Declaration

Declaration of the Manufacturer

We hereby certify that the colour monitors

MultiSync FE700+ (N0701)

is in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 55024

(IEC 61000-4-2)

(IEC 61000-4-3)

(IEC 61000-4-4)

(IEC 61000-4-5)

(IEC 61000-4-6)

(IEC 61000-4-8)

(IEC 61000-4-11)

and marked with

NEC-Mitsubishi Electric Visual Systems Corporation

686-1, NISHIOI OI-MACHI

ASHIGARAKAMI-GUN

KANAGAWA 258-8533, JAPAN

01b_Safety_en 11.09.2000, 7:56 Uhr1

TCO’99

Congratulations!

You have just purchased a TCO’99 approved

and labelled product! Your choice has

provided you with a product developed for

professional use. Your purchase has also

contributed to reducing the burden on the

environment and also to the further

development of environmentally adapted

electronics products.

Why do we have environmentally labelled

computers?

In many countries, environmental labelling has become an established

method for encouraging the adaptation of goods and services to the

environment. The main problem, as far as computers and other

electronics equipment are concerned, is that environmentally harmful

substances are used both in the products and during their manufacture.

Since it is not so far possible to satisfactorily recycle the majority of

electronics equipment, most of these potentially damaging substances

sooner or later enter nature.

There are also other characteristics of a computer, such as energy

consumption levels, that are important from the viewpoints of both the

work (internal) and natural (external) environments. Since all methods of

electricity generation have a negative effect on the environment (e.g.

acidic and climate-influencing emissions, radioactive waste), it is vital to

save energy. Electronics equipment in offices is often left running

continuously and thereby consumes a lot of energy.

01b_Safety_en 11.09.2000, 7:56 Uhr2

What does labelling involve?

This product meets the requirements for the TCO’99 scheme which

provides for international and environmental labelling of personal

computers. The labelling scheme was developed as a joint effort by the

TCO (The Swedish Confederation of Professional Employees), Svenska

Naturskyddsforeningen (The Swedish Society for Nature Conservation)

and Statens Energimyndighet (The Swedish National Energy Admini-

stration).

Approval requirements cover a wide range of issues: environment,

ergonomics, usability, emission of electric and magnetic fields, energy

consumption and electrical and fire safety.

The environmental demands impose restrictions on the presence and

use of heavy metals, brominated and chlorinated flame retardants,

CFCs (freons) and chlorinated solvents, among other things. The

product must be prepared for recycling and the manufacturer is obliged

to have an environmental policy which must be adhered to in each

country where the company implements its operational policy.

The energy requirements include a demand that the computer and/or

display, after a certain period of inactivity, shall reduce its power

consumption to a lower level in one or more stages. The length of time

to reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for

example, in respect of the reduction of electric and magnetic fields,

physical and visual ergonomics and good usability.

Below you will find a brief summary of the environmental requirements

met by this product. The complete environmental criteria document may

be ordered from:

TCO Development

SE-114 94 Stockholm, Sweden

Fax: +46 8 782 92 07

Email (Internet): [email protected]

Current information regarding TCO’99 approved and

labelled products may also be obtained via the Internet,

using the address:

http://www.tco-info.com/

01b_Safety_en 11.09.2000, 7:56 Uhr3

Environmental requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires,

casings and housings. Their purpose is to prevent, or at least to delay

the spread of fire. Up to 30% of the plastic in a computer casing can

consist of flame retardant substances. Most flame retardants contain

bromine or chloride, and those flame retardants are chemically related

to another group of environmental toxins, PCBs. Both the flame

retardants containing bromine or chloride and the PCBs are suspected

of giving rise to severe health effects, including reproductive damage in

fish-eating birds and mammals, due to the bio-accumulative* processes.

Flame retardants have been found in human blood and researchers fear

that disturbances in foetus development may occur.

The relevant TCO’99 demand requires that plastic components weighing

more than 25 grams must not contain flame retardants with organically

bound bromine or chlorine. Flame retardants are allowed in the printed

circuit boards since no substitutes are available.

Cadmium**

Cadmium is present in rechargeable batteries and in the colour-

generating layers of certain computer displays. Cadmium damages the

nervous system and is toxic in high doses. The relevant TCO’99

requirement states that batteries, the colour-generating layers of display

screens and the electrical or electronics components must not contain

any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches. It

damages the nervous system and is toxic in high doses. The relevant

TCO’99 requirement states that batteries may not contain any mercury.

It also demands that mercury is not present in any of the electrical or

electronics components associated with the labelled unit.

CFCs (freons)

The relevant TCO’99 requirement states that neither CFCs nor HCFCs

may be used during the manufacture and assembly of the product.

CFCs (freons) are sometimes used for washing printed circuit boards.

CFCs break down ozone and thereby damage the ozone layer in the

stratosphere, causing increased reception on earth of ultraviolet light

with e.g. increased risks of skin cancer (malignant melanoma) as a

consequence.

01b_Safety_en 11.09.2000, 7:56 Uhr4

Lead**

Lead can be found in picture tubes, display screens, solders and

capacitors. Lead damages the nervous system and in higher doses,

causes lead poisoning. The relevant TCO’99 requirement permits the

inclusion of lead since no replacement has yet been developed.

* Bio-accumulative is defined as substances which accumulate within

living organisms

** Lead, Cadmium and Mercury are heavy metals which are Bio-

accumulative.

ENERGYSTAR®Product

As an ENERGYSTAR Partner, NEC-Mitsubishi Electronics Display of

America, Inc. has determined that this product meets the ENERGYSTAR

guidelines for energy efficiency. The ENERGYSTAR emblem does not

represent EPA endorsement of any product or service.

IBM is registered trademark of International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

ENERGYSTAR is a U.S. registered trademark.

NEC is a registered trademark of NEC Corporation.

All other trademarks or registered trademarks are property of their respective owners.

01b_Safety_en 11.09.2000, 7:56 Uhr5

English

âesky

Deutsch

Ελληνικά

Español

Français

Italiano

Nederlands

Polski

Русский

Türkçe

01d_ChapterOpener 11.09.2000, 7:57 Uhr1

English-1

English

Contents

MultiSync FE700+ monitor box* should contain the

following:

•MultiSync FE700+ Monitor with tilt/swivel base

•Power cord

•Captive Signal Cable

•User’s manual

•CD ROM (includes complete User's Manual in PDF format)

* Remember to save your original box and packing material to

transport or ship the monitor.

User`s manual

Power Cord

Capative

Signal Cable

CD ROM

01c_english 11.09.2000, 7:57 Uhr1

English-2

Quick Start

To attach the MultiSync FE700+ monitor to your

system, follow these instructions:

1. Turn off the power to your computer and MultiSync monitor.

2. If necessary, install the display card. For more information, refer to

the display card manual.

3. For PC: Connect the 15-pin

mini D-SUB of the captive

signal cable to the connector

for the display card in your

system (Figure A.1). Tighten

all screws.

4. Connect one end of the power

cord to the MultiSync FE700+

monitor and the other end to

the power outlet (Figure B.1).

Captive Signal Cable

15-pin mini D-SUB

Figure A.1

Figure B.1

Power Outlet

Power

Cord

01c_english 11.09.2000, 7:57 Uhr2

English-3

English

5. Turn on the monitor (Figure C.1) and the computer.

6. This completes the installation.

NOTE: If you have any problems, please refer to the

Troubleshooting section of this User’s Manual.

EXIT PROCEED RESET

+–

Figure C.1

Power Button

01c_english 11.09.2000, 7:57 Uhr3
