Operating Instructions
Side ap protector
Figure 5
NOTE: Never use the sucker release handle (see g 7) to carry the seat unit.
Figure 6
Backrest assembly
Figure 7
Actuator not fully retracted
X INCORRECT
Figure 8
4
4. Preparing the bath for installation
i ) Remove any non-slip mats from the bath.
ii ) Ensure the bottom of the bath is clean and smooth, with no oil or bath cleaner
residues that will prevent the suction feet from sticking.
iii ) The suction feet may not be suitable in baths that have been re-enamelled or
that have rippled or textured surfaces. For some baths with rippled or textured
surfaces, the front suction feet (see g 7) can be relocated to the middle of the
bath lift base frame, to clear the bath’s textured area. A centre sucker xture kit is
available, if required (see section 16).
iv ) It is essential that the side aps do not catch under any obstructions such as bath
handles, handrails or soap dishes, when rising. If your bath has handles, t the
side ap protectors to them (see g 1 and g 5) to prevent the side aps from
catching.
5. Installing the bath lift
i ) If your bath lift is supplied with optional soft or cushioned covers, t them at this
stage (see cover tting instructions).
ii ) Place the backrest assembly carefully on the oor when not attached to the seat
unit. The actuator forms a useful handgrip for transporting (see g 6).
iii) Pick up the seat unit (see g 7). The rear of the base frame forms a useful
handhold for this purpose.
iv ) Place the seat unit in the bottom of the bath and as far back as possible at the
opposite end to the taps. Ensure there is enough clearance at the rear of the
bath for the backrest to fully recline without resting on the bath or wall.
v ) Press rmly down on the seat unit, ensuring all four suction feet are stuck to the bath
surface. All suction feet swivel and can stick to the contours of the bath as required.
vi ) Before tting the backrest assembly to the seat unit, ensure the actuator end is
fully retracted (see g 8).
vii ) Place the backrest assembly face down onto the seat unit, whilst aligning the
hinges at the bottom of the backrest with the slots located at the rear of the seat
unit (see g 9).
viii) Ensure the backrest hinges locate into BOTH slots, with the bottom edge of the
backrest positioned in front of the two blocks (see g 9).
ix ) Hold the top of the backrest and lift upwards until the backrest rests in the fully
reclined position. Check the hinges are still located in both seat unit slots.
Figure 9
Backrest
Actuator
Seat unit
Sucker
release
handle
Rear of
base frame
Base frame
Seat
Front
suction
feet
Actuator end fully retracted
üCORRECT
Actuator
Backrest
Hinge
Hinge
Seat
unit
slot
Seat
unit
slot
Seat unit blocks
