Motorola Smart Controller Manuel utilisateur

MOTOROLA SMART

CONTROLLER

1Check it out

Check it out

here’s what you can do

No need to get off the couch. Use the touchpad and

buttons on your Motorola Smart Controller remote to

control your phone or tablet, or flip it over for handsfree

calls.

Go ahead, check it out:

At a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Connect & go. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Want more?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Caution: Please read the important safety, regulatory

and legal information at the back of this guide.

2At a glance

At a glance

the important bits, quick and easy

Note:

Your battery is designed to last the life of your product. It

should only be removed by a recycling facility. Any attempt to

remove or replace your battery will damage your remote.

Home

Back

Call Button

Microphone

Speaker

Remote

Calls (Phone Only)

Android Buttons

To u chpad

(works like a

laptop computer

touchpad)

Power Switch

Charge

(MicroUSB)

On Off

Status Light

Volume & Mute

Phone

Tablet

Computer

Connections

Mouse

Buttons

Green full charge

Yellow mediumcharge

Red low charge

Charge Level (when

connected to power)

3Connect & go

Connect & go

let’s get you connected

Motorola Devices (Newer)

Tip: For daily use, just make sure your remote is on, and

your device’s Bluetooth feature is on. Your remote and

device connect automatically.

Turn Bluetooth on.

Status Light - Blue

Turn remote on.

Enter “0000”

if prompted

Enter passcode.

Complete.

Status Light - Blue flash

(5 times)

Status Light - Blue pulse

(30 seconds)

Status Light

4Connect & go

Non-Motorola Devices/Motorola

Devices (Older)

Tip: For daily use, just make sure your remote is on, and

your device’s Bluetooth feature is on. Your remote and

device connect automatically.

Status Light - Blue

Turn remote on.

Enter “0000”

if prompted

Select either one first on

device. Enter passcode

(if prompted).

Complete.

Status Light - Blue flash

(5 times)

Status Light - Blue pulse

(30 seconds)

Status Light

Turn Bluetooth on and

search for remote.

On and

Motorola RZ100 is listed

once or twice in search

results.

If RZ100 is listed twice in

step 2, select the other

listing and repeat steps 3

and 4.

5Basics

Basics

standard features, advanced quality

Touchpad

Scroll list

on screen.

Zoomout.

Rotate image

clockwise.

Custom

(based on application).

Mouse* Multi-touch gestures*

Tap

Press right

mouse button.

Display and

move pointer.

Touch & slide

Select item

under pointer.

Click & hold

Add a shortcut or

widget to screen.

Touch & hold

Move (drag) item

under pointer.

-- Screen itemunderneath pointer.

-- No screen itemunderneath

pointer.

Rotate image

counterclockwise.

Zoomin.

Tap or Click

Click & move

Display item’s

menu options.

* Multi-touch gestures are supported

by selected Motorola devices only. Scan

the QR code below to find out if yours

does.

* Cursor speed can be adjusted.

See TROUBLESHOOTING on page 7 for

details.

6Basics

Android Buttons

Calls

Note: Some features are phone/network dependent.

To…

answer a call Press the Call button .

reject a call Press and hold a Volume button until

you hear a tone.

redial last call Press and hold the Call

button until you hear a tone.

mute or

unmute

Press the Mute button .

end a call Press the Call button .

Display item’s menu

Return to home

Go back a step

Do Google search

7Advanced

Advanced

more clever stuff

Status light

An easy way to check your remote.

Note: After 30 seconds of inactivity, the light stops

flashing to save battery power, but the remote stays on.

If status light is… remote is…

steady blue pairing mode

rapid blue/purple

flashes

connecting to your device

slow blue flash connected (remote or call audio

connected but not in use)

slow purple flash connected (remote and call

audio connected but not in use)

slow red flash idle (not connected to a device)

quick red flash in a low battery state

8Want more?

Want more?

we’re here to help

Troubleshooting

A few frequently asked questions—with answers of

course. Find more at www.motorola.com/support.

My remote won’t go into pairing mode. Make sure

that any previously paired devices are turned off. Also,

the status light should show steady blue (pairing

mode)—if not, turn off the remote, then turn back on

while holding the Volume Up (+) and buttons

until the light turns blue.

My device doesn't find my remote when searching.

Make sure the status light shows steady blue when your

device is searching for devices. If not, turn off the

remote, then turn back on while holding the Volume Up

(+) and buttons until the light turns blue.

My remote worked before, but now it's not working.

Make sure your device is on and its Bluetooth feature is

on. You may need to pair your device and remote again

(see “Connect & go” on page 3).

The touchpad cursor is slow on the screen. You can

adjust the speed as follows:

•For Android 3.2 tablet devices, touch

Settings

Language&Input

Mouse

and

Trackpad

Settings

Pointer Speed
