Motorola LS750 Manuel utilisateur
A
USER GUIDE
1031B20B.fr5 Page -1 Friday, April 23, 1999 3:25 PM
Introduction ...........................................1
Getting Started......................................2
Installing/Replacing the Battery .........3
Control Buttons..................................4
TurningYour Pager On.......................5
TurningYour Pager Off.......................6
Sending a Test Page toYourself.........7
Backlight ............................................7
Setting upYour Pager.........................7
Time and Date........................................8
Setting the Time and Date .................8
PrivateTime ......................................... 11
To Turn PrivateTime On...................11
To Turn Private Time Off ..................14
Alerts....................................................15
Selecting the Incoming
Message Alert ..............................15
Alert Audio .......................................17
Messages.............................................18
Reading New Messages..................18
Reading Stored Messages...............21
Saving Messages.............................22
Deleting Messages..............................23
Deleting a Single Message ..............23
Deleting All Messages......................24
Message Folder...................................25
Moving a Message
into the Folder...............................26
Reading Messages in the Folder .....28
Deleting Messages
from the Folder .............................30
Alarm....................................................31
Setting the Alarm .............................31
Turning Off a Daily
or Weekly Alarm ...........................35
Use and Care .......................................40
1031B20B.fr5 Page 0 Friday, April 23, 1999 3:25 PM
1
Congratulations on purchasing an LS750 pager.Your new pager provides
exciting capabilities in messaging and can become a vital part of your
business and personal life.This compact pager combines messaging and
time keeping functions in a package that is convenient to carry.
If your LS750 has the
f
symbol, it uses FLEX
™
technology.The Motorola
FLEX protocol-based pagers offer extended battery life and improved
paging reliability.
To fully understand the features this pager offers, please take a few
minutes to read this user’s guide.
This user’s guide also includes a detachable quick reference card on
the back cover.
INTRODUCTION
1031B20B.fr5 Page 1 Friday, April 23, 1999 3:25 PM
2
Effective Use ofYour Pager
Your pager can help you keep in contact with everyone important to
you.By giving your pager number to your business associates,
family, and friends, you can be contacted whenever needed.
If you have a cellular phone, give your pager number instead of your
cellular number.Then you can decide who to call back on your cellular
phone without paying for incoming calls.
Battery Information
Your pager operates with one AAA-size
alkaline battery (carbon zinc batteries are not
recommended).
(+)
(-)
Battery
Compartment
GETTING STARTED
1031B20B.fr5 Page 2 Friday, April 23, 1999 3:25 PM
3
Installing/Replacing the Battery
➊
Turn the pager off.Refer to “TurningYour Pager Off”on page 6.
➋
Locate the battery door on the back of the pager.
➌
Slide the battery door in the direction of the arrow to unlatch the battery
door.
➍
Lift the battery door up to open.
➎
Remove the old battery, noting the polarity.
➏
Position the new battery so the + and - markings on the battery match
the polarity markings in the battery compartment.
➐
Close the battery door.
➑
Slide the door until it is fully closed.
Note:
Check your pager’s clock time after replacing the battery.
GETTING STARTED
1031B20B.fr5 Page 3 Friday, April 23, 1999 3:25 PM
4
Control Buttons
d
Menu Used to access pager menus and to turn on the
backlight.
c
Read Used to turn the pager on, read messages, and
navigate through menus.
f
Select Used to select pager settings and features. Also
used to read additional screens of messages.
Read Button
Select
Button
Menu
Button
GETTING STARTED
1031B20B.fr5 Page 4 Friday, April 23, 1999 3:25 PM
5
TurningYour Pager On
➊
Press
c
.The start-up screens are
displayed and your pager activates the
power on chime (when in audible mode).
➋
Press any button to stop the alert.
The unread message screen is
displayed.
When your pager is on and no activity
is taking place, the Standby screen is
displayed.The Standby screen
displays the time and date and may
display other status indicators.
MOTOROLA
m00:00o00/08 hjlb e
NEW! =
m03:30o07r05 hjlb e
m03:30o07r05 hjlb e
GETTING STARTED
1031B20B.fr5 Page 5 Friday, April 23, 1999 3:25 PM
6
TurningYour Pager Off
➊
From the Standby screen, press
d
twice.
➋
Press and release
c
until
PAGER OFF
is displayed, then press
f
.
OFF
is displayed momentarily before
the pager shuts off, and
m
is removed
from the display.
The off screen displays the time and
date, and if an alarm is set, the alarm
indicator.
PAGER OFF
m53:70o07r05 hjlb e
OFF
m03:30o07/05 hjlb e
m03:30o07r05 hjlb e
GETTING STARTED
1031B20B.fr5 Page 6 Friday, April 23, 1999 3:25 PM
7
Sending aTest Page toYourself
After you have read this guide and your pager has been activated
by your service provider, send yourself a test page.Refer to
“Functionality and Use ofYour Pager” on page 41.
Backlight
In low-light conditions, press and hold
d
for 2 seconds to turn on the
pager’s backlight.The backlight turns off automatically after the pager
returns to the Standby screen.
Setting upYour Pager
This section gives instructions for setting the time and date and Private
Time.Access to these features is obtained through the Setup Pager menu.
GETTING STARTED
1031B20B.fr5 Page 7 Friday, April 23, 1999 3:25 PM
8
Setting theTime and Date
➊
From the Standby screen, press
d
twice.
➋Press and release cuntil SET UP
PAGER is displayed.
➌Press f.
TIME/DATE is displayed.
➍Press f.
FORMAT!AM/PM or FORMAT!24HR is
displayed.
SET UP PAGER
m63:70o07/05 hjlb e
TIME/DATE
m13:20o07/05 hjlb e
FORMAT!AM/PM
m13:20o07/05 hjlb e
TIME AND DATE
1031B20B.fr5 Page 8 Friday, April 23, 1999 3:25 PM
