MultiDyne Versatile Brix Series Manuel utilisateur

INSTRUCTION MANUAL

Versatile Brix Cards

10 NEWTON PLACE

HAUPPAUGE, NY 11788 USA

(877) 685-8439 / (516) 671-7278 / FAX (516) 671-3362

[email protected]

www.multidyne.com

MultiDyne

Harnessing The Power of Light

Versatile Brix Cards

Table of Contents

LIST OF FIGURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

LIST OF TABLES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2. FEATURES AND OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3. DIFFERENT CARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3.1. VIDEO CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3.2. AUDIO CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3.3. DATA CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

3.4. ETHERNET CARDS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.FRONT PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

4.1 VB6 SERIES FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

4.2 VB3 SERIES FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

5. APPENDIX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.1 VIDEO CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.2 DATA CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.3 SYNC SIGNAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

5.4 ETHERNET CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6 POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Versatile Brix Cards

List of Figures

Figure 3.1: VIDEO CARD 5

Figure 3.2 AUDIO CARD 5

Figure 3.3: DATA CARD 7

Figure 3.4: ETHERNET CARD 8

Figure 4.1: FRONT PANEL FRONT VIEW VB6 8

Figure 4.1: REAR PANEL REAR VIEW VB6 8

Figure 4.2: VB3 SERIES FRONT PANEL 9

Figure 5.1: SDI INPUT FRONT 10

Figure 5.1: SDI INPUT REAR 10

Figure 5.1: SDI OUTPUT FRONT 10

Figure 5.1: SDI OUTPUT REAR 10

Figure 5.2: DATA CARD FRONT 10

Figure 5.2: REAR DATA CARD REAR 10

Figure 5.3: FRONT SERIALIZER CARD 11

Figure 5.3: REAR OF SERIALIZER CARD 11

Figure 5.4: FRONT OF ETHERNET CARD 11

Figure 5.4: REAR ETHERNET CARD 11

Figure 6.1: POWER 11

List of Tables

Table 1: AUDIO CARD PIN DESCRIPTION 6

Table 2: DATA CARD PIN DESCRIPTION 7

Table 3: DIFFERENT SLOTS FUNCTIONALITY WITH DIFFERENT CARDS FOR VB6 9

Table 4: DIFFERENT SLOTS FUNCTIONALITY WITH DIFFERENT CARDS FOR VB3 9

Versatile Brix Cards

Introduction

e Versatile Brix Series of stand-alone SMPTE 4K video Serial Digital Interface (UHD-SDI) with audio, Ethernet

and data transport systems extends the range limits of electrical interfaces. It combines all the signals along with

a single optical ber link. e system will transport digital signals from 5 Mbps up to 12Gbps video, analog audio,

and AES digital audio, serial data, tally, and General Purpose I/O (GPIO) signals.

Applications include transmission links for high denition or digital television, studio to transmitter; studio-to-

studio, robotic studio cameras, studio to CATV head-end and backhaul feeds from special events.

Features and Operation

e VB series video cards supports all popularstandards fordigital video transportsuch as SMPTE ST2082, SMPTE

ST 2081, SMPTE 424M, SMPTE 292M,and SMPTE 259M working at 12G-SDI, 6G-SDI, 3G-SDI, HD-SDI,SD-SDI

respectively. In addition, the SDI interface also will transport signals compatible with DVB/ASI, and SMPTE 297M

interfaces at the dened rates. e units include a digital re-clocked DA and repeater forthe SMPTE SDI standards

mentioned above. For other standards and rates, the signal is automatically or manually passed thru without

re-clocking. For all SDI input, the units include automatic cable equalization based on the data rate detected.

e VB series also transports 4x4 analog audio channelswith maximum congurable levels of 4dBu, 10dBu, 16dBu,

or 28 dBu; 2 digital AES pairs up to 96 KHz that cross convert with the 4 analog channels; and a bidirectional

stereo channel for intercom applications with maximum level of 4dBu.

e VB series data card supports 1 bidirectional tally and 1 GPIO bidirectional channel and 2 data channel with

RS232 or RS422/ RS485 transport up to 3Mbps.

eVBseriescanalsobeorderedwithanEthernetcard.eEthernetcardcanalsobeorderedwith2Ethernetports.at

canbeusedtoextendagigabitEthernetconnectivityoverber.Ratesof10/100/1000MbpsaresupportedforEthernet.

e VB series also sports a Sync transport option. It supports sync formats are NTSC, PAL, and HD Tri-Level.

Versatile Brix Cards

Dierent Cards

3.1. VIDEO CARD

e video cards are dual channel cards. ey can be ordered in 2 options based on the data rate required.

1) 3G option

2) 12G option

evideocardscanbeconguredintosingle\dualtransmitterorsingle\dualreceiveroptionsonly.econguration

is based on the SFPs plugged into the module. e SFPs have to be NON-MSA, and SDI video SFPs. When in

transmit conguration is used the board congures to receive video over copper. So the video is equalized and

re-clocked before transmitting over ber. In receive conguration they are received over ber and re-clocked and

driven over copper by the cable driver. e data rates are indicated over the front led panel. e 3G video board

indicates SD, HD and 3G for both the channels. e 12G video board indicates 3G, 6G or 12G option.

3.2. AUDIO CARD

e audio cards support 2 stereo inputs and 2 stereo outputs on each side. So, the link supports two balanced

stereo pairs, or two AES channels of high quality audio. In the RX side, for each stereo pair, and whatever signal

either analog or digital was congured on the TX side, is sent simultaneously to the analog and digital AES ports.

e system has to be ordered either as analog orAES or a combination of both.is feature eectively can convert

an analog signal in the TX side to digital in the RX side, or the reverse case. e AES channels can be ordered to

75ohms single ended or 110 ohms balanced. e audio LEDs indicate three possible statuses: constant blinking

green indicates AES signal is present, green indicates analog level is present.

4 AUDIO INPUTS

4 AUDIO OUTPUTS

Figure 3.2: AUDIO CARD

Figure 3.1: VIDEO CARD

Versatile Brix Cards

PIN NUMBER PURPOSE

1GND

2AUD_IN-

3AUD_IN+

4GND

5AUD2_IN+

6AUD2_IN-

7GND

8 AUD3_IN+

9AUD3_IN-

10 GND

11 AUD4_IN+

12 AUD4_IN-

13 GND

14 GND

15 AUD1_OUT+

16 AUD1_OUT-

17 GND

18 AUD2_OUT+

19 AUD2_OUT-

20 GND

21 AUD3_OUT+

22 AUD3_OUT-

23 GND

24 AUD4_OUT+

25 AUD4_OUT-

26 GND

Table 1: AUDIO CARD PIN DESCRIPTION

Versatile Brix Cards

3.3. DATA CARD

e data card support one channel of bidirectional Tally and one bi-directional general purpose input output. It

also supports 2 channel of bidirectional data. e data can be set in dierent conguration. e channels are set to

by default RS422. e cards can be ordered with RS422 or RS485 by changing the switch on the card as shown in

the above image or preset with RS232, RS422 or RS485 at the customers request. e LEDS in the front will turn

on showing the data paths are active.

e interface is through a HD15 connector. e pinouts of the connector are as shown below.

Figure 3.3: DATA CARD

PIN NUMBER FUNCTION

1CH1 RX-

6CH1 RX+

7CH1 TX-

11 CH1 TX+

2CH2 RX+

8CH2 RX-

12 CH2 TX+

3CH2 TX-

9TALLY IN

10 GPI

13 GPO

4TALLY OUT

14 GND

15 GND

Table 2: DATA CARD PIN DESCRIPTION

Versatile Brix Cards

3.4. ETHERNET CARDS

e Gigabit Ethernet includes a copper to ber Ethernet media converter. Data rates of 10/100/1000 Mbps are

supported. When a link is established between 2 units. e green LED in the front will turn on. en as the ports

are connected the lights will icker.

Front Panel

4.1 VB6 SERIES FRONT PANEL

e front panel of a standard VB6 box has 6 slots. Each slots have capabilities of driving 6 green color LEDs for

signals as shown in the image above. e slot have an opening in the front to mount a centrifugal fan that pushes

air outside. When the box is populated with more than 3 cards it is a standard feature to mount it with a fan to

keep the box temperature.

Figure 4: ETHERNET CARD

Figure 4.1: VB6 SERIES FRONT PANEL VIEW

Figure 4.1: VB6 SERIES REAR PANEL VIEW

Versatile Brix Cards

CARD TYPE SLOT1 SLOT2 SLOT3 SLOT4 SLOT5 SLOT6

VIDEO CARD YES YES YES YES YES YES

ETHERNET CARD YES YES YES YES YES YES

DATA CARD NO YES NO (ALLOCATED FOR

SERIALIZER) YES YES(2 DATA

AND TALLY) YES

AUDIO CARD NO YES NO (ALLOCATED FOR

SERIALIZER) YES YES YES

SYNC(SERIALIZER) YES YES YES YES YES YES

e below table talks about what are the capabilities of dierent slots.

4.2 VB3 SERIES FRONT PANEL

Similar to the VB6 Series front panel. e VB3 series front panel can accommodate to 3 cards. Below shown are

the card slots and their adaptability.

Figure 4.2: VB3 SERIES FRONT PANEL VIEW

CARD TYPE SLOT1 SLOT2 SLOT3

VIDEO CARD YES YES YES

ETHERNET CARD YES YES YES

DATA CARD NO NO (ALLOCATED FOR

SERIALIZER) YES

AUDIO CARD NO NO (ALLOCATED FOR

SERIALIZER) YES

SYNC(SERIALIZER) YES YES YES

Table 3: VB6 SERIES SLOTS FUNCTIONALITY WITH DIFFERENT CARDS

Table 4: VB3 SERIES SLOTS FUNCTIONALITY WITH DIFFERENT CARDS

Versatile Brix Cards

5. Appendix

e products changes are based on the conguration ordered, and there is no consistent front panel. e front

panel changes are based on the conguration ordered and the box ordered.

e below shows what fashion of LEDs to expect for dierent cards.

5.1 VIDEO CARD

e front top of the led panel shows the channel number and the rear shows the BNC number. It also shows the

data rate of the signal and whether it is an input or output.

Figure 5.1: SDI INPUT FRONT

Figure 5.1: SDI OUTPUT FRONT

5.2 DATA CARD

e data light remains on when the channels are active.

Figure 5.2: DATA CARD FRONT Figure 5.2: DATA CARD REAR

Figure 5.1: SDI OUTPUT REAR

Figure 5.1: SDI INPUT REAR

TX+ TX- RX+ RX-

RS 485

+ –

* For RS485 applications connect

together TX and RX with a small

680 Ohm resistor as shown below
