NEC MultiSync E500 Manuel utilisateur

MultiSync E500/E700

User’s Manual

Declaration of the Importer

We hereby certify that the color monitors

MultiSync E500 JC-1575VMB

MultiSync E700 JC-1746UMB

are in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 60555-2

- EN 60555-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC Europe Ltd. Ismaning Office

Steinheilstraße 4-6

D-85737 Ismaning, Germany

Safety Instruction

Caution:

When operating the JC-1575VMB/JC-1746UMB with a 220-240V AC

power source in Europe except UK, use the power cord provided with

the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the JC-1575VMR/JC-1746UMR with a 220-240V AC

power source in Australia, use the power cord provided with the

monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of

International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

NEC is a registered trademark of NEC Corporation.

ErgoDesign is a registered trademarks of NEC Home Electronics, Ltd. in U.K., Germany,

France, Spain, Italy, Denmark, Norway, Sweden and Benelux.

CROMACLEAR is a trademark of NEC Home Electronics, Ltd. in U.K., Germany, France,

Spain, Italy, Sweden and Benelux.

MultiSync is a registered trademark of NEC Technologies, Inc in U.S. and of NEC Home

Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,

Switzerland, Denmark, Finland, Norway and Saudi Arabia.

All other trademarks or registered trademarks are property of their respective owners.

TCO’95

Congratulations! You have just

purchased a TCO’95 approved

and labelled product! Your choice

has provided you with a product

developed for professional use.

Your purchase has also contri-

buted to reducing the burden on

the environment and also, to the

further development of environ-

mentally adapted electronics

products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established

method for encouraging the adaptation of goods and services to the

environment. The main problem, as far as computers and other

electronics equipment are concerned, is that environmentally harmful

substances are used both in the products and during the manufacturing.

Since it has not been possible for the majority of electronics equipment

to be recycled in a satisfactory way, most of these potentially damaging

substances sooner or later enter Nature.

There are also other characteristics of a computer, such as energy

consumption levels, that are important from the viewpoints of both the

work (internal) and natural (external) environments. Since all methods

of conventional electricity generation have a negative effect on the

environment (acidic and climate-influencing emissions, radioactive

waste, etc.), it is vital to conserve energy. Electronics equipment in

offices consume an enormous amount of energy since they are often left

running continuously.

What does labelling involve?

This product meets the requirements for the TCO’95 scheme which

provides for international and environmental labelling of personal

computers. The labelling scheme was developed as a joint effort by the

TCO (The Swedish Confederation of Professional Employees),

Naturskyddsforeningen (The Swedish Society for Nature Conservation)

and NUTEK (The National Board for Industrial and Technical

Development in Sweden).

The requirements cover a wide range of issues: environment,

ergonomics, usability, emission of electrical and magnetic fields, energy

consumption and electrical and fire safety.

The environmental demands concern restrictions on the presence and

use of heavy metals, brominated and chlorinated flame retardants, CFCs

(freons) and chlorinated solvents, among other things. The product must

be prepared for recycling and the manufacturer is obliged to have an

environmental plan which must be adhered to in each country where the

company implements its operational policy.

The energy requirements include a demand that the computer and/or

display, after a certain period of inactivity, shall reduce its power

consumption to a lower level in one or more stages. The length of time

to reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for

example, in respect of the reduction of electric and magnetic fields,

physical and visual ergonomics and good usability.

On the back page of this folder, you will find a brief summary of the

environmental requirements met by this product. The complete

environmental criteria document may be ordered from:

TCO Development Unit

S-114 94 Stockholm

Sweden

Fax: +46 8 782 92 07

Email (Internet): [email protected]

Current information regarding TCO’95 approved and labelled products

may also be obtained via the Internet, using the address:

http://www.tco-info.com/

TCO’95 is a co-operative project between TCO (The Swedish

Confederation of Professional Employees), Naturskyddsforeningen

(The Swedish Society for Nature Conservation) and NUTEK (The

National Board for Industrial and Technical Development in Sweden).

Environmental Requirements

Brominated flame retardants

Brominated flame retardants are present in printed circuit boards,

cables, wires, casings and housings. In turn, they delay the spread of

fire. Up to thirty percent of the plastic in a computer casing can consist

of flame retardant substances. These are related to another group of

environmental toxins, PCBs, which are suspected to give rise to similar

harm, including reproductive damage in fisheating birds and mammals,

due to the bio-accumulative* processes. Flame retardants have been

found in human blood and researchers fear that disturbances in foetus

development may occur.

TCO’95 demand requires that plastic components weighing more than

25 grams must not contain organically bound chlorine and bromine.

Lead**

Lead can be found in picture tubes, display screens, solders and

capacitors. Lead damages the nervous system and in higher doses,

causes lead poisoning.

TCO’95 requirement permits the inclusion of lead since no replacement

has yet been developed.

Cadmium**

Cadmium is present in rechargeable batteries and in the

colourgenerating layers of certain computer displays. Cadmium

damages the nervous system and is toxic in high doses.

TCO’95 requirement states that batteries may not contain more than 25

ppm (parts per million) of cadmium. The colour-generating layers of

display screens must not contain any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches. Mercury

damages the nervous system and is toxic in high doses.

TCO’95 requirement states that batteries may not contain more than 25

ppm (parts per million) of mercury. It also demands that no mercury is

present in any of the electrical or electronics components concerned

with the display unit.

CFCs (freons)

CFCs (freons) are sometimes used for washing printed circuit boards

and in the manufacturing of expanded foam for packaging. CFCs break

down ozone and thereby damage the ozone layer in the stratosphere,

causing increased reception on Earth of ultraviolet light with consequent

increased risks of skin cancer (malignant melanoma).

The relevant TCO’95 requirement: Neither CFCs nor HCFCs may be

used during the manufacturing of the product or its packaging.

* Bio-accumulative is defined as substances which accumulate within living organisms

** Lead, Cadmium and Mercury are heavy metals which are Bio-accumulative.

English

Introduction

Congratulations on your purchase of the MultiSync E500/E700 colour

Monitor!

The MultiSync E500/E700 monitor includes the CROMACLEAR CRT,

Microsoft’s Plug and Play, NEC’s ErgoDesign properties, the On

Screen Manager (OSM), as well as all the unique features you expect

from MultiSync Monitors.

The MultiSync technology provides you with automatic compatibility

with multiple operating platforms and a vast array of graphics standards

allowing resolution upgrades without upgrading the monitor.

The MultiSync E500/E700 monitor strictly follows ErgoDesign

guidelines featuring enhanced human ergonomics (human and earth

condition). The goal of ErgoDesign is to maximise the comfort and

productivity of the end user. ErgoDesign parallels the strict European

standards of power management and reduced emissions. In addition our

monitor is designed to be recyclable.

CROMACLEAR CRT Technology

The MultiSync E500/E700 monitor features NEC’s exclusive

CROMACLEAR CRT (Cathode Ray Tube), the latest advancement in

display technology. This technology, patented by NEC, delivers images

with more clarity than found in traditional dot-trio CRTs. Unlike the

conventional shadow mask with phosphor dots, CROMACLEAR CRT

has ellipse-shaped phosphors. Screen images have higher definition,

color saturation and more depth and dimension.

The CROMACLEAR CRT has Dynamic Beam Focus which provides

precise and continuous focus adjustment of the electron beams.

Dynamic beam focus provides optimum image quality, even to the far

edges of the screen. You will notice a significant difference in the focus

and clarity of the image for realistic text, graphics and video.

The OptiClear Surface of the E500/E700 CRT dramatically reduces the

reflection of ambient illumination and glare resulting in greatly improved

user comfort and productivity. This multilayered screen coating increases

the contrast without sacrificing the focus level, clarity or brightness.

Introduction E - 1
