OPENPATH SINGLE DOOR
CONTROLLER INSTALLATION
GUIDE
Rev. 1.7 © Openpath 2023 2
© 2023, Openpath Security, Inc. All rights reserved.
Allegion, ENGAGE technology and Schlage are trademarks of Allegion plc, its
subsidiaries and/or affiliates in the United States and other countries. Safari is a
trademark of Apple Inc., registered in the U.S. and other countries and regions.
PDF-20230119-EN
REVISIONS
Guide Description
Rev.1.7 Menu name and icon updates in the Openpath Control Center
Other updates:
lOpenpath Embedded USB Smart Reader support: FOR MORE
INFORMATION on page4, WIRING OPENPATH READERS on page8
lEuropean (EU) Partner Center Control Center: CREATESDC on
page12
Rev. 1.7 © Openpath 2023 3
TABLEOFCONTENTS
REVISIONS 2
TABLEOFCONTENTS 3
BEFORE YOUSTART 4
CONDUCTING SITE SURVEYS 4
FOR MORE INFORMATION 4
INSTALLATION 5
NETWORK REQUIREMENTS 5
POWER REQUIREMENTS 5
SELECTING A BACKUP BATTERY 6
MOUNTING INSTRUCTIONS 6
INSTALL ONA STANDARD US 1-GANGE BOX 6
MONITOR TAMPER ALERTS 7
WIRING OPENPATH READERS 8
WIRING INFORMATION 8
STANDARD WIRING CONFIGURATION 10
WIRING FAIL SAFE AND FAIL SECURE LOCKING HARDWARE 10
PROVISIONING THE SDC 11
REQUIREMENTS 12
CREATESDC 12
ADD MULTIPLE SDCS USING QUICK START OPTION 12
ADD ONESDC 13
PROVISIONINGSTEPS 14
PROVISION THE SDC USING THE OPENADMIN APP 14
TROUBLESHOOTING THESDC 16
TEST INTERNETCONNECTION 17
NETWORK SETTINGS 17
CHANGE NETWORKSETTINGS 18
SET UP WI-FI ON THE SDC 18
COUNTRY SETTINGS 18
TROUBLESHOOTING 19
SDC LEDS 19
RESETTING THE SDC 20
SOFT RESET 20
HARD RESET 20
LEGACY WIRING 21
REGULATORY 21
UL 294 21
FCC 21
RF RADIATION HAZARD WARNING 22
INDUSTRY CANADA NOTICE AND MARKING 22
WARNINGS 23
SPECIFICATIONS 23
Rev. 1.7 © Openpath 2023 4
BEFORE YOUSTART
This Installation Guide explains how to install and configure the Openpath Embedded
USB Smart Reader (SDC) as part of an Openpath Access Control system.
CONDUCTING SITE SURVEYS
Before installing Openpath hardware, conduct a customer site survey to determine
the following:
lHow many entriesneed to be configured (e.g. doors, gates, and elevator floors)
lWhether you're using legacy wiring or new wiring
lWhat kind of electronic entry mechanisms, Request to Exit (REX) mechanisms,
and door contact sensors will be used and their power requirements.
lWhether you're providing backup batteries for the SDCs. See SELECTING A
BACKUP BATTERY on page6.
lWhether you're supporting a legacy access control panel for mobile gateway.
FOR MORE INFORMATION
lOpenpath Smart Reader Datasheet
lOpenpath Embedded USB Smart Reader Datasheet
lOPENPATH ACCESS CONTROL USER GUIDE FOR ADMINISTRATOR WEB PORTAL
lOPENPATHACCESSCONTROLSYSTEM INSTALLATION GUIDE
lOpenpath Embedded USB Smart Reader Installation Instructions (included in
the box)
For additional product and support documentation, see support.openpath.com.
Rev. 1.7 © Openpath 2023 5
INSTALLATION
NETWORK REQUIREMENTS
An Ethernet connection with DHCP can be used to connect the SDC to the Local Area
Network (LAN). You also need to configure firewall settings to communicate with the
Openpath system, which uses the following outbound ports:
lTCP port 443
lUDP port 123
Note: If using an external DNS server, the outbound UDP port 53 must also be open.
To support Wi-Fi unlocking from the mobile app, the inbound TCP port 443 of the SDC
must be available from within the LAN. Inbound port forwarding on the router, firewall,
or NATdevice is not required.
The SDC also supports Wi-Fi connections. Refer to NETWORK SETTINGS on page17.
POWER REQUIREMENTS
The Openpath SDC can be powered with PoE, PoE+, and/or an external 12-24V supply.
The SDC will automatically switch to the higher voltage source if both PoE and an
external source are available. Openpath recommends using a backup battery in
case of power failures on the external 12-24V supply or the PoE supply.
Operating Voltage: 12-24VDC
Input Rating: 12V @ 2A (min) or 24V @ 1A (min)
Output Ratings:
lPower Out connector can supply up to 100mA @ 12V or 50mA @ 24V
l2 reader ports, max power output: 250mA @ 12V each
l2 relays, max power output:
oPoE: Max 3W combined output (e.g. 250mA @ 12V or 125mA @ 24V)
oPoE+: Max 9W combined output (e.g. 750mA @ 12V or 375mA @ 24V)
Rev. 1.7 © Openpath 2023 6
SELECTING A BACKUP BATTERY
While not required, Openpath recommends having a backup battery in case of power
outages. The size of batterydepends on your setup and how long you want to power
the system.
Table 1 Power requirements (24V)
SDC .3A
Smart Reader (2) 0.25A
Locking hardware (while engaged) 0.25A--0.5A
Assuming an external 24V power supply, an SDC configured with two Openpath
Readers and locking hardware uses about 1.1 Amps. To keep the system running for 3
hours with all entries engaged, you need 1.1A x 3 hours = 3.3 AH, so two 12V 4AH sealed
lead acid (SLA) or gel cell batteries in series.
MOUNTING INSTRUCTIONS
The SDC can be mounted a few different ways: on a single or double gang box or on
drywall.
INSTALL ONA STANDARD US 1-GANGE BOX
1. Use two 6-32 screws (A) to attach backplate (B) to gang box.
Recommended:Use the provided drywall screws (C) and anchors (not shown)
on drywall for added stability.
2. Snap on main housing (D) to backplate (B).
3. On the right side of the main housing (D), ensure that the two edge clips fit into
their respective notches on the backplate (B).
4. Press firmly on the main housing (D) to snap into place.
5. Partially unscrew the pre-installed M4 set screw (E) to secure main housing (D)
to backplate (B).
6. Use the cable slot (F) to hold cables while wiring; see STANDARD WIRING
CONFIGURATION on page10.
7. Snap on front cover (G).
Rev. 1.7 © Openpath 2023 7
Note: For a double gang box, follow the directions above, using additional 6-32
screws.
Figure 1 Mounting SDC to wall
1. Use the provided drywall screws (C) and anchors (not shown) to attach
backplate (B) to wall.
2. Snap on main housing (D) to backplate (B).
3. On the right side of the main housing (D), ensure that the two edge clips fit into
their respective notches on the backplate (B).
4. Press firmly on the main housing (D) to snap into place.
5. Partially unscrew the pre-installed M4 set screw (E) to secure main housing (D)
to backplate (B).
6. Use the cable slot (F) to hold cables while wiring; see STANDARD WIRING
CONFIGURATION on page10.
7. Snap on front cover (G).
MONITOR TAMPER ALERTS
The front cover of the SDC has a built-in tamper sensor and will report tamper events
when the cover is removed. You can monitor tamper events using the Tamper
Detector State Changed alert. Refer to How do I set up alerts?
Rev. 1.7 © Openpath 2023 8
WIRING OPENPATH READERS
Openpath Readers and SDCs communicate via RS-485. The following wire types are
compatible, listed in the order of preference which impacts distance.
lShielded CAT6A (recommended, additional two pairs can be used for sensors)
lShielded CAT6
lShielded RS485 w/22-24AWG (lower gauge, thicker wire is better)
lShielded CAT5
lUnshielded CAT6
lUnshielded CAT5
lShielded 22/6
lUnshielded 22/6
Ideally, use one twisted pair for GND and VIN (power) and one twisted pair for +B and
-A (data).
Note: The Openpath Embedded USB Smart Readercan be wired via RS-485, or
connected using the micro USB port and the cable provided in the box. Only one
method, RS-485 or micro USB port, can be used at the same time. For more
information, see the Openpath Embedded USB Smart Reader Datasheet and the
Openpath Embedded USB Smart Reader Installation Instructions (included in the
box). The Openpath Embedded USB Smart Reader supports only Openpath Mifare
or DESFire EV3card credentials. Mobile credentials are not supported at this time.
WIRING INFORMATION
Rev. 1.7 © Openpath 2023 9
Recommended maximum cable length: 300 ft (91 m) with CAT6 or 500 ft (152 m) if
two wire pairs are used for GND and VIN (power).
For shielded wiring:Connect one side of the drain wire (the shield around the wires)
to the GND terminal on the SDC. Both the shield and the GND wire can share the same
GND terminal. Do not connect the other side of the shield to anything.
For standard reader installation:We recommend that you install a 1-Gang 20 CU
box in order to flush-mount the reader. Alternatively, the reader may also be surface
mountedwith the included back plate.
Note: For elevators, all relays and readers must be connected to the same SDC. If
you need more than four access controlled floors or readers, add the Openpath
Elevator Expansion Module.
WARNING: Always remove power from the SDC and locking hardware when wiring
readers and other devices. Failure to do so can damage the SDC.
Rev. 1.7 © Openpath 2023 10
STANDARD WIRING CONFIGURATION
Figure 2 Example SDC wiring
WIRING FAIL SAFE AND FAIL SECURE LOCKING HARDWARE
Fail safe and fail secure are ways of configuring locking hardware:
lFail safehardware unlockswhen power is interrupted.
lFail securehardware lockswhen power is interrupted.
VOLTAGE SWITCHES
WARNING: Remove the DC Input Power and PoE before changing the voltage of
the relays.
