N-Com Basic kit multi Manuel utilisateur

EN SAFETY AND INSTRUCTIONS FOR USE

Congratulations on your purchase of a Nolan N-Com product.

The N-Com Basic Kit MULTI was designed and built using the latest technologies

and the best materials. Long tests and thorough system development have made

it possible to achieve the highest sound quality.

The Basic Kit MULTI system can be used in combination with an N-Com

system (Bluetooth Kit3, Bluetooth Kit2, Bluetooth Kit X-Series or Intercom

Kit) as a passenger connected via cable, or by itself for cable connection to

a multimedia device (MP3, radio for motorcycle-to-motorcycle

communication, etc.) or to a cell phone (please visit www.n-com.it for

compatibility tables).

Table of contents

1.WARNINGS AND SAFETY............... 4

1.1. Reference standards ............................4

1.2. Road safety ........................................5

1.3. Switching on the system in safe

environments ........................................ 5

1.4. Interferences ........................................6

1.5. Appropriate use.....................................6

1.6. Qualified personnel...............................7

1.7. Disposal ........................................7

2.CONTENTS OF THE PACKAGING ..8

3.INSTALLING THE BASIC MULTI ..... 9

3.1. Example of installation in Jet and Mini-

Jet helmets ........................................9

3.2. Example of installation in Flip-up/Full-

face helmets ......................................12

4.USE WITH CELL PHONE/AUDIO

SOURCES ..................................... 17

5.INTERPHONE VIA CABLE ............ 18

5.1. Possible configurations .......................19

6.LIMITED WARRANTY.................... 20

6.1. Warranty coverage..............................20

6.2. Exclusions and limitations of the

coverage .......................................20

6.3. Validity of this limited warranty ...........21

6.4. Procedure for the forwarding of claims22

7.WARRANTY REGISTRATION

FORM............................................ 23

1. WARNINGS AND SAFETY

Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you will be using with the N-

Com Basic Kit MULTI. Read the simple rules listed below. Failure to comply with these rules may lead to dangerous

situations.

Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks

and the like.

Caution: Installation of the N-Com Basic Kit MULTI system results in a weight increase of approximately 70g,

which is added to the weight of the helmet and of the other accessories.

Warning: The electronic components of the N-Com system mounted inside the helmet are not waterproof.

Consequently, make sure the inside of the helmet, including the comfort padding, does not get wet in

order to avoid damage to the system. If it does, remove the N-Com system and the helmet comfort

padding and let it air dry.

1.1. Reference standards

The Basic Kit MULTI of the N-Com line complies with EEC directive

EMC 2004/108

1.2. Road safety

Always obey all Traffic Regulations in force. While riding the motorcycle, your hands should always be

engaged in actually riding the vehicle. Any operation to the N-Com system must be carried out with the

vehicle stopped. Specifically:

Set your cell phone on automatic answer (see the cell phone instructions to do this).

If your cell phone is not equipped with this function, first stop your vehicle in a safe area, in compliance with

Traffic Regulations and then answer the call.

Do not make any calls while riding. Stop your vehicle in a safe place in compliance with Traffic Regulations,

and then make the call.

Adjust the volume so that it does not cause a disturbance or distraction while riding and at the same time

allows you to distinctively hear background noises.

Do not operate your cell phone or other devices connected to N-Com while riding your motorcycle.

In all cases, obey the Traffic Regulations and remember that riding the motorcycle has absolute priority over

any other maneuver.

1.3. Switching on the system in safe environments

When using the N-Com system, comply with all limitations and instructions related to the use of

cell phones.

Do not turn on your cell phone or the N-Com system whenever their use is forbidden or when the devices can

cause interference or dangerous situations.

Turn off while refueling. Do not use the N-Com system in filling stations. Do not use the device near

combustible materials or chemical products.

Turn off in proximity to explosive materials.

1.4. Interferences

All phones and devices with wireless signal transmission are subject to interferences that may affect the

performance of the device connected to them. These interferences are not ascribable to a defect of the

N-Com system.

1.5. Appropriate use

Use the device only in the normal position, as described in the product documentation. Do not attempt

to disassemble, tamper with or modify any part of the N-Com system.

Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected to it before

you use the system on the road.

Caution: Adjusting the volume to very high levels may cause damage to your hearing

Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected to it so as

to avoid audio reproduction at high volumes. Constant exposure to high audio volumes may damage your

hearing.

Caution: An incorrect installation of the system in the helmet may alter the aerodynamic and safety characteristics

of the helmet itself, thus creating dangerous conditions. Install the N-Com system according to the

instructions provided in the product documentation. In case of doubt, please contact your local N-Com

dealer.

1.6. Qualified personnel

Only qualified personnel can carry out technical assistance on this product. In case of any malfunction,

always turn to your local dealer.

The helmet is a safety device. Tampering with it and/or with the electronic system inside the helmet, in

addition to invalidating the product warranty, can also lead to dangerous situations.

1.7. Disposal

Refer to this user manual and to manuals related to other parts of the N-Com system in order to disassemble the

system from the helmet. Once the system has been disassembled, dispose of it according to the following

instructions:

The presence of a crossed-out wheelie bin indicates that in the European Union the product is subject

to separate collection at the end of its useful life (European Directive 2002/96/EC).

Do not dispose of these products together with undifferentiated urban waste.

The proper disposal of obsolete equipment contributes to preventing possible negative consequences on

people’s health and on the environment.

For more detailed information on the disposal of obsolete equipment, contact your municipality, a waste

disposal service or the store where the product was purchased.

2. CONTENTS OF THE PACKAGING

Intercom Wire

Wiring system

Removable microphone

Velcro used

to secure the

speakers

Velcro used to

secure the

microphone

Adhesive tape

3. INSTALLING THE BASIC MULTI

3.1. Example of installation in Jet and Mini-Jet helmets

Fig. 1

Fig. 2

Simulate positioning the microphone to determine the position where the support Velcro should be glued (Fig.

1). After installing the microphone, the anti-wind sponge should be in front of the mouth.

Thoroughly clean the surface where the microphone Velcro will be applied.

Apply the microphone Velcro to the helmet shell and allow it to fully adhere for at least 12 hours.

WARNING: On certain types of jet helmets the microphone can also be applied inside the helmet. In this case,

install the microphone as illustrated for a flip-up/full-face helmet (chapter 3.2.).

Fig. 3

Fig. 4

Fig. 5

Remove the inner lining, if present.

Cut the Velcro used to secure the speakers so as

to obtain two pieces that adapt to the shape of

the helmet ears area (Fig. 3).

Remove the film from the Velcro and position the

latter on the helmet ear area. Repeat the

procedure on both sides.

N.B.: If possible, position the Velcro underneath

the comfort padding (Fig. 4).

Position the speaker so that it adheres perfectly

to the Velcro (Fig. 5). Repeat the procedure on

the opposite side.
