8Description of the Sensor
Depending on the application, Move 4 sensor can be worn in various
locations: hip, chest, wrist, thigh, ankle, upper arm.
For the different sensor locations, the sensor system offers different
possibilities for the analysis of the acceleration signal. The preferred
position for energy expenditure measurements is the hip.
Included in the delivery you also receive a cradle with a micro USB interface.
To connect the sensor to a PC, you have to separate it from the chest belt
or the electrodes and plug it into the cradle.
Move 4 is also equipped with a Bluetooth Smart interface. The sensor can
be used in conjunction with a gateway or a mobile phone for live
applications. The Bluetooth Smart interface is activated in the default
configuration of the sensor. To deactivate this interface, a firmware update
is required.
The axes of the integrated acceleration sensor are defined as described in
the following figure:
9User interface and indicators
Move 4 is equipped with a multi-colored LED to show the status of the
sensor:
