Motorola CT1 Manuel utilisateur
Motorola CT1
Corded Telephone
Welcome...
to your new Motorola CT1 Corded Telephone!
• 3 direct dial memory keys for easy one-touch dialling.
• 10 two-touch memory keys for easy dialling.
• Redial to easily dial the last number called.
• Tone dialling.
• Mute your caller so you can have a private conversation with someone nearby.
• LED indicator shows when mute is activated.
• Ringer volume switch to change the volume between high and low.
• Recall for network functions.
• Wall mountable for space eiciency.
Need help?
If you have any problems setting up or using your CT1, please contact Customer
Services on xxxxxxxxxxxxx.
Alternatively, you may nd the answer in the ‘Help’ section at the back of this guide.
This user guide provides you with all the information you need to get the
most from your phone.
To set up your phone, follow the simple instructions in ‘Getting Started’.
IMPORTANT
Only use the telephone line cord supplied.
Got everything?
• Corded handset and curly cord
• Corded base
• Telephone line cord
• User guide
ECOMOTO: a convergence of eorts by marketing, design, research, engineering
and supply chain management that
leads to better products for everyone. A holistic view that focuses on both social and
environmental responsibility.
A passion and a shared point of view.
The right thing to do.
• Meets and/or exceeds EMEA environmental regulatory requirements.
• Eco friendly packaging with a minimum 20% post consumer recycled content.
• Phone housing is built with a minimum of 25% post consumer recycled content plastic.
4
1. Getting started .....................................................................5
2. Getting to know your phone ................................................6
3. Using the phone ...................................................................9
3.1 Calls .................................................................................................................9
3.1.1 Make a call ............................................................................................9
3.1.2 End a call ..............................................................................................9
3.1.3 Receive a call ........................................................................................9
3.2 Mute.................................................................................................................9
3.3 Redial ...............................................................................................................9
4. Memory ..............................................................................10
4.1 Store a direct dial number.............................................................................10
4.2 Dial a direct dial number ...............................................................................10
4.3 Store a two-touch number.............................................................................10
4.4 Dial a two-touch number ...............................................................................10
5. Recall mode........................................................................11
6. Help.....................................................................................12
7. General information ...........................................................13
8. Wall mounting ....................................................................17
5Getting started
1. Getting started
IMPORTANT
Do not place your CT1 in the bathroom or other humid areas.
Location
You need to place your CT1 base within 2 metres of the telephone wall socket so that the
cable will reach. The socket-outlet shall be installed near the equipment and shall be easily
accessible.
If you are wall mounting your phone please refer to the wall mount template on page 17.
Connecting the handset and base
1. Plug one end of the handset curly cord into the socket marked on the underside of
the base and the other end into the socket at the bottom of the handset.
2. Plug the telephone line cord into the socket marked .
6 Getting to know your phone
2. Getting to know your phone
Overview of the base
Redial
Memory
M1
M2
M3
Store
A
B
C
D
E
F
G
H
I
J
K
7Getting to know your phone
A Hook switch
Hangs up a call when pressed or when you replace the handset.
B Handset hook
Rotate to secure the handset in wall mount mode.
C Store
For storing direct dial or two-touch memory numbers.
D Memory
For dialling numbers from the two-touch memory.
E Memory label
Make a record of your 3 direct dial numbers; remove covering plastic before recording
the number.
F Direct dial (M1, M2, M3)
Press to store or dial a direct dial number.
G LED
Lights up when mute is activated.
H Mute
Speak to someone nearby without your caller hearing the conversation.
I R
Recall used with switchboards / PABX.
J Redial
Press to redial the last number called.
K Ringer switch
Switch the ringer volume from high (u) to low (d).
8 Getting to know your phone
Overview of your handset
A Earpiece
To listen to your caller.
B Microphone
To speak to your caller.
C Curly cord socket
Where you plug in your curly cord.
A
B
C
9Using the phone
3. Using the phone
3.1 Calls
3.1.1 Make a call
Lift the handset, when you hear the dial tone, dial the number.
3.1.2 End a call
Place the handset back on the base.
3.1.3 Receive a call
Lift the handset to answer the call.
3.2 Mute
You can mute your handset so that you can talk to someone nearby without your caller
hearing.
1. During a call, press m. The LED will light up.
2. Press magain to resume your call. The LED will turn o.
3.3 Redial
The last entry dialled is stored in the phone; the number can be up to 48 digits long.
To redial the last entry called, pick up the handset and press R.
10 Memory
4. Memory
You can store one of your most frequently used telephone numbers in each of the direct
dial memories (M1, M2 or M3), the number can be up to 20 digits long.
You can store a further ten telephone numbers in the two touch memory; the numbers can
be up to 20 digits long.
4.1 Store a direct dial number
1. Lift the handset and press skey.
2. Dial the number to be stored.
3. Press skey .
4. Press one of the memory keys M1, M2 or M3.
5. Place the handset back on the base.
NOTE
Remember to record your direct dial memory names on the label provided.
4.2 Dial a direct dial number
1. Lift the handset.
2. Press one of the memory keys M1, M2 or M3.
3. The memory number will be dialled out automatically.
4.3 Store a two-touch number
1. Lift the handset and press skey.
2. Dial the number to be stored.
3. Press skey.
4. Press one of the keypad buttons 0-9.
5. Place the handset back on the base.
NOTE
Remember to make a note of which phone numbers are store under which keypad
number.
4.4 Dial a two-touch number
1. Lift the handset.
2. Press Mkey.
3. Press one of the keypad buttons 0-9.
4. The memory number will be dialled out.
