NAMCO BONGO MONKEY Manuel utilisateur

Operators Manual

BONGO MONKEY™

1. SPECIFICATIONS

POWER SUPPLY :- 220/240volts AC

TICKET DISPENSER :- Coin Controls type C2000

DIMENSIONS :- 1205(w) x 895(d) x 1900(h)

WEIGHT :- 160kg.

ACCESSORIES :- Keys: (Cash Door).........................................2

(Coin Assy) .........................................2

(Dispenser Door)................................2

(Back Door).........................................2ea

Operators Manual..................................................1

IEC mains Lead .....................................................1

Page 1

Page

2. PRECAUTIONS

2-1 Cautions When Installing.

This game is designed for indoor use only. The game must not be installed outdoors or

under the following conditions:-

a. In areas directly exposed to sunlight, high humidity, direct water contact, dust, high

heat or extreme cold.

b. In locations that would present an obstacle in the case of an emergency, ie. near

fire equipment or emergency exits.

c. On an unstable surface or subject to floor vibration.

2-2 Caution when Handling.

a. AC power must always be turned OFF, and the game disconnected, before

replacing any parts or connecting/disconnecting connectors.

b. When unpluggung the game from an ellectrical outlet, always grasp the plug, not

the mains lead.

c. The machine must be earthed with a securely connected earthed plug.

d. Care must be taken at all times to avoid electric shock when insopecting or

adjusting the game.

2-3 When Transporting.

a. Do not subject the game to physical shock when transporting or moving it.

b. Always return the levellers to the UP position before moving the machine.

c. Take care not to rope any moulded (plastic) parts when transporting.

Page

3. MAJOR COMPONENTS

Coconut assy

Credit

Display

Cash Box

Speakers

Bongo Assy

Monkey

Assy

Score

Displays

Ticket

Dispenser

Coin Assy

Mains In

Monkey

Drive

Assy

PCB Assy

Power

Supply

Page

4. HOW TO PLAY.

• Insert coins to establish credit then press the credit dispense button once to start the

game.

• Use the mallet to hit the bongo drum, in front of the monkey that moves, to stop

the monkey climbing the tree. Hitting the bongo once will stop the monkey

climbing, hitting the bongo repeatedly will cause the monkey to fall part of the way

back down the tree.

• If a monkey reaches the coconut at the top of the tree the game is over.

• If you are able to stop the monkeys reaching the coconuts in the given time a

period of extended play will be given.

5. ADJUSTMENTS

Volume, number of tickets dispensed, game difficulty and test are adjusted on the

Main PCB Assy.

Main

Volume

Option

Switches

BGM

Volume

Board

Reset

Button

Page

5-1Price of Play

The price of play is adjusted with the switches on the Credit Dispense Board.























SWITCH BANK 1 (8 way)

100p BONUS STANDARD PRICE OF PLAY

SW8 SW7 SW6 Bonus Credits SW5 SW4 SW3 SW2 SW1 Price per Credit

0 0 0 0 0 0 0 0 0 5p

0 0 1 1 0 0 0 0 1 10p

0 1 0 2 0 0 0 1 0 15p

0 1 1 3 0 0 0 1 1 20p

1 0 0 4 0 0 1 0 0 25p

1 0 1 5 0 0 1 0 1 30p

1 1 0 6 0 0 1 1 0 35p

1 1 1 7 0 0 1 1 1 40p

0 1 0 0 0 45p

0 1 0 0 1 50p

0 1 0 1 0 55p

0 1 0 1 1 60p

0 1 1 0 0 65p

0 1 1 0 1 70p

0 1 1 1 0 75p

0 1 1 1 1 80p

1 0 0 0 0 85p

1 0 0 0 1 90p

1 0 0 1 0 95p

1 0 0 1 1 100p

1 0 1 0 0 105p

1 0 1 0 1 110p

1 0 1 1 0 115p

1 0 1 1 1 120p

1 1 0 0 0 125p

1 1 0 0 1 130p

1 1 0 1 0 135p

1 1 0 1 1 140p

1 1 1 0 0 145p

1 1 1 0 1 150p

1 1 1 1 0 155p

1 1 1 1 1 160p

0 = OFF 1 = ON 1 Credit 50p 3 Credits 100p





















SWITCH BANK 2 (6way)

CREDIT PULSE SPEED COIN SET 50p BONUS

SW6 SW5 Pulse Length SW4 SW3 Coin Ratio SW2 SW1 Bonus Credits

0 0 70ms 0 0 10/20/50/10 0 0 0

0 1 100ms 0 1 5/10/25/100 0 1 1

1 0 130ms 1 0 1/4/10/20 1 0 2

1 1 160ms 1 1 1/5/10/20 1 1 3

0 = OFF 1 = ON 1 Credit 50p 3 Credits 100p

Page

5-2Option Switches

FUNCTION DESCRIPTION SW1 SW2 SW3 SW4 SW5 SW6 SW7 SW8

GAME

DIFFICULTY EASY 0

HARD 1

ATTRACT

MODE OFF O

ON 1

TEST

MODE TEST OFF 0

TEST ON 1

TICKET ON

CREDIT 1 TICKET 1

NO TICKET 0

TICKET

PAYOUT

SCORE

LEVELS

2 TICKETS AT 25 POINTS 0 0 0 0

2 TICKETS AT 30 POINTS 1 0 0 0

3 TICKETS AT 35 POINTS 0 1 0 0

3 TICKETS AT 40 POINTS 1 1 0 0

4 TICKETS AT 50 POINTS 0 0 1 0

4 TICKETS AT 55 POINTS 1 0 1 0

6 TICKETS AT 65 POINTS 0 1 1 0

6 TICKETS AT 70 POINTS 1 1 1 0

7 TICKETS AT 80 POINTS 0 0 0 1

7 TICKETS AT 85 POINTS 1 0 0 1

8 TICKETS AT 85 POINTS 0 1 0 1

8 TICKETS AT 90 POINTS 1 1 0 1

9 TICKETS AT 90 POINTS 0 0 1 1

10 TICKETS AT 90 POINTS 1 0 1 1

NO SETTING 0 1 1 1

NO SETTING 1 1 1 1

5-3 Volume Adjust

The volume is adjusted on the Main PCB Board. Adjust the BGM volume control to set

the balance between background music and voice, then adjust Main volume for desired

overall volume.

5-4 Test Mode

Each time the machine is switched on it will automatically carry out a routine to

check the operation of the up/down motors and the opto sensors for each monkey.

If a motor error is detected the score display will show 'Er' and the high score

display will show the number of the faulty assembly e.g '1'. If an opto error is

detected the score display will show 'Er', and the high score display will show the

number of the faulty assembly e.g. 'o1'. The assemblies are counted from left to

right when viewed from the front of the machine.

The test mode is entered with DIP switch 3 on the PCB, see above.

a. Turn the machine off, and switch DIP switch 3 On, then turn the machine back on.

b. The score display shows test number. Hitting bong 5 will advance to the next test.

c. When testing has been completed turn the machine off and reset DIP switch 3 OFF

Page7

Test 1

All score/high score display segments are flashing.

Test 2

All controlled lamps will be illuminated.

Test 3

The monkey lift motors will travel to the top and then to the bottom in

sequence.

Test 4

All the monkey swing motors will operate.

Test 5

Each time bongo five is operated the next sound will be activated. Operate

bongo four to advance to the next test.

Test 6

The ticket dispenser will dispense five tickets.

Test 7

A sound will be produced each time a bongo is pressed or released to test the

bongo switches.

Turn the machine off, reset DIP switch 3 to OFF, to return to normal game mode

5-5 Bongo Switch Adjust

1. Remove 4 x M4 Screws, retaining the bongo drum body to the front panel, and lift

off the drum body.

2. Lift off the drum head.

3. Alter the height of the microswitch by adjusting the microswitch retaining nuts.

5-6 Ticket Refill

Open the ticket dispenser door to gain access to ticket holder.

Page

6. PARTS

CABINET

DESCRIPTION PART No

Fluorescent Lamp Diffuser 45000003

Fluorescent Tube 33" 64500024

Top Flash Perspex 30000013

Front Perspex 39000016

Coconut Lamp Cover 45000004

Coconut Lamp 12v 3w Wedge 64000034

Play Panel Perspex 33000008

Speaker Grille 45000009

Loudspeaker 4 1/2" 20 watt 62000006

Credit Dispense Board 81000111

Credit Dispense Display Board 81000112

Side Decal L & R 40000014

Ticket Dispenser C2000 67000007

Credit Dispence Button -MPB green 60200233

Panel Mount Meter 65000002

Service Button 60000059

Back Drop Display Decal 40000017

Schaffner Mains Filter Assy 66000016

5A 20mm Quick-Blo Fuse 63500601

Soft Mallet 88700016

Page

DRUM ASSY

DESCRIPTION PART No

Bongo Top Vac-Form 45000020

Black Sponge - 80 x 80 x 20 45000021

Black Sponge - Round 45000022

Black Sponge - 50 x 30 x 25 45000024

Rubber Washer M8 45000025

Coil Spring 45000028

Micro Switch 45000030

MONKEY DRIVE & SWING MOTOR ASSY

DESCRIPTION PART No

Coconut Micro Switch - Lever Type 60000078

Circlip - 6mm 45000037

Black Sponge - 50 x 30 x 25 45000038

Circlip - 8mm 'E' type 45000042

Circlip - 5mm 45000045

Grub Screw - M4 x 5 26300285

Swing Motor and Gearbox 45000049

Monkey Fixing Spring Clip 45000054

Spiral Shaft Bearing 45000075

Black Sponge - 40 x 40 x 40 45000056

Motor Limit Microswitch - Lever Type 60000079

Opto Sensor 88300893

Grub Screw - M5 x 5 26300559

Timing Belt 45000071

Timing Pulley 45000070

Drive Motor and Gearbox 45000072

Spiral Shaft 45000066
