MSI Mega Player 515 Lite Manuel utilisateur

MEGA PLAYER 515 LITE

The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL.

We take every care in the preparation of this document, but no guarantee is given as to the

correctness of its contents. Our products are under continual improvement and we reserve

the right to make changes without notice.

TRADEMARKS

All trademarks are the properties of their respective owners.

MICRO-STAR INTERNATIONAL STATEMENT

All contents are subject to change without notice.

One year guarantee is for the device only. Warranty for accessories expired within seven

days of purchase date.

WEEE STATEMENT

To protect the global environment and as an environmentalist, MSI must

remind you that...

Under the European Union ("EU") Directive on Waste Electrical and

Electronic Equipment, Directive 2002/96/EC, which takes effect on

August 13, 2005, products of "electricaland electronic equipment" cannot

be discarded as municipal waste anymore and manufacturers of covered

electronic equipment will beobligatedto take back suchproducts at the end of their useful life.

MSI will comply with the product take back requirements at the end of life of MSI-branded

products that are sold into the EU. You can return these products to local collection points.

Operation Menus

Music File names

Voice File names

Playlist Decide which folder or which music file will be played.

EQ Normal/ Rock/ Jazz/ Classical/ Pop

Repeat Normal/ Repeat One/ Repeat All/ Shuffle/ Shuffle Rep

Power Off Disable/ 1 Min/ 2 Mins/ 5 Mins/10 Mins

Record Rate Standard/Better/Best

Language Supports up to 10 languages, the supported languages

may vary from country to country.

Startup Logo Startup logo files (.mlg)

Settings

Exit Exit to the main menu

Del Music Delete a Music file (.mp3)

Del Voice Delete a Voice/ FM recorded file (.wav)

Del All Music Delete all Music files

Del All Voice Delete all Voice or FM radio recording files

Delete

File

Exit Exit to the main menu

About Show Firmware Version and Memory Status

Exit Exit to the playback mode

Figure 1.

Figure 2.

001/024

MP3

02:35/04:58

56789

10 11

14 15 17

English

Figure 1. Overview

1. Power On/Off

Play/Pause

2. 5-way MENU button

Fast-Forward/ Rewind

Volume+/-

3. FM / A->B

4. REC

5. Hold Switch

6. Earphone Jack

7. USB Connector

8. MIC

Figure 2. Display

1. Function Status

2. Numbers of Files

3. File Info

4. File Name

5. Hold (Lock) Switch

6. Play Mode

7. Playback Status

8. A to B Repeat

9. Repeat Mode

10. Equalizer

11. Battery Status

12. FM Frequency (optional)

13. Recording Status

14. Recording Timer

15. Recording File Name

16. Function Status

17. Operation Menu

English

Power On/Off

1.Press / button once to turn the power on.

2.To power off MEGA PLAYER 515 Lite, press and hold / button

until the power is switched off. Check the display to see the power off

status, and note that it takes about three to five seconds to turn the

power off.

Li-ion Battery Recharging

1.Plug in one end of the USB cable to MEGA PLAYER 515 Lite,

connect the other end to the optional AC adapter, and plug it to AC

power outlet. (Or connect MEGA PLAYER 515 Lite and the computer

by the USB cable directly.)

2.While recharging is on going, a lightning icon in the display will be

flashing rapidly.

3.To stop recharging, simply disconnect the USB cable from MEGA

PLAYER 515 Lite.

Note: The build-in battery will also start recharging when MEGA

PLAYER 515 Lite is connected to the computer with the supplied

USB cable.

Hold Switch

Slide Hold Switch to the “LOCK” position to disable the function keys for

preventing accidental operation.

English

USB Connection

1.Plug one end of the supplied USB cable to your computer, and plug

the other end to MEGA PLAYER 515 Lite.

2.Once MEGA PLAYER 515 Lite is connected to the computer, it

should be detected by the operating system automatically.

Note: If the operating system of your computer is Windows 98SE, a

hardware driver for MP3 Player will be required. Insert the

supplied driver CD, and install the hardware driver by following the

on-screen instructions.

Note: To format the MP3 Player, please use the supplied driver

CD’s Format Utility to ensure the format quality.

USB Flash Disk

To save data into the memory of this USB Disk, simply connect it to your

computer, and use Windows Explorer to manage your data.

Music Playback (Default Mode)

1. Press /button to play the current selected file.

2. During playback, press /button again to pause the playback.

3. During playback, push Menu button to the right or left once to skip to

the next or the previous track.

4. To fast-forward or rewind the playback, push and hold Menu button to

the right or left to fast-forward or rewind the current track.

English

Editing Play List

1.Press Menu button once, and push it to the right or left to select

PLAYLIST. Press Menu button again to enter PLAYLIST mode.

2.To locate a previous or next folder, push Menu button up or down

repeatedly. To select or deselect a folder, press Menu button. The

check box goes empty when the folder is deselected. Read the check

box to see if a folder is selected or deselected.

3.To enter a located folder, push Menu button to the right once. To leave

the folder, push Menu button to the left once.

4.To locate a previous or next song (file), push Menu button up or down

repeatedly. To select or deselect a song, press Menu button. The

check box goes empty when the song is deselected. Read the check

box to see if a song is selected or deselected.

FM Radio Mode (optional feature)

1.Select FM Mode by pressing FM/A-B button once.

2.Use Menu button to select desired station by pushing it right or left.

3.To record broadcasting program, press REC button to start.

4.To stop recording, press REC button again.

5.To leave FM Mode, press FM/A-B button again.

Voice Recording

1.Press REC button to start voice recording function.

2.To stop recording, press REC button again.

English

Language Learning Function

1.During music playback, press FM/A-B button to select the starting

point. Then, press FM/A-B button again to select the ending point.

2.Then, you will see the indicator of A-B appearing on the screen, and

that means you have set the repeating playback successfully and you

will now hear the repeating playback again and again.

3.To cancel the repeating playback and return to the normal playback,

simply press FM/A-B button again, and the indication of A-B will

disappear from the Display.

5-way Menu button

The 5-way Menu button includes most functions designed for MEGA

PLAYER 515 Lite. With this button, you can adjust various settings.

Press down Menu button to enter operation menu, and push Menu

button to the right or the left to make different adjustments. During

playback, push Menu button to the right or the left to go to next or

previous track. Press down Menu button and push it up or down to

adjust volume.

Special Features

You can select or edit a logo to show on the screen by using the Screen

Editor program when power up MEGA PLAYER 515 Lite. The Screen

Saver will run automatically to protect the OLED screen.

Srpski

Slika 1. Pregled

1. Uključivanje/Isključivanje

(On/Off)

Reprodukcija/Pauziranje

2. Petosmerni MENI taster

Premotavanje unapred/unazad

Jačina zvuka+/-

3. FM / A->B

4. REC (snimanje)

5. Taster za blokiranje

6. Utičnica za slušalice

7. USB konektor

8. Mikrofon

Slika 2. Displej

1. Status funkcije

2. Broj fajlova

3. Informacije o fajlu

4. Ime fajla

5. Tajmer

6. Taster (brava) za blokiranje

7. Režim reprodukcije

8. Status reprodukcije

9. Ponavljanje od A do B

10. Režim sa ponavljanjem

11. Ekvilajzer

12. Status baterije

13. FM Frekvencija

14. Status snimanja

15. Tajmer snimanja

16. Ime fajla koji se snima

17. Status funkcije

18. Meni operacija
