MTX MUD65PL Manuel utilisateur

MTX.COM

MUD65PL

CAGE MOUNT SPEAKER WITH RGB LEDS

OWNER’S MANUAL

MTX.COM

PRODUCT INFORMATION

Model #

Serial #

Dealer’s Name

Date of Purchase

IN THE BOX

• Speaker and Enclosure

• Brackets

• For mounting the bracket base to the enclosure

• (8) M6-1.0x14mm stainless steel Hex Bolt

• (8) M6 at washer stainless steel

• (8) M6 split lock washer stainless steel

• For tightening the bracket strap to the base

• (2) M6-1.0x50mm stainless steel Hex Bolt

• (2) M6 serrated ange lock nut stainless steel

INTRODUCTION

Thank you for purchasing this MTX Audio cage mount speaker pod. This high performance speaker

features all-weather construction designed to deliver exceptional sound quality and volume for high

output systems for those that love to hear their music wherever they are. Additionally, each speaker

enclosure includes a RGB LED light kit that enables customization of the speaker lighting color on the

grille. Congratulations and enjoy the ultimate audio experience with MTX!

FEATURES

• Integrated RGB LED Lighting

• Includes Rotating Brackets for 1.5", 1.75", and 2" Bars

• ABS Impact Resistant Enclosure and Grille with UV Inhibitor

• Polypropylene Woofer and Mylar Dome Tweeter

• Tested 500 Hrs to ASTM B117, D4329 Standard

• IP67 Rated for Outdoor Use

SPECIFICATIONS

RMS Power Handling: 50-Watts

Peak Power Handling: 100-Watts

Sensitivity (2.83V/1m): 89.9dB

Sensitivity (1W/1m): 85.6dB

Frequency Response: 70Hz - 20kHz

Impedance: 4Ω

Fits Bars 1.5", 1.75", and 2"

WIRE COLOR

Grey / Black: +/- speaker wire

Black / Red / Green / Blue: +/ground speaker illumination

MTX.COM 3

INSTALLATION

1. Choose appropriate bracket clamp, 1.5", 1.75", and 2", for the application. If using the MUD65P

with a ProFit or Prole style enclosure, use optional bracket MUDPFC, to attach speaker

enclosure to cage.

2. Attach bracket base to enclosure at desired angle using a minimum of two (2) M6-1.0x14mm Hex

bolts and M6 lock washers. If only two (2) bolts are used, ensure there is a bolt on each side of

the round base for secure mounting.

3. Slide bracket clamp over pipe or bar at desired mounting location.

4. Hold the enclosure in place where the base ts in the open section of the clamp. Then place the

M6-1.0x50mm Hex bolt through making sure the threads are towards the front of the enclosure.

See Figure 1.

5. Tighten the M6 serrated nut onto the bolt until the bracket is tight. The nut is serrated and will lock

in place. The speaker will not rotate on the bar if it is mounted when these are fully tightened.

6. Adjust and tighten the bolts to the desired position making sure to use a minimum of two bolts.

Depending on the position of the speaker, only two (2) insertion points will be usable.

7. Attach the MTX badge to the rear recess of the enclosure with the included double stick tape.

8. Connect the speaker wires to your amplier ensuring correct polarity Grey to positive and

Black to negative. The MUD65PL includes speaker illumination. When hard-wiring the RGB

lighting, the Black lead is +12V and the Red, Green, and Blue leads are ground. There are seven

colors available, depending on the wiring conguration. MTX recommends using the MUDLEDC

remote control (sold separately) for more colors, patterns and special effects. See Figure 2.

Figure 1

MTX.COM

Figure 2

RGB Ground

+12V –

2A Fuse (max)

(sold separately)

<7"

(17.5cm)

+12V

Color Combinations: Splice and combine the ground wires to yeild a different color.

Red Red

Green Green

Blue Blue

Red / Green Lime Green

Red / Blue Magenta

Green / Blue Aquamarine

Red / Green / Blue Blue-White

MTX.COM 5

The bracket base can rotate in any direction desired, a minimum of 2 bolts must be used, 1 on each side.

MTX.COM

NOTES:

MTX.COM 7

NOTES:

MTX.COM

of Mitek Corporation. All other trademarks are property of their respective owners. Designed and Engineered in

the U.S.A.

Due to continual product development, all specications are subject to change without notice.

MTX Audio, 4545 East Baseline Rd. Phoenix, AZ 85042 U.S.A. 1-800-225-5689

MTX005835 RevA 9/18 •21A10686 • AW0015692
