Motwane DM6K3 Manuel utilisateur
DIGITAL
MULTIMETER
DM6K3
Trms
1
TABLE OF CONTENTS
1. Welcome & Congratulations 1
2. Safety Instructions 2
3. General Information 5
4. Product at Glance 6
5. Operating Instructions 12
a.Push button over view
6. Making Measurement 14
7. Specifications 21
8 Maintenance 26
9. Warranty 27
10. Service Call Check 25
2
Congratulations on your excellent choice and sound investment in Trms-6000
Count Digital Multimeter Model - DM6K3
Your new Multimeter represents both the latest in engineering development
and the culmination of many years of experience from the leading
manufacturer of Measuring Instruments.
Your new Multimeter is the most efficient and reliable measuring instrument
available today. To assure its dependability spend just a few minutes with this
booklet. Learn about the operation of your multimeter and the small amount of
maintenance it takes to keep it operating at its peak efficiency. With minimal
care, your new Instrument will provide you with comfort – both now and for
years to come.
This Instruction Manual provides specific operating instructions for your
model. Use your Multimeter as instructed in this manual. These instructions
are not meant to cover up the entire possible situation that would arise while
operating this Multimeter. CAUTION AND ALERTNESS must be regularly
practiced when installing, operating and maintaining any appliance.
NEED HELP
Visit the Motwane's Web Site at: http://www.motwane.com
Before you call for service, there are a few things you can do to help us serve
you better.
Read this manual- It contains instructions to help you use and maintain your
Multimeter properly.
If you have received a damaged Multimeter... immediately send it back to the
factory.
If there are any kind of operating problems or some common problems, you
can relax knowing help is only a phone call away. The phone numbers are
provided in this manual.
1. Welcome & Congratulations
1
3
2. SAFETY INSTRUCTIONS
SAFETY INFORMATION
COMMON SYMBOLS
Caution! Risk of danger
Earth (Ground)
Double Insulation
Fuse
AC -Alternating Current
Warning Mark
(Document must be consulted all cases)
Conformity of European
Direct Current
AC /DC Select
Diode
Capacitance
Continuity
IEC 61010-1 CATEGORY IV
CAT IV
42
2.1 SAFETY CONSIDERATION
Understand the words DANGER, WARNING, or CAUTION. These words are
used with the safety-alert symbol or
DANGER - Identifies the most serious hazards, which will result in severe
personal injury or death.
WARNING - Signifies hazards that could result in potential damage to the
instrument.
CAUTION - Identifies unsafe practices, which would result in minor personal
injury or product and property damage.
53
THE WARNINGS PROVIDED ARE IN THE INTEREST OF YOUR SAFETY.
ENSURE THAT YOU UNDERSTAND THEM ALL BEFORE INSTALLING OR
USING THE MULTIMETER. PLEASE READ THE INSTRUCTIONS
CAREFULLY BEFORE USING THE MULTIMETER.
Warning
To protect your investment and to eliminate unnecessary service calls,
familiarize yourself with the following facts:
lBefore using the Multimeter, inspect the case. Do not use the Multimeter if
damaged or the case (or part of the case) is removed. Look for cracks or
missing plastic parts. Pay attention to the insulation around the
connectors.
lInspect the test leads for damaged insulation or exposed metal. Check the
test leads for continuity. Replace damaged test leads with identical model
number or electrical specifications before using the Multimeter.
lDo not apply more than the rated voltage, as marked on the Multimeter,
between the terminals or between any terminal and ground.
lPrior to measurement, ensure that the rotary switch is in proper position.
To prevent potential damage to the Multimeter, do not change range or
mode function during measurement.
lWhen the Multimeter is working at an effective voltage over 60V DC, or
30V RMS AC, take special care, for there is danger of electric shock.
lUse the proper terminals, functions, and ranges for your measurements.
64
l
range and reduce the range gradually until a satisfactory reading is
obtained.
lDo not use or store the Multimeter in an environment of high
temperature, humidity, explosive, flammable gas or strong magnetic field.
Do not use the meter if it is wet.
lWhen using the test leads, keep your fingers behind the finger guards.
lDisconnect circuit power and discharge all high-voltage capacitors before
testing resistance, continuity, diodes, current, or capacitance.
lBefore measuring current, check the Multimeters fuses and turn off power
to the circuit before connecting the Multimeter to the circuit.
If the value to be measured is unknown, use the maximum measurement
3.0 GENERAL INFORMATION
3.1 INTRODUCTION
The DM6K3 Multimeter is 6000 count handheld, Trms & battery operated
professional industrial grade multimeter providing high resolution, high
accuracy, measurements of AC voltage & current, DC voltage & Current,
Resistance, Capacitance, Diode, Continuity, Frequency and Duty cycle.
The multimeter is designed by a special purpose ASIC which ensures low
component count assuring a very high reliability. The Multimeter has a
pleasant Blue Backlit LCD with elaborate annunciation.
3.2 FEATURES
l6000 Count LCD display with pleasant blue backlit
lAuto ranging, Trms AC Voltage & Current Measurment.
l15 minutes Auto power off facility provided to save battery life.
l60 position Analog bar graph for trend indication.
lHighly linear Readings
lSelect, Range, Hold/Light, Relative, Min/Max measurement facility.
lCapacitance, Diode and Continuity.
lSelectable Frequency and Duty Cycle measurement.
lPolycarbonate, rugged, Dust proof and fire retardant case for high
temperature endurance.
lCE and IEC 61010-1 CAT IV for enhanced safety in outdoor use.
75
Backlit LCD Display
Keypad for
extended functions
Rotary Switch for
function selection
Measurement
Terminals
4.0 PRODUCT AT GLANCE
4.1 FRONT VIEW
86
Hz
mA
A
OFFOFF
V
V
RANGE
HOLD/LIGHT
SELECT
REL
Digital Multimeter
DM6K3
Trms
FUSED
20A MAX.
FUSED
600mA MAX.
AmA COM VW
Hz
0
10
20
30 40
50
60
APO
MIN AUTO MAX
LO BAT
AC
S1
S2
RS232 REL
0 0
hFE C F
% RPM
MkWHz
6 60 600
DH
mVA
nF
43 2 1
mV
Hz
DUTY
MAX
MIN
CAT IV
1000 VDC
750VAC
MAX.
4.2 REAR VIEW
Stand
Battery Cover
Screw
Battery : 9V (6F22)
97
4.3 EXPLODED VIEW
Friction
Pad
Stand
Screw
Screw
Battery Cover
Battery
9V (6F22)
10 8
