Murray YARD KING ELT155420GF Manuel utilisateur

7103092

Revision A

Riding Mower

Model No. Description

7800480 ELT155420GF Murray CE Riding Mower, 15.5HP, 42"

7800485 EYK155420GF Yard King CE Riding Mower, 15.5HP, 42"

Operator’s Manual

en Operator’s Manual – Riding mower

fr Manuel d’utilisation – Tondeuse autoportée

Not for

Reproduction

Thank you for purchasing this quality-built MURRAY mower. We are pleased that you’ve placed your confidence in the

MURRAY brand. When operated and maintained according to the instructions in this manual, your MURRAY mower will

provide many years of dependable service.

This manual contains safety information to make you aware of the hazards and risks associated with mowers and how to

avoid them. Because Briggs & Stratton Power Products Group, LLC does not necessarily know all the applications this mower

could be used for, it is important that you read and understand these instructions. Keep this manual near the mower for

convenient reference.

This mower requires final assembly before use. Refer to the Assembly section of this manual for instructions on final

assembly procedures. Follow the instructions completely.

Where to Find Us

You never have to look far to find Briggs & Stratton support and service for your mower. There are over 30,000 Briggs &

Stratton authorized service dealers worldwide who provide quality service. You can also contact Briggs & Stratton Customer

Service by phone at (800) 528-5087, or on the Internet at www.murray.com.

Mower

Model Number _____________________________________

Serial Number _____________________________________

Engine

Model Number _____________________________________

Serial Number _____________________________________

Date Purchased

Murray is a trademark of Briggs & Stratton Power Products Group, LLC.

Briggs & Stratton Power Products Group, LLC

900 N. Parkway

Jefferson, WI 53549

No part of this material may be reproduced or transmitted in any

form by any means without the express written permission of Briggs

& Stratton Power Products Group, LLC.

Not for

Reproduction

ABCDEF

GHI J K

ABCDEFGHI

JKLMNO

max 10°

max ±150N max ±90N

stop

(#1) (#2) (#3)

(#5)

(#6)

(#7)

(#8)

(#9)

(#10)

(#4)

Not for

Reproduction

2 murray.com

(#4)

(#9)

(#8)

(#7)

(#5)

(#3)

(#6)

(#1)

(#2)

Not for

Reproduction

English Français

Table of Contents

Operator Safety.................................. 4

International Pictorials ......................................... 4

Responsibility of the Owner ..................................... 4

Safe Operation Practices........................................ 5

Assembly...................................... 7

Install the Front Wheels ........................................ 7

Install the Seat ............................................... 7

Assemble the Steering Wheel .................................... 7

Maintenance Free Battery ....................................... 7

Important! Before You Start Mowing .............................. 8

Features and Controls ............................. 9

Location of Controls ........................................... 9

Attachments ................................................. 9

Operation...................................... 10

Safety Interlock System Tests.................................... 10

Using The Controls ............................................ 10

Mowing..................................................... 11

Before Starting the Engine ...................................... 12

Mowing and Bagging Tips ...................................... 13

Maintenance ................................... 14

Maintenance Chart ............................................ 14

Check Tire Pressure ........................................... 14

Maintenance Free Battery ....................................... 14

Storage ..................................................... 15

Order Replacement Parts ....................................... 15

Troubleshooting ................................. 16

Warranty ...................................... 18

WARNING

Battery posts, terminals and related accessories contain

lead and lead compounds, chemicals known to the State

of California to cause cancer and birth defects or other

reproductive harm. Wash hands after handling.

!!WARNING

Engine exhaust, some of its constituents, and certain

vehicle components contain or emit chemicals known to

the State of California to cause cancer or other reproductive

harm.

Not for

Reproduction

4 murray.com

Operator Safety

International Pictorials

IMPORTANT: The following pictorials are located on your

unit or on literature supplied with the product. Before you

operate the unit, learn and understand the purpose for each

pictorial.

NOTE: Illustrations and pictorials begin on page 1.

Safety Warning Pictorials (Figure 1)

A - WARNING.

B - IMPORTANT: Read Owner’s Manual Before Operating

This Machine.

C - WARNING: Thrown Objects. Keep Bystanders Away.

Read User Instructions Before Operating This Machine.

D - WARNING: Do Not Use This Machine On Slopes Greater

Than 10 Degrees.

E - DANGER: Keep People, Especially Children, Away From

Unit.

F - DANGER: No Step.

G - DANGER: Keep Feet And Hands Away From Rotating

Blade.

H - DANGER: Disconnect Spark Plug Wire Before Servicing

Unit.

I - WARNING: Hot Surface.

J - WARNING: Use Caution When Connecting Or

Disconnecting Accessories.

K - WARNING: Crushed Fingers.

L - IMPORTANT: Follow Instructions In Owner’s Manual To

Level The Deck.

M - WARNING: Stay Clear Of Mower Blade As Long As

Engine Is Running.

Control and Operating Pictorials (Figure 2)

A - Engine Start

B - Lights

C - Engine Stop

D - Engine Run

E - Engine Run

F - Brake

G - Parking Brake

H - Clutch

I - Slow

J - Fast

K - Choke

L - Oil

M - Blade Rotation Control

N - Raise

O - Fuel

Responsibility of the Owner

Know your product: If you understand the unit and how the

unit operates, you will get the best performance. As you read

this manual, compare the illustrations to the unit. Learn the

location and the function of the controls. To help prevent

an accident, follow the operating instructions and the safety

rules. Save these original instructions for future reference.

WARNING: Look for this symbol to indicate

important safety precautions. This symbol

indicates: “Attention! Become Alert! Your Safety Is

At Risk.”

WARNING: This cutting machine is capable of

amputating hands and feet and throwing objects.

Failure to observe the following safety instructions

could result in serious injury or death to the

operator or bystanders.

The responsibility of the owner is to follow the instructions

below.

Not for

Reproduction

Safe Operation Practices

For Ride-On (Riding) Rotary Mower Machines

Training

Read the instructions carefully. Be familiar with the1.

controls and the proper use of the equipment.

Never allow children or people unfamiliar with these2.

instructions to use the mower. Local regulations may

restrict the age of the operator.

Never mow while people, especially children, or pets3.

are nearby.

Keep in mind that the operator or user is responsible4.

for accidents or hazards occurring to other people or

their property.

Do not carry passengers.5.

All drivers should seek and obtain professional6.

and practical instruction. Such instruction should

emphasize:

the need for care and concentration when workinga.

with ride-on machines;

control of a ride-on machine sliding on a slope willb.

not be regained by the application of the brake. The

main reasons for loss of control are:

insufficient wheel grip;t

being driven too fast;t

inadequate braking;t

the type of machine is unsuitable for its task;t

lack of awareness of the effect of groundt

conditions, especially slopes;

incorrect hitching and load distribution.t

Preparation

While mowing, always wear substantial footwear and1.

long trousers. Do not operate the equipment when

barefoot or wearing open sandals.

Thoroughly inspect the area where the equipment is to2.

be used and remove all objects which may be thrown

by the machine.

WARNING – Petrol is highly flammable.3.

Store fuel in containers specifically designed fora.

this purpose.

Refuel outdoors only and do not smoke whileb.

refuelling.

Add fuel before starting the engine. Never removec.

the cap of the fuel tank or add petrol while the

engine is running or when the engine is hot.

If petrol is spilled, do not attempt to start thed.

engine but move the machine away from the area

of spillage and avoid creating any source of ignition

until petrol vapours have dissipated.

Replace all fuel tanks and container caps securely.e.

Replace faulty silencers.4.

Before using, always visually inspect to see that the5.

blades, blade bolts and cutter assembly are not worn or

damaged. Replace worn or damaged blades and bolts

in sets to preserve balance.

On multi-blade machines, take care as rotating one6.

blade can cause other blades to rotate.

Operation

Do not operate the engine in a confined space where1.

dangerous carbon monoxide fumes can collect.

Mow only in daylight or in good artificial light.2.

Before attempting to start the engine, disengage all3.

blade attachment clutches and shift into neutral.

Do not use on slopes of more than 10 degrees.4.

Remember there is no such thing as a “safe” slope.5.

Travel on grass slopes requires particular care. To

guard against overturning:

do not stop or start suddenly when going up ora.

downhill;

engage clutch slowly, always keep machine in gear,b.

especially when travelling downhill;

machine speeds should be kept low on slopes andc.

during tight turns;

stay alert for humps and hollows and other hiddend.

hazards;

never mow across the face of the slope, unless thee.

mower is designed for this purpose.

Not for

Reproduction

6 murray.com

Operation (Continued)

Use care when pulling loads or using heavy equipment.6.

Use only approved drawbar hitch points.a.

Limit loads to those you can safely control.b.

Do not turn sharply. Use care when reversing.c.

Use counterweight(s) or wheel weights whend.

suggested in the Instruction Book.

Watch out for traffic when crossing or near roadways.7.

Stop the blades rotating before crossing surfaces other8.

than grass.

When using any attachments, never direct discharge of9.

material toward bystanders nor allow anyone near the

machine while in operation.

Never operate the mower with defective guards or10.

shields, or without safety protective devices in place.

Do not change the engine governor settings or11.

overspeed the engine. Operating an engine at excessive

speed may increase the hazard of personal injury.

Before leaving the operator’s position:12.

disengage the power take-off and lower thea.

attachments;

change into neutral and set the parking brake;b.

stop the engine and remove the key.c.

Disengage drive to attachments, stop the engine,13.

and disconnect the spark plug wire(s) or remove the

ignition key:

before cleaning blockages or unclogging chute;a.

before checking, cleaning or working on the mower;b.

after striking a foreign object. Inspect the mowerc.

for damage and make repairs before restarting and

operating the equipment;

if the machine starts to vibrate abnormally (checkd.

immediately).

Disengage drive to attachments when transporting or14.

not in use.

Stop the engine and disengage drive to attachment:15.

before refuelling;a.

before removing the grass catcher;b.

before making height adjustment unless adjustmentc.

can be made from the operator’s position.

Reduce the throttle setting during engine run-out and,16.

if the engine is provided with a shut-off valve, turn the

fuel off at the conclusion of mowing.

Before and when backing, look17. behind and down for

small children.

Use extra care when approaching blind corners, shrubs,18.

trees or other objects that may obscure vision.

Maintenance and Storage

On multi-blade machines, take care as rotating one1.

blade can cause other blades to rotate.

When machine is to be parked, stored or left2.

unattended, lower the cutting means unless a positive

mechanical lock is used.

Keep all nuts, bolts, and screws tight to be sure the3.

equipment is in safe working condition.

Never store the equipment with petrol in the tank inside4.

a building where fumes may reach an open flame or

spark.

Allow the engine to cool before storing in any5.

enclosure.

To reduce the fire hazard, keep the engine, silencer,6.

battery compartment and petrol storage area free of

grass, leaves, or excessive grease.

Check the grass catcher frequently for wear or7.

deterioration.

Replace worn or damaged parts for safety.8.

If the fuel tank has to be drained, this should be done9.

outdoors.

Not for

Reproduction

Assembly

All fasteners are in the parts bag. Do not discard any parts or

material until the unit is assembled.

WARNING: Before doing any assembly or

maintenance to the mower, remove the wire from

the spark plug.

NOTE: In this instruction book, left and right describe the

location of a part with the operator on the seat.

NOTE: Illustrations and pictorials begin on page 1.

NOTE: To assemble the following loose parts, use the

fasteners shown at full size in Figure 3.

Install the Front Wheels

Use a knife and cut the four sides of the container. Install the

front wheels (A) in the container (see Figure 4).

NOTE: Use a piece of wood about 4 feet (1.25 meters) long

to raise the front of the tractor. If a piece of wood cannot be

found, get another person to help lift the tractor. Be careful,

do not let the tractor fall.

Raise the front of the tractor. Set a support (block of1.

wood) under the tractor.

Make sure the2. valve stem (B) is to the outside of the

tractor. Slide the front wheel (A) on the spindle (C).

Fasten each front wheel with3. washer (D), washer (G)

and cotter pin (E). Bend the ends of the cotter pin apart

to keep the front wheel on the spindle.

After the front wheels are installed, lift the tractor from4.

the support. Roll the tractor off of the container.

If your tractor has5. hub caps (F), install the hub caps.

Make sure the washers hold the hub caps in place.

Install the Seat

Carefully remove the plastic bag from the seat.1.

Align the holes in the2. seat hinge (B) to the holes in

the seat (A) (see Figure 5). Fasten the seat to the seat

hinge with the fasteners (D) and (E).

Check the operating position of the seat. If the seat3.

needs to be adjusted, loosen the two wing bolts (E).

Slide the seat forward or backward along the seat

adjusting holes (C). Tighten the wing bolts.

Assemble the Steering Wheel

Make sure the front wheels point forward.1.

Slide the2. cover (C) over the steering post (B) (see

Figure 6). Make sure the collar of the cover is on top.

Slide the3. steering wheel (A) onto the steering post.

Attach the steering wheel to the steering post with4.

screw (D) and washer (E).

Some models have an5. optional insert (F) in the parts

bag. Attach the insert to the center of the steering

wheel.

Maintenance Free Battery

IMPORTANT: Before you attach the battery cables to the

battery, check the battery date. The battery date tells if the

battery must be charged.

(Figure 7) Check the top of the1. battery (A) for the

location of the battery date.

If the2. battery (A) is put into service before the battery

date, the battery cables can be attached without

charging the battery (A). See “Install The Battery

Cables”.

If the3. battery (A) is put into service after the battery

date, the battery (A) must be charged. See “Charge The

Battery”.

Charge The Battery (Figure 7)

WARNING: When you charge the battery, do not

smoke. Keep the battery away from any sparks. The

fumes from the battery acid can cause an

explosion.

Remove the1. battery (A) and battery tray (C).

Remove the protective cap from the battery terminal.2.

Use a 12 volt battery charger to charge the3. battery (A).

Charge at a rate of 6 amperes for one hour. If you do

not have a battery charger, have an authorized service

centre charge the battery.

Install the4. battery (A) and battery tray (C). Make sure

the positive (+) terminal (D) is on the left side.

Not for

Reproduction

8 murray.com

Install The Battery Cables (Figure 7)

WARNING: To prevent sparks, fasten the red cable

to the positive (+) terminal before you connect the

black cable.

Remove the protective cap from the battery terminal.1.

Slide the2. terminal cover (B) onto the red cable (E).

Fasten the red cable (E) to the positive (+) terminal

(D) with the fasteners (F) and (G).

Fasten the3. black cable (H) to the negative (-) terminal

with the fasteners (F) and (G).

Important! Before You Start Mowing

Check the engine oil.t

Fill the fuel tank with petrol.t

Check the air pressure of the tires.t

Check the level of the mower housing.t

Attach the battery cables.t

Check Tire Pressure

Check the air pressure in the tires. Tires with too much air

pressure will cause the unit to ride rough. Also, the wrong

air pressure will keep the mower housing from cutting level.

The correct air pressure is: Front Tires 0,97 BAR (14 PSI),

Rear Tires 0,69 BAR (10 PSI). The tires were over inflated

for shipment.

Prepare The Engine

NOTE: The engine was shipped from the factory filled with

oil. Check the level of the oil. Add oil as needed.

See the engine manufacturer’s instructions for the type

of petrol and oil to use. Before you use the unit, read the

information on safety, operation, maintenance, and storage.

WARNING: Follow the engine manufacturer’s

instructions for the type of petrol and oil to use.

Always use a safety petrol container. Do not smoke

when adding petrol to the engine. When inside an

enclosure, do not fill with petrol. Before you add

petrol, stop the engine. Let the engine cool for

several minutes.

Not for

Reproduction

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Murray Tondeuse à gazon

Murray

Murray 425620x92B Manuel utilisateur

Murray

Murray 204210X8C Manuel utilisateur

Murray

Murray 405000x8C Manuel utilisateur

Murray

Murray 425016x48A Manuel utilisateur

Murray

Murray 198933 Manuel utilisateur

Murray

Murray SPRINT Manuel utilisateur

Murray

Murray M2255FC Manuel utilisateur

Murray

Murray 22" Push Manuel utilisateur

Murray

Murray 465307X51A Manuel utilisateur

Murray

Murray 309008x99A Instructions d'installation

Murray

Murray 224110X92E0 Manuel utilisateur

Murray

Murray 405011x48A Manuel utilisateur

Murray

Murray 425615x50A Manuel utilisateur

Murray

Murray 309008X51 Manuel utilisateur

Murray

Murray SELECT 425001x8A Manuel utilisateur

Murray

Murray 309007x8A Instructions d'installation

Murray

Murray 465306x8A Manuel utilisateur

Murray

Murray 465609x24A Manuel utilisateur

Murray

Murray 22" Front Drive Manuel utilisateur

Murray

Murray PRO Series Manuel du propriétaire

Murray

Murray 405600x50A Manuel utilisateur

Murray

Murray mulcher 20-inch Push Manuel utilisateur

Murray

Murray MD20475FC Manuel utilisateur

Murray

Murray 42583X9A Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
