Nemesis Hydra Air Manuel utilisateur
nemesisuvc.com | (469)-466-2UVC | Version 1.3
Hydra Air
USER MANUAL
English
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
2
Table of Contents
Safety
3
General Guidelines
9
Unpacking
9
Customer Support
10
General Information
10
Installation Instructions
11
Wiring
15
Limited Warranty
15
Benefits of UV-C Technology
16
UV-C Disclaimer
16
Technical Specifications
17
Setting Up Your Hydra Air
18
App Use
21
Key Fob Remote Setup
22
Resetting the Wi-Fi Unit
22
Cleaning
23
Replacing Radiators
23
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
3
Safety
HIGH INTENSITY ULTRAVIOLET LIGHT RISK OF EXPOSURE TO ULTRAVIOLET
RADIATION AVOID DIRECT EYE AND SKIN EXPOSURE
WARNING: This product can expose you to chemicals including mercury,
which is known to the State of California to cause cancer. For more
information, go to www.P65Warnings.ca.gov.
All Nemesis™ units are built and registered under our EPA™
registered facility #99690 as a Risk Group 3 UV-C product under 40
CFR 156
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be
followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
a) This equipment is designed for use with germicidal UV radiation sources and must be
installed in compliance with competent technical directions to prevent risk of personal injury
from UV radiation .
b) UV radiation can pose a risk of personal injury. Overexposure can result in damage to eyes
and bare skin. To reduce the risk of overexposure this equipment must be installed in
accordance with the manufacturer’s site planning recommendations. This may include
instructions on the relative location of each germicidal system component, the minimum
distances between UV-generating devices and other objects or surfaces, and protection
from line-of-sight exposure to UV radiation in occupied spaces located above the equipment
mounting area (e.g. upper floor balconies, open staircases, etc.)
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
4
c) UV and optical radiation can be reflected by surrounding surfaces such as ceilings and walls.
Since the reflective properties of surfaces can vary widely, it should be considered as part of site
planning. Follow the manufacturer’s recommendations for selecting appropriate ceiling and wall
finishes.
d) IT IS THE RESPONSIBILITY OF THE INSTALLER TO ENSURE THAT PERSONS WILL NOT BE
EXPOSED TO EXCESSIVE UV OR OPTICAL RADIATION DURING EQUIPMENT OPERATION.
THIS WILL REQUIRE THE INSTALLER TO CONDUCT AN ASSESSMENT OF IRRANDIANCE
OR ILLUMINANCE LEVELS IN THE SURROUNDING OCCUPIED SPACES PRIOR TO
OCCUPANCY.
e) Equipment should be mounted in locations and at heights where it will not readily be
subjected to tampering by unauthorized personnel.
f) Maintenance and servicing of this UV generating equipment shall be performed by authorized
personnel. Service personnel must wear appropriate Personal Protective Equipment (PPE) if the
equipment will be in operation during the maintenance or servicing work. Contact Nemesis
UV-C for PPE recommendations and guidance.
g) When replacing lamps, replace them only with the lamps for which the equipment is
marked and intended.
h) The use of accessory equipment not recommended by the manufacturer may cause an
unsafe condition.
i) Do not use this equipment for other than intended use.
SAVE THESE INSTRUCTIONS
Never allow humans, animals or plants to have direct exposure of UV-C light without proper
PPE. Since UV-C is not visible light, the fixtures have safety protocols built-in to avoid exposure.
Many studies have been done on the effects of UV-C and the results show minimal effect in the
short term. Studies have shown short term, temporary damage to the eye can be an effect of
exposure to UV-C light. Long term exposure may produce fading or degradation of some
materials. Amounts of degradation are completely dependent on types and quality of materials
and if they have UV-C protection built-in. The FDA approved waivers on UV-A, UV-B and UV-C,
more information is available from the FDA at: https://www.fda.gov/media/136533/download
For the proper, safe, and effective use of your device it is ESSENTIAL that the user follows
all guidelines and instructions in this manual. Proper installation and use is essential for the
effectiveness and safety of this product.
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
5
The airflow vents must remain unobstructed to allow for the best possible operating conditions
and to ensure the longevity of your device.
Disconnect the device from power source before cleaning the device or replacing radiators
(see page 24 for detailed instructions)
There are no serviceable parts inside the unit. DO NOT attempt to do any repairs beyond
basic cleaning and lamp replacement. Any attempts to repair the unit will void the
warranty. Nemesis is not responsible for any damages or harm caused by your repairs. Please
contact Nemesis at: (972) 423-0075 for repair assistance.
WARNING: To guard against injury, basic safety precautions should be observed, including the
following:
1. Read and save all notices, warnings and safety instructions received with equipment.
2. Avoid exposure to direct or reflected germicidal ultraviolet rays. Germicidal ultraviolet
rays are harmful to the eyes and skin.
3. Always disconnect power to the equipment and unplug before performing any service
or maintenance.
4. Do not operate without proper electrical ground.
5. To prevent the risk of severe or fatal electrical shock, special precautions must be
taken.
6. Equipment is intended for indoor use only.
7. Do not alter the construction or design. Do not remove safety labels or devices
8. Do not use equipment for other than its intended purpose, as described in the
equipment manual.
9. Keep inlet and outlet vents, clean and clear of objects.
10. Over time germicidal ultraviolet rays may break down plastic, rubber, or other non-
metallic materials, can fade colors, and can be damaging to plant life. Shield all plastic,
rubber, or other non-metallic parts, plant life, etc. which may be exposed to direct or
reflected germicidal ultraviolet rays.
11. Do not operate equipment if the power cord and/or plug are damaged, or if any other
damage to the unit is visible or suspected.
12. Utility power must match power requirements listed on the unit label.
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
6
13. Equipment should be protected from the elements and from temperatures below
freezing.
14. Do not exceed equipment’s maximum rated flow capacity and/or operating pressure.
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
7
Safety Warnings
All occupants and personnel should be alerted to the potential hazards indicated by the product
safety labeling on this unit.
The following conventions are used to indicate and classify precautions and on product safety
labeling. Failure to observe precautions could result in injury to people or damage to property.
This is the safety alert symbol. It is used to alert you to potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
Danger indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
Warning indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
Caution indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury.
Caution used without the safety alert symbol indicates a potentially hazardous
situation, which, if not avoided, may result in property damage.
This symbol / pictorial is used to identify an ELECTRICAL SHOCK or
ELECTROCUTION hazard.
This symbol / pictorial is used to identify an ULTRAVIOLET LIGHT hazard.
This symbol / pictorial is used to identify the need to wear approved ultraviolet
resistant face shield.
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
8
The symbol / pictorial is used to identify the need to wear approved
ultraviolet resistant eyewear.
This symbol / pictorial is used to identify the need to wear protective
gloves.
*This symbol / pictorial is used to identify components which must not be
disposed of in the trash.
Product safety labels should be periodically inspected and cleaned, as necessary, to maintain
good legibility. Always replace illegible safety labels. Contact the factory to obtain
replacement safety labels.
*WARNING - Hg - RADIATORS CONTAIN MERCURY, manage in accord with disposal laws; see:
LampRecycle.org OR contact Nemesis: Email: support@nemesisuvc.com Phone: (469)-466-
2UVC (M-F, 9AM-5PM CST) and ask about our lamp recycling program.
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
9
General Guidelines:
DO NOT attempt any repairs on the Hydra Air. Anything beyond replacing the radiators and
basic cleaning must be done by a trained technician. Attempts to repair the device will void
the warranty.
Avoid touching the radiators. Oils and moisture from the skin can cause the coating on the
radiator to deteriorate. Take extreme care when replacing radiators. (See Page 24 for detailed
instructions)
Check the fixture for dust and other contaminates monthly. Cleaning can be done with a fresh,
dry, lint-free cloth or with an air compressor on very low psi. The included dust collectors also
need to be cleaned periodically. See page 24 for more detailed instructions.
Take care when cleaning debris from broken radiators. DO NOT dispose with household
waste, follow your local hazardous waste guidelines OR contact Nemesis at (469)-466-
2UVC and ask about our Radiator Recycling Program.
For any questions or concerns, contact the Nemesis Customer Service Line 24/7 at:
P: (469)-466-2UVC E: [email protected] www.nemesisuvc.com
Unpacking
Your Nemesis Hydra Air has been sent out in perfect working order. Inspect packaging for any
damages that may have occurred during shipping. If the packaging appears damaged, carefully
inspect your Hydra Air. If you find any damage, contact customer support immediately before
attempting to operate your unit.
Contents:
Nemesis Hydra Air
2 UV-C Radiators (“lamps”) (Installed)
Key Fob Remote
Manual
ATTENTION: Operator MUST READ ENTIRE MANUAL before attempting to operate or
install the Hydra Air Extreme. Failure to follow instructions/guidelines laid out in this
manual will void the warranty and could lead to physical harm or cause damage to product.
Nemesis Hydra Air Manual V1.3
nemesisuvc.com | (469)-466-2UVC | Version 1.3
10
General Information
Offering incredibly powerful UV-C air recirculation for 24/7 disinfection. The Hydra Air fixture
fits seamlessly into existing drop ceilings and disinfects the air you breathe.
• Nemesis Hydra DC 24/7 UV-C Air recirculation
• 232 Cubic feet of air per minute
• In a 2800 cubic foot space, the air is circulated 6 times an hour
• Hydra UV-C disinfection technology ensures efficacy and efficiency
• Ultra-quiet fans create no distracting noise
• All UV-C is contained within the fixture, allowing for a 24/7 runtime
Customer Support
The customer support line is available for any inquiries on your product. Visit
https://www.nemesisuvc.com/ or call (469)-466-2UVC, 8am-5pm CST M-F
For 24/7 support, contact: [email protected]
For servicing or repairs, contact: (469)-466-2UVC, or go to: https://www.nemesisuvc.com/
