MSI US54G Manuel utilisateur
1. ENGLISH................................................…3
2. DEUTSCH................................................13
3. FRANÇAIS...............................................23
4. ESPAÑOL................................................33
5. ITALIANO.................................................43
6. NEDERLANDS........................................ 53
7. ČESKY..................................................... 63
8. PORTUGUÊS.......................................... 73
9. POLSKI....................................................83
10. PУCCKИЙ................................................93
11. Polski.....................................................103
12. Pols........................................................113
13. Polski.....................................................123
14. ไทย...................................................….133
15. 简体中文.................................................143
16. 繁體中文.................................................153
Version 1.0
P/N: G52-C6861X1
For Radio Product (purly) (EMC+LVD+RF)
EC DECLARATION OF CONFORMITY (EUROPE)
MICRO-STAR INTERNATIONAL declares that the Wireless 11g USB2.0
Stick (MSI US54G) conforms to the specifications listed below, following
the provisions of the European R&TTE directive 1999/5/EC and Low
Voltage Directive 73/23/EEC:
EN 301 489-1..., EN301 489-n (n depends on product requirement) General
EMC requirements,
EN 609 50 Safety requirement,
EN 300 328-2 Technical requirement for Radio equipment.
NOTE: This equipment is intended to be used in all EU and EFTA countries.
Outdoor use may be restricted to certain frequencies and/or may require a
license for operation. For more details, please contact MICRO-STAR
INTERNATIONAL.
NOTE: Combinations of power levels and antennas resulting in a radiated
power level of above 100 mW are considered as not compliant with the
above mentioned directive and are not allowed for use within the European
community and countries that have adopted the European R&TTE directive
1999/5/EC and/or the CEPT recommendation Rec 70.03. For more details
on legal combinations of power levels and antennas, please contact
MICRO-STAR INTERNATIONAL.
Technical Support:
1. Visit the MSI website for technical guide, driver and software updates,
and other information: http://www.msi.com.tw/
ENGLISH
4
Before You Begin
This Quick Start Guide can be used for your MSI US54G – the
Wireless 11g USB2.0 Stick, providing you with easy installation steps
to help you build your network easily and quickly. For further
instructions, please refer to your User’s Guide. For the latest
information or other technical support, please visit MSI website at:
http://www.msi.com.tw.
How to Use This Guide
If you want to... refer to...
install your wireless network adapter page 5
install software page 6 ~ 7
connect the network page 8 ~ 11
5
QuickStartGuide
Hardware Installation
Connection 1
The hardware installation for US54G is simply plugging it into an
available USB port on your desktop/notebook computer.
Connection 2
If necessary, you can connect the provided USB cable to your
computer, and connect US54G to the cable.
USB port
Installing US54G
6
Software Setup
After installing the wireless adapter to your computer and then turning
on the computer, the operating system will detect a new device and
start the configuration automatically. Please CANCEL the system’s
Add New Hardware Wizard here to install the required driver and
utility from InstallShield Wizard of your Software CD.
Insert the Software CD into your CD-ROM drive, and the Setup
program should launch automatically.
If the Autorun program does not launch automatically, click Start at
the taskbar and select Run.... Type E:\setup.exe (where E is your
CDROM drive) in the Open box and click OK to launch the Setup
program manually.
The main screen of Setup program will appear as below. Click the
Install Software button.
X
7
QuickStartGuide
Software Setup (2)
The welcome screen of InstallShield Wizard appears. Click Next.
Read and accept the License Agreement; then, click Next.
In the following window, enter the user’s information (User Name and
Organization) in the respective fields; then, click Next.
Click Install and the program will copy the necessary files to the
system. The progress indicator shows the installing status.
Click Finish when the installation is completed. The MSI Wireless
LAN icon will appear in the status area.
MSI Wireless LAN icon
Y
Z
[
8
Connecting Network
After installing the software, the MSI wireless adapter provides you
with a convenient and powerful utility that allows you to set up,
configure, and know your networking status easily and clearly.
Your MSI wireless adapter can be used by two networking modes:
Infrastructure mode and Ad-hoc mode.
Infrastructure Mode allows your computer to communicate with the
other computers in the network through an Access Point.
To connect the Access Point:
1. Click the MSI Wireless LAN icon to bring up the Wireless
Network Connection window.
2. In the list of Available wireless networks, select (highlight) the
network you want, and then click Connect.
select
click
9
QuickStartGuide
Connecting Network (2)
Advanced Settings for Infrastructure Mode
Follow the instructions below to configure advanced settings in the
Infrastructure mode.
1. Click Advanced in the Wireless Network Connection window.
2. You can click Refresh to search the available Access Points in the
network again. The results will be displayed in the Available
Networks field.
3. Select one network (Access Point) you want, and click Configure
to set up the selected network.
4. For security purpose, you can set up the Network Key and
Authentication.
5. Click OK to complete the configuration. The MSI Wireless LAN
icon indicates the connection status.
10
Connecting Network (3)
Ad-hoc Mode allows your computer to communicate directly with any
computer installed with compatible wireless adapter.
To build the Ad-hoc network:
1. Click the MSI Wireless LAN icon to bring up the Wireless
Network Connection window. Then, click Advanced.
2. Click Add.
3. Set up the Network Name (SSID) and Network Key (if needed)
for the Ad-hoc network.
4. Check “This is a computer-to-computer [ad hoc] network;
wireless access points are not used” option and click OK to
enable the Ad-hoc mode, and return to the Wireless Connection
window.
