NEC EXPRESS5800/120Rd-1 Manuel utilisateur

()

■■■■■■■

EXPRESS5800/120Rd-1

Service Guide

NEC CONFIDENTIAL AND PROPRIETARY

ll rights reserved by NEC Corporation. This document must be used solely fo

the purpose for which it was furnished by NEC Corporation.

No part of this document may be reproduced or disclosed to others, in any form,

without the prior written permission of NEC Corporation.

Revision Record

Edition COMP Date Page Description

1 0 2003.1.16

－First Edition

II Service Guide

III Service Guide

Safety Indications

To ensure proper and safe use of the server, handle the server according to the direction of the

Service Guide.

The Service Guide describes possible dangers in use of the server, the dangers you encounter if you

do not observe the instructions, and the ways to avoid the dangers.

Warning labels are attached to components with possible danger or their vicinity in the server when

operating the server.

In the Service Guide and the warning labels, "WARNING" and "CAUTION" are used as the terms

indicating hazardous levels. The terms are defined to have the following meanings.

WARNING

Indicates the presence of a hazard that may result in death or serious

personal injury if the instruction is ignored.

CAUTI ON

Indicates the presence of a hazard that may cause minor personal injury,

including burns, or property damage if the instruction is ignored.

Precautions and notices against hazards are presented with one of the following three symbols.

The individual symbols are defined as follows:

This symbol indicates the presence of a hazard if the instruction is ignored.

An image in the symbol illustrates the hazard type. (Attention)

This symbol indicates prohibited actions. An image in the symbol illustrates a

particular prohibited action. (Prohibited Action)

This symbol indicates mandatory actions. An image in the symbol illustrates a

mandatory action to avoid a particular hazard. (Mandatory Action)

IV Service Guide

SYMBOLS USED IN THIS GUIDE AND WARNING LABELS

Attentions

Indicates that improper use may cause an electric shock.

Indicates that improper use may cause personal injury.

Indicates that improper use may cause fingers to be caught.

Indicates that improper use may cause fumes or fire.

Indicates a general notice or warning that cannot be specifically identified.

Indicates that improper use may cause loss of eyesight due to laser beam.

Prohibited Actions

Indicates a general prohibited action that cannot be specifically identified.

Do not disassemble, repair, or modify the server. Otherwise, an electric

shock or fire may be caused.

Mandatory Actions

Unplug the power cord of the server. Otherwise, an electric shock or fire

may be caused.

Indicates a mandatory action that cannot be specifically identified. Make

sure to follow the instruction.

V Service Guide

GENERAL

WARNING

Do not use the server for services where critical high availability may

directly affect human lives.

Your server is not intended to be used with or control facilities or devices

concerning human lives, including medical devices, nuclear facilities

and devices, aeronautics and space devices, transportation facilities

and devices; and facilities and devices requiring high reliability. NEC

assumes no liability for any accident resulting in personal injury, death,

or property damage if the server has been used in the above conditions.

Do not use the server if any smoke, odor, or noise is present.

If smoke, odor, or noise is present, immediately turn off the power and

disconnect the power plug from the outlet, then contact your sales

agent. Using the server in such conditions may cause a fire.

Keep needles or metal objects away from the server.

Do not insert needles or metal objects into ventilation holes in the server

or openings in the floppy disk or CD-ROM drive. Doing so may cause

an electric shock.

Do not use the server in any unapproved place.

Install the server on a standard EIA 19-inch rack assembly. Do not

install the rack containing the server in a place inappropriate to the rack

installation environment.

Failure to follow these instructions may cause some bad influences to

be imposed on the server and other systems installed on the rack and

also a fire or personal injury due to falling of the rack may occur. For

the detailed explanation on the place where the server should be

installed and the earthquake-resistant construction for the rack, refer to

the manual attached to the rack or contact you sales agent.

Always install the server on a rack conforming to the relevant standard.

Install the server on a rack conforming to the EIA standard for the server

to be used. Do not install the server on any other rack than a standard

EIA 19-inch rack. Failure to follow these instructions may cause the

server to operate incorrectly and/or personal injury or damages of

surrounding devices to occur. Contact your sales agent for the racks

available for the server.

VI Service Guide

CAUTION

Keep water or foreign matter away from the server.

Do not let any form of liquid (water etc.) or foreign matter (e.g., pins or

paper clips) enter the server. Failure to follow this warning may cause

an electric shock, a fire, or a failure of the server. When such things

accidentally enter the server, immediately turn off the power and

disconnect the power plug from the outlet. Do not disassemble the

server. Contact your sales agent.

VII Service Guide

POWER SUPPLY AND POWER CORD USE

WARNING

Do not hold the power plug with a wet hand.

Do not disconnect/connect the plug while your hands are wet. Failure

to follow this warning may cause an electric shock.

Do not connect the ground wire to a gas pipe.

Never connect the ground wire to a gas pipe. Failure to follow this

warning may cause a gas explosion.

CAUTION

Plug in to a proper power source.

Use a proper wall outlet. Use of an improper power source may cause

a fire or a power leak.

Do not install the server where you need an extension cord. Use of a

cord that does not meet the power specifications of the server may heat

p the cord and cause a fire.u

Do not connect the power cord to an outlet that has an illegal number of

onnections.c

The electric current exceeding the rated flow overheats the outlet, which

ay cause a fire.m

Insert the power plug into the outlet as far as it goes.

Heat generation resulting from a halfway inserted power plug (imperfect

contact) may cause a fire. Heat will also be generated if condensation

is formed on dusty blades of the halfway inserted plug, increasing the

ossibility of fire.p

VIII Service Guide

Use the authorized power cord only.

Use only the power cord that comes with the server. Use of an

unauthorized power cord may cause a fire when the electric current

exceeds the rated flow.

Also, observe the following to prevent an electric shock or fire caused by

a damaged cord.

! Do not stretch the cord harness.

! Do not pinch the power cord.

! Do not bend the power cord.

! Keep chemicals away from the power cord.

! Do not twist the power cord.

! Do not place any object on the power cord.

! Do not bundle power cords.

! Do not alter, modify, or repair the power cord.

! Do not secure the power cord with staples or equivalents.

! Do not use any damaged power cord. (Replace a damaged power cord with

a new one of the same specifications. Ask your sales agent for

replacement.)
