NEC V850 ZigBee Pro Manuel utilisateur

User's Manual

32-bit V850 ZigBee™ PRO

Gateway Development

Platform

Document No. U19026EE3V0UM00

Date published October 2009

Printed in Germany

Legal Notes

•The information in this document is current as of July, 2008. The

information is subject to change without notice. For actual

design-in, refer to the latest publications of NEC Electronics

data sheets or data books, etc., for the most up-to-date

specifications of NEC Electronics products. Not all products

and/or types are available in every country. Please check with

an NEC Electronics sales representative for availability and

additional information.

• No part of this document may be copied or reproduced in any form

or by any means without the prior written consent of NEC

Electronics. NEC Electronics assumes no responsibility for any

errors that may appear in this document.

• NEC Electronics does not assume any liability for infringement of

patents, copyrights or other intellectual property rights of third

parties by or arising from the use of NEC Electronics products listed

in this document or any other liability arising from the use of such

products. No license, express, implied or otherwise, is granted under

any patents, copyrights or other intellectual property rights of NEC

Electronics or others.

•Descriptions of circuits, software and other related information in this

document are provided for illustrative purposes in semiconductor

product operation and application examples. The incorporation of

these circuits, software and information in the design of a customer's

equipment shall be done under the full responsibility of the customer.

NEC Electronics assumes no responsibility for any losses incurred

by customers or third parties arising from the use of these circuits,

software and information.

• While NEC Electronics endeavors to enhance the quality, reliability

and safety of NEC Electronics products, customers agree and

acknowledge that the possibility of defects thereof cannot be

eliminated entirely. To minimize risks of damage to property or injury

(including death) to persons arising from defects in NEC Electronics

products, customers must incorporate sufficient safety measures in

their design, such as redundancy, fire-containment and anti-failure

features.

• NEC Electronics products are classified into the following three

quality grades: "Standard", "Special" and "Specific".

• The "Specific" quality grade applies only to NEC Electronics

products developed based on a customer-designated "quality

assurance program" for a specific application. The recommended

applications of an NEC Electronics product depend on its quality

grade, as indicated below. Customers must check the quality grade

of each NEC Electronics product before using it in a particular

application.

"Standard": Computers, office equipment, communications

equipment, test and measurement equipment, audio and visual

equipment, home electronic appliances, machine tools, personal

electronic equipment and industrial robots.

"Special": Transportation equipment (automobiles, trains, ships,

etc.), traffic control systems, anti-disaster systems, anti-crime

2User's Manual U19026EE3V0UM00

systems, safety equipment and medical equipment (not specifically

designed for life support).

"Specific": Aircraft, aerospace equipment, submersible repeaters,

nuclear reactor control systems, life support systems and medical

equipment for life support, etc.

The quality grade of NEC Electronics products is "Standard" unless otherwise

expressly specified in NEC Electronics data sheets or data books, etc. If

customers wish to use NEC Electronics products in applications not intended by

NEC Electronics, they must contact an NEC Electronics sales representative in

advance to determine NEC Electronics' willingness to support a given application.

(Note)

(1) "NEC Electronics" as used in this statement means NEC Electronics

Corporation and also includes its majority-owned subsidiaries.

(2) "NEC Electronics products" means any product developed or manufactured

by or for NEC Electronics (as defined above).

User's Manual U19026EE3V0UM00 3

Regional Information

Some information contained in this document may vary from country to country. Before

using any NEC product in your application, please contact the NEC office in your country

to obtain a list of authorized representatives anddistributors. They will verify:

• Device availability

• Ordering information

• Product release schedule

• Availability of related technical literature

•Development environment specifications (for example, specifications for

third-party tools and components, host computers, power plugs, AC

supply voltages, and so forth)

• Network requirements

In addition, trademarks, registered trademarks, export restrictions, and otherlegal

issues may also vary from country to country.

NEC Electronics Corporation

1753, Shimonumabe, Nakahara-ku,

Kawasaki, Kanagawa 211-8668, Japan

Tel: 044 4355111

http://www.necel.com/

[America]

[Europe]

[Asia & Oceania]

NEC Electronics America, Inc.

2880 Scott Blvd.

Santa Clara, CA 95050-2554,

U.S.A.

Tel: 408 5886000

http://www.am.necel.com/

NEC Electronics (Europe) GmbH

Arcadiastrasse 10

40472 Düsseldorf, Germany

Tel: 0211 65030

http://www.eu.necel.com/

United Kingdom Branch

Cygnus House, Sunrise Parkway

Linford Wood, Milton Keynes

MK14 6NP, U.K.

Tel: 01908 691133

Succursale Française

9, rue Paul Dautier, B.P. 52

78142 Velizy-Villacoublay Cédex

France

Tel: 01 30675800

Tyskland Filial

Täby Centrum

Entrance S (7th floor)

18322 Täby, Sweden

Tel: 08 6387200

Filiale Italiana

Via Fabio Filzi, 25/A

20124 Milano, Italy

Tel: 02 667541

Branch The Netherlands

Steijgerweg 6

5616 HS Eindhoven,

The Netherlands

Tel: 040 2654010

NEC Electronics (China) Co., Ltd

7th Floor, Quantum Plaza, No. 27

ZhiChunLu Haidian District,

Beijing 100083, P.R.China

Tel: 010 82351155

http://www.cn.necel.com/

NEC Electronics Shanghai Ltd.

Room 2511-2512, Bank of China

Tower,

200 Yincheng Road Central,

Pudong New Area,

Shanghai 200120, P.R. China

Tel: 021 58885400

http://www.cn.necel.com/

NEC Electronics Hong Kong Ltd.

12/F., Cityplaza 4,

12 Taikoo Wan Road, Hong Kong

Tel: 2886 9318

http://www.hk.necel.com/

NEC Electronics Taiwan Ltd.

7F, No. 363 Fu Shing North Road

Taipei, Taiwan, R.O.C.

Tel: 02 27192377

NEC Electronics Singapore Pte. Ltd.

238A Thomson Road,

#12-08 Novena Square,

Singapore 307684

Tel: 6253 8311

http://www.sg.necel.com/

NEC Electronics Korea Ltd.

11F., Samik Lavied’or Bldg., 720-2,

Yeoksam-Dong, Kangnam-Ku, Seoul,

135-080, Korea Tel: 02-558-3737

http://www.kr.necel.com/

4User's Manual U19026EE3V0UM00

Table of Contents

Chapter 1 V850 ZigBee PRO Gateway Development Platform

.......................................................................... 7

1.1 Features of the TK-850/SG2+UZ .................................................... 7

1.2 Package Content ................................................................. 7

1.3 System Requirements ............................................................. 8

1.4 Complementary ZigBee™ Development Platform and Hardware ...................... 8

Chapter 2 Sample Program ................................................. 10

2.1 Operational Procedure for the TK-850/SG2+UZ ..................................... 10

2.2 Operation Procedure with TK-78K0/KF2+UZ boards ................................. 14

Chapter 3 Hardware specification ........................................ 19

3.1 Terminal list ...................................................................... 19

3.2 Switches and LED ................................................................. 22

3.2.1 SW1, JP1 ................................................................ 22

3.2.2 SW2, SW3 ............................................................... 24

3.2.3 SW4 ..................................................................... 24

3.2.4 LED5 .................................................................... 24

3.2.5 LED1, LED2, LED3 and LED4 ............................................... 24

3.3 LAN Controller .................................................................... 25

3.3.1 Connection ............................................................... 25

3.3.2 Reset of LAN Controller .................................................... 26

3.3.3 Access to the LAN Controller ............................................... 26

3.4 Temperature Sensor .............................................................. 26

3.5 Power Supply ..................................................................... 26

Chapter 4 TK-850/SG2+UZ Data ......................................... 28

4.1 Parts Layout ...................................................................... 28

4.2 RF Board connection figure ........................................................ 29

Chapter 5 Programming the TK-850/SG2+UZ with WriteEZ1 ... 30

Chapter 6 V850 ZigBee Gateway Development Platform,

Installation and Operation .................................... 36

6.1 Hardware Installation .............................................................. 36

6.2 Software Installation .............................................................. 36

6.2.1 IAR Systems Embedded Workbench installation .............................. 36

6.2.2 GUI software WriteEZ1 for Flash Programming ............................... 37

6.2.3 Sample Program Installation ................................................ 37

6.3 USB Driver Installation ............................................................ 37

6.3.1 Installation on Windows XP ................................................. 37

Chapter 7 IAR Sample Session ............................................ 40

7.1 Sample Structure ................................................................. 40

7.2 Project Loading ................................................................... 41

7.3 Sample Debug session using the TK interface ....................................... 42

7.4 Generating a Hex file for Flash programming ........................................ 48

User's Manual U19026EE3V0UM00 5

Chapter 8 Sample Program ................................................. 50

8.1 User configurable network Parameters ............................................. 50

8.2 Libraries .......................................................................... 50

8.3 Embedded functions in Web Pages ................................................. 50

8.4 System Initialization ............................................................... 52

Chapter 9 Schematic Diagram TK-850/SG2+UZ ..................... 53

Chapter 10 Circuit Diagram of UZ2400 RF Board ..................... 57

6User's Manual U19026EE3V0UM00

Chapter 1 V850 ZigBee PRO Gateway

Development Platform

The V850 ZigBeeTM PRO Gateway Development Platform is the NEC Electronics

32-bit starter kit specifically designed for the development of wireless networking

applications combined with Ethernet and Internet communications. The above

platform can be used to design and develop high-end wireless networking,

incorporating all the features of a fully compliant ZigBeeTM network. This

development platform also has Ethernet and Internet capability which can support

communications via WEB browser-based technology.

The development kit contains the TK-850/SG2+UZ evaluation board, which

includes the V850ES/SG2, a 32-bit single-chip microcontroller of NEC

Electronics, and the UZ2400 RF board of Uniband Electronic Corporation.

1.1 Features of the TK-850/SG2+UZ

Features of the TK-850/SG2+UZ CPU evaluation board are as follows.

• The evaluation board used the NEC Electronics 32-bit single chip

microcontroller (µPD70F3281YGC). All of the ROM, RAM and

peripheral circuit are efficiently built in one chip on a single board.

• High-speed operation is realized via the 20 MHz internal clock.

• 32.768 kHz sub-clock standard equipment

•The high speed RAM: 32 KB and the flash memory 384 KB are built

into CPU chip.

•Hardware is ready to accommodate the 2.4 GHz transceiver UZ2400

RF board (Accordance with IEEE 802.15.4 ZigBeeTM Specifications

for Low Rate Wireless Personal Area Networks) made by Uniband

Electronic Corporation.

( http://www.ubec.com.tw/index.html)

• Attached antenna Titanis made by Gigaant

( http://www.gigaant.com)

• 17 I/O ports are equipped for expand use.

• On board temperature sensor S-8120C made by SII

( http://www.sii.co.jp)

• The board itself is quite and easy to handle; the CPU board size is

91 mm x 62 mm, and 103 mm x 62 mm when the RF transceiver

board is included.

Note Please inquire direct to the parts maker about specification of UZ2400 RF board,

antenna and temperature sensor.

1.2 Package Content

The V850 ZigBeeTM PRO Gateway Development Platform consists of one

TK-850/SG2+UZ development board and one 78K0_UZ_Stick which is

configured to act as Air Sniffer hardware. Also supplied is the unlimited security

User's Manual U19026EE3V0UM00 7

dongle for the V850 ZigBeeTM PRO stack and ZigBeeTM PRO Software

Developers Kit (ZigBeeTM PRO SDK tools).

The following software is also supplied on the accompanying CDROM.

•IAR Embedded Workbench Kickstart edition 64KB code size limited

•WriteEZ1 Flash programming Software for the V850 microcontrollers

• IEEE 802.15.4 MAC libraries

• TCPIP libraries, Mail and Web application libraries

• Web Page Conversion Utility Program

• Sample Web to Wireless application program for the TK-850/SG2

+UZ board

• Compiled HEX file for remote TK-78K0/KF2+UZ wireless node

(hardware not supplied)

1.3 System Requirements

Host PC A PC supporting Windows 2000 or Windows XP for the IAR Systems Embedded

Workbench Kickstart edition and the V850 ZigBee™ PRO Gateway Development

Platform.

Pentium 200 MHz minimum, 128 MB of RAM, 256 colour display (1024 x 768),

mouse, CD ROM drive and 200 MB of disk space are required to install the tool

packages.

Host Interface USB interface that enables communication based on USB (Version 1.1 or later)

Package Contents Please verify that you have received all of the parts listed in the package contents

list attached to the V850 ZigBee™ PRO Gateway Development Platform. If any

parts are missing or seem to be damaged please contact the dealer from whom

you received your V850 ZigBee™ PRO Gateway Development Platform.

Note Updates for the IAR Embedded workbench for V850, documentation and/or

utilities for the V850 ZigBee™ PRO Gateway Development Platform if available

maybe downloaded from the NEC Electronics web pages at: http://

www.eu.necel.com/updates

Trademarks IAR Embedded Workbench, visualSTATE, IAR MakeApp and C-SPY are

registered trademarks of IAR Systems AB. Microsoft and Windows are registered

trademarks of Microsoft Corporation.

Adobe and Acrobat Reader are registered trademarks of Adobe Systems

Incorporated.

All other product names are trademarks or registered trademarks of their

respective owners.

1.4 Complementary ZigBee™ Development Platform and

Hardware

Other evaluation boards and hardware available to develop a ZigBeeTM network

from NEC Electronics:

•ZigBeeTM Starter Kit

-2 x 8-bit ZigBeeTM node boards TK-78K0/KF2+UZ

Chapter 1 V850 ZigBee PRO Gateway Development Platform

8User's Manual U19026EE3V0UM00

- IEEE 802.15.4 MAC libraries

- Sample programs

- IAR Embedded Workbench Kickstart Version

- Flash programmer for 78K0

-Article code 78K0-ZIGBEE-SK

•ZigBeeTM Premium Development Kit for 78K0

-4 x 8-bit ZigBeeTM node boards TK-78K0/KF2+UZ

-8-Bit USB ZigBeeTM node programmed as Air Sniffer

- IEEE 802.15.4 MAC libraries

-ZigBeeTM Stack

-Unlimited ZigBeeTM license for the 78K0 family

- GUI Tools (SDK)

- Sample programs

- IAR Embedded Workbench Kickstart Version

- Flash programmer for 78K0

-Article code 78K0-ZIGBEE-PREM

•ZigBeeTM Premium Development Kit for 78K0R

-4 x 16-bit ZigBeeTM node boards TK-78K0R/KG3+UZ

-16-bit USB ZigBeeTM node programmed as Air Sniffer

- IEEE 802.15.4 MAC libraries

-ZigBeeTM Stack

-Unlimited ZigBeeTM license for the 78K0R family

- GUI Tools (SDK)

- Sample programs

- IAR Embedded Workbench Kickstart Version

-Article code 78K0R-ZIGBEE-PREM

•ZigBeeTM PRO Premium Development Kit for 78K0R

-4 x 16-bit ZigBeeTM node boards TK-78K0R/KG3+UZ

-16-bit USB ZigBeeTM node programmed as Air Sniffer

- IEEE 802.15.4 MAC libraries

-ZigBeeTM Stack

-Unlimited ZigBeeTM license for the 78K0R family

- GUI Tools (SDK)

- Sample programs

- IAR Embedded Workbench Kickstart Version

-Article code 78K0R-ZIGBEEPRO-PREM

Additional single boards or modules can be purchased in case the customer

needs additional hardware for Premium or Gateway kits:

- TK-850/SG2+UZ-EE

- TK-78K0/KF2+UZ-EE

- 78K0_UZ_Stick-EE

- TK-78K0R/KG3+UZ-EE

- 78K0R_UZ_Stick-EE

V850 ZigBee PRO Gateway Development Platform Chapter 1

User's Manual U19026EE3V0UM00 9

Chapter 2 Sample Program

The sample program provided permits the user to set up the following network

where the TK-850/SG2+UZ board occupies the central position. The

TK-850/SG2+UZ is already pre-programmed with the "mac_app.hex" file which

utilises the following network configuration:

Figure 2-1 System Configuration

The sample application utilizes TCP/IP and HTTP communications on the

TK-850/SG2+UZ board, and wireless communications of IEEE 802.15.4, between

one TK-850/SG2+UZ board and up to 4 TK-78K0/KF2+UZ boards (not supplied).

The TK-850/SG2+UZ board is called “Coordinator” and the TK-78K0/KF2+UZ

boards “Devices”.

The following parts present firstly, the operation of the central board alone, and

then the operation with the addition of TK-78K0/KF2+UZ boards.

2.1 Operational Procedure for the TK-850/SG2+UZ

If you intend to execute the sample program without using the debugger, set the

mode switch as shown below, and then, make a hardware reset by pushing the

reset switch.

Table 2-1 Operation mode settings for the TK-850/SG2+UZ

SW1 – 1, 2, 3 and 4 OFF

SW1 – 5, 6, 7 and 8 X

Connect your PC to the TK-850/SG2+UZ board with a LAN cable. The LAN cable

should be a crossover cable if connected directly through to the PC or a straight

cable if utilising normal network connections.

Apply the power source to the TK-850/SG2+UZ board (batteries or powered

USB).

10 User's Manual U19026EE3V0UM00

Table des matières

Autres manuels NEC Logiciel

NEC

NEC Storage Manager Manuel utilisateur

NEC

NEC NECSAM RICHER APPT FINAL2 Manuel utilisateur

NEC

NEC SOFTDVD PLAYER Manuel utilisateur

NEC

NEC LED-06AF1 Manuel utilisateur

NEC

NEC Versa 2730M Manuel utilisateur

NEC

NEC SpectraView Reference 241 Manuel utilisateur

NEC

NEC DiamondPro 2070SB Manuel utilisateur

NEC

NEC NEAX 2000 IVS Manuel utilisateur

NEC

NEC ExpressCluster SRE Manuel de l'opérateur

NEC

NEC NECAM NEWSREL 070306 Manuel utilisateur

NEC

NEC SMB8000 Manuel utilisateur

NEC

NEC Storage Manager Manuel utilisateur

NEC

NEC Storage Manager IS015-9E Manuel utilisateur

NEC

NEC Storage Manager Messages Manuel utilisateur

NEC

NEC AccuSync LCD52V Guide de référence rapide

NEC

NEC Storage ReplicationControl SQL Option Manuel utilisateur

NEC

NEC Storage Manager Configuration Setting Manuel utilisateur

NEC

NEC MultiSync LT280 Manuel utilisateur

NEC

NEC NEC Express5800 Series Manuel utilisateur

NEC

NEC Memory Editor Manuel utilisateur

NEC

NEC LCD2490W2-BK-SV - MultiSync - 24" LCD... Manuel utilisateur

NEC

NEC AccuSync LCD52V Guide de référence rapide

NEC

NEC CD-RW AND SOFTDVD SOFTWARE Fiche technique

NEC

NEC Versa LX Manuel d'utilisation

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur
