Preface

This addendum to the PowerMate®Professional Series Service and Reference Manual

(document number 819-181764-000) provides updated specifications, illustrated parts lists,

and NECCSD service and support telephone numbers.

This information applies to PowerMate Professional Built to Order (BTO) systems and

systems with the following model numbers:



MT-2550-24874X



MT-2560-24874X



MT-2560-24874C



MT-2560-2784S



MT-2560-2785S.

This addendum is written for NECCSD-trained customer engineers, system analysts, service

center personnel, and dealers. The material in this addendum is organized as follows.

Section 1 — Specifications, provides specfications for the computer’s BTO options

(storage devices and I/O boards).

Section 2 — Illustrated Parts Breakdown, provides an exploded view diagram of the

system. Also included are updated parts lists for field-replaceable parts.

Section 3 — NECCSD Service and Information, provides updated NECCSD service and

support telephone numbers and online information access procedures.

Section 4 — Processor Speed Settings, provides jumper setting information for changing

the processor speed setting for a PowerMate Professional Series system.

Section 1

Specifications

This section provides specifications for the following PowerMate Professional built-to-

order (BTO) options:



Diskette drive (see Table 1-1)



Quantum Stratus 3.2-GB IDE hard disk (see Table 1-2)



Quantum ST 4.3-MB IDE hard disk (see Table 1-3)



Quantum ST 6.4-MB IDE hard disk (see Table 1-4)



NEC 16X CD-ROM reader (see Table 1-5)



Lite-on 24X CD-ROM reader (see Table 1-6)



Lucky Goldstar 24X CD-ROM reader (see Table 1-7)



U.S. Robotics 56K fax/modem board (see Table 1-8)



3COM 3C905-TX network interface board (see Table 1-9)



3COM 3C905B network interface card (see Table 1-10)



Intel®LAN Pro 100M2 network interface card (see Table 1-11).

For other specifications, see the PowerMate Professional Series Service and Reference

Manual (819-181764-000).

1-2 Specifications

Table 1-1 Diskette Drive Specifications

Feature Specification

Diskette Drive NEC Diskette Drive FD1231H-013

Performance

Recording Capacity Hi

h densit

mode:

Unformatted:

2.00/1.00 MB

Formatted:

1440 KB (512B 18 Sec)

720 KB (256B 18 Sec)

Normal densit

mode:

Unformatted:

1.00/0.50 MB

Formatted:

640 KB (256B 16 Sec)

320 KB (128B 16 Sec)

Data Transfer Rate Hi

h densit

mode:

500/250 Kbit/sec

Normal densit

mode:

250/125 Kbit/sec

Disk Speed 300 rpm

Number of Tracks 160 (80 tracks x 2 sides)

Maximum Bit Density Hi

h densit

mode:

17434/8717 BPI

Normal densit

mode:

8717/4359 BPI

Seek Time 3 ms

Head Setting Time 15 ms

Tracks per Inch 135 TPI

Recording Mode MFM/FM

General Specifications

Temperature Operating: 4°to 46°

Relative Humidity 20°to 80°

Dimensions (W x H x D) 25.4 mm x 101.6 mm x 146 mm

Weight 430 grams (typical)

Specifications 1-3

Table 1-2 3.2-GB Quantum Stratus Hard Disk Drive Specifications

Feature Specification

Hard Disk Drive 3.2-GB Quantum Fireball ST

Physical Configuration

Formatted Capacit

Nominal rotational speed

Number of Disks

Number of R/W Heads

3228

5,400(rpm)

Data Organization Zones per surface:15

Tracks per surface: 7,066

Total tracks: 28,264

Sectors per Track Inside zone: 154

Outside zone: 277

Total User Sectors: 6,306,048

tes per Sector: 512

Number of tracks per cylinder: 4

Recording Recordin

technolo

: Multiple Zone

Maximum linear densit

: 168,650 fci

Encodin

method: 16/17 PRML

Interleave: 1:1

Track densit

: 7,777 tpi

Maximum effective areal density: 1230 Mbits/in. sq.

Performance Seek times

Read-on-arrival: 10.0 ms t

pical; 12.0 ms max.

Track-to-track: 2.0 ms t

pical

Avera

e write: 11.0 ms t

pical; 13.0 ms max.

Full Stroke: 20.0 ms t

pical; 24.0 ms max.

Data transfer rate

Disk to read buffer: 78 Mb/sec. min; 132 Mb/sec. max;

Read Buffer to IDE Bus (PIO Mode with IORDY):

16.7 MB/sec. max.

Read Buffer to IDE Bus (Ultra ATA Mode):

33 Mb/sec. max.

Buffer Size 128 KB

Power +5V +/-5%; 100 mV peak-to-peak allowable ripple/noise

12V +/-10%; 250 mV peak-to-peak allowable ripple/noise

Temperature (non-condensing) Operatin

: 5°to 55°C (41°to 131°F)

Non-operating: -40°to 65°C (-40°to 149°F)

Humidity (non-condensing) Operatin

: 5% to 85% rh, 30°C (86°F)

Non-operating: 5% to 95% rh, 40°C (104°F)

Altitude Operatin

: -200 m to 3,000 m (-650 to 10,000 ft.)

Non-operating: -200 m to 12,000 m (-650 to 40,000 ft.)

Dimensions Hei

ht:1.0 inches (25.4 mm)

Width: 4.0 inches (101.6 mm)

Depth: 5.75 inches (146.1 mm)

1-4 Specifications

Table 1-3 4.3-GB Quantum Stratus Hard Disk Drive Specifications

Feature Specification

Hard Disk Drive 4.3-GB Quantum Fireball ST

Physical Configuration

Formatted Capacit

Nominal rotational speed

Number of Disks

Number of R/W Heads

4310

5,400 rpm

Data Organization Zones per surface: 15

Tracks per surface: 7,066

Total tracks: 42,396

Sectors per Track Inside zone: 143

Outside zone: 239

Total User Sectors: 8,418,816

tes per Sector: 512

Number of tracks per cylinder: 6

Recording Recordin

technolo

: Multiple Zone

Maximum linear densit

: 152,390 fci

Encodin

method: 16/17 PRML

Interleave: 1:1

Track densit

: 7,777 tpi

Maximum effective areal density: 1115 Mbits/in

Performance Seek times

Read-on-arrival: 10.0 ms t

pical; 12.0 ms max.

Track-to-track: 2.0 ms t

pical

Avera

e write: 11.0 ms t

pical; 13.0 ms max.

Full Stroke: 20.0 ms t

pical; 24.0 ms max.

Data transfer rate

Disk to read buffer: 70 Mb/sec. min; 119 Mb/sec. max

Read Buffer to IDE Bus (PIO Mode with IORDY):

16.7 MB/sec. max.

Read Buffer to IDE Bus (Ultra ATA Mode):

33 Mb/sec. max.

Buffer Size 128 KB

Power +5V +/-5%; 100 mV peak-to-peak allowable ripple/noise

12V +/-10%; 250 mV peak-to-peak allowable ripple/noise

Temperature (non-condensing) Operatin

: 5°to 55°C (41°to 131°F)

Non-operating: -40°to 65°C (-40°to 149°F)

Humidity (non-condensing) Operatin

: 5% to 85% rh, 30°C (86°F)

Non-operating: 5% to 95% rh, 40°C (104°F)

Altitude Operatin

: -200 m to 3,000 m (-650 to 10,000 ft.)

Non-operating: -200 m to 12,000 m (-650 to 40,000 ft.)

Dimensions Hei

ht:1.0 inches (25.4 mm)

Width: 4.0 inches (101.6 mm)

Depth: 5.75 inches (146.1 mm)

Specifications 1-5

Table 1-4 6.4-GB Quantum Stratus Hard Disk Drive Specifications

Feature Specification

Hard Disk Drive 6.4-GB Quantum Fireball ST

Physical Configuration

Formatted Capacit

Nominal rotational speed

Number of Disks

Number of R/W Heads

6448

5,400 rpm

Data Organization Zones per surface: 15

Tracks per surface: 7,066

Total tracks: 56,528

Sectors per Track Inside zone: 154

Outside zone: 277

Total User Sectors: 12,594,960

tes per Sector: 512

Number of tracks per cylinder: 8

Recording Recordin

technolo

: Multiple Zone

Maximum linear densit

: 168,650 fci

Encodin

method: 16/17 PRML

Interleave: 1:1

Track densit

: 7,777 tpi

Maximum effective areal density: 1230 Mbits/in

Performance Seek times

Read-on-arrival: 10.0 ms t

pical; 12.0 ms max.

Track-to-track: 2.0 ms t

pical

Avera

e write: 11.0 ms t

pical; 13.0 ms max.

Full Stroke: 20.0 ms t

pical; 24.0 ms max.

Data transfer rate

Disk to read buffer: 78 Mb/sec. min; 132 Mb/sec. max

Read Buffer to IDE Bus (PIO Mode with IORDY):

16.7 MB/sec. max.

Read Buffer to IDE Bus (Ultra ATA Mode):

33 Mb/sec. max.

Buffer Size 128 KB

Power +5V +/-5%; 100 mV peak-to-peak allowable ripple/noise

12V +/-10%; 250 mV peak-to-peak allowable ripple/noise

Temperature (non-condensing) Operatin

: 5°to 55°C (41°to 131°F)

Non-operating: -40°to 65°C (-40°to 149°F)

Humidity (non-condensing) Operatin

: 5% to 85% rh, 30°C (86°F)

Non-operating: 5% to 95% rh, 40°C (104°F)

Altitude Operatin

: -200 m to 3,000 m (-650 to 10,000 ft.)

Non-operating: -200 m to 12,000 m (-650 to 40,000 ft.)

Dimensions Hei

ht:1.0 inches (25.4 mm)

Width: 4.0 inches (101.6 mm)

Depth: 5.75 inches (146.1 mm)

1-6 Specifications

Table 1-5 NEC 16X CD-ROM Reader Specifications

Feature Specification

16X CD-ROM Reader NEC CDR-1600A/BR

Performance

Data Transfer Rate 2400 KB/sec

Burst Transfer Rate 16.67 MB/sec (PIO Mode 4)

(Sin

le-DMA Mode 2)

16.67 MB/sec (Multi-DMA Mode 2)

Supported Modes 1X, 12X, and 16X Rotational modes

CD-Audio

CD-ROM (Mode 1 and Mode 2)

PIO Mode 4

Multi DMA Mode 2

CD-XA (Mode 2, form 1 and form 2)

CD-I (FMV)

CD+

Video CD

CD Extra

Multisession Photo CD

Single Session Photo CD

General Specifications

Capacity 656 MB (Mode 1)

748 MB (Mode 2)

Physical Format Standards: Red, Yellow, and Orange (part 2) book.

Weight 1.03 Kg

Operating Temperature 5°C to 45°C

Autres manuels pour POWERMATE ENTERPRISE - 09-1997

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NEC Ordinateur de bureau

NEC

NEC PowerMate MB MC32M/B-H Manuel utilisateur

NEC

NEC PowerMate 2000 Series Mode d’emploi

NEC

NEC POWERMATE 5100 - SERVICE Manuel utilisateur

NEC

NEC POWERMATE ES 5250 - S Manuel utilisateur

NEC

NEC PowerMate ES SlimLine Series Mode d’emploi

NEC

NEC OPS i5 PC Manuel utilisateur

NEC

NEC PowerMate ES SlimLine Series Manuel utilisateur

NEC

NEC PowerMate eco Manuel utilisateur

NEC

NEC POWERMATE P - SERVICE 1996 Manuel utilisateur

NEC

NEC POWERMATE V AND P - SERVICE Manuel utilisateur

NEC

NEC POWERMATE ES 5250 - S Manuel utilisateur

NEC

NEC PowerMate VT 300i Series Manuel utilisateur

NEC

NEC POWERMATE V486 - SERVICE Manuel utilisateur

NEC

NEC POWERMATE P - SERVICE MANUAL 1995 Manuel utilisateur

NEC

NEC POWERMATE Manuel utilisateur

NEC

NEC POWERMATE 2000 - S 02-2000 Mode d’emploi

NEC

NEC PowerMate 2000 Series Manuel utilisateur

NEC

NEC POWERMATE CT 815 - RELEASE NOTES Manuel utilisateur

NEC

NEC POWERMATE P60D - SERVICE Manuel utilisateur

NEC

NEC Express5800/53Xi Manuel utilisateur

NEC

NEC PowerMate CT Mode d’emploi

NEC

NEC PowerMate SPB-Wash Manuel utilisateur

NEC

NEC MC33M/B-K Manuel utilisateur

NEC

NEC DIRECTION SP B - SERVICE 1998 Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
