Find the MSA MiniOX at our website: Click HERE

MiniCO®, MiniH2S®,

MiniOX®, MiniOX®Remote,

MiniCl2TM, and MiniClO2TM

Responder®Detectors

Instruction Manual

"! WARNING

THIS MANUAL MUST BE CAREFULLY READ BY ALL

INDIVIDUALS WHO HAVE OR WILL HAVE THE

RESPONSIBILITY FOR USING OR SERVICING THESE

PRODUCTS. Like any complex equipment, these

instruments will perform as designed only if used and

serviced in accordance with the manufacturer’s

instructions. OTHERWISE, THEY COULD FAIL TO

PERFORM AS DESIGNED AND PERSONS WHO RELY

ON THESE PRODUCTS FOR THEIR SAFETY COULD

SUSTAIN SEVERE PERSONAL INJURY OR DEATH.

The warranties made by Mine Safety Appliances

Company with respect to the product are voided if the

product is not used and serviced in accordance with

the instructionsin this manual. Please protectyourself

and others by following them. We encourage our

customers to write or call regarding this equipment

prior to use or for any additional information relative

to use or repairs.

In the U.S., to contact your nearest stocking location,

dial toll-free 1-800-MSA-2222.

To contact MSA International, dial 1-412-967-3354.

This manual is available on the internet at

www.msanet.com

Manufactured by

MINE SAFETY APPLIANCES COMPANY

P.O. Box 427, Pittsburgh, Pennsylvania 15230

(L) Rev 5 10004100

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents

Section 1

MiniCO®Responder Carbon Monoxide

Detector (P/Ns 710424, 710510,

10008671 and 10008673) . . . . . . . . . . 1-1

Instructions for Use and Maintenance. 1-1

"WARNINGS . . . . . . . . . . . . . . . . . . 1-1

"CAUTIONS. . . . . . . . . . . . . . . . . . . 1-2

Turning ON/OFF. . . . . . . . . . . . . . . . . . 1-2

FAS (Fresh Air Setup) . . . . . . . . . . . . . 1-2

Gas Alarms. . . . . . . . . . . . . . . . . . . . . . 1-2

Low Battery Alarm . . . . . . . . . . . . . . . . 1-3

Vibrating Alarms . . . . . . . . . . . . . . . . . . 1-3

Backlight . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Peak Readings . . . . . . . . . . . . . . . . . . . 1-3

Calibration Check/Adjustment. . . . . . . . 1-4

Setting Alarm Setpoints . . . . . . . . . . . . 1-4

Installing/Replacing the Battery . . . . . . 1-5

"CAUTION. . . . . . . . . . . . . . . . . . . . 1-5

Replacing Sensor Assembly. . . . . . . . . 1-5

Hot Gas Sampling . . . . . . . . . . . . . . . . 1-5

Specifications . . . . . . . . . . . . . . . . . . . . 1-6

Interferant Data. . . . . . . . . . . . . . . . . . . 1-7

Replacement Parts . . . . . . . . . . . . . . . . 1-7

Table of Contents

TOC-1

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Section 2

MiniH2S®Responder

Hydrogen Sulfide Detector

(P/Ns 710850 and 10008672). . . . . . . 2-1

Instructions for Use and Maintenance. 2-1

"WARNINGS . . . . . . . . . . . . . . . . . . 2-1

"CAUTIONS. . . . . . . . . . . . . . . . . . . 2-2

Turning ON/OFF. . . . . . . . . . . . . . . . . . 2-2

FAS (Fresh Air Setup) . . . . . . . . . . . . . 2-2

Gas Alarms. . . . . . . . . . . . . . . . . . . . . . 2-2

Low Battery Alarm . . . . . . . . . . . . . . . . 2-3

Vibrating Alarms . . . . . . . . . . . . . . . . . . 2-3

Backlight . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Peak Readings . . . . . . . . . . . . . . . . . . . 2-3

Calibration Check . . . . . . . . . . . . . . . . . 2-3

Setting Alarm Setpoints . . . . . . . . . . . . 2-4

Installing/Replacing the Battery . . . . . . 2-4

Replacing Sensor Assembly. . . . . . . . . 2-5

Specifications . . . . . . . . . . . . . . . . . . . . 2-5

Interferant Data. . . . . . . . . . . . . . . . . . . 2-6

Replacement Parts . . . . . . . . . . . . . . . . 2-6

Section 3

MiniOX®Responder Oxygen Detector

(P/Ns 710965 and 10008676). . . . . . . 3-1

Instructions for Use and Maintenance. 3-1

"WARNINGS . . . . . . . . . . . . . . . . . . 3-1

Table of Contents

TOC-2

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

"CAUTIONS. . . . . . . . . . . . . . . . . . . 3-2

Turning On/OFF . . . . . . . . . . . . . .. . . . 3-2

FAS (Fresh Air Setup) . . . . . . . . . . . . . 3-2

Gas Alarms. . . . . . . . . . . . . . . . . . . . . . 3-2

Low Battery Alarm . . . . . . . . . . . . . . . . 3-3

Vibrating Alarms . . . . . . . . . . . . . . . . . . 3-3

Backlight . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Peak Readings . . . . . . . . . . . . . . . . . . . 3-3

Calibration Check . . . . . . . . . . . . . . . . . 3-3

Setting Alarm Setpoints . . . . . . . . . . . . 3-4

Installing/Replacing the Battery . . . . . . 3-4

Replacing Sensor Assembly. . . . . . . . . 3-4

Specifications . . . . . . . . . . . . . . . . . . . . 3-5

Replacement Parts . . . . . . . . . . . . . . . . 3-5

Section 4

MiniOX®Responder

Remote Oxygen Detector

(P/Ns 10001923 and 10008675). . . . . 4-1

Instructions for Use and Maintenance. 4-1

"WARNINGS . . . . . . . . . . . . . . . . . . 4-1

"CAUTIONS. . . . . . . . . . . . . . . . . . . 4-2

Turning ON/OFF. . . . . . . . . . . . . . . . . . 4-2

FAS (Fresh Air Setup) . . . . . . . . . . . . . 4-2

Gas Alarms. . . . . . . . . . . . . . . . . . . . . . 4-2

Low Battery Alarm . . . . . . . . . . . . . . . . 4-3

Vibrating Alarms . . . . . . . . . . . . . . . . . . 4-3

Table of Contents

TOC-3

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Backlight . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Peak Readings . . . . . . . . . . . . . . . . . . . 4-3

Calibration Check . . . . . . . . . . . . . . . . . 4-4

Setting Alarm Setpoints . . . . . . . . . . . . 4-4

Installing/Replacing the Battery . . . . . . 4-4

Replacing Sensor Assembly. . . . . . . . . 4-5

Specifications . . . . . . . . . . . . . . . . . . . . 4-5

Section 5

MiniCl2TM Responder

Chlorine Detector

(P/Ns 10020744 and 10020747). . . . . 5-1

Instructions for Use and Maintenance. 5-1

"WARNINGS . . . . . . . . . . . . . . . . . . 5-1

"CAUTIONS. . . . . . . . . . . . . . . . . . . 5-2

Turning ON/OFF. . . . . . . . . . . . . . . . . . 5-2

FAS (Fresh Air Setup) . . . . . . . . . . . . . 5-2

Gas Alarms. . . . . . . . . . . . . . . . . . . . . . 5-2

Low Battery Alarm . . . . . . . . . . . . . . . . 5-3

Vibrating Alarms . . . . . . . . . . . . . . . . . . 5-3

Backlight . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Peak Readings . . . . . . . . . . . . . . . . . . . 5-3

Calibration Check . . . . . . . . . . . . . . . . . 5-3

Setting Alarm Setpoints . . . . . . . . . . . . 5-4

Installing/Replacing the Battery . . . . . . 5-4

Replacing Sensor Assembly. . . . . . . . . 5-5

Specifications . . . . . . . . . . . . . . . . . . . . 5-5

Table of Contents

TOC-4

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Interferant Data. . . . . . . . . . . . . . . . . . . 5-6

Replacement Parts . . . . . . . . . . . . . . . . 5-7

Special Instructions. . . . . . . . . . . . . . . . 5-7

Section 6

MiniCLO2TM Responder

Chlorine Dioxide Detector

(P/Ns 10020745 and 10020749). . . . . 6-1

Instructions for Use and Maintenance. 6-1

"WARNINGS . . . . . . . . . . . . . . . . . . 6-1

"CAUTIONS. . . . . . . . . . . . . . . . . . . 6-2

Turning ON/OFF. . . . . . . . . . . . . . . . . . 6-2

FAS (Fresh Air Setup) . . . . . . . . . . . . . 6-2

Gas Alarms. . . . . . . . . . . . . . . . . . . . . . 6-2

Low Battery Alarm . . . . . . . . . . . . . . . . 6-3

Vibrating Alarms . . . . . . . . . . . . . . . . . . 6-3

Backlight . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Peak Readings . . . . . . . . . . . . . . . . . . . 6-3

Calibration Check . . . . . . . . . . . . . . . . . 6-3

Setting Alarm Setpoints . . . . . . . . . . . . 6-4

Installing/Replacing the Battery . . . . . . 6-5

Replacing Sensor Assembly. . . . . . . . . 6-5

Specifications . . . . . . . . . . . . . . . . . . . . 6-6

Interferant Data. . . . . . . . . . . . . . . . . . . 6-7

Replacement Parts . . . . . . . . . . . . . . . . 6-7

Special instructions. . . . . . . . . . . . . . . . 6-7

Table of Contents

TOC-5

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Section 7

Suggested Daily Use for All Units

(MiniCO unit shown) . . . . . . . . . . . . . 7-1

Table of Contents

TOC-6

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Section 1

MiniCO®Responder Carbon

Monoxide Detector (P/Ns 710424,

710510, 10008671 and 10008673)

Instructions for Use and Maintenance

"WARNINGS

FAILURE TO FOLLOW CAN RESULT IN

SERIOUS PERSONAL INJURY OR DEATH:

1. The MiniCO Responder is designed to

measure carbon monoxide in air only. Do

not use these detectors to sample for CO

in gases other than air.

2. Alarm functions must be checked and a

response check must be performed before

each day’s use. If the instrument fails the

response check and cannot be calibrated,

DO NOT use the instrument. The sensor

or battery must be replaced, or the

instrument must be serviced.

3. Calibration must be checked if the sensor

is replaced, if the battery is replaced, or if

the instrument is dropped or subjected to

severe physical shock.

4. The CO sensors are sealed units containing

sulfuric acid electrolyte. If a sensor

develops a leak, dispose of it properly.

Should contact occur with skin or clothing,

rinse area with large quantities of water. In

case of eye contact, immediately flush eyes

for at least 15 minutes, holding eyes open;

call a physician.

5. Do not change the battery in

hazardous locations.

6. Substitution of components may impair

intrinsic safety.

7. Once a high alarm condition is detected

and the alarms latch, the displayed

reading may not fall within the specified

accuracy range for the instrument.

Section 1, MiniCO Responder

1-1

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

"CAUTIONS

To prevent sensor damage, store the

instrument under the following conditions:

INTERMITTENT

TEMPERATURE OPTIMAL

STORAGE

TEMPERATURE

-30oC to 50oC

(-20oF to 120oF) 4oC to 32oC

(40oF to 90oF)

Turning ON/OFF

When unit is delivered, the battery is not

connected. See "Installing/Replacing the Battery"

later in this section prior to use. To turn the

instrument ON, press the Power/Peak button on

the left-hand side of the display. All segments of

the display light upon turn-ON. To turn OFF the

monitor, press and hold the Power/Peak button

for five seconds. After a series of beeps, the

display turns OFF.

NOTE: MiniCO Responder (P/Ns 710510 and

10008673) are designed in such a way

that the only way to turn the instrument

OFF is to disconnect the battery.

FAS (Fresh Air Setup)

Upon instrument turn-ON, the display flashes

"zero." While the "Zero" is flashing, pressing the

Zero button zeroes the instrument. The monitor

will not zero out background concentrations

greater than 5 ppm. If a concentration higher

than this is detected, the instrument will display

the actual concentration and not zero out the

background.

Gas Alarms

There are two levels of audible and visual

alarms. The warning level alarms are low-rate

intermittent and non-latching. This is indicated by

a "W" on the display and a beep approximately

every five seconds on P/N 710424 and every

Section 1, MiniCO Responder

1-2

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels MSA Capteur de sécurité

MSA

MSA General Monitors FL500 UV/IR Manuel utilisateur

MSA

MSA Ultima OPIR-5 Manuel utilisateur

MSA

MSA Sirius Manuel utilisateur

MSA

MSA FL500 UV/IR Manuel utilisateur

MSA

MSA General Monitors TL105 Manuel utilisateur

MSA

MSA Evotech Instructions de fonctionnement

MSA

MSA FlameGard 5 MSIR HART Manuel utilisateur

MSA

MSA altair 5 Manuel technique

MSA

MSA FireHawk M7 Manuel utilisateur

MSA

MSA S-Cap-Air Manuel utilisateur

MSA

MSA ExtendAire II Series Manuel utilisateur

MSA

MSA Ultra Elite-PF Manuel utilisateur

MSA

MSA Altair Manuel utilisateur

MSA

MSA ICM 2000 Manuel utilisateur

MSA

MSA Hip-Air Instructions d'utilisation

MSA

MSA FireHawk M7XT Manuel utilisateur

MSA

MSA PointGuard Concrete Anchorage Connector... Manuel utilisateur

MSA

MSA FireHawk M7XT ExtendAire II Manuel d'utilisation et d'entretien

MSA

MSA V-TEC PFL Manuel utilisateur

MSA

MSA ALTAIR5 Manuel utilisateur

MSA

MSA FlameGard 5 UV/IR-E Manuel utilisateur

MSA

MSA Ultima OPIR-5 Mode d'emploi

MSA

MSA ALTAIR 5X Manuel utilisateur

MSA

MSA ALTAIR 5X Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur
