MSI MS-4413 Manuel utilisateur
MS-4413
Accelerated Graphic Port
VERSION1.0
1997/10/01ROC
User’sGuide
FCC-BRadioFrequencyInterferenceStatement
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference, in which case the
user will be required to correct the interference at his own expense.
Notice1
The changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Notice2
Shielded interface cables and A.C. power cord, if any, must be used in order
to comply with the emission limits.
VOIRLANOTICED’INSTALLATIONAVANTDERACCORDERAU
RESEAU.
MICRO-STAR
FOR HOME OR OFFICE USE
Tested to Comply
with FCC Standard
MS-4413
MS-4413
Accelerated Graphic Port
The material in this document is the intellectual property of MICRO-
STAR INTERNATIONAL. Wetake everycare inthe preparationof
this document, but no guarantee is given as to the correctness of its
contents. Our products are under continual improvement and we
reserve the right to make changes without notice.
Copyright Notice
Trademarks
All trademarks used in this manual are the sole property of their
respective owners.
VGA is a trademark of International Business Machines Corporation.
Pentium is a registered trademark of Intel Corporation.
Windows is a registered trademark of Microsoft Corporation.
User’sGuide
Table of Contents
Chapter 1 MS-4413 3DLABs Permedia 2 AGP
True 3D VGA Card
1. Overview ............................................................... 1-1
2. Features................................................................ 1-1
ChipList...........................................................................1-1
Full support for Intel’s Accelerated Graphics Port (AGP) ....
.........................................................................................1-1
Enhanced 3D graphics features and performance....... 1-1
Integrated 100MFlop Glint Delta Geometry pipeline setup ..
processor ..................................................................... 1-2
Integratedtrue-color230MHz RAMDAC........................ 1-2
Fully Microsoft®
PC97 and Intel®
GPC compliant.......... 1-2
MemorySupport ........................................................... 1-2
2D Driver ...................................................................... 1-2
3D Driver ...................................................................... 1-2
Resolutions Supported ................................................. 1-3
3. SystemRequirements..................................................1-4
4. PackageContents.........................................................1-4
5. CardLayout....................................................................1-5
6. DB15PinConnector.....................................................1-6
7. VerticalRefreshRate.....................................................1-7
MS-4413
Accelerated Graphic Port
Chapter 2 Installation of MS-4413 VGA Drivers
1. Driver ..................................................................... 2-1
1.1 Install Enhance Drivers for Windows®
95................ 2-1
1.2 Install Enhance Drivers for Windows®
NT ............... 2-8
1.3 Install Enhance Drivers for Windows®
98 (Memphis)
........................................................................................... 2-15
User’sGuide
1-1
Chapter 1
MS-4413 3DLABs Permedia 2 AGP
True 3D VGA Card
1. Overview
TheMS-4413 3DLABs Permedia2 AGP True3D VGA cardis a
high performance graphics card that integrates high quality
3D polygon and textured graphics acceleration, windows
accelerationand state-of-the-art MPEG1/MPEG2 playback
with fast integrated SVGA core, integrated RAMDAC and
video ports.
2. Features
Chip List:
r3DLABsPermedia 2: 2D & 3D accelerator processor w/
build-inGlint setup engine and 230MHz RAMDAC.
Full support for Intel’s Accelerated Graphics Port
(AGP)
l66MHz operation
lDMA support
lExecute mode support
lFull sideband addressing
Enhanced 3D graphics features and performance
l800k Polygons/sec Texture Mapped
lPolygon-based with Z-buffer
lTrue-color 3D graphics
lTexture decompression
lFull scene anti-aliasing
MS-4413
Accelerated Graphic Port
1-2
l83Mperspective correct, bilinear-filtered, texture-mapped
pixel/sec
l42Mperspective correct, bilinear-filtered, texture-mapped,
depth buffered pixel/sec
Integrated 100MFlop GLINT Delta Geometry
pipeline setup processor
Integrated true-color 230 MHz RAMDAC
lDPMS,DDC1and DDC2AB+
lClock synthesizer and Hardware cursor
Fully Microsoft PC97 and Intel GPC compliant
Memory Support
lOn-board4MB or8MB(optional), High-performance
Synchronous Graphics RAM (SGRAM)
2D Driver
lWindows®
95/98 with DirectDraw
lWindows®
NT with DirectDraw
lQuickDraw
3D Driver
lDirect3D
lOpenGL
lCreativelabs’ CGL
lQuickdraw3D and RAVE
lAutodesk’sHeidi for 3D Studio MAX
User’sGuide
1-3
Resolutions Supported
l640x480x32bpp
l800x600x32bpp
l1024x768x32bpp
l1152x870x32bpp
l1280x1024x32bpp
l1600x1200x16bpp
MS-4413
Accelerated Graphic Port
3. System Requirements
To install MS-4413 VGA card, your computer system needs to
meet the following requirements:
Computer Intel Pentium®
II processor or compatible
system
ExpansionSlot AGP slot
Monitor VGASupport,minimum640x480resolution
Operatingsystem Windows®
95, Windows®
98,
Windows®
NT 3.51 or 4.0
CD-ROM Double Speed or Higher
4. Package Contents
Before installing the MS-4413 VGA card, please check to make
sure that your package is complete:
lVGAcard
lCD-ROM
- drivers and applications on CD-ROM
- documentation on CD-ROM
lUser’sGuide
1-4
User’sGuide
5. Card Layout
1-5
1. J1 VGA Connector
2. U1 3DLABs Permedia 2
3. Y1 Crystal 14.31818MHz
4. U5~U12 256kx32SGRAM
5. U2 VGA BIOS
JP2
Y1
U1
U2
U5
U6 U8 U10 U12
U7 U9 U11
J1
Jumper Setting: JP2
Short1-2 VGAEnable
Short2-3 VGADisable
