Muller licht 57006 Manuel utilisateur

MANUAL RGB STICKS

ENGLISH

LED-Sticks #57006

english 9

Implied warranty

Ourproductismanufacturedunderstrictqualityinspections.

Wedeliverourproductswithimpliedwarrantyoftwoyears.

Ifyoushouldhaveanycauseforcomplains,pleasecontactyour

localdealerfromwhichyouboughttheproduct.

Hewillhandlethereplacement,whereapplicable.

Theimpliedwarrantywillbeaffectedbyimproperorincorrect

usageofourproduct.

Installation

Fortechnicalsupportyoucancontactusdirectly:

MÜLLER-LICHT International GmbH

Goebelstr. 61/63

D-28865 Lilienthal

Tel. +49 (0) 4298-93700

service@mueller-licht.de

MANUAL RGB STICKS

10 english

Security advice

Pleasereadthismanualcompletelyandstoreitsafely.

Bypassingtheproducttoanotherperson,pleaseaddthismanual.

Usage

• Notsuitableforhouseholdroomillumination.

Onlyfordecorativeusage.

• TheLED-sticksareintendedtouseinhomes

• TheLED-sticksareintendedformountingonwallandroof

• TheLED-sticksareintendedforuseonlyonnormalammable

environment

• TheLED-sticksareprotectedagainstpenetrationofsolid

matter, IP20

Security

• TheLED-sticksareonlyallowedtobepoweredbydriverofthe

original accessory.

• DonotusetheLED-sticksorcables,ifdamaged

• Pleaseprotectthecableinuseagainstdamage,

ifplacedontheoor

• Pleaseconnectthelineadapteronlytoapprovedpowersockets

(220-240 V ·50/60Hz)

• Pleasedisconnectthelineadapterfromthepowersocket

beforecleaningormountingoftheLED-sticks

MANUAL RGB STICKS

english 11

Security advice

Application

• DonotlookfromclosedistanceintotheoperatingLED

• DonotlookintotheoperatingLEDbyamagnier

• DonotusetheLED-sticksinsidethecolorbox

• DonotusetheLED-stickscovered

•

DonotconnecttheLED-stickstoothersticksorelectricdevices

Battery

• Doneverchargethebattery!Riskofexplosion!

• Protectchildrenfromthebattery

• Donotthrowthebatteryintoreordismantleit

• Pleaseremoveanemptybatteryfromthecompartment

• Donotexposethebatterytoextremeconditions

 (e.g.heater,re)

• Avoidcontacttoskin,eyesormucosawithbatteryacid

• Incaseofcontacttobatteryacid,pleasecleantheaffected

 areaswithpurewaterandcontactimmediatelyadoctor

• Pleasereplacethebatteryonlywithsameorequivalenttype

• Pleasecontactimmediatelyadoctorincaseofaswallowed

battery

• Inlongertimesofnon-usepleaseremovethebatteryfrom

 thecompartment

MANUAL RGB STICKS

Scope of delivery

1. 4x connectors 10 cm

2. 8x connector bridges

3. 4x end cap

4. Mounting material

5. Line adapter with cable

6. 4x LED-stick

7. Remote control with battery (1x CR2025 ·3 V)

8. Repeater with IR-receiver

12 english

MANUAL RGB STICKS

1. 2. 3. 4. 5.

7. 8.

Mounting

 1.  Estimatethepositionofholdingclipsorglueares

2. Assembly the sticks with the connectors and check the

   positionoftheholdingclipsorplacethegluepadsonthe

sticks

 3.  Pushthesticksintotheholdingclipsor

   gluethesticksonthedesiredplace

 5.  Puttheendcaponthelaststick

 6.  Connecttherststickwiththelineadapter

 7.  Connectthelineadaptertothepowersocket

 8.  Removethecontactprotectioninthebatterycompartment

 9.  StarttheLEDstripbyusingtheremotecontrol

10.

Advice

   Receiverfortheinfrared-signalsoftheremoteisthe

   repeater.Theremotecontrolneedadirectandbarrier-free

   connectiontotherepeater.Max.distance5-7m.

Battery replacement

Pleaseopenthebatterycompartmentonthesideoftheremote

controlbypushingtheclampingpinbysimultaneously

extractingthecompartment.

PleasealwaysuseanidenticalbatteryoftypeCR2025·3 V.

Pleaseconsidercorrectpolingbyplacingthebatteryinthe

compartment.Thesideofthepositivepoleismarkedby(+)

onthecompartment.

english 13

MANUAL RGB STICKS

14 english

Technical details

Model 57006

15 W ·12 V DC ·1 A ·RGB

Protection class II ·IP20

Lineadapter: XY-1201000-E

In: 100-240 V ·1,5 A ·50/60Hz

Out: 12 V ·1 A

Power: 15 W

Protection class: II

Battery(remotecontrol)

1xCR2025·3 V

Ifdesiredyoucanrequestthedeclarationofconformity

fortheCEsignviaservic[email protected].

MANUAL RGB STICKS

www.

mueller-licht.de/

recycle

english 15

MANUAL RGB STICKS

16Level

Brightness

Adjusting*

15 Kinds

OfExisting

Colors 7 color

jumpychange

All fade out

& fade in

7 color

fade change

3 base

colorjumpy

Power(ON/OFF)

White

OFF ON

FLASH

FADE

STROBE

SMOOTH

BGR

* WhenswitchingtodynamicmodetheBrightness-buttonmeansthe

speedoflightchangesin32steps

Recycle

LED-devicesarenotallowedtobeplacedinhouseholdgarbage.

Please recycle it.

Please contact your local recycling agency for details.

MÜLLER-LICHT International GmbH

Goebelstr. 61/63

D-28865 Lilienthal

Tel. +49 (0) 4298-93700

service@mueller-licht.de

MANUAL RGB STICKS

Nachdruck, auch auszugsweise, nur mit schriftlicher Genehmigung des Urhebers • Irrtum und Änderung vorbehalten

Full or partial reproduction subject to prior written approval • Errors and changes are excepted

57006_LED-Sticks_RGB_MANUAL_002.pdf
