NEC Express5800 Series

N8800-103F, EXP320HR

NEC Express5800/320Fc-MR

User's Guide

N8800-103F, EXP320HR

NEC Express5800/320Fc-MR

User's Guide

1st Edition

7-2007

856-126614-901- A

PROPRIETARY NOTICE AND LIABILITY DISCLAIMER

The information disclosed in this document, including all designs and related materials, is the

valuable property of NEC Corporation (NEC) and /or its licensors. NEC and/or its licensors, as

appropriate, reserve all patent, copyright and other proprietary rights to this document, including all

design, manufacturing, reproduction, use, and sales rights thereto, except to the extent said rights are

expressly granted to others.

The NEC product(s) discussed in this document are warranted in accordance with the terms of the

Warranty Statement accompanying each product. However, actual performance of each such

product is dependent upon factors such as system configuration, customer data, and operator control.

Since implementation by customers of each product may vary, the suitability of specific product

configurations and applications must be determined by the customer and is not warranted by NEC.

To allow for design and specification improvements, the information in this document is subject to

change at any time, without notice. Reproduction of this document or portions thereof without prior

written approval of NEC is prohibited.

First Printing, July 2007

NEC Corporation

7-1 Shiba 5-Chome, Minato-Ku

Tokyo 108-8001, Japan

Printed in Japan

Keep this User's Guide handy for quick reference when necessary.

SAFETY INDICATIONS

To use NEC Express5800 series safely, follow the instructions in this User's Guide.

This guide explains components that pose a danger, types of dangers, and actions taken to prevent

them; such components are labeled warning.

This guide and warning labels use “WARNING” and “CAUTION” to indicate a danger depending on

the degree. These terms are defined as follows:

WARNING Indicates a danger that could lead to a death or serious injury.

CAUTION Indicates a danger that could lead to a burn, other injuries or damage to

physical assets.

This guide uses the following three types of symbols to give indications and precautions against a

danger. They are defined as follows:

Indicates that there is a risk of danger. Each image symbolizes a particular type of

danger. (Attention)

Indicates what you must not do. Each image symbolizes a particular type of

prohibition. (Prohibited actions)

Indicates what you must do. Each image symbolizes a particular type of action

necessary to avoid a danger. (Mandatory actions)

(Example) Symbol to draw attention

Term indicating a degree of danger

CAUTION

High temperature.

Immediately after the power-off, system components such as hard disk are

very hot. Wait the server to cool down completely before adding/removing

some component.

Symbol indicating a prohibited

action (may not always be

indicated)

Description of a danger

SYMBOLS USED IN THIS USER'S GUIDE AND WARNING LABELS

Attention

Indicates a risk of an electric shock.

Indicates a risk of a personal injury due to heat.

Indicates a risk of catching your fingers.

Indicates a risk of a fire or smoke.

Indicates a general precaution or warning that is not defined herein.

Indicates a risk of losing eyesight due to laser beam.

Indicates a risk of an explosion.

Indicates a risk of a personal injury.

Prohibited actions

Indicates a general prohibition that is not defined herein.

Do no touch the indicated area. There is a risk of an electric shock or fire.

Do not touch with wet hands. There is a risk of an electric shock.

Keep from flame. There is a risk of a fire.

Avoid using water or liquid nearby. If it spills on the equipment, there is a risk of an

electric shock or fire.

Do not disassemble, repair, or modify the equipment. There is a risk of an electric

shock or fire.

Mandatory actions

Unplug the server. There is a risk of an electric shock or fire.

Indicates a general action to take that is not defined herein. Make sure to follow the

instructions.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.



This class A digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numériqeu de la classeArespecte toutes les exigences du Règlement sur le matériel

brouilleur du Canada.

This system is classified as a CLASS 1 LASER PRODUCT. This label id located on

the internal DVD-ROM installed in your system.

CLASS 1

LASER PRODUCT

NOTE: This product provides resistance against hardware faults with its redundant hardware

modules. However, this does not mean complete fault-tolerance is assured. For example,

there is a risk of system down when:

– A fatal fault occurs in software.

– Both modules within a redundant hardware pair break down.

– A fatal fault occurs in a non-redundant component, such as the clock generator circuitry

or the interconnect backplane.

– The entire system is cut off from AC power.

Trademarks and Patents

NEC EXPRESSBUILDER and NEC ESMPRO are trademarks of NEC Corporation.

Microsoft, and Windows are registered trademarks of Microsoft Corporation in the United States

and other countries.

All other product, brand, or trade names used in this publication are the trademarks or registered

trademarks of their respective trademark owners.

Microsoft Windows Server 2003 R2 Standard x64 Edition operating system, Microsoft Windows

Server 2003 R2 Enterprise x64 Edition operating system, Microsoft Windows Server 2003 Standard

x64 Edition operating system, and Microsoft Windows Server 2003 Enterprise x64 Edition

operating system are called Windows Server x64 Edition for short.

Microsoft Windows Server 2003 R2 32-bit Standard Edition operating system, Microsoft Windows

Server 2003 R2 32-bit Enterprise Edition operating system, Microsoft Windows Server 2003

Standard Edition operating system and Microsoft Windows Server 2003 Enterprise Edition

operating system are called Windows Server 2003 for short. Microsoft Windows 2000 Server

operating system, Microsoft Windows 2000 Advanced Server operating system and Microsoft

Windows 2000 Professional operating system are called Windows 2000 for short. Microsoft

Windows Vista Business operating system is called Windows Vista for short. Microsoft Windows

XP Professional x64 Edition operating system is called Windows XP x64 Edition for short.

Microsoft Windows XP Home Edition operating system and Microsoft Windows XP Professional

operating system is called Windows XP for short. Microsoft Windows NT Server network operating

system version 3.51/4.0 and Microsoft Windows NT Workstation operating system version 3.51/4.0

are called Windows NT for short. Microsoft Windows Millennium Edition Operating System is

called Windows Me for short. Microsoft Windows 98 operating system is called Windows 98 for

short. Microsoft Windows 95 operating system is called Windows 95 for short.

Names used with sample applications are all fictitious. They are unrelated to any existing product

names, names of organizations, or individual names.

To prevent voltage sag:

This product may be affected by voltage sag caused due to lightning. To prevent voltage sag, you

are recommended to use anAC uninterruptible power supply (UPS) unit.

Notes:

(1) No part of this manual may be reproduced in any form without prior written permission of

NEC Corporation.

(2) The contents of this manual are subject to change without prior notice.

(3) The contents of this manual shall not be copied or altered without prior written permission of

NEC Corporation.

(4) All efforts have been made to ensure the accuracy of all information in this manual. If you find

any part unclear, incorrect, or omitted in this manual, contact the sales agent where you

purchased this product.

(5) NEC assumes no liability arising from the use of this product, nor any liability for incidental or

consequential damage arising from the use of this manual regardless of (4) above.

©NEC Corporation 2007
