--------------------------------------------------------------------------------------------------- 19

7.1 LED Indication of Error------------------------------------------------------------------------------------------------------------------- 19

7.1.C Error Mode (except for grounding error)----------------------------------------------------------------------------------- 19

7.1.B NOT communicating with BDG-256, and with no error----------------------------------------------------------------- 19

7.1.C Grounding Fault-------------------------------------------------------------------------------------------------------------------19

7.2 Troubleshooting An Inoperable BDM-600x/400----------------------------------------------------------------------------------- 19

7.3 Disconnecting a BDM-600x from the PV Module---------------------------------------------------------------------------------- 20

7.4 Installing a Replacement BDM-600x-------------------------------------------------------------------------------------------------- 20

8. Data Sheets------------------------------------------------------------------------------------------------------------------------------------------21

9. WARRANTY AND PRODUCTION INFORMATION-------------------------------------------------------------------------------------------- 22

What does this warranty cover and how long does it last?-------------------------------------------------------------------------- 22

What will NEP do?------------------------------------------------------------------------------------------------------------------------------22

How do you get service?----------------------------------------------------------------------------------------------------------------------22

What does this warranty not cover?-------------------------------------------------------------------------------------------------------23

Disclaimer Product----------------------------------------------------------------------------------------------------------------------------- 23

Modified 05/18/2023 by JMB

COMPANY PROFILE

Northern Electric Power Technology Inc. (NEP) is a U.S.-based company with manufacturing and

R&D facilities in Asia. Our mission is to develop cutting-edge clean energy technologies and provide

state-of-the-art solar inverter, rapid shutdown, and monitoring products to our customers.

Our headquarters are located in Tsingtao, a major industrial center and trading port in

northeastern China. Our campus occupies over 18 acres in the Tsingtao Export Processing Zone,

with more than 650,000 square feet of building space. We plan to connect our campus through a

micro smart grid demo community, powered by solar, wind, and micro turbines. In addition to our

headquarters, we have operation offices in Pleasanton, USA.

Our founders are well-known experts in the fields of power electronics, automatic control, signal

processing, and communications. Each of our founders has multiple U.S. and world patents in their

specialty areas, and received Ph.D. degrees from top universities in North America. They each have

over 10 years of engineering and management experience in leading U.S. companies.

NEP offers a complete product line of grid-tied solar inverters, including micro inverters ranging

from 180W to 2000W, and industry leading Rapid Shutdown Devices (RSD). Our field deployment

results have demonstrated the high efficiency and reliability of NEP solar inverters.

At NEP, we are committed to developing Clean, Reliable, Affordable, and Efficient products for our

customers worldwide.

Modified 05/18/2023 by JMB

1. INTRODUCTION

1.1 Prefix

We hope that our products will meet your needs for renewable energy. We highly value your feedback regarding our

products and would greatly appreciate any comments you may have.

Thank you for your business, and please do not hesitate to contact us if you have any questions or concerns.

1.2 Standards Compliance

The --------------- complies with the NEC 2014 and NEC 2017 article 690.12, and CEC 2015 section 64-218.

1.3 How to Use This Manual

This manual provides detailed product information and installation instructions for the ---------------. Please read

through this manual before installation and operation.

WARNING: This indicates a situation where failure to follow instructions may be a safety hazard or cause

equipment malfunction. Use extreme caution and follow

instructions carefully.

1.4 Label

Modified 05/18/2023 by JMB

2. SAFETY INSTRUCTION

WARNING:

PLEASE READ THIS MANUAL BEFORE INSTALLATION. ANY DAMAGE TO THE PRODUCT

DUE TO NOT FOLLOWING THIS MANUAL IS NOT COVERED BY THE WARRANTEE. ALL THE INSTALLATION SHOULD BE

DONE BY CERTIFIED ELECTRICIAN.

IT IS IMPORTANT TO NOTE THAT NOTHING INSIDE THE PRODUCT SHOULD BE MODIFIED, ASIDE FROM THE CABLE

CONNECTORS. ANY MODIFICATION TO THE INTERNAL COMPONENTS OF THE PRODUCT MAY RESULT IN MALFUNCTION

OR DAMAGE, AND MAY ALSO VOID THE PRODUCT'S WARRANTY.

ALL INSTALLATION SHOULD FOLLOW THE LOCAL ELECTRIC CODES.

WARNING:

WHEN THE PHOTOVOLTAIC ARRAY IS EXPOSED TO LIGHT, IT SUPPLIES A DC VOLTAGE TO THE PVG RSD

WARNING:

THIS PHOTOVOLTAIC RAPID SHUTDOWN EQUIPMENT (PVRSE) DOES NOT PERFORM ALL OF THE FUNCTIONS OF A

COMPLETE PHOTOVOLTAIC RAPID SHUTDOWN SYSTEM (PVRSS). THIS PVRSE MUST BE INSTALLED WITH OTHER

EQUIPMENT TO FORM A COMPLETE PVRSS THAT MEETS THE REQUIREMENTS OF NEC (NFPA 70) SECTION 690.12

FOR CONTROLLED CONDUCTORS OUTSIDE THE ARRAY. OTHER EQUIPMENT INSTALLED IN OR ON THIS PV SYSTEM

MAY ADVERSELY AFFECT THE OPERATION OF THE PVRSS. IT IS THE RESPONSIBILITY OF THE INSTALLER TO ENSURE

THAT THE COMPLETED PV SYSTEM MEETS THE RAPID SHUTDOWN FUNCTIONAL REQUIREMENTS. THIS EQUIPMENT

MUST BE INSTALLED ACCORDING TO THE MANUFACTURER’S INSTALLATION INSTRUCTIONS.

Modified 05/18/2023 by JMB

3. FCC COMPLIANCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

●Reorient or relocate the receiving antenna.

●Increase the separation between the equipment and the receiver.

●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

●Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance may void the user’s authority

to operate the equipment.

Modified 05/18/2023 by JMB

4. INSTALLATION

Please be aware that the installation of this equipment carries the risk of electric shock. Conductors that are typically

grounded may become ungrounded and energized when a ground fault is detected.

4.1 NEP Parts Needed

In addition to the micro inverters, PV modules, racking, and associated hardware, you’ll need the BDM-600x installation

kit. This kit includes the following items:

●AC trunk cable (one per micro)

●Protective end cap (one per branch circuit)

●Tail cable (one per branch circuit- 16’ long)

●Male connector (optional) Used to make extension cables

●BDG-256 (or BDG-256P3 for 3 phase)

The BDM-600 Ships six (6) to a box with each box measuring approximately 18” x 13.5” x 16”and weighing

57 lbs. A typical pallet contains 27 boxes.

4.2 Additional Parts and Tools Required

In addition to the PV modules, racking, and associated hardware, you’ll need the following parts:

●MLPE rail or frame attach clamps (2 per microinverter)

●AC junction boxes (multiple options possible)

●Cordgrip with locknut or strain relief fitting (one per branch circuit)

●A subpanel may be required for systems with multiple branch circuits

●Cable clips

●Sockets, wrenches, torque wrench, multimeter, small ﬂat head screwdriver, and mirror with extension rod

●Lightning and surge suppressor (recommended)

4.3 Lightning Surge Suppression

●It's important to note that lightning strikes can cause damage to PV systems even without directly hitting the

equipment or building where the system is installed. The electrical grid can experience voltage spikes induced

by a nearby lightning strike, which can in turn damage the equipment. While the BDM-600x includes integrated

surge protection that is greater than that found in most string inverters, it is still possible for the protection to

be exceeded if the surge has sufficient energy, resulting in damage to the equipment.

●Because the NEP Limited Warranty does not cover "acts of God" such as lightning strikes, and given that these

strikes can occur anywhere, it is recommended to install surge protection as part of any solar installation. Any

surge protection devices should be installed in accordance with the vendor's instructions

Modified 05/18/2023 by JMB

4.4 Installation Procedure

WARNING: : DO NOT CONNECT BDM-600x TO THE UTILITY GRID OR ENERGIZE THE AC CIRCUIT(S) UNTIL YOU HAVE COMPLETED ALL

OF THE INSTALLATION PROCEDURES AS DESCRIBED IN THE FOLLOWING SECTIONS.

Installing the BDM-600x Micro inverter System involves several key steps:

●Measuring service and installing the AC branch circuit junction box.

WARNING: ONLY USE ELECTRICAL SYSTEM COMPONENTS APPROVED FOR WET LOCATIONS

●Attaching the BDM-600x Micro inverter to the racking.

●Connecting the BDM-600x Micro inverter daisy chain connections

●.Grounding the system (optional)1

●Completing the BDM-600x Micro inverter installation map and connecting the PV modules.

The finished system should be similar as in the diagram. Detailed installation steps are listed in the following

section.

1DC circuits of BDM-600x are isolated and insulated from ground. An integrated grounding protection circuit is included in the micro inverter.

Modified 05/18/2023 by JMB

4. 5 Install the AC Branch Circuit Junction Box

●Measure service entrance conductors to confirm AC service at the site. Acceptable ranges are

shown in the table below:

1. BDM-600x-240A & BDM-600x-208A (North America)

2. BDM-600x-AU (Australia and New Zealand)

3. BDM-600x-EU (Europe)

●Mount the adapter plate onto the PV racking system at a suitable location, usually at the end of a row of

modules.

●Install a junction box with the adapter plate that is compatible with the microinverter.

●Connect the open wire end of the AC interconnect cable to the junction box using a gland or strain relief fitting

that is appropriate for the cable. It is important to use a strain relief connector with a diameter opening of 3/8

inches for the AC interconnect cable.

Modified 05/18/2023 by JMB

Autres manuels pour BDM-600

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NEP Onduleur

NEP

NEP BDM-300X2 Mode d’emploi

NEP

NEP SHP600 Manuel utilisateur

NEP

NEP BDM-650 Manuel utilisateur

NEP

NEP BDG?256 Manuel utilisateur

NEP

NEP BDM-600 Manuel utilisateur

NEP

NEP BDM-300X2-240A-D Manuel utilisateur

NEP

NEP BDM-250-240A Manuel utilisateur

NEP

NEP BDM-800 Manuel utilisateur

NEP

NEP BDM-500 Manuel utilisateur

NEP

NEP BDM-300-240A-D Manuel utilisateur

NEP

NEP BDM-600x Manuel utilisateur

NEP

NEP BDM-550 Manuel utilisateur

NEP

NEP BDM-300 Manuel utilisateur

NEP

NEP BDM-300 Manuel utilisateur

Manuels Onduleur populaires d'autres marques

Fourgroup

Fourgroup Easy Manuel utilisateur

Velleman

Velleman PI300M Manuel utilisateur

Sungrow

Sungrow SG350HX-US Manuel utilisateur

WilTec

WilTec 61897 Manuel utilisateur

SMA

SMA SUNNY BOY STORAGE 2.5 Manuel utilisateur

Simplicity

Simplicity LANDLORD 316 Manuel utilisateur

Santak

Santak SMAX 3000 Manuel utilisateur

ATON

ATON RA.Store-3 Manuel utilisateur

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Manuel utilisateur

Tektronix

Tektronix CFG250 Manuel utilisateur

Champion

Champion 200989 Manuel utilisateur

Vanner

Vanner 20-500 Series Manuel utilisateur

GE GEP Manuel utilisateur

Astrel Group

Astrel Group Power Reducer Guide rapide

MULTIQUIP

MULTIQUIP GDP-5H Mode d’emploi

GoWISE

GoWISE PS1007 Manuel utilisateur

Promate

Promate PM13500D ES Manuel utilisateur

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Manuel utilisateur
