Naxa NID-7019 Manuel utilisateur

7" Core™ Tablet with Android™ OS 7.1

& GMS Certication

NID-7019

Instruction Manual

Please read carefully before use and keep for future reference.

Page 3 Naxa Electronics

Thank You

We know you have many choices when it comes to

technology; thank you for choosing us here at Naxa

Electronics. Established in 2001 in Los Angeles, Califor-

nia, we are dedicated to delivering products that en-

tertain and delight.

We trust that you will be happy with your purchase.

Please read this manual carefully and save it for refer

ence. You may also find the latest FAQ, documentation,

and other product material at our website. Come visit

us on the web at www.naxa.com and see all that we

have to offer!

In the Box

Please take a moment to make sure that you have ev-

erything in the list below. Although we make every ef-

fort to ensure that each Naxa device is securely packed

and sealed, we know a lot can happen in between us and

you. If anything is missing, check back with your local

retailer to get immediate assistance. If they cannot help

you, please contact our Naxa Support team at www.

naxa.com/naxa_support.

•NID-7019 tablet

•USB power adapter

•USB cable

•User’s manual

•Warranty Card

www.naxa.com Page 3

Before You Start

Please take note of the following before you start.

1) Do not drop the unit. Avoid forceful shaking of the

display to prevent damage or unusual operation.

2) Do not touch the unit with metal or sharp

objects to avoid short circuit or damage.

3) Schedule regular backup of your data to prevent

the loss of important data. Always backup your

data before upgrading the firmware.

4) Do not disassemble. Do not wipe the surface of the

unit with alcohol, thinner or benzene.

5) Do not disconnect the tablet while it is formatting

or uploading/downloading. Doing so may corrupt

your data.

6) Do not allow water or foreign objects to enter the

tablet.

7) Do not use the tablet in places that are extremely

hot, cold, dusty, or humid.

8) Please charge your tablet when the Low Battery

icon is displayed, system turns off automatically,

or keys are not responsive.

9) It is normal for the tablet to become slightly warm

during the charging process.

10) The USB port is for transferring data only. The port

is not used to charge any devices.

11) Specifications are subject to change without

prior notice.

Page 4 Naxa Electronics

At a Glance

1 Front camera

2 LCD touchscreen

3Power button

4Headphone jack

9FCC ID: 2ACJAPLT76XXG

www.naxa.com Page 5

Memory card slot (microSD/microSDHC)

Rear Camera

Volume + / -

Micro USB port

9 Reset

Microphone

Page 6 Naxa Electronics

Basic Operation

To ensure the longevity of your battery, please charge

your tablet for 10 hours upon initial charge. Afterwards,

charge the device accordingly as needed. Connect the

DC adapter that is supplied with your device and plug

it into an AC outlet that supports 100-240V ~50/60 Hz Powering On

Charging your device

Saving Battery Life

Please review the following several key points on

extending the battery life of your tablet.

1. When device is not in use, press the power button

once to go into sleep mode

2. Shut down applications when not in use

3. Turn off WLAN when not in use

4. Disable application sync

5. Set a shorter time for display backlight

6. Reduce brightness on the display

Press and Hold the Power Button for 2-3 seconds

to turn on the unit.

Sleep Mode

After the devise is on, press the power button once

and it will go into sleep mode. The screen is now on

standby and under low battery consumption. To wake

up the device, simply press the power button again.

Power Oﬀ

To power off the device, press and hold the power

button for 2-3 seconds until the screen displays

“Power Off”, then select “OK” to power off the unit

completely.

www.naxa.com Page 7

If the device is locking up, use a small pin to press

Reset as it will force shut down and restart the device.

You can also perform a hard reset by press and holding

the Power and ESC buttons at the same time for 3-5

seconds. Then press ESC buton to select “wipe data/

factory reset.” Now press the Power button to confirm

your selection. Then press ESC button again to select

“Yes--delete all user data,” and press the power button

to confirm your selection. Finally the screen will display

“reboot system now” press the power button to confirm.

Your device will reboot and start up normally.

Reset / Force Shutdown Touch Panel

Click – Use finger or capacity panel pen to touch once,

to select or activate function, select menu, or

turn on applications.

Tap and hold – Tap and hold for 2 seconds, a pop up

menu with options will display.

RESET

Page 8 Naxa Electronics

Slide – Slide up, down, left or right for fast scrolling,

browsing page and display screen.

Drag – drag an icon to relocate the position.

Double Click – Double click to enlarge or shrink the

display size of the picture or while browsing a website.

Shut – Use two fingers at same time on touch panel,

to enlarge or to shrink the display scale.

www.naxa.com Page 9

Home Screen

①

③

④

⑤

⑧

⑥

⑦

②

①Google search

②Tap to turn on voice search, it will search

according to voice input ( Make sure WI-FI is on)

③List of current running applications

④Back to Home screen

⑤Back to previous screen

⑥Display of icons and device status, tap to

turn on notification screen

⑦Screenshot

⑧Enter applications page

Page 10 Naxa Electronics

To place an app icon shortcut on another

home screen, drag it to the edge of the

screen and wait for a new home screen to

appear. (If the current home screen is emp

ty, the tablet will not create a new home

screen).

Changing the Wallpaper

1. Press the home screen for about 2 seconds, it will

pop-up the wallpaper selection.

2. Select from the preloaded wallpapers or picture

as wallpaper

3. Click “set wallpaper” to confirm

Adding a Shortcut on Home

Screen

1. On the application page, tag the icon of application

2. Tap and hold an app icon then drag it to a home

screen to create a shortcut that is easily accessible.

Adding Widgets to the

Home Screen

Some apps have Widgets that can be placed on a Home

screen. Widgets are like windows into your apps; they

allow you to use some features of the app quickly from

the Home screen.

To add a widget:

1) Tap & hold on an empty part of a Home screen,

then tap WIDGETS.

2) Swipe left/right to browse the available widgets.

Tap and hold a widget to pick it up, then drag it to

an empty space on a Home screen.

If you have dragged the widget to a Home

screen that doesn’t have room for it, the

widget will not be added.

Some widgets will prompt you to make

additional choices before it is added to the

Home screen.
