THIS MANUAL MUST ACCOMPANYTHE EQUIPMENT AT ALLTIMES.

Revision #0 (03/06/09)

MODELS

C10SH8 (STEEL)

C10PH8 (PLASTIC)

CONCRETE MIXER

(HONDA GX240U1QA2 GASOLINE ENGINE

OPERATION AND PARTS MANUAL

Go to Discount-Equipment.com to order your parts

Discount-Equipment.com is your online resource for quality parts & equipment.

Florida: 561-964-4949 Outside Florida TOLL FREE: 877-690-3101

Need parts?

Click on this link: http://www.discount-equipment.com/category/5443-parts/ and

choose one of the options to help get the right parts and equipment you are looking

for. Please have the machine model and serial number available in order to help us

get you the correct parts. If you don’t find the part on the website or on one of the

online manuals, please fill out the request form and one of our experienced staff

members will get back to you with a quote for the right part that your machine needs.

We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,

Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,

Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack,

Lull, Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic,

Dynapac, MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti,

Morrison, Contec, Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S.

Curtis, Gehl Pavers, Heli, Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin,

Rice, CH&E, General Equipment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent,

Stanley, Tamco, Toku, Hatz, Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air,

APT, Wylie, Ingersoll Rand / Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith

Surface Prep,Small Line, Wanco, Yanmar

PAGE 2 — C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09)

PROPOSITION 65 WARNING

Engine exhaust and some of

itsconstituents,andsomedustcreated

of California to cause cancer, birth

defects and other reproductive harm.

by power sanding, sawing, grinding,

drillingandotherconstructionactivities

contains chemicals known to the State

Someexamplesofthesechemicalsare:

Leadfromlead-basedpaints.

Crystallinesilicafrombricks.

Cementandothermasonryproducts.

Arsenicandchromiumfromchemically

treatedlumber.

Your risk from these exposures varies,

dependingonhowoftenyoudothistype

of work.To reduce your exposure to

these chemicals: work in aALWAYS

well ventilated area, and work with

approved safety equipment, such as

dust masks that are specially designed

to filter out microscopic particles.

Go to Discount-Equipment.com to order your parts

C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09) — PAGE 3

Grinding/cutting/drillingofmasonry,concrete,metaland

other materials with silica in their composition may give

off dust or mists containing crystalline silica. Silica is a

basic component of sand, quartz, brick clay, granite and

numerous other minerals and rocks. Repeated and/or

substantial inhalation of airborne crystalline silica can

cause serious or fatal respiratory diseases, including

silicosis. In addition, California and some other

authorities have listed respirable crystalline silica as a

substance known to cause cancer. When cutting such

materials, always follow the respiratory precautions

mentionedabove.

WARNING

Grinding/cutting/drillingofmasonry,concrete,metaland

other materials can generate dust, mists and fumes

containing chemicals known to cause serious or fatal

injury or illness, such as respiratory disease, cancer,

birth defects or other reproductive harm. If you are

unfamiliar with the risks associated with the particular

process and/or material being cut or the composition of

the tool being used, review the material safety data

sheet and/or consult your employer, the material

manufacturer/supplier, governmental agencies such as

OSHA and NIOSH and other sources on hazardous

materials. California and some other authorities, for

instance, have published lists of substances known to

cause cancer, reproductive toxicity, or other harmful

effects.

Control dust, mist and fumes at the source where

possible. In this regard use good work practices and

follow the recommendations of the manufacturers or

suppliers, OSHA/NIOSH, and occupational and trade

associations. Water should be used for dust

suppression when wet cutting is feasible. When the

hazardsfrom inhalationofdust, mistsandfumescannot

be eliminated, the operator and any bystanders should

always wear a respirator approved by NIOSH/MSHAfor

thematerialsbeingused.

WARNING

SILICOSISWARNING RESPIRATORY HAZARDS

SILICOSIS/RESPIRATORY WARNINGS

Go to Discount-Equipment.com to order your parts

PAGE 4 — C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09)

TABLE OF CONTENTS

C10SH8-PH8

Concrete Mixer

Proposition 65 Warning ........................................... 2

Silicosis/Respiratory Warnings ................................ 3

Table Of Contents.................................................... 4

Parts Ordering Procedures...................................... 5

Safety Information .............................................. 6-10

Speciﬁcations ........................................................ 12

Dimensions............................................................ 13

General Information............................................... 14

Components .......................................................... 15

Basic Engine.......................................................... 16

Towing Guidelines.................................................. 17

Safety Chain Connection....................................... 18

Inspection .............................................................. 19

Operation.......................................................... 20-21

Maintenance (Engine) ...................................... 22-23

Maintenance (Mixer)......................................... 24-26

Troubleshooting (Engine)....................................... 28

Troubleshooting (Mixer) ......................................... 29

Explanation Of Code In Remarks Column ............ 30

Suggested Spare Parts ......................................... 31

Component Drawings

Nameplates And Decals................................... 32-33

Plastic Drum Assembly..................................... 34-35

Steel Drum Assembly....................................... 36-37

Yoke Assembly.................................................. 38-39

Frame Assembly............................................... 40-41

Hub/Tire Assembly ........................................... 42-43

Cabinet Assembly............................................. 44-45

Engine Assembly.............................................. 46-47

Terms And Conditions Of Sale — Parts ................ 48

NOTICE

Speciﬁcations and part numbers are subject to change

without notice.

Go to Discount-Equipment.com to order your parts

PAGE 6 — C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09)

Do not operate or service the equipment before reading

the entire manual. Safety precautions should be followed

at all times when operating this equipment.

Failure to read and understand the safety

messages and operating instructions could

result in injury to yourself and others.

SAFETY MESSAGES

The four safety messages shown below will inform you

about potential hazards that could injure you or others.The

safety messages speciﬁcally address the level of exposure

to the operator and are preceded by one of four words:

DANGER, WARNING, CAUTION or NOTICE.

SAFETY SYMBOLS

DANGER

Indicates a hazardous situation which, if not avoided,

WILL result in DEATH or SERIOUS INJURY.

WARNING

Indicates a hazardous situation which, if not avoided,

COULD result in DEATH or SERIOUS INJURY.

CAUTION

Indicates a hazardous situation which, if not avoided,

COULD result in MINOR or MODERATE INJURY.

NOTICE

Addresses practices not related to personal injury.

Potential hazards associated with the operation of this

equipment will be referenced with hazard symbols which

may appear throughout this manual in conjunction with

safety messages.

Lethal exhaust gas hazards

Explosive fuel hazards

Burn hazards

Rotating parts hazards

Symbol Safety Hazard

SAFETY INFORMATION

Go to Discount-Equipment.com to order your parts

C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09) — PAGE 7

GENERAL SAFETY

CAUTION

NEVERoperate this equipment without proper protective

clothing, shatterproof glasses, respiratory protection,

hearing protection, steel-toed boots and other protective

devices required by the job or city and state regulations.

Avoid wearing jewelry or loose ﬁtting clothes that may

snag on the controls or moving parts as this can cause

serious injury.

NEVERoperate this equipment when not

feeling well due to fatigue, illness or when

under medication.

NEVERoperate this equipment under the

inﬂuence of drugs or alcohol.

ALWAYSclear the work area of any debris, tools, etc.

that would constitute a hazard while the equipment is

in operation.

ALWAYScheck the equipment for loosened threads or

bolts before starting.

DO NOTuse the equipment for any purpose other than

its intended purposes or applications.

NOTICE

This equipment should only be operated by trained and

qualiﬁed personnel 18 years of age and older.

Whenever necessary, replace nameplate, operation and

safety decals when they become difﬁcult read.

Manufacturer does not assume responsibility for any

accident due to equipment modiﬁcations. Unauthorized

equipment modiﬁcation will void all warranties.

NEVERuse accessories or attachments that are not

recommended by Multiquip for this equipment. Damage

to the equipment and/or injury to user may result.

ALWAYSknow the location of the nearest

ﬁre extinguisher.

ALWAYSknow the location of the nearest

ﬁrst aid kit.

ALWAYSknow the location of the nearest phone or keep

a phone on the job site. Also, know the phone numbers

of the nearest ambulance, doctor and ﬁre department.

This information will be invaluable in the case of an

emergency.

SAFETY INFORMATION

Go to Discount-Equipment.com to order your parts

PAGE 8 — C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09)

SAFETY INFORMATION

MIXER SAFETY

DANGER

NEVERoperate the equipment in an explosive

atmosphere or near combustible materials.An

explosion or ﬁre could result causing severe

bodily harm or even death.

DO NOTmix ﬂammable or explosive substances.

WARNING

NEVERplace your hands inside the drum

while starting or operating this equipment.

NEVERdisconnect any emergency

or safety devices. These devices are

intended for operator safety. Disconnection of these

devices can cause severe injury, bodily harm or even

death. Disconnection of any of these devices will void

all warranties.

Before operating mixer, ensure that safety grate is in

position and correctly ﬁtted.

CAUTION

NEVERlubricate components or attempt service on a

running machine.

NOTICE

ALWAYSkeep the machine in proper running condition.

ALWAYSensure mixer is on level ground before mixing.

Fix damage to machine and replace any broken parts

immediately.

DO NOTtip mixer onto drum mouth when the drum is

rotating.

Ensure the drum is rotating while ﬁlling and emptying

the drum.

ALWAYSstore equipment properly when it is not being

used. Equipment should be stored in a clean, dry location

out of the reach of children and unauthorized personnel.

ENGINE SAFETY (GASOLINE MODELS ONLY)

DANGER

Engine fuel exhaust gases contain poisonous carbon

monoxide. This gas is colorless and odorless, and can

cause death if inhaled.

The engine of this equipment requires an adequate

free ﬂow of cooling air. NEVER operate this equipment

in any enclosed or narrow

area where free ﬂow of the

air is restricted. If the air

ﬂow is restricted it will cause

injury to people and property

and serious damage to the

equipment or engine.

WARNING

DO NOTplace hands or fingers inside engine

compartment when engine is running.

NEVERoperate the engine with heat shields or

guards removed.

Keep ﬁngers, hands hair and clothing away

from all moving parts to prevent injury.

DO NOTremove the engine oil drain plug

while the engine is hot. Hot oil will gush out of the oil

tank and severely scald any persons in the general area

of the mixer.

CAUTION

NEVERtouch the hot exhaust manifold,

mufﬂer or cylinder. Allow these parts to cool

before servicing equipment.

Make certain the operator knows how to and is capable

of turning the engine OFF in case of an emergency.

NOTICE

NEVERrun engine without an air ﬁlter or with a dirty air

ﬁlter. Severe engine damage may occur. Service air ﬁlter

frequently to prevent engine malfunction.

NEVERtamper with the factory settings

of the engine or engine governor. Damage

to the engine or equipment can result

if operating in speed ranges above the

maximum allowable.

DANGEROUS

GAS FUMES

Go to Discount-Equipment.com to order your parts

C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09) — PAGE 9

SAFETY INFORMATION

FUEL SAFETY (GASOLINE MODELS ONLY)

DANGER

DO NOTstart the engine near spilled fuel or combustible

ﬂuids. Fuel is extremely ﬂammable and its vapors can

cause an explosion if ignited.

ALWAYSrefuel in a well-ventilated area, away from

sparks and open ﬂames.

ALWAYSuse extreme caution when working with

ﬂammable liquids.

DO NOTﬁll the fuel tank while the engine is running

or hot.

DO NOToverﬁll tank, since spilled fuel could ignite if it

comes into contact with hot engine parts or sparks from

the ignition system.

Store fuel in appropriate containers, in well-ventilated

areas and away from sparks and ﬂames.

NEVERuse fuel as a cleaning agent.

DO NOTsmoke around or near the

equipment. Fire or explosion could result

from fuel vapors or if fuel is spilled on a

hot engine.

GENERATOR SAFETY

If using a generator to power mixer, refer to

applicable generator manual safety information

section.

ELECTRIC MOTOR SAFETY

(ELECTRIC MODELS ONLY)

NOTICE

Operate electric motor only at the speciﬁed voltage

indicated on the nameplate.

DO NOTspray water onto electric motor.

ALWAYSdisconnect AC power plug from power source

before moving mixer.

ALWAYSmake sure the ON/OFF switch

on the electric motor is in the OFF position

when not in use and before inserting the

mixer’s power plug into an AC receptacle.

Power Cord/Cable Safety

DANGER

NEVERlet power cords or cables lay in water.

NEVERuse damaged or worn cables or cords when

connecting equipment to generator. Inspect for cuts in

the insulation.

NEVERgrab or touch a live power

cord or cable with wet hands. The

possibility exists of electrical shock,

electrocution or death.

Make sure power cables are securely connected.

Incorrect connections may cause electrical shock and

damage to the mixer.

CAUTION

Ensure that cables and cords will not be tripped over or

trapped underneath the mixer.

NOTICE

ALWAYSmake certain that proper power or extension

cord has been selected for the job.

TRANSPORTING SAFETY

CAUTION

NEVERallow any person or animal to stand underneath

the equipment while lifting.

NOTICE

ALWAYSmake sure forklift forks are inserted into pockets

(if applicable) as far as possible when lifting the mixer.

ALWAYSshutdown engine before transporting.

NEVERlift the equipment while the engine is running.

Tighten fuel tank cap securely and close fuel cock to

prevent fuel from spilling.

DO NOTlift machine to unnecessary heights.

ALWAYStie down equipment during transport by

securing the equipment with rope.

NEVERtip the engine to extreme angles during lifting as

it may cause oil to gravitate into the cylinder head, making

the engine start difﬁcult.

Go to Discount-Equipment.com to order your parts

PAGE 10 — C10SH8-PH8 CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #0 (03/06/09)

SAFETY INFORMATION

TOWING SAFETY

CAUTION

Check with your local county or state safety towing

regulations, in addition to meeting Department of

Transportation (DOT) Safety Towing Regulations,

before towing your mixer.

In order to reduce the possibility of an accident while

transporting the mixer on public roads, ALWAYS make

sure the towing vehicle is mechanically sound and in

good operating condition.

ALWAYS shutdown engine before transporting.

ALWAYSinspect the hitch and coupling for wear. NEVER

tow a mixer with defective hitches, couplings, chains, etc.

Check the tire air pressure on both towing vehicle and

mixer Mixer tires should be inﬂated to 50 psi cold.Also

check the tire tread wear on the vehicle and mixer.

ALWAYSmake sure the mixer is equipped with a safety

chain.

ALWAYSproperly attach mixer’s safety chains to towing

vehicle.

The maximum speed for highway towing is55 MPH unless

posted otherwise.Recommended off-road towing is not to

exceed 15 MPH or less depending on type of terrain.

Avoid sudden stops and starts.This can cause skidding,

or jack-kniﬁng. Smooth, gradual starts and stops will

improve towing.

Avoid sharp turns to prevent rolling.

Mixer should be adjusted to a level position at all times

when towing.

Raise and lock mixer wheel stand in up position when

towing.

Placechock blocks underneath wheel to prevent rolling

while parked.

ENVIRONMENTAL SAFETY

NOTICE

Dispose of hazardous waste properly.

Examples of potentially hazardous waste

are used motor oil, fuel and fuel ﬁ

lters.

DO NOTuse food or plastic containers to dispose of

hazardous waste.

DO NOTpour waste, oil or fuel directly onto the ground,

down a drain or into any water source.

Go to Discount-Equipment.com to order your parts

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels MULTIQUIP Matériel de construction

MULTIQUIP

MULTIQUIP Whiteman series Manuel utilisateur

MULTIQUIP

MULTIQUIP MC64SH Mode d’emploi

MULTIQUIP

MULTIQUIP Mikasa Series Mode d’emploi

MULTIQUIP

MULTIQUIP Mikasa MVH208DZ Manuel utilisateur

MULTIQUIP

MULTIQUIP Whiteman series Mode d’emploi

MULTIQUIP

MULTIQUIP Mikasa Series Manuel utilisateur

MULTIQUIP

MULTIQUIP Mikasa Series Manuel utilisateur

MULTIQUIP

MULTIQUIP Mikasa MRH800GS Mode d’emploi

MULTIQUIP

MULTIQUIP AR13H Manuel utilisateur

MULTIQUIP

MULTIQUIP EM90SH8 Manuel utilisateur

MULTIQUIP

MULTIQUIP AR14H Manuel utilisateur

MULTIQUIP

MULTIQUIP Mikasa Series Manuel utilisateur

MULTIQUIP

MULTIQUIP MC94PH8 Mode d’emploi

MULTIQUIP

MULTIQUIP Rammax RX1575 Manuel utilisateur

MULTIQUIP

MULTIQUIP WTB-16PD Manuel utilisateur

MULTIQUIP

MULTIQUIP Whiteman MC94P Mode d’emploi

MULTIQUIP

MULTIQUIP Mikasa MVH508DE Manuel utilisateur

MULTIQUIP

MULTIQUIP WHITEMAN PRX Manuel utilisateur

MULTIQUIP

MULTIQUIP P54K-K2B-K4B Manuel utilisateur

MULTIQUIP

MULTIQUIP MC12PH Mode d’emploi

MULTIQUIP

MULTIQUIP Whiteman WM120PH Series Mode d’emploi

MULTIQUIP

MULTIQUIP MC94SK Manuel utilisateur

MULTIQUIP

MULTIQUIP Whiteman WM90SLF Manuel utilisateur

MULTIQUIP

MULTIQUIP DSGPULW Manuel utilisateur

Manuels Matériel de construction populaires d'autres marques

SASFORKS

SASFORKS EXTREME Manuel utilisateur

Hailo

Hailo H-50 Manuel utilisateur

Graco

Graco LineLazer ES 1000 Manuel d'utilisation et d'entretien

Greenlee

Greenlee 555RSC Manuel utilisateur

Manitowoc

Manitowoc Grove CD3340B Manuel utilisateur

Lux Tools

Lux Tools A-FMR-20 Set Manuel utilisateur

SIP

SIP 03683 Manuel utilisateur

Volvo

Volvo L30G Manuel utilisateur

Grizzly

Grizzly G8712 Manuel utilisateur

Modulift

Modulift CMOD 12 Manuel utilisateur

Case

Case DV201 Manuel utilisateur

Sealey

Sealey SC10.V2 Manuel utilisateur

Wacker Neuson

Wacker Neuson DT05 Manuel utilisateur

HYVA

HYVA AMCO VEBA 81 Series Manuel utilisateur

Atlas Copco

Atlas Copco Dynapac V5100TV Manuel utilisateur

Toro

Toro 323 Manuel utilisateur

Manitowoc

Manitowoc National Crane 1400A Manuel utilisateur

SGS

SGS EC1500 Manuel utilisateur
