OPERATING INSTRUCTIONS FOR

"MR. COFFEE”,

SR. SERIES

COFFEEMAKER

MODEL SRX20

Featuring...

Two Hour Automatic Shutoff

On/Off Indicator Light

Automatic Pause ‘N Serve drip stop valve

24 Hour Digital Clock Timer

12 cup capacity

FOR HOUSEHOLD USE ONLY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed to reduce the risk of fire, electric shock. and/

or injury to persons, including the following:

Read all instructions before using

the

machine.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electric shock do not immerse cord, plugs,

or machine in water or other liquid.

4. Close supervision is necessary when any appliance is used

by or near children.

5. Turn control switch OFF and unplug from outlet when not

in use and before cleaning. Allow to cool before putting on

or taking off parts, and before cleaning.

6. Do not operate any appliance with a damaged cord or plug

or after the appliance malfunctions, or has been damaged in

any manner. Return this appliance only to the nearest

authorized service center for repair.

7. The use of accessory attachments not recommended by MR.

COFFEE, inc. may cause hazards or injuries.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch

hot surfaces.

10. Do not place this appliance on or near a hot gas or electric

burner or in a heated oven.

11. To disconnect, turn any control to “off”, then remove plug

from wall outlet.

12. Do not use appliance for other than intended use.

13. Use on a hard,

flat

level surface only. to avoid interruption

of air flow underneath the appliance.

14. Decanter Use and Care

Breakage may occur if the following instructions are not followed:

a. This decanter is designed for use with your Mr. Coffee

coffeemaker and therefore must never be used on a range

top.

b. Do not set a hot

decanter

on a wet or cold surface

Do not use a cracked decanter or a decanter having a loose

or weakened handle

d. Do not clean the decanter with cleansers, steel wool pads,

or other abrasive materials.

Discard decanter immediately if it is ever boiled dry.

Avoid sharp blows, scratches, or rough handling.

15.

WARNING:

To reduce the risk of fire or electric shock, do not remove

any service covers. No user serviceable parts inside. Repair should

be done by authorized personnel only.

SAVE THESE INSTRUCTIONS

SPECIAL CORD SET INSTRUCTIONS

A short power supply cord is provided to reduce the hazards resulting

from becoming entangled in or tripping over

longer cord.

An extension cord may be purchased and used if care is exercised in

its use.

If an extension cord is used, the marked electrical rating of the exten-

sion cord must be at least 10 amps and 120 volts. The resulting

extended cord must be arranged so that it will not drape over the

counter top or table top where it can be pulled on by children or

tripped over accidentally.

This appliance has a polarized plug (one blade is larger than the

other). As a safety feature, this plug will fit In a polarized outlet

only one way. if the plug does not fully fit in the outlet, reverse

the plug. if

still

does not fit, contact a qualified electrician. Do

not attempt to defeat this safety

feature.

PRECAUTIONS

WHEN USING THIS MACHINE

Do%...

Avoid areas of the coffeemaker which

may

become hot or emit steam

when the machine is ‘on’, particularly the filter basket and the water

reservoir.

’

Avoid jerking or straining the power cord when unplugging. Grasp the

molded plug to unplug.

’

Unplug the unit when not in use.

Don’&..

’

DO NOT place a cloth or otherwise restrict airflow beneath the appli-

ance.

’

DO NOT reheat a beverage by passing it through the brewing system.

’

DO NOT use abrasive or caustic cleaning compounds to clean the

exterior of the unit.

’

DO NOT store the machine until warmer plate has cooled.

Introduction

Congratulations! You are the owner of a 12 cup Mr. Coffee SR

series coffeemaker. This appliance has been designed to provide

you with delicious fresh brewed coffee quickly and conveniently,

whenever you want it.

Our SRX20 Model offers a digital timer with 2 hour Automatic

Shut-off. The automatic brew feature allows you to

pre-set

your

brewing time

so if you wish, you can awaken to the aroma

of freshly brewed coffee or enjoy a cup the moment you return

home from your outside

activities.

Our Automatic Pause ‘n Serve drip-stop valve feature allows you

one minute to sneak a cup while the coffee’s still brewing. Just

remove the decanter and pour a cup

no need to wait for the

brewing cycle to complete. Once the brewing cycle is

completed,

the drip-stop valve prevents coffee from dripping onto

the warmer

plate when the decanter is removed.

Please read carefully

all

of the instructions In this booklet before

you begin to use this appliance. Proper care and maintenance

will insure the long life of this appliance and its trouble-free

operation. Save these instructions and refer to them often for

cleaning and care

tips...and.

happy brewing!

Table Of Contents

Page

Important Safeguards

............................................... .l-2

Cord Set Instructions

..................................................

Product Features and Diagram of Parts

.............................

Setting the Clock and Timer

.......................................

.5-6

Before Using..

..........................................................

Brewing Coffee

.........................................................

Automatic Shut Off

....................................................

Automatic Pause ‘n Serve

...............................................

Cleaning Instructions

..............................................

.8-10

Decanter Cleaning

....................................................

.10

Helpful Hints...........................................................

If Service Is Required

................................................

.11

Limited Warranty

......................................................

Product Features and Diagram of Parts

Model

SRX20

Coffeemaker

Water

Intake

Coffee

Brewing

Funnel

On-Off

IRkIll

Indicator .

Light

Digital

Tim&

with Automatic

Shut-Off

GIleM

Decanter

Warmer

-2 Hour Automatic Shut-Off

Coffeemaker shuts off automatically in 2 hours for added safety

-Automatic Pause ‘n Serve drip-stop valve

Allows you to sneak a cup while the coffee is still brewing. Prevents

dripping on the warmer plate once the brewing cycle is completed.

-24 Hour Digital Clock/Timer

Lets you preset your coffeemaker to brew coffee automatically.

As an additional safety feature, an automatic lock-out feature keeps

the coffeemaker from repeating the brew cycle in 24 hours unless

the timer is turned off and then to auto again.

-12 cup capacity

Important, Please Read Before First Use

. THE CLOCK ON THIS MODEL MUST BE SET FIRST,

BEFORE THE COFFEEMAKER WILL OPERATE.

Please refer to setting the clock instructions, below.

. THE SPECIAL PAUSE ‘N SERVE DECANTER LID MUST BE

PROPERLY IN PLACE ON THE DECANTER AT ALL TIMES.

This lid opens and closes the drip-stop valve on the bottom

of the brewing funnel. If this lid is not in place on the decanter

when brewing coffee, coffee will build up in the brewing funnel

and begin to overflow onto the warming plate.

. AUTOMATIC PAUSE ‘N SERVE ALLOWS YOU TO REMOVE

THE DECANTER FOR NO LONGER THAN ONE MINUTE

to sneak a cup while the coffee is still brewing. If the decanter

is removed for more than one minute, the brewing funnel

will overflow.

Be sure any replacement decanter you purchase is a Mr.

Coffee decanter with the Pause ‘n Serve lid.

Setting the Clock and Timer

AUTO OFF LIGHT

indicates machine shut

PM INDICATOR

‘“‘,:;,FQ.

itself off or Auto brew

HOUR SET

-2~

needs to be reset

d’

advances clock

BREW SET

by the hour

sets time to brew

y-0

SIGNAL LIGHT

‘--$.$:

’

MINUTE SET

indicates when

advances clock

coffeemaker is on

by the minute

CONTROL SWITCH

OFF

AUTOMATIC

TO SET CLOCK...

1. Move the CONTROL SWITCH to OFF.

2. Plug the power cord into your electrical outlet. The display

on the clock will flash until you set the time.

3. Alternately press and hold the HOUR and MINUTE buttons until

you reach the current time. A red dot will appear in the upper

left display corner for PM time.

TO PRESET THE BREWING TIME...

Simply press and hold the BREW SET button while setting the

brew time with the HOUR and MINUTE buttons. Please pay

attention to PM INDICATOR light.

TO AUTOMATICALLY BREW AT PRE-SET TIME...

1. Follow steps

through

#5in

“How to Brew Coffee”.

2. Always slide the control switch to OFF and then to AUTO.

3. Brewing will begin at the time you have preset and the coffee

will remain hot in the decanter for 2 hours. If more keep warm

time is needed, turn the switch to ON for an additional 2 hour

keep warm time.

IMPORTANT

To Reset Auto Brew at Pre-Set Time.....

This coffeemaker will NOT automatically come on again the

next day if you leave the switch in the AUTO position after

its last use. This is a safety feature. Each time you choose to

use auto brew you must slide the switch to OFF and then to

AUTO.

To make sure Auto brew is set, check the auto off light. If the

light is off, auto brew is set. If it is on, slide the switch to OFF

and then to AUTO.

Before Using Your Mr. Coffee

Make sure your first cup of coffee is as good as can be by cleaning

your Mr. Coffee coffeemaker before you use it the first time. Just

follow these simple steps:

1. Wash the

.decanter,

lid and brew funnel in a mixture of mild

detergent and water. Rinse each thoroughly.

2. Set the clock. The clock on this model must be set first, before

the coffeemaker will operate. See instructions for setting the

clock.

Slide the brew funnel into place and then follow steps

through

in the “HOW TO BREW COFFEE” section. This will clean

the inside of your coffeemaker.

4. When the brew cycle is finished, slide the control switch to

off. Discard the water in the decanter and rinse the decanter

and brew funnel.

Your coffeemaker is now ready to use.

How To Brew Coffee

If the display on the clock is flashing, the clock has not been

set yet and the coffeemaker will not operate. See instructions for

setting the clock.

Remove the brew funnel. Place one Mr. Coffee paper filter inside.

2. Place coffee into the paper filter according to the coffee

measurement chart below.

3. Make sure the paper filter is in the proper position then slide

the brew funnel back into position.

4. Fill the decanter with tap water to desired capacity as marked

on the side of the decanter. (1 cup equals 5 ounces.) To brew

12 cups of coffee, fill the decanter to the bottom of the silver

band.

5. Pour the water into the intake screen. Place the empty decanter

onto the warmer plate.

CAUTION: The special Pause ‘n Serve

decanter lid must be on the decanter at all times.

This lid controls

the flow of coffee into the decanter. If it is not in place, the

coffee in the brewing funnel will overflow onto the warming

plate.

6. Slide the control switch to on. When coffee stops flowing,

the brewing cycle is complete.

7. Discard the used grounds and filter. Rinse the brew funnel and

slide it back into place.

Note: The warmer plate will keep your coffee piping hot for

2 hours and then, as a safety feature, the coffeemaker will shut

off automatically. For an additional 2 hours of keep warm time,

slide the control switch to OFF and then back to ON.

8. To make another pot of coffee, turn the coffeemaker off and

repeat steps

through

#6.

9. Be sure to turn the control switch off when the decanter is

empty and you are no longer using your coffeemaker.

COFFEE MEASUREMENT CHART

For best results, use level tablespoons (tbls.) of drip grind or grind

recommended for automatic drip coffeemakers.

To brew this much coffee: Use this many tablespoons:

12 cups

11 level tbls.

10 cups

9 level tbls.

8 cups

7 level tbls.

6 cups 6 level tbls.

4 cups 5 level tbls.

2 cups 3 level tbls.

‘Use more or less coffee to suit your taste.

2 level tablespoons = 1 coffee scoop.

Automatic Shut Off

Once your coffeemaker is turned on, the coffee in the decanter

will stay hot for 2 hours. Then, as a safety feature, the

coffeemaker will shut itself off.

You

will

know that your coffeemaker has automatically shut

off when the red AUTO OFF LIGHT has appeared in the lower

right hand corner of the clock display.

3. To keep your coffee hot for an additional 2 hours, simply move

the control switch to off and then back to on.

4. Move the control switch to off if you empty the decanter before

the end of the 2 hour period.

Automatic Pause

‘n

Serve

For your convenience, our Automatic Pause ‘n Serve feature allows

you ONE MINUTE to sneak a cup while the coffee is still brewing.

But don’t delay, if the decanter is removed for more than one

minute, the brewing funnel will overflow.

To use, simply remove the decanter, pour the coffee and then

replace the decanter onto the warmer plate. Be sure that the special

Pause

‘n

Serve lid is properly placed on the decanter before

returning it to the warmer plate.

Cleaning Is A Must

Your coffeemaker

be delimed when you begin to notice an

increase in steaming. If the pumping action stops before all the

water has been pumped out of the machine, then the appliance

requires deliming.

The frequency of cleaning depends upon the hardness of water

used. The following table gives the recommended cleaning

intervals.

RECOMMENDED CLEANING SCHEDULE

Type of Water

Cleaning Frequency

Soft water

every

brew cycles

Hard

water every 40 brew cycles

Your coffeemaker may be delimed by using MR. COFFEE

CLEANER@ or vinegar. For best results, use MR. COFFEE

CLEANER. It works better than vinegar and has no unpleasant

odor.

Using Mr. Coffee Cleaner:

(Read Caution Statement on Side Panel of Mr. Coffee Cleaner

Box Before Use)

1. Fill the decanter with 4-5 cups of warm water.

2. Empty contents of one packet of MR. COFFEE CLEANER into

the decanter and stir until the cleaner is completely dissolved.

This will make a clear blue solution.

3. Pour the blue solution into the coffeemaker.

4. Place the empty decanter on the warming plate and slide the

brew funnel into place.

CAUTION: The special PAUSE ‘n SERVE decanter lid’ must

be on the decanter at all times. This lid controls the flow of

liquids into the decanter. If it is not in place, the cleaning

solution will overflow in the brew funnel onto the warming

plate.

5. Turn your coffeemaker on.

6. When the blue solution has stopped flowing, turn your

coffeemaker off.

7. Discard the blue solution and thoroughly rinse the decanter

and brew funnel.

8. Repeat steps l-7 with clean water only (no blue solution).

9. Continue to rinse out the unit until you see no trace of the

blue solution.

10. If a normal brewing flow rate is not achieved, repeat the

cleaning steps 1-9.

Using vinegar:

1. Pour 1 quart of undiluted white household vinegar into your

coffeemaker.

2. Put a paper filter into the brew funnel. Slide the brew funnel

back into place and place the empty decanter on the warming

plate.

CAUTION: The special PAUSE ‘n SERVE decanter lid must

be on the decanter at all times. This lid controls the flow of

liquids into the decanter. If it is not in place, the cleaning

solution will overflow in the brew funnel onto the warming

plate.

3. Turn the coffeemaker on. Watch the cup markings as the

vinegar flows into the decanter. When three cups have flowed

through, turn the coffeemaker off, and let stand for

l/2

hour.

4. After

l/2

hour, pour the 3 cups of vinegar back into the

coffeemaker.

5. Place the empty decanter on the warming plate. Turn the

coffeemaker on and let all of the vinegar flow through.

Turn the coffeemaker off and discard the vinegar and the paper

filter.

Table des matières

Autres manuels Mr. Coffee Cafetière

Mr. Coffee

Mr. Coffee CS Series Manuel utilisateur

Mr. Coffee

Mr. Coffee BVMC-MLXX Series Manuel utilisateur

Mr. Coffee

Mr. Coffee BVMC-EL1 Manuel utilisateur

Mr. Coffee

Mr. Coffee ECM3 Manuel utilisateur

Mr. Coffee

Mr. Coffee DR12 Manuel utilisateur

Mr. Coffee

Mr. Coffee ECMP50 Caractéristiques techniques

Mr. Coffee

Mr. Coffee FT Series Manuel utilisateur

Mr. Coffee

Mr. Coffee BVMC-PC14 Series Manuel utilisateur

Mr. Coffee

Mr. Coffee SCTX Series Manuel utilisateur

Mr. Coffee

Mr. Coffee SP Series Manuel utilisateur

Mr. Coffee

Mr. Coffee STAINLESSSTEEL ThermalPumpPot coffeemaker Manuel utilisateur

Mr. Coffee

Mr. Coffee UTC 403 Series Manuel utilisateur

Mr. Coffee

Mr. Coffee NL4 Manuel utilisateur

Mr. Coffee

Mr. Coffee NL4 Manuel utilisateur

Mr. Coffee

Mr. Coffee TF4 Manuel utilisateur

Mr. Coffee

Mr. Coffee ECMPT1000 Manuel utilisateur

Mr. Coffee

Mr. Coffee JWX27 Manuel utilisateur

Mr. Coffee

Mr. Coffee JWX31BP Manuel utilisateur

Mr. Coffee

Mr. Coffee TOUCH DISPLAY Series Manuel utilisateur

Mr. Coffee

Mr. Coffee BVMC-SS12XTH Manuel utilisateur

Mr. Coffee

Mr. Coffee 115949 Manuel utilisateur

Mr. Coffee

Mr. Coffee AR4 Manuel utilisateur

Mr. Coffee

Mr. Coffee ZH series Manuel utilisateur

Mr. Coffee

Mr. Coffee Home Cafe SingleServe AT13 Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur
