MP-Man MP724 Manuel utilisateur
Internet Tablet
Quick Start Guide
Please read this instruction carefully before the operation
For series /
MP724
MP824
MP1024
Page 2 Table Of Contents
English
THANK YOU .....................................................3
Package Contents ........................................................3
Features..........................................................................4
GETTING TO KNOW THE INTERNET TABLET .....5
About the Touchscreen ...............................................8
Protective Film ........................................................8
Using the Stylus (MP724 & MP824) ........................8
Touchscreen Actions..............................................8
About the Orientation Sensor ...................................10
Charging the Tablet ...................................................10
Inserting a Memory Card .......................................... 11
GETTING STARTED .........................................12
Turning the Tablet on and off ...................................12
Turning the Screen On and Off (Standby) .......13
Unlocking the Screen ..........................................13
Home Screen at a Glance ........................................14
About Applications ....................................................15
Preinstalled Applications .....................................16
Installing Applications .........................................17
About Menus ...............................................................17
About Notications .....................................................19
CONNECTING TO THE INTERNET ................. 20
Requirements ............................................................. 20
Connect to a Wi-Fi network ......................................21
BROWSING THE WEB .....................................23
MANAGING APPLICATIONS ........................27
OPTIONAL CONNECTIONS ......................... 30
Connecting to a Computer ..................................... 30
Connecting to a TV ....................................................31
Connecting Headphones .........................................32
Using the USB Full-Size Adapter ................................ 33
Connecting a Keyboard .................................... 33
Connecting a Storage Device .......................... 33
SETTING THE SYSTEM OPTIONS ....................34
SPECIFICATIONS ...........................................35
ÂTable of Contents
Page 3 Thank You
English
ÂThank You
Congratulations on your purchase of the Internet Tablet. This guide is provided to help you get started quickly with
your player; please read it carefully and save it for future reference.
Package Contents
Please make sure that the items shown below are included in the package. Should an item be missing, please contact
the local retailer from which you purchased this product.
Internet Tablet
Protective pouch
Stylus (MP724 & MP824 only)
USB cable
USB host/keyboard adapter
Professional stereo
Earphones
Power adapter
This package may contain plastic bags or other materials that pose a hazard to children. Be sure to
safelydisposeofallpackingmaterialsafteropening.
Page 4 Thank You
English
Features
Browse the Web.
Visit your favorite websites
Check your e-mail
Keep in touch with friends and family
Watch YouTube™ videos
Browse the world’s most popular video-sharing com-
munity
Read your favorite books
Download thousands of books with the included
Aldiko E-book reader *
Discover thousands of apps for Android™
Download apps from AppsLib—the marketplace
designed for tablets
Connect to the Internet wirelessly
High-speed Wi-Fi 802.11 b/g networking
HDMI™ output to your TV **
Enjoy videos, photos and more in the comfort of your
living room
Enjoy your media library anywhere
Portable powerhouse plays popular music, video,
and photo formats
microSD memory card reader
Increase your storage capacity (up to 32 GB sup-
ported)
Built-in camera
Convenient front-facing camera
Automatic orientation detection
Read any way you want; the display adjusts auto-
matically!
* Reading books in the ePub format requires the included
Aldiko E-book reader application.
** Requires optional HDMI cable (Type A-to-Type C). 1080p
HD video playback requires a video le encoded at 1080p.
Streaming video quality will be affected by the source, and
the quality and condition of your network connection.
Page 5 Getting To Know The Internet Tablet
English
ÂGetting to Know the Internet Tablet
Unit at a Glance
Name Description
1 Volume +
key
Press to increase the volume level.
2 Volume –
key
Press to decrease the volume level.
3 Power key Press to turn the unit on, or to turn the
screen on and off.
Press and hold to access the Power Off
menu.
4 Speakers Stereo speakers.
Model: MID7024 DC IN 9V
Coby Electronics Corp. Made in China
Page 6 Getting To Know The Internet Tablet
English
Name Description
5 Camera Front-facing camera
6Search soft
key
Tap to search with Google.
7Back soft
key
Tap to return to the previous screen. If
the keyboard is on the screen, tap to
close the keyboard.
8Home soft
key
Tap to return to the home screen.
Tap and hold to view a list of recently
used applications; touch an application
in the list to launch it.
9Menu soft
Key
Tap to view the option menu.
Note: When you Tap the Menu key
from within an application, you will
see the options for that application. To
view the Android system options, tap
the Menu key from the home screen.
10 Browser
soft Key
Tap to launch the Browser to visit your
favorite websites.
5
6
7
8
9
10
Page 7 Getting To Know The Internet Tablet
English
Name Description
11 microSD
card slot
Load external microSD memory cards
here.
12 Reset key Press to reset the tablet if it freezes or
otherwise behaves abnormally. (Use a
paperclip or other small object to gen-
tly press this key.)
13 Power jack
(DC input)
Charge and power the tablet with the
included power adapter.
14 USB 2.0 Hi-
speed port
Connect to a computer to transfer data
(e.g., music, videos, photos, files).
15 Headphone
jack
Audio output connection for head-
phones.
Note: Speaker output is automatically
disabled when headphones are con-
nected to the player.
16 HDMI jack
(mini Type C)
Connect to a TV or other display.
13
11
12
14
15
16
DC 9V RESET
HDMI microSD
DC IN 9V
Page 8 Getting To Know The Internet Tablet
English
About the Touchscreen
Your tablet comes equipped with an easy-to-use touch-
screen which allows access to the tablet’s functions.
Use your nger tip to touch the area of the screen where
a control icon is displayed. If you touch and hold the
screen, it will register as a continuous button press.
Toavoiddamagingthescreen,donottouchit
with excessive force or with any object other
thanyournger(orastylus).Forbestresponse,
makesureyourhandsarecleanbeforeusing
thetouchscreencontrols.
Protective Film
A thin lm has been applied to the touchscreen to protect
it during shipping. The protective lm should be removed
before use. To remove it, simply take a corner of the lm
and peel it away from the screen.
Using the Stylus (MP724 & MP824)
A stylus is included for your convenience. You can use
the tip of the stylus to make precise selections on the
touchscreen.
The MP1024 will not work with a stylus; you
mustuseyourngertooperateitstouchscreen.
Touchscreen Actions
You can control the functions of the tablet by using
the touchscreen in combination with the three touch
keys located on the bezel. To control the tablet with the
touchscreen, use your ngertip or stylus to manipulate
icons, buttons, menu items, the on-screen keyboard, and
other items displayed on the screen.
You can perform the following actions on the touchscreen
using your ngertip or stylus.
Touch: To activate an on-screen item (e.g.,
application icons, buttons, menu
items, and the letter/symbols of the
on-screen keyboard), simply touch
them with your ngertip or stylus.
Page 9 Getting To Know The Internet Tablet
English
Touch and
Hold:
Some on-screen items have an
alternate action if you touch and hold
it (e.g., opening an alternate menu, or
to activate the drag function). To touch
and hold an item, touch the item and
do not lift your ngertip/stylus until the
action occurs.
Drag: Drag an on-screen item to change its
position (e.g., an application icon on
the home screen).
To drag an item, touch and hold it for
a moment, then without lifting your
ngertip/stylus, move your ngertip/
stylus on the screen until the item
reaches its target destination.
Swipe: Swipe up/down on the screen to scroll
through a list. On some screens,
you may be able to swipe left/right to
change the view.
To swipe, touch the screen and then
quickly move your ngertip/stylus
across the screen without lifting your
ngertip/stylus. Do not pause on the
screen with your ngertip/stylus at
the initial point of contact or you may
accidentally drag an item instead.
Double-tap: Quickly tap the screen twice on a
webpage or other application screen
to zoom (the application must support
the double-tap/zoom function). Within
the browser, double-tapping a web-
page section will cause the browser to
zoom and t that section to the width
of the screen.
Page 10 Getting To Know The Internet Tablet
English
About the Orientation Sensor
The tablet contains a sensor that will automatically
change the orientation of most screens as you rotate the
tablet. The sensor works best when the tablet is rotated
perpendicular to the ground (i.e., when the tablet is held
upright and not fat on its back).
The orientation sensor can be turned on and off in the
Display settings menu.
Charging the Tablet
The tablet comes with a built-in rechargeable lithium-
polymer battery.
Before using the tablet, the battery should be charged
fully. The Status Indicator will light green when the bat-
tery is charged fully.
To charge the battery:
1. Plug one end of the included power adapter into an
AC 100-240V outlet.
2. Plug the other end of the included power adapter into
the Power jack on the tablet.
3. Disconnect the power adapter when the tablet is fully
charged.
Thebatteryusedinthisdevicemaypresenta
re or chemical burn if mistreated. Do not
disassemble,incinerate,orheatthedevice.Do
notleavethede-viceinaplacesubjecttodirect
sunlight,orinacarwithitswindowsclosed.Do
notconnectthedevicetoapowersourceother
thanthatwhichisindicatedhereoronthelabel
asthismayresultintheriskofreorelectric
shock.
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels MP-Man Comprimé
MP-Man
MP-Man MPDC9000 Manuel utilisateur
MP-Man
MP-Man MPDC 705 Manuel utilisateur
MP-Man
MP-Man MPQC30I Manuel utilisateur
MP-Man
MP-Man MPQC12 Manuel utilisateur
MP-Man
MP-Man MPDC88 BT IPS Manuel utilisateur
MP-Man
MP-Man MP 10 OCTA Manuel utilisateur
MP-Man
MP-Man MPWIN810CL Manuel utilisateur
MP-Man
MP-Man MP959 Manuel utilisateur
MP-Man
MP-Man MPQC 1114 IPS Manuel utilisateur
MP-Man
MP-Man MPW 102 CL Manuel utilisateur
MP-Man
MP-Man MP1027 Series Manuel utilisateur
MP-Man
MP-Man MPQC 780 Manuel utilisateur
MP-Man
MP-Man MPWIN8900CL Manuel utilisateur
MP-Man
MP-Man MID82C Manuel utilisateur
MP-Man
MP-Man MP43HD Manuel utilisateur
MP-Man
MP-Man MP720 Series Manuel utilisateur
MP-Man
MP-Man MP101 DC Manuel utilisateur
MP-Man
MP-Man MP40HD Manuel utilisateur
MP-Man
MP-Man MID82C Manuel utilisateur
MP-Man
MP-Man MPQC109 Manuel utilisateur
