NAD 2100 Manuel utilisateur

3100

Integrated Amplifier

Date of manufacture : ?

Please note that this document contains the text from the original product brochure, and some technical statements may now be out of date

For most manufacturers, the highest quality parts and most highly refined designs are used only in

separate audio components-in preamplifiers, power amplifiers, and tuners. Integrated amplifiers are

usually made to a less exalted standard, while all-in-one stereo receivers are regarded as compromise

products suitable only for casual listeners. But not at NAD. NAD electronics are designed in modular

form, and many of the same circuits are used in all product categories. The 3100 Integrated Amplifier,

for example, combines NAD’s robust 2100 Power Amplifier with high-quality preamplifier circuitry

derived from some of NAD’s finest preamplifiers. The pre- and power amplifier sections of the 3100 are

joined by removable external jumpers that allow you to insert external processors such as a surround-

sound unit or an electronic crossover for bi-amping in the signal path.

The power amplifier section of the 3100 employs all of the NAD innovations described on pages 4 and

5. Like the 2100 Power Amplifier, it is conservatively rated at 50 watts/ channel for sine-wave test tones,

while its Power Envelope circuit produces 200 to 330 watts channel of long-term tone-burst power for

the dynamic waveforms of music. Its high-current output stage, impedance selector, and heavy-duty

speaker terminals are designed to deliver maximum power to loudspeakers of any impedance. The

preamplifier section of the 3100 contains the same low-noise MM/MC phono stage as the 1700

Preamplifier/ Tuner and the same switchable Infrasonic Filter, flexible two-way tape connections, Bass

EQ, and ultra-quiet feedback-operated volume control as NAD’s state-of-the-art 1300 Preamplifier.

The tone controls are Baxandall bass and treble circuits, but with their parameters carefully selected to

allow substantial adjustments at low and high frequencies without altering the neutrality of the

midrange.

PRE-AMP SECTION

Phono input

Input impedance (R and C) MM 47kΩ/ 100pF

MC 100Ω/ 1000pF

Input sensitivity, 1kHz MM 2.5mV ref. 0.5V

MC 0.18mV

Signal/Noise ratio (A-weighted with cartridge connected) MM 75dB ref. 5mV

MC 75dB ref. 0.5mV

THD (20Hz - 20kHz) <0.04%

RIAA response accuracy (20Hz - 20kHz) ±0.5dB

Line level inputs

Input impedance (R and C) 50kΩ/ 500pF

Input sensitivity (ref. 1W) 20mV

Maximum input signal 10V

Signal/Noise ratio (A-weighted ref 1W) 94dB

Frequency response 20Hz - 20kHz / ±0.5dB

Line level outputs

Output impedance Pre-amp 600Ω

Tape Source Z + 1kΩ

Maximum output level Pre-amp 10V

Tone controls

Treble ±9dB at 10kHz

Bass ±10dB at 50Hz

Bass EQ +3dB at 55Hz

+6dB at 36Hz

Infrasonic filter (switchable) -3dB at 12Hz - 12dB/octave

POWER AMP SECTION

Continuous output power into 8Ω* 60W (17dBW)

Rated distortion (THD 20Hz - 20kHz) 0.03%

Clipping power (maximum continuous power per channel) 70W

IHF Dynamic headroom at 8Ω+6dB

IHF dynamic power (maximum short term power per channel) 8Ω200W (23dBW)

4Ω250W (24dBW)

2Ω330W (25dBW)

Damping factor (ref. 8Ω, 50Hz) >100

Input impedance 10kΩ/ 600pF

Input sensitivity (for rated power into 8Ω)850mV

Frequency response 3Hz - 100kHz / +0, -3dB

Signal/noise ratio ref. 1W 100dB

ref. rated power 117dB

THD (20Hz - 20kHz) <0.03%

Remote No

NAD Link No

PHYSICAL SPECIFICATIONS

Dimensions (W x H x D) 435 x 106 x 385mm

Net weight 10.5kg

Shipping weight 11.6kg

Power consumption (120 ~ 240V, 50/60Hz) 330VA

* Minimum power per chnnel, 20Hz - 20kHz, both channels driven with no more than rated distiortion.

Dimensions are of unit’s cabinet without attached feet; add up to 18mm for total height.

Dimension depth excludes terminals, sockets, controls and buttons.
