MTD 660 Series Guide de configuration

FORM NO.

769-00642B.fm

(10/24/2003)

PRINTED IN U.S.A.

Illustrated Parts Manual

Transmatic Lawn Tractor

MODELS 660, 680

662, 682

663, 683

665, 685

668, 688

MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-9722

Models 660, 665, 680 & 685

7†

7‡

5†1†

11†

2‡

19‡

21‡

23 27

323

†Found on Models 660 & 680 Only

‡Found on Models 665 & 685 Only

20‡

Models 660, 665, 680 & 685

REF.

NO. PART

NO. DESCRIPTION

1 728-0162 Flat-head Rivet, 1/4

2 710-0642 Self-tapping Screw, 1/4-20 x .75

3 712-0185 U-type Speed Nut, 1/4-20

4 712-0429 Lock Nut, 5/16-18

5 712-0324 Lock Nut, 1/4-20

6 726-0201 Speed Nut, .3125

7 726-04012 Push-on Nut, .25

8 731-1099A Lens

9 738-04015 Shoulder Screw, 5/16-18 x .625

10 738-0952A Shoulder Screw, 1/4-20 x .375 /.125

11 749-0722C Grille Support Rod

12 783-0250A Hood w/ Louvers

13 629-0469B Headlamp Harness Assembly

14 725-0963 Headlamp, 12V

15 725-1649 Headlamp Socket

16 731-1097F Grille

17 725-1396 Ignition Switch, 6-pin

18 725-0201 Keys (pair)

19 710-0751 Hex Screw, 1/4-20 x .620

20 783-0150B RH Side Panel

21 783-0151B LH Side Panel

22 17632D Support Bracket

23 710-0599 Self-tapping Screw, 1/4-20 x .5

24 710-0607 Self-tapping Screw, 5/16-18 x .5

25 710-0788 Self-tapping Screw, 1/4-20 x 1.0

26 726-3054 U-type Speed Nut, 1/4-20

27 731-04179 Dash Panel (models w/o choke knob)

731-04082 Dash Panel (models w/ choke knob)

28 746-04020A Throttle / Choke Control, 18.5”

746-04023A Throttle Control, 35.5”

746-04030A Throttle Control, 18.5”

29 736-3090 Flat Washer, .260 x .720 x .060

30 726-0230 Cable Tie, 34.75

31 751-0555B Fuel Tank, 1.5 gal.

32 751-0603 Fuel Tank Cap

33 746-0614A Choke Control, 38”

746-0616A Choke Control, 23”

34 731-0954 Steering Bellow, 4.75”

NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.

Models 662, 663, 682 & 683

†Found on Models 662 & 682 Only

‡Found on Models 663 & 683 Only

21‡

2‡

20‡

26 30

10†

15†

11†

18†

19†

NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.

Models 662, 663, 682 & 683

REF.

NO. PART

NO. DESCRIPTION

1 629-0469B Headlamp Harness Assembly

2 710-0642 Self-tapping Screw, 1/4-20 x .75

3 710-0751 Hex Screw, 1/4-20 x .620

4 710-3008 Hex Screw, 5/16-18 x .75

5 712-0185 U-type Speed Nut, 1/4-20

6 712-0429 Lock Nut, 5/16-18

7 712-3027 Lock Nut, 1/4-20

8 725-0963 Headlamp, 12V

9 725-1651 Headlamp Socket

10 726-04012 Push-on Nut, .25

11 728-0162 Flat-head Rivet, 1/4

12 731-1503A Lens

13 736-3078 Flat Washer, .344 x 1.0 x .063

14 738-0952A Shoulder Screw, 1/4-20 x .375 /.125

15 749-0722C Grille Support Rod

16 783-0156B Grille

17 783-0250A Hood w/ Louvers

18 783-0366 RH Side Panel (Insert)

19 783-0367 LH Side Panel (Insert)

20 783-0150B RH Side Panel

21 783-0367 LH Side Panel

22 725-1396 Ignition Switch, 6-pin

23 725-0201 Keys (pair)

24 746-0614A Choke Control, 38”

746-0616A Choke Control, 23”

25 17632D Battery Support Bracket

26 710-0599 Self-tapping Screw, 1/4-20 x .5

27 710-0607 Self-tapping Screw, 5/16-18 x .5

28 710-0788 Self-tapping Screw, 1/4-20 x 1.0

29 726-3054 U-type Speed Nut, 1/4-20

30 731-04179 Dash Panel (models w/o choke knob)

731-04082 Dash Panel (models w/ choke knob)

31 746-04020A Throttle / Choke Control, 18.5”

746-04023A Throttle Control, 35.5”

746-04030A Throttle Control, 18.5”

32 736-3090 Flat Washer, .260 x .720 x .060

33 726-0209 Cable Tie, 30.66

34 751-0555B Fuel Tank, 1.5 gal.

35 751-0603 Fuel Tank Cap

36 731-0954 Steering Bellow, 4.75”

Models 668 & 688

18 5

35 5

20 17 11

14/15

12 13

NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.

Models 668 & 688

REF.

NO. PART

NO. DESCRIPTION

1 629-0469B Headlamp Harness Assembly

2 683-0195 Bracket Assembly

3 710-0351 Screw, #10-16 x .50

4 710-0456 Screw, #10-16 x .50

5 710-0599 Self-tapping Screw, 1/4-20 x .5

6 710-0642 Self-tapping Screw, 1/4-20 x .75

7 710-0751 Hex Cap Screw:1/4-20 x .620

8 710-0896 Hex Index Washer Screw, 1/4-14 x .0625

9 710-3008 Hex Screw, 5/16-18 x .75

10 712-0185 U-type Speed Nut, 1/4-20

11 712-0431 Flange Lock Nut, 3/8-16

12 712-0429 Lock Nut, 5/16-18

13 712-3027 Flange Lock Nut, 1/4-20

14 725-0963 Headlamp, 12V

15 725-1649 Headlamp Socket

16 731-1854A Headlight Lens (8-style)

17 735-0126 Rubber Washer, .87 x .33

18 725-0201 Keys (pair)

19 736-0300 Flat Washer, .406 x .875 x .059

20 736-3039 Flat Washer, .406 x 1.5 x 11 gauge

21 736-3078 Flat Washer, .344 x 1.0 x .063

22 783-0475B LH Side Panel

23 783-0476C RH Side Panel

24 783-0477A Grille

25 783-0478B Hood

26 783-0553A Hood Support Bracket

27 783-1495 Hood Side Bracket

28 17632D Battery Support Bracket

29 710-0607 Self-tapping Screw, 5/16-18 x .5

30 710-0788 Self-tapping Screw, 1/4-20 x 1.0

31 726-3054 U-type Speed Nut, 1/4-20

32 731-04180 Dash Panel (models w/o choke knob)

731-04080A Dash Panel (models w/ choke knob)

33 736-3090 Flat Washer, .260 x .720 x .060

34 746-0614A Choke Control, 38”

746-0616A Choke Control, 23”

35 746-04020A Throttle / Choke Control, 18.5”

746-04023A Throttle Control, 35.5”

746-04030A Throttle Control, 18.5”

36 726-0209 Cable Tie, 30.66

37 751-0555B Fuel Tank, 1.5 gal.

38 751-0603 Fuel Tank Cap

39 725-1396 Ignition Switch, 6-pin

Models 660 – 688

814

30710

534

12 41

Models 660 – 688

REF.

NO. PART

NO. DESCRIPTION

1 17198A Retainer Gear Segment Plate

2 683-0002A Pivot Bar, .625

3 710-0514 Hex Cap Screw, 3/8-16 x 1.0

4 710-0643 Hex Cap Screw, 5/16-18 x 1.0

5 710-0726 Self-tapping Screw, 5/16-12 x .75

6 710-0805 Hex Cap Screw, 5/16-18 x 1.5

7 710-1309 Machine Screw, 5/16-18 x .75

8 712-0240 Jam Nut, 7/16-20 (Grade 2)

9 712-0262 Jam Nut, 3/8-24

10 712-0431 Flange Lock Nut, 3/8-16

11 712-3004A Flange Lock Nut, 5/16-18

12 714-0470 Cotter Pin, 1/8 x 1.25

13 717-1757A Stearing Segment Gear

14 723-0448A Ball Joint, 7/16 -20

15 726-0214 Push Cap, .625

16 731-04057A Axle End Cap, Standard

17 736-0187 Flat Washer, .64 x 1.24 x .060

18 731-2290A Deluxe Hub Cap

19 736-0242 Bell Washer, .34 x .872 x .060

20 736-0356 Bell Washer, .391 x .380 x .062

21 731-04039 Steering Wheel Cap, Small

731-04040 Steering Wheel Cap w/ Sprig, Small

22 738-0141 Shoulder Screw, .435 x .350, 5/16-18

23 738-0527 Shoulder Screw, .498 x 2.045

24 738-0919 Steering Shaft, 21.86

25 741-0475 Plastic Bushing, .38 ID

NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.

26 741-0487A Flange Bushing, .632 ID

27 741-0656 Hex Flange Bearing, 5/8

28 747-04008 Tie Rod, Non-adjustable

29 747-1268B Steering Drag Link, 7/16-20

30 748-0389 Cap, 1.25 x .16

31 748-04014B Steering Arm

32 748-04020 Spacer, 1.0 x .645 x .56

33 750-0535 Spacer, .380 x .625 x .21

34 783-0041D Pivot Bar Bracket

35 631-04028 Steering Wheel, Three Spoke

631-04008 Steering Wheel, Three Spoke Soft Grip

36 731-04058 Axle End Cap, w/ Fitting

37 731-04064 Steering Wheel Cap, Large

731-04065 Steering Wheel Cap w/ Sprig, Large

38 634-0056A Round Shoulder Wheel Ass’y Complete

634-0105A Square Shoulder Wheel Ass’y Complete

634-0115 Square Shoulder Wheel Ass’y Complete

39 683-04016 RH Axle Assembly

683-04015 LH Axle Assembly

683-04014 RH Axle Ass’y (models with 46-in Deck)

683-04013 LH Axle Ass’y (models with 46-in Deck)

40 731-0484A Hub Cap

41 736-0162 Flat Washer, .64 x 1.0 x .12

42 736-0285 Flat Washer, .635 x 1.589 x .06

43 747-04057 Tie Rod, Adjustable

44 711-04059 Ferrule, 3/8-24 x .437 Dia

REF.

NO. PART

NO. DESCRIPTION

Wheel Ass’y

Complete Rim Assembly Inner Bearing Outer Bearing Tire Only Air Valve

Round Shoulder 634-0056A 634-0172 741-0706

(Flange w/ Fitting) 741-0487A

(Plastic Flange) 734-0864

(15 x 6 x 6) 734-0255

Square Shoulder 634-0105A 634-0172 741-0706

(Flange w/ Fitting) 741-0487A

(Plastic Flange) 734-1731

(15 x 6 x 6) 734-0255

Square Shoulder 634-0115 634-0051 741-0569

(Ball Bearing) 741-0569

(Ball Bearing) 734-1731

(15 x 6 x 6) 734-0255

Round ShoulderSquare Shoulder

Models 660 – 688

11*

13 31**

1718

32**

19**

32**

19**

31**

23 4

* Attach the short end of spring to the notch in the rear

of Ref. No. 2. Attach the long end to Ref. No. 1.

** Shown in orientation for 38-inch deck. Found on tractor

models with 38- or 42-inch deck only.

Models with Knob-adjust Seat

38 29

Models with

Quick-adjust Seat
