AWK-3121-SSC-RTG

Quick Installation Guide

Moxa AirWorks

Third Edition, May 2014

- 2 -

Overview

Moxa’s AWK-3121-SSC-RTG Access Point/Client is ideal for applications

that are hard to wire, too expensive to wire, or use mobile equipment that

connects over a TCP/IP network. The AWK-3121-SSC-RTG is rated to

operate at temperatures ranging from -25 to 60°C for standard models

and -40 to 75°C for extended temperature models, and is rugged enough

for any harsh industrial environment. Installation is easy, with either

DIN-Rail mounting or distribution boxes. The DIN-Rail mounting ability,

wide operating temperature range, and IP30 housing with LED indicators

make the AWK-3121-SSC-RTG a convenient yet reliable solution for any

industrial wireless application.

Package Checklist

Moxa’s AWK-3121-SSC-RTG is shipped with the following items. If any of

these items is missing or damaged, please contact your customer service

representative for assistance.

•1 AWK-3121-SSC-RTG

•2 dual-band omni-directional antennas, 2 dBi, RP-SMA (male)

•1 Quick Installation Guide

•1 Software CD

•1 Moxa Product Warranty Booklet

•1 Cable Holder with a Screw

•3 Protective Caps

NOTE

Antennas are not included and should be purchased separately.

The AWK is certified

with 2dBi omni-directional antennas with

QMA to RP-SMA adaptors.

Installation and Configuration

Before installing the AWK-3121-SSC-RTG, make sure that all items in the

Package Checklist are in the box. In addition, you will need access to a

notebook computer or PC equipped with an Fiber port. The

AWK-3121-SSC-RTG has a default IP address that you must use when

connecting to the device for the first time.

Step 1: Select the power source

The AWK-3121-SSC-RTG can be powered by a DC power input.

Step 2: Connect the AWK-3121-SSC-RTG to a notebook or

Since the AWK-3121-SSC-RTG supports 100BaseFX, you can use either a

media converter or fiber Ethernet switch to connect the

AWK-3121-SSC-RTG to the notebook. The 100M LED on the

AWK-3121-SSC-RTG will light up when the connection is established.

- 3 -

Step 3: Set up the computer’s IP address

Set an IP address on the same subnet as the AWK-3121-SSC-RTG. Since

the AWK-3121-SSC-RTG’s default IP address is 192.168.127.253, and

the subnet mask is 255.255.255.0, you should set the IP address of the

computer to 192.168.127.xxx and subnet mask to 255.255.255.0.

Step 4: Use the web-based manager to configure

AWK-3121-SSC-RTG

Open your computer’s web browser and then type

http://192.168.127.253 in the address field to access the homepage

of the web-based management. Before the homepage opens, you will

need to enter the user name and password. For first-time configuration,

enter the default user name and password and then click on the Login

button:

User name: admin

Password: root

ATTENTION

For security reasons, we strongly

recommend changing the

password. To do so,

select Maintenance



Password

, and then

follow the on-screen instructions.

Step 5: Select the operation mode for the

AWK-3121-SSC-RTG

By default, the AWK-3121-SSC-RTG’s operation mode is set to AP. You

can change the setting in Wireless Settings Basic Wireless

Settings if you would like to use the Client mode.

NOTE

To make the change effective, you must click Save Configuration

to save the change or Restart ( Save and Restart button to apply

all changes.

- 4 -

Panel Layout of the AWK-3121-SSC-RTG

1. Grounding screw

Terminal block for PWR1, PWR2,

relay, DI1, and DI2

3. Reset button

4. Heat dissipation orifices

5. System LEDs: PWR1, PWR2,

FAULT, and STATE LEDs

6. LEDs for signal strength

7. WLAN LEDs: CLIENT BRIDGE

(no function), and WLAN LEDs

8. RS-232 console port

9. 100BaseFX fiber Port

10.

MAIN antenna port

11.

AUX antenna port

12.

Model name

13.

Screw hole for wall mounting kit

14.

DIN-Rail mounting kit

- 5 -

Mounting Dimensions

DIN-Rail Mounting

The aluminum DIN-Rail attachment plate should be fixed to the back

panel of the AWK-3121-SSC-RTG when you take it out of the box. If you

need to reattach the DIN-Rail attachment plate to the

AWK-3121-SSC-RTG, make sure the stiff metal spring is situated towards

the top, as shown in the figures below.

STEP 1:

Insert the top of the DIN

-Rail into

the slot just

below the stiff metal

spring.

STEP 2:

The DIN

-Rail attachment unit will

snap into place as shown below.

To remove the AWK-3121-SSC-RTG from the DIN-Rail, simply reverse

Steps 1 and 2.

- 6 -

Wall Mounting (optional)

For some applications, it may be more convenient to mount the

AWK-3121-SSC-RTG to a wall, as illustrated below.

STEP 1:

Remove the aluminum

DIN

-Rail attachment plate

from the

AWK

-3121-SSC-RTG, and

then attach the wall mount

plates with M3 screws, as

shown in the adjacent

diagrams.

STEP 2:

Mounting the

AWK-3121-SSC-RTG

to a wall requires 4

screws. Use the

AWK-3121-SSC-RTG

device, with wall

mount plates attached, as a guide to mark the correct

locations of the 4 screws. The heads of the screws

should be less than 6.0 mm in diameter, and the

shafts

should be less than 3.5 mm in diameter, as shown in

the figure at the right.

Do not screw the screws in all the way—leave a space of about 2 mm to

allow room for sliding the wall mount panel between the wall and the

screws.

NOTE

Test the screw head and shank size by inserting the screw into

one of the keyhole shaped apertures of the Wall Mounting Plates

before it is screwed into the wall.

STEP 3:

Once the screws are fixed into

the wall, insert the four screw

heads through the large

opening of the

keyhole

-shaped apertures,

and then slide the

AWK

-3121-SSC-RTG

downwards, as indicated to

the right. Tighten the four

screws for added stability.

- 7 -

WARNING

•

This equipment is intended to be used in a Restricted Access

Location, such as a dedicated computer room. Access can

only be gained by SERVICE PERSONS or by USERS who have

been instructed about the fact that the metal chassis of the

equipment is extremely hot and may cause burns.

•

Service persons or users have to pay special attention and

take special precaution before handling the equipment.

•

Access is to be controlled through the use of a lock and key or

a security identity system, controlled by the authority

responsible for the location. Only authorized, well-trained

professionals are allowed to access the restricted access

location.

•

External metal parts are hot!! Pay special attention or use

special protection before handling.

Wiring Requirements

WARNING

Safety First!

Be sure to disconnect the power cord before installing and/or

wiring your Moxa AWK-3121-SSC-RTG.

WARNING

Safety First!

Calculate the maximum possible current in each power wire and

common wire. Observe all electrical codes dictating the

maximum current allowed for each wire size.

If the current goes above the maximum ratings, the wiring could

overheat, causing serious damage to your equipment.

You should also pay attention to the following items:

•Use separate paths to route wiring for power and devices. If power

wiring and device wiring paths must cross, make sure the wires are

perpendicular at the intersection point.

NOTE: Do not run signal or communications wiring and power wiring

in the same wire conduit. To avoid interference, wires with different

signal characteristics should be routed separately.

•You can use the type of signal transmitted through a wire to

determine which wires should be kept separate. The rule of thumb is

that wiring with similar electrical characteristics can be bundled

together.

•Keep input wiring and output wiring separate.

•It is strongly advised that you label wiring to all devices in the system

when necessary.

- 8 -

ATTENTION

This product is intended to be supplied by a Listed Power Unit

marked

“Class 2” or “LPS” and rated O/P: 12 to 48 VDC

, minimum

6 W (12 V/0.494 A to 48V/0.121 A), 25°C.

ATTENTION

Make sure

the external power adapto

r (includes power cords and

plug assemblies) provided with the unit is certified and suitable

for use in your country.

Grounding the Moxa AWK-3121-SSC-RTG

Grounding and wire routing help limit the effects of noise due to

electromagnetic interference (EMI). Run the ground connection from the

ground screw to the grounding surface prior to connecting devices.

ATTENTION

This product is intended to be mounted to a well

-grounded

mounting surface, such as a metal panel.

Wiring the Redundant Power Inputs

The top two pairs of contacts of the 10-contact terminal block connector

on the AWK-3121-SSC-RTG’s top panel are used for the

AWK-3121-SSC-RTG’s two DC inputs. Top and front views of the terminal

block connector is shown here.

STEP 1:

Insert the negative/positive DC wires into the

-/V+ terminals.

STEP 2:

To keep the DC wires from pulling

loose, use a

small flat

-blade screwdriver to tighten the

wire

-clamp screws on the front of the terminal

block connector.

STEP 3:

Insert the plastic terminal block connector

prongs into the terminal block receptor, which is

located on

the AWK-3121-SSC-RTG’s top panel.

ATTENTION

Before connecting the

AWK-3121-SSC-RTG to the DC power

inputs, make sure the DC power source voltage is stable.

- 9 -

Wiring the Relay Contact

The AWK-3121-SSC-RTG has one relay output, which consists of the two

contacts of the terminal block on the AWK-3121-SSC-RTG’s top panel.

Refer to the previous section for detailed instructions on how to connect

the wires to the terminal block connector, and how to attach the terminal

block connector to the terminal block receptor. These relay contacts are

used to indicate user-configured events. The two wires attached to the

Relay contacts form an open circuit when a user-configured event is

triggered. If a user-configured event does not occur, the Relay circuit will

be closed.

Wiring the Digital Inputs

The AWK-3121-SSC-RTG has two sets of digital input—DI1 and DI2. Each

DI comprises two contacts of the 10-pin terminal block connector on the

AWK-3121-SSC-RTG’s top panel. You can refer to the “Wiring the

Redundant Power Inputs” section for detailed instructions on how to

connect the wires to the terminal block connector, and how to attach the

terminal block connector to the terminal block receptor.

Cable Holder Installation (Optional)

You can attach the cable holder to the bottom of the AWK-3121-SSC-RTG.

This helps to keep cabling neat and avoid accidents that result from

untidy cables.

STEP 1:

Screw the cable holder onto the bottom of the

AWK

-3121-SSC-RTG.

STEP 2:

After mounting the

AWK-3121-SSC-RTG and plugging in the fiber

cable,

tighten the cable along the device and wall.

- 10 -

Communication Connections

100BaseFX Fiber Port Connection

The concept behind the SC port and cable is quite straightforward.

Suppose you are connecting devices 1 and 2; contrary to electrical signals,

optical signals do not need a circuit in order to transmit data.

Consequently, one of the optical lines is used to transmit data from device

1 to device 2, and the other optical line is used to transmit data from

device 2 to device 1, for full-duplex transmission. Remember to connect

the Tx (transmit) port of device 1 to the Rx (receive) port of device 2, and

vice versa. If you make your own cable, we suggest labeling the two sides

of the same line with the same letter (A-to-A and B-B, as illustrated below,

or (A1-to-A1 and B1-to-B2…).

SC-Port Pinouts

SC-Port to SC-Port Cable Wiring

ATTENTION

This is a Class 1 Laser/LED product. To avoid causing serious

damage to your eyes, do not stare directly into the laser beam.

RS-232 Connection

The AWK-3121-SSC-RTG has one RS-232 (8-pin RJ45) console port

located on the front panel. Use either an RJ45-to-DB9 or RJ45-to-DB25

cable to connect the Moxa AWK-3121-SSC-RTG’s console port to your

PC’s COM port. You may then use a console terminal program to access

the AWK-3121-SSC-RTG for console configuration.

Console Pinouts for 10-pin or 8-pin RJ45

10-Pin

Description

8-Pin

-----

DSR

RTS

GND

TxD

RxD

DCD

CTS

DTR

-----

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Moxa Technologies Point d'accès sans fil

Moxa Technologies

Moxa Technologies AirWorks AWK-3121 Manuel utilisateur

Moxa Technologies

Moxa Technologies Airworks AWK-3131A-M12-RCC Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-622 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-5222 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-3121-M12-RTG Manuel utilisateur

Moxa Technologies

Moxa Technologies AWK-4131 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-3121 Manuel utilisateur

Moxa Technologies

Moxa Technologies AWK-4121 Manuel utilisateur

Moxa Technologies

Moxa Technologies AWK-3121B Series Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-1131A Manuel utilisateur

Moxa Technologies

Moxa Technologies TAP-6226 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-1127 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-3251A-M12-RCC Series Manuel utilisateur

Moxa Technologies

Moxa Technologies AWK-3121-M12 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-3121-RTG Manuel utilisateur

Moxa Technologies

Moxa Technologies AWK-3131A-M12-RTG-EU-T Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-6222 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-3121 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorksAWK-6232-M12 Manuel

Moxa Technologies

Moxa Technologies AirWorks AWK-1200-AP Manuel utilisateur

Moxa Technologies

Moxa Technologies AWK-1121 Manuel utilisateur

Moxa Technologies

Moxa Technologies NPort NWH650 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-3121 Manuel utilisateur

Moxa Technologies

Moxa Technologies AirWorks AWK-6222 Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
