iVECTOR Specifiers Guide.

heatingthroughinnovation.

iVECTOR Heater/Cooler

Models: iV080, iV100, iV120, iV140, iV160

01.03.2012

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 2

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 3

1.0 Introduction 04

2.0 iVECTOR Benefits 05

2.1 Compact in Size 05

2.2 Renewable Technology 05

2.3 Rapid Response 05

2.4 Low Surface Temperature (LST) 05

3.0 iVECTOR Specification Data 06

3.1 Unit Sizes 06

3.2 Outputs 06

3.3 Flow Rates/Pressure Losses 07

3.4 Noise Levels 07

3.5 Hydronic Connections 07

3.6 Weight, Water Content and Motor Power 07

4.0 iVECTOR Installation 08

4.1 Ease of Installation 08

4.2 Mounting Dimensions 08

4.3 Water Connection - Pipe Routing Options 09

4.4 Electrical Connection 09

5.0 Applications 11

5.1 All Round Suitability 11

5.2 Traditional Heating System 11

5.3 Renewable Heating System 11

5.4 Mix ‘n‘ Match Heating Solutions 11

6.0 Intelligent and Easy to Use Controls 12

6.1 Introduction 12

6.2 Easy Mode 13

6.3 Full Mode 14

6.4 Building Management System (BMS) 15

Contents

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 4

04 Introduction

1.0 Introduction

The iVECTOR is MYSON’s latest product innovation and an

exciting, energy efficient addition to our range of modern

heating solutions.

The iVECTOR is the first in a new generation of intelligent fan

convectors. It has been designed specifically to combine all the

traditional advantages of a fan convector with a range of new

product benefits made possible by the inclusion of our latest

heating technology, such as a large surface area heat exchanger,

low water content, energy efficient fans and intelligent controls.

Grill Heat exchanger

Outer casing

Grill hinge

Control panel

Motor

Filter

Fan

Internal chassis

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 5

iVECTOR Benefits

2.1 Compact in Size

The large surface area of the iVECTOR’s heat exchanger means

that units are compact in size (all units are a standard height of

only 600mm, the same as the most popular size of panel

radiator) and occupy significantly less wall space than a panel

radiator of equivalent output. By utilising fan convection, the

iVECTOR increases its heat output even further and provides an

even distribution of warm air throughout a room. This means that

rooms feel more comfortable, even at lower temperatures.

2.2 Renewable Technology

Due to its heat exchanger and fan, the iVECTOR will produce

significantly higher heat output than a panel radiator of the same

size. This means that iVECTORs are ideal for use with low water

temperature systems. For example, when operating with a low

flow temperature of 45°C the iVECTOR will produce around

twice as much heat output as a similar double panel radiator.

2.3 Rapid Response

The iVECTOR has a low water content, between 5 and 10% of

the amount used in a traditional radiator with equivalent output.

This lower water content means that an iVECTOR produces an

instant heat response where needed and cools quicker when

heat is no longer required. Heat is accurately controlled as a

result, leading to improved indoor comfort.

2.4 Low Surface Temperature (LST)

When operating with low flow temperatures of 35 - 55°C no

outer part of an iVECTOR will exceed a temperature of 43°C. As

a result, when used with heat pumps, iVECTORs provide a high

output and energy efficient alternative to standard LST radiators

for sensitive environments such as nurseries and care homes.

(Please note that this does not apply when iVECTORs are used

with high water temperature systems, please contact MYSON

Technical Services for full information).

2.0 1.0

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 6

06 iVECTOR Specification Data

3.1 Unit Sizes

All iVECTORs are the same height and depth and there is a

choice of 5 different lengths as detailed in the table (right). The

performance data for each model is supplied in the following

sections of this guide.

Model

Nominal Height

(mm)

Depth

(mm)

Length

(mm)

iV60x080 600 153 800

iV60x100 600 153 1000

iV60x120 600 153 1200

iV60x140 600 153 1400

iV60x160 600 153 1600

3.2 Outputs

The heat output of the iVECTOR is affected by the flow rate of

water through its heat exchanger, even when the mean water

temperature is constant. Each iVECTOR model requires the

specified flow rate to ensure the temperature drop will be

reasonable, as shown in the outputs table. For quietest

operation MYSON recommends sizing the iVECTOR based on

normal fan speed.

Model Flow

(l/h) ΔT20 ΔT25 ΔT30 ΔT35 ΔT40 ΔT45 ΔT50

Mean water - air temp difference (watts)

iV60x080

iV60x100

iV60x120

iV60x140

iV60x160

Fan Speed

Normal 341 738 940 1146 1355 1567 1781 1997

Medium 341 989 1260 1537 1817 2101 2388 2678

Boost 341 1360 1733 2113 2499 2889 3284 3682

Normal 450 1012 1289 1572 1859 2149 2443 2739

Medium 450 1352 1723 2101 2484 2872 3265 3661

Boost 450 1892 2412 2941 3477 4020 4569 5124

Normal 600 1214 1548 1887 2231 2580 2932 3288

Medium 600 1643 2094 2553 3018 3490 3967 4448

Boost 600 2409 3070 3743 4425 5117 5815 6521

Normal 700 1428 1820 2219 2624 3034 3449 3867

Medium 700 1945 2478 3022 3573 4131 4695 5265

Boost 700 2916 3716 4531 5357 6194 7040 7894

Normal 800 1647 2099 2560 3027 3499 3977 4460

Medium 800 2246 2863 3491 4127 4772 5424 6082

Boost 800 3422 4362 5318 6288 7270 8263 9266

Model

Cooling (watts)

Condition 7-12-27

Total Sensible

Normal 707 527

Medium 1126 829

Boost 1648 1227

Normal 1011 753

Medium 1600 1178

Boost 2304 1716

Normal 1250 931

Medium 1960 1442

Boost 2918 2173

Normal 1490 1110

Medium 2320 1707

Boost 3533 2631

Normal 1729 1288

Medium 2679 1972

Boost 4147 3088

iV60x080

iV60x100

iV60x120

iV60x140

iV60x160

Fan Speed

Relative Humidity: Sensible cooling at 50%.

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 7

iVECTOR Specification Data

3.4 Noise Levels

The iVECTOR has three different fan speeds. The lower the fan

speed, the lower the noise level. At the lowest fan speed, the

unit operates almost silently. It is our quietest fan convector ever.

The following table provides a comprehensive overview of noise

levels as tested in accordance with ISO 3741. For quietest

operation MYSON recommends sizing the iVECTOR based on

normal fan speed.

Model Sound Power LwA (dB)

iV60x080 31.9 44.8 55 24.8 37.7 47.9

iV60x100 34.1 42.9 55 27 35.8 47.9

iV60x120 31.1 44.7 58.8 24 40.5 51.7

iV60x140 32 42.6 61.9 24.9 35.5 54.8

iV60x160 34.1 42.1 63.4 27 35 56.3

Normal Medium Boost

Sound Pressure (dBA) - at 2.5m

Normal Medium Boost

3.0

3.5 Hydronic Connections

The iVECTOR is suitable for use on closed circulation, two pipe*,

pump assisted central heating systems or heating and cooling

systems. Not suitable for one pipe or microbore systems.

Note: A pressure independent balancing and control valve is

available for this product as an accessory. This valve can simplify

system design by eliminating the possible need for larger

balancing valves elsewhere in the system, and will maintain the

flow in the unit to the required levels.

*Pipes should be sized using flow rate and pressure losses.

No microbore pipework

3.6 Weight, Water Content and Motor Power

Model Motor

Power (w)

Water

Content (l)

Unpacked

Weight (kg)

iV60x080 32 0.66 22.8

iV60x100 35 0.92 27.7

iV60x120 45 1.19 32.5

iV60x140 53 1.45 37.5

iV60x160 65 1.72 42.6

3.3 Flow Rates/Pressure Losses

100 69 104 145 163 191

150 145 213 291 325 380

220 293 421 565 625 728

330 619 866 1140 1250 1447

500 1328 1812 2338 2542 2926

750 2800 3728 4713 5082 5817

Pressure Drop (mm wg)Flow

(l/h) iV60x080 iV60x100 iV60x120 iV60x140 iV60x160

100 675 1015 1418 1594 1877

150 1423 2088 2859 3187 3731

220 2878 4127 5543 6131 7140

330 6067 8489 11176 12257 14194

500 13026 17775 22926 24929 28700

750 27459 36559 46221 49837 57051

Pressure Drop (Pa)Flow

(l/h) iV60x080 iV60x100 iV60x120 iV60x140 iV60x160

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 8

08 iVECTOR Installation

4.1 Ease of Installation

The iVECTOR has been designed specifically to make installation

as easy as possible. Unlike panel radiators it does not have any

brackets to fit and unlike some fan convectors it is not supplied

in kit form – there is only a one-piece casing to attach!

The iVECTOR can be securely fitted on most flat walls with a

minimum side clearance of 100mm and a minimum floor

clearance of 150mm. Units should not be installed in locations

with high humidity levels, such as bathrooms.

4.2 Mounting Dimensions

Model A B

Dimensions (mm)

iV080 800 503

iV100 1000 703

iV120 1200 903

iV140 1400 1103

iV160 1600 1303

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 9

iVECTOR Installation

4.4 Electrical Connection

The electrical installation of an iVECTOR should be carried out

by a qualified electrician in accordance with current regulations.

A fused electrical spur with a maximum 3A fuse and a switch

having 3mm separation on all poles must be provided in an easily

accessible position adjacent to the unit. The electrical cable

should be fed through the underside of the unit, into the control

box on the right hand side using the cable gland provided. The

supply cord must be 0.75mm² only. The live and neutral wires

are connected to the power board terminal connections and the

earth wire to the chassis earth terminal.

There is a built-in connection for use with Building Management

Systems in all iVECTORs, however, this will require additional

wiring to the unit.

Routing cable

4.3 Water Connection - Pipe Routing Options

The iVECTOR has two pipes to connect – flow and return. This

pipework can be routed in one of two ways, either from the floor

or through the wall at the back of the unit (see diagram below).

Please note that the flow pipe must be connected to the

bottom connection of the heat exchanger and the return pipe

to the top connection.

2-pipe connection

83-108* MAX

*Dimension from chassis side to pipe centre.

**For cooling, a condensate drain must be fitted to the condensate tray.

Condensate tray**

4.0

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 10

10 iVECTOR Installation

POWER

BOARD

CONTROL

BOARD

Supply 230V

50Hz

TRANSFORMER

FAN

T+

T-

M-

M+

Med

AIR

SENSOR

WATER SENSOR

2-PIPE

2-pipe 0 valve

Supply 230V 50Hz

24V 50Hz

24V DC

Supply 230V

50Hz

POWER

BOARD

CONTROL

BOARD

WATER SENSOR

2-PIPE

AIR

SENSOR

T+

T-

M-

M+

Med

FAN

TRANSFORMER

2-pipe 1 valve

4.4 Electrical Connection (continued...)

24434 iVector Specifier Guide_Layout 1 22/03/2012 15:00 Page 11

Autres manuels pour iV080

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Myson Chauffage

Myson

Myson WHISPA III 5000 Manuel utilisateur

Myson

Myson Kickspace 500 Manuel utilisateur

Myson

Myson Kickspace 500E Manuel d'utilisation et d'entretien

Myson

Myson iVector S2 Manuel utilisateur

Myson

Myson FINESSE Manuel utilisateur

Myson

Myson ELECTRIC DECOR H EXX20060 Series Guide de maintenance et de service

Myson

Myson WHISPA III 5000 WM Manuel utilisateur

Myson

Myson Kickspace 600E Manuel utilisateur

Myson

Myson Kickspace 500 Manuel d'utilisation et d'entretien

Myson

Myson 6-4 Manuel utilisateur

Myson

Myson TS4 Manuel utilisateur

Myson

Myson Finesse EC Guide rapide

Myson

Myson LO-LINE RC 9-6 Manuel utilisateur

Myson

Myson LO-LINE RC 6-4 Manuel utilisateur

Myson

Myson WHISPA III 12000 RCU Manuel utilisateur

Myson

Myson 2-Pipe Manuel utilisateur

Myson

Myson SELECT Guide de démarrage rapide

Myson

Myson H11 2 Manuel utilisateur

Myson

Myson WHISPA WE50K Manuel utilisateur

Myson

Myson Rio Manuel utilisateur

Myson

Myson WHISPA III 9000 WM Manuel utilisateur

Myson

Myson Kickspace 500 Instructions d'installation

Myson

Myson RIO Series Manuel utilisateur

Myson

Myson FINESSE SC. Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur

Myson iV080 Manuel utilisateur

Manuels Chauffage populaires d'autres marques
